Siemens SITRANS LR560 Instruction manual

Radar Transmitters
Quick Start Manual 11/2012
SITRANS LR560 (Foundation Fieldbus)
SITRANS

IQ300IX.fm Page 5 Tuesday, October 2, 2001 1:43 PM

7ML19985XR82 SITRANS LR560 (FF) Page EN-1
mmmmm
English
SITRANS LR560 (Foundation Fieldbus) Quick
Start Manual
This manual outlines the essential features and functions of the SITRANS LR560 (Foundation
Fieldbus). We strongly advise you to acquire the detailed version of the manual so you can use
your device to its fullest potential. The complete manual can be downloaded from the
SITRANS LR560 product page of our web site at: www.siemens.com/LR560. The printed manual
is available from your local Siemens Milltronics representative.
Questions about the contents of this manual can be directed to:
Siemens AG
Siemens Milltronics Process Instruments
1954 Technology Drive, P.O. Box 4225
Peterborough, Ontario, Canada, K9J 7B1
Email: [e-mail]
MILLTRONICS is a registered trademark of Siemens Milltronics Process Instruments.
Technical Support
Support is available 24 hours a day.
To find your local Siemens Automation Office address, phone number, and fax number, go to:
www.siemens.com/automation/partner:
• Click on the tab Contact, select Service, then click Service again to find your
product group (+Automation Technology > +Sensor Systems >+Process
Instrumentation > +Level Measurement > +Continuous). Select Radar.
• Select the country followed by the City/Region.
• Select Technical Support under Service.
For on-line technical support go to: www.siemens.com/automation/support-request
• Enter the device name (SITRANS LR560) or order number, then click on Search, and
select the appropriate product type. Click on Next.
• Enter a keyword describing your issue. Then either browse the relevant documentation,
or click on Next to email a description of your issue to Siemens Technical Support staff.
Siemens IA/DT Technical Support Center: phone [phone]
Copyright Siemens AG 2012.
All Rights Reserved Disclaimer of Liability
We encourage users to purchase autho-
rized bound manuals, or to view elec-
tronic versions as designed and
authored by Siemens Milltronics Process
Instruments. Siemens Milltronics Pro-
cess Instruments will not be responsible
for the contents of partial or whole
reproductions of either bound or elec-
tronic versions.
While we have verified the contents of this manual
for agreement with the instrumentation described,
variations remain possible. Thus we cannot guar-
antee full agreement. The contents of this manual
are regularly reviewed and corrections are
included in subsequent editions. We welcome all
suggestions for improvement.
Technical data subject to change.

Page EN-2 SITRANS LR560 (FF) 7ML19985XR82
mmmmm
English
Safety Guidelines
Warning notices must be observed to ensure personal safety as well as that of others, and to
protect the product and the connected equipment. These warning notices are accompanied by
a clarification of the level of caution to be observed.
FCC Conformity
US Installations only: Federal Communications Commission (FCC) rules
Industry Canada
a) Operation is subject to the following two conditions: (1) this device may not cause
interference, and (2) this device must accept any interference, including interference that
may cause undesired operation of the device.
b) This device shall be installed and operated in a completely enclosed container to prevent
RF emission which otherwise can interfere with aeronautical navigation. Installation shall
be done by trained installers, in strict compliance with the manufacturer’s instructions.
c) The use of this device is on a “no-interference, no-protection” basis. That is, the user
shall accept operations of high-powered radar in the same frequency band which may
interfere with or damage this device. On the other hand, level probing devices found to
interfere with primary licensing operations will be required to be removed at the user’s
expense.
WARNING symbol relates to a caution symbol on the product, and means that
failure to observe the necessary precautions can result in death, serious injury,
and/or considerable material damage.
WARNING symbol, used when there is no corresponding caution symbol on the
product, means that failure to observe the necessary precautions can result in
death, serious injury, and/or considerable material damage.
Note: means important information about the product or that part of the operating manual.
WARNING: Changes or modifications not expressly approved by Siemens
Milltronics could void the user’s authority to operate the equipment.
Notes:
• This equipment has been tested and found to comply with the limits for a Class A digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reason-
able protection against harmful interference when the equipment is operated in a com-
mercial environment.
• This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instruction manual, may cause harmful inter-
ference to radio communications. Operation of this equipment in a residential area is
likely to cause harmful interference to radio communications, in which case the user will
be required to correct the interference at his own expense.

