Bante Instruments TB100 User manual

TB100 Portable Turbidity Meter
Instruction Manual
Bante Instruments Inc.

TB100
Introduction
Thank you for selecting the TB100 portable turbidity meter. This manual provides a step-by-step guide to help you operate the meter, please
carefully read the following instructions before use.
Environmental Conditions
Before unpacking, ensure that current environmental condition meets the following requirements.
•Relative humidity is less than 80%
•Ambient temperature is greater than 0° C/32° F and less than 50° C/122° F
•No ambient light and electromagnetic interference
Packing List
The following list describes all components of the meter. If any items are missing or damaged, contact the supplier immediately.
Operating Principle
The TB100 turbidity meter operates on the nephelometric principle of turbidity measurement and is designed to meet the criteria specified in ISO
7027. The following figure shows the basic optical system of meter. It includes a light source and a detector to monitor the light scattered at 90°
with respect to the incident beam.
1. IR LED
2. Sample solution
3. Detector
•Turbidity meter
•Lint-free cloth
•Turbidity standards
•Sample vials
The sample vial in the measurement chamber has been indexed with the 0.02 and 10 NTU standards at the factory.

TB100
Meter Overview
1. Measurement chamber
2. Display
3. Membrane keypad
4. Measurement module
5. Battery compartment
6. USB-A interface to computer
Keypad
Key
Function
• Switch the meter on or off
• Press the key to perform a measurement
• Exit the calibration, settings, data log and return to the measurement mode
• Start calibration
• Press and hold the key to enter the setup menu
• Store current reading to memory
• Increase value or scroll up through a list of options
• View the stored readings
• Decrease value or scroll down through a list of options
• Confirm the calibration, setting or displayed option
Display
1. Shows the battery status.Replace the
batteries if the icon disappears.
2. Indicates that the meter is in the
measurement mode.
3. Indicates that the meter is in the
calibration mode.
4. Indicates that the meter is in the
setup mode.
5. Indicates that you are viewing stored
data or a reading is stored into the
memory.
6. Indicates that the meter is calibrating.

TB100
Installing the Batteries
1. Remove the battery compartment cover from the backside of meter.
2. Insert the three AA batteries into the battery compartment, note polarity.
3. Replace the battery compartment cover to its original position, push the limiter until it locks.
Switching the Meter On and Off
•Press the key to switch on the meter.
•Press and hold the key to switch off the meter.
Setup Menu
The TB100 turbidity meter contains 8 menu items in the setup menu, the following table describes the functions of each option.
Menu
Description
Options
Description
Default
Set the number of calibration points
2 to 5 points
2 points
Set the date and time
---
Year, month, day, hour, minute
---
Set the turbidity unit
NTU
Nephelometric turbidity unit
NTU
FNU
Formazin nephelometric unit
EBC
European Brewery Commission units
ASBC
American Society of Brewing Chemists units
Set the resolution of measurement
0.01
0.01
0.1
Set the measurement mode
Single measurement
Yes
Continuous measurement
Auto-power off
15 minutes after last key pressed
No
Disable
Clear all data logs
Enable
No
Disable
Reset the meter to factory defaults
Enable
No
Disable
The meter allows using the DC5V power adapter (order code: DCPA-5V) or USB port on computer as a power supply. Note, take out the
batteries before connecting an external power supply.
push
To enable the auto-power off function, refer to the Setup Menu section.

TB100
Setting a Default Option
1. In the measurement mode, press and hold the key to enter the setup menu.
2. Press the /key to select a menu item.
3. Press the Enter key, the meter shows the default option.
4. Press the /key to select a desired option.
5. Press the Enter key to save and return to the measurement mode.
Setting the Date and Time
1. In the measurement mode, press and hold the key to enter the setup menu.
2. Press the key, the meter shows /.
3. Press the Enter key, the meter shows the current year.
4. Press the /key to set the year, press the Enter key to switch to the date and time options.
5. Press the /key to set the month, day, hour, minute, press the Enter key to save until the meter returns to the measurement mode.
Factory Reset
The option is used to restore the meter back to the factory default settings. If enabled, all of the calibration data and user-specific settings
will be deleted or reset, the meter must be recalibrated.
1. In the measurement mode, press and hold the key to enter the setup menu.
2. Press the key, the meter shows /.
3. Press the Enter key, the meter shows /indicating that do not reset the meter.
4. Press the key to select the /, press the Enter key to confirm.
menu
item
page
option
menu
year
month-day
hour:minute
To exit the setup menu without saving changes, press the Meas key.

TB100
Measurement and Calibration Hints
•Do not hold the meter in the hand during the calibration and measurement.
•Never pour liquid directly into the measurement chamber.
•Keep the outside of vial clean and dry. If necessary, wipe the vial with a lint-free cloth.
•If the vial has scratches or scuffs, replace a new one (order code: TB-GV).
•Ensure that the sample is homogeneous. Do not shake or agitate the solution violently to prevent air bubbles.
•During the calibration and measurement processes, the triangle mark on the vial must be aligned with the arrow on the meter.
•Always close the light shield lid to prevent the measurement errors from ambient light.
•Wash the vial thoroughly with distilled water after measurement. Any residues can cause inaccurate readings.
Turbidity Calibration
The TB100 turbidity meter allows turbidity calibration up to 5 points with minimum of 2 points, the default calibration points include the 0.02, 10,
200, 500, 1000 NTU. For better accuracy, we recommend that selecting a calibration point close to the sample value you are measuring. Note,
the meter is calibrated with Formazin Standards at the factory and does not require user calibration before use.
Selecting the Number of Calibration Points
1.1 Press and hold the key to enter the setup menu, the meter shows /.
1.2 Press the Enter key, the display shows /(2 points calibration).
1.3 Press the /key to select the number of calibration points, press the Enter key to confirm.
Calibrating the Meter
2.1 Press the Cal key, the meter enters the calibration mode, the display shows "0.02 NTU/CAL 1". If necessary, press the /key to select
first calibration point, the meter will perform the calibration from the low to high turbidity.
2.2 Take out the corresponding turbidity standard from carrying case (e.g., 0.02 NTU), wipe the vial with a lint-free cloth to remove fingerprints.
Hold the vial cap and gently inverting vial several times. Ensure that the turbidity standard is homogeneous and no air bubbles.
2.3 Insert the vial into the measurement chamber. Align the triangle mark on the vial cap with the arrow on the meter. Close the light shield lid.
2.4 Press the Enter key, the meter begins the calibration, the icon continuously flashing.
2.5 When the reading stabilizes, the meter shows the next calibration point. If necessary, press the key to select a desired calibration point.
2.6 Repeat steps 2.2 through 2.4 above until the meter shows "End". Calibration is completed.
arrow
To exit the calibration without saving calibrated values, press the Meas key.

TB100
Turbidity Measurement
Selecting the Measurement Mode
The TB100 turbidity meter contains two measurement modes. If the single measurement mode is enabled, the meter will automatically sense a
stable reading and lock the measurement. If the continuous measurement mode is enabled, the meter will continuously measure and update
readings.
1. In the measurement mode, press and hold the key to enter the setup menu.
2. Press the key until the meter shows /.
3. Press the Enter key, the display shows /indicating that the single measurement mode is enabled.
4. Press the key, the display shows /indicating that the continuous measurement mode is enabled.
5. Select one of the above options, press the Enter key to confirm.
Single Measurement - Low Turbidity Samples
For the low turbidity samples ( < 200 NTU), we recommend that use the same vial to perform the calibration and measurement.
1.1 Rinse the vial with approximately 10 ml of sample. Cap the vial and gently inverting it several times. Discard the used sample and repeat
the rinsing procedure two more times.
1.2 Fill the vial with the sample. Cap the vial and wipe with the lint-free cloth to remove waterdrop and fingerprints. Ensure that the outside
of vial is dry and clean, the sample is homogeneous, no air bubbles.
1.3 Insert the vial into the measurement chamber. Align the triangle mark on the vial with the arrow on the meter. Close the light shield lid.
1.4 Press the Meas key, the meter begins the measurement. When the reading stabilizes, the Measure icon will stop flashing.
Single Measurement - High Turbidity Samples
For the high turbidity samples ( >1100 NTU), the solution must be diluted before measurement. The dilution water can be obtained by filtering
distilled water through a < 0.45 µ m filter membrane.
2.1 Repeat steps 1.1 through 1.4 above and record the reading.
2.2 Calculate the true turbidity of the original sample using the following formula.
T = [Td(Vs+ Vd)] / Vs
Where: T = Ture turbidity of the original sample Vs= Volume of the original sample (ml)
Td= Measured value Vd= Volume of the dilution water (ml)
Continuous Measurement
3.1 Ensure that the meter is in the continuous measurement mode.
3.2 Repeat steps 1.1 through 1.3 above.
3.3 Press the Meas key, the Measure icon begins flashing, the meter continuously measures the sample.
To stop the measurement, press the Meas key again.
align

TB100
Data Management
Storing a Measurement Result
The TB100 turbidity meter is capable of storing and recalling up to 100 data sets. In the measurement process, press the MI key to store the
reading into the memory, the Memory icon appears on the display.
Viewing the Data Logs
1. Press the MR key, the meter shows the serial number of stored data.
2. Press the key to view the date and time of measurement (format: month - day, hour : minute).
3. Press the key to view the stored data.
4. Press the key to view the next data set.
5. Press the Meas key to return to the measurement mode.
Clearing the Data Logs
If the memory is full, the meter will automatically show when the MI key is pressed. To delete data logs, please follow the steps below.
1. In the measurement mode, press and hold the key to enter the setup menu.
2. Press the key until the meter shows /.
3. Press the Enter key, the meter shows /.
4. Press the key to select the /, press the Enter key to confirm.
Serial No.

TB100
Communication
The TB100 turbidity meter is capable of transfering the data to computer or importing the data to Excel by a DAS software. You are able to
download this software from our official website at www.bante-china.com. Before installation, ensure that Windows 10 operating system has
been installed on your computer.
Receiving the Data
1. Connect the USB cable to meter and computer.
2. Click the DAS_TB_Series icon, the system automatically scans an available communication port and shows a message box "Found a port
on your computer".
3. Click the OK button, the application starts.
4. Click the Connect button, the screen shows "Port is connected".
5. Click the OK button, then click the Receive button, the stored data automatically transfer to computer.
Creating an Excel File
When the transfer is completed, click the Save as Excel button, the readings in data sheet will automatically convert to Excel file.
If your computer can not find a communication port, click the "CP210xVCPInstaller_x64.exe" or "CP210xVCPInstaller_x86.exe" to update
the drive program.
Note, once the software is closed, all received data will be lost and can not be recovered.

TB100
Appendix
Indexing a Sample Vial
The United States Environmental Protection Agency (U.S. EPA) recommends that the vial used for turbidity calibration or sample measurement be
indexed. Its purpose is obtain a position which provides the lowest turbidity reading. The indexing methods are as follows.
1.1 Fill the vial with the distilled water (< 0.5 NTU). Cap the vial.
1.2 Wipe the vial with the lint-free cloth. Ensure that the outside of vial is clean and dry.
1.3 Place the vial in the measurement chamber. Align the triangle mark on the vial with the arrow on the meter.
1.4 Press the Meas key, the meter begins the measurement.
1.5 Slowly rotate the vial approximately 45° . Close the light shield lid and record the reading.
1.6 Repeat the step 1.5 until the lowest turbidity reading is shown. Mark this position on the vial.
Matching the Sample Vials
For better accuracy and repeatability, using a indexed vial is best choice for turbidity measurement. If you need to use a few vials, match these
vials are necessary.
2.1 Repeat steps 1.1 through 1.6 above for each vial and record the readings.
2.2 Find the closest position of these vials measuring value and mark it.
Preparation of Formazin Standards
Turbidity-Free Water:
The turbidity-free water is used for preparation of turbidity standards and is prepared by filtering distilled water through a 0.45 µ m or smaller
pore-sized membrane.
Turbidity Standards:
4000 NTU
•Dissolve 1 gram hydrazine sulfate (NH2)2•H2SO4in the turbidity-free water and dilute to 100 ml in a volumetric flask
•Dissolve 10 grams hexamethylenetetramine (CH2)6N4in the turbidity-free water and dilute to 100 ml in a volumetric
flask
•Mix 5 ml of hydrazine sulfate and 5 ml of hexamethylenetetramine solutions in a 100 ml volumetric flask and let stand
24 hours at 25/± 3° C (77/± 5.4° F)
1000 NTU
Mix 25 ml of 4000 NTU standard in a 100 ml volumetric flask and dilute to the mark
500 NTU
Mix 12.5 ml of 4000 NTU standard in a 100 ml volumetric flask and dilute to the mark
200 NTU
•Mix 10 ml of 4000 NTU standard in a 100 ml volumetric flask and dilute to the mark
•Mix 50 ml of above standard in a 100 ml volumetric flask and dilute to the mark
10 NTU
•Mix 10 ml of 4000 NTU standard in a 100 ml volumetric flask and dilute to the mark
•Mix 2.5 ml of above standard in a 100 ml volumetric flask and dilute to the mark
- Or -
Mix 2 ml of 500 NTU standard in a 100 ml volumetric flask and dilute to the mark
Optional Accessories
Order Code
Description
TB-GV
Glass sample vial, 60 (H) ×25 (Dia) mm (2.36 ×0.98")
TB-CAL
Turbidity standards kit, includes 0.02, 200, 500, 1000 NTU, 30 ml each bottle
TB-FZ
4000 NTU formazin standard stock solution, 480 ml
USB-A
USB cable, 1 m (3.2 ft)
DCPA-5V
DC5V power adapter, european standard plug, 1m (3.2 ft) cable

TB100
Specifications
Model
TB100
Measurement Method
ISO 7027 nephelometric method (90° )
Range
0 to 1100 NTU/FNU, 0 to 275 EBC, 0 to 9999 ASBC
Resolution
0.01 NTU (0 to 100 NTU), 0.1 NTU (100 to 999 NTU), 1 NTU (999 to 1100 NTU)
Accuracy
± 2% of reading (0 to 500 NTU), ± 3% of reading (501 to 1100 NTU)
Calibration Points
2 to 5 points
Calibration Standards
0.02, 10, 200, 500, 1000 NTU
Light Source
Infrared-emitting diode (850 nm wavelength)
Detector
Silicon photodiode
Stray Light
< 0.02 NTU
Sample Vial
60 (H) ×25 (Dia) mm (2.36 ×0.98")
Sample Volume
30 ml (1 oz.)
Memory
100 data sets
Communication Interface
USB
Operating Temperature
0 to 50° C (32 to 122° F), meter only
Storage Temperature
-5 to 60° C (23 to 140° F)
Relative Humidity
< 80% (non-condensing)
Display
Segmented LCD, 60 ×40 mm (2.36 ×1.57")
Power Requirements
3 × 1.5V AA alkaline batteries or DC5V power adapter
Dimensions
180 (L) ×85 (W) ×70 (H) mm (7.08 ×3.34 ×2.75")
Weight
300 g (10.6 oz.)
Disposal
This meter is required to comply with the European Union’s Waste Electrical and Electronic Equipment (WEEE) Directive 2002/96/EC and may not
be disposed of in domestic waste. Please dispose of this product in accordance with local regulations at the collecting point specified for electrical
and electronic equipment.
Warranty
The warranty period for meter is 1 year from the date of shipment. Above warranty does not cover the standard solutions. Out of warranty products
will be repaired on a charged basis. The warranty on your meter shall not apply to defects resulting from:
• Improper or inadequate maintenance by customer.
• Unauthorized modification or misuse.
• Operation outside of the environment specifications of the products.
For more information, please contact the supplier.

Bante Instruments Inc.
Office: 4715 Castlewood St., Sugar land, TX 77479, USA
Tel: [phone]
E-mail: [email protected]
Factory: A10, No.2066, Laifang Rd., Shanghai 201615, China
Tel: [phone]
E-mail: [email protected]
www.bante-china.com