7ML19985XR82 SITRANS LR560 (FF) Page EN-3
mmmmm
English
d) This level probing device is only permitted for installation inside enclosed containers. The
installer/user of this device shall ensure that it is at least 10 km from the Penticton radio
astronomy station (British Columbia latitude: 49° 19' 12" N, longitude: 119° 37'12" W). For
devices not meeting this 10 km separation (e.g. the Okanagan Valley, British Columbia)
the installer/ user must coordinate with and obtain the written concurrence of the
Director of the Penticton radio astronomy station before the equipment can be installed
or operated. The Penticton contact is Tel: [phone]/ fax: [phone]. (In case of
difficulty, the Manager, Radio Equipment Standards, Industry Canada, may also be
contacted.)
R&TTE Compliance (Europe)
Hereby, Siemens Milltronics Process Instruments, declares that the SITRANS LR560
is in compliance with the essential requirements and other relevant provisions of
Directive 1999/5/EC.
The LR560 complies with EN 302 372 for use in closed storage vessels, when installed
according to the installation requirements of EN 302 372, and may be used in all EU countries.
The LR560 complies with Draft ETSI EN 302 729 for use outside of closed tanks in most EU
countries. (For a list of exceptions, see the LR560 Declaration to EN 302 729, which can be
accessed online at www.siemens.com/LR560.) For open air installations, the following
conditions must be observed:
Installation and maintenance is performed by suitably qualified and trained personnel.
The LR560 shall be installed only in a permanent fixed position pointing downwards. Its
location shall comply with the following two restrictions:
1) It shall be installed with a minimum separation distance of 4 km from Radio
Astronomy sites listed below unless special authorization has been provided by the
responsible national regulatory authority.
2) If it is installed at a location between 4 and 40 km from any Radio Astronomy site
listed below, the LR560 shall be installed at a height not exceeding 15m from the
ground.
The LR560 Declaration of Conformity may be accessed online at www.siemens.com/LR560.
Country Name of Station Geographic Latitude Geographic Longitude
France Plateau de Bure 44°38’01” N 05°54’26” E
Bordeaux 44°84’00” N 0°52’00” W
Germany Effelsberg 50°31’32” N 06°53’00” E
Italy Sardinia 39°29’50” N 09°14’40” E
Spain Yebes 40°31’27” N 03°05’22” W
Pico Veleta 37°03’58.3” N 03°23’33.7” W
Sweden Onsala 57°23’45” N 11°55’35” E

Page EN-4 SITRANS LR560 (FF) 7ML19985XR82
mmmmm
English
SITRANS LR560
SITRANS LR560 is a 2-wire 78 GHz FMCW radar level transmitter for continuous monitoring of
solids in vessels to a range of 100 m (329 ft). The plug and play performance is ideal for all solids
applications, including those with extreme dust and high temperatures to +200 °C (+392 °F).
The device consists of an electronic circuit coupled to a lens antenna and flange for quick and
easy positioning.
SITRANS LR560 supports Foundation Fieldbus communication protocol, and AMS Device
Manager software. Signals are processed using Process Intelligence.
Specifications
For a complete listing, see the SITRANS LR560 (Foundation Fieldbus) Instruction Manual. For
Approvals information see
Approvals on page 5.
Ambient/Operating Temperature
Power
• Bus powered 9 to 32 V DC, per IEC 61158-2 (Foundation Fieldbus)
• Current consumed 13.5 mA
WARNING: SITRANS LR560 is to be used only in the manner outlined in this manual,
otherwise protection provided by the equipment may be impaired.
Note: This product is intended for use in industrial areas. Operation of this equipment in a
residential area may cause interference to several frequency based communications.
Notes:
• The reference drawing listed on the device label can be downloaded from the Siemens
website at: www.siemens.com/LR560 under Support.
• Maximum and minimum temperatures are dependent on the process connection, antenna
and O-ring materials. Use of the Easy Aimer limits maximum temperature.
•See Temperature De-Rating Curve on page 18, for more details.
process temperature at process connection:
–40 oC to +100 oC (–40 oF to +212 oF) or
–40 oC to +200 oC (–40 oF to +392 oF) depending on the version
ambient temperature
(surrounding enclosure)
–40 °C to 80 °C (–40 °F to 176 °F) device label
pressure/
temperature
related
information

7ML19985XR82 SITRANS LR560 (FF) Page EN-5
mmmmm
English
Approvals
•General CSA
US/C, FM, CE, C-TICK
• Radio R&TTE (Europe), FCC, Industry Canada
• Hazardous
Non-sparking/
Energy Limited 1) (Europe) ATEX II 3G Ex nA/nL IIC T4 Gc
Dust Ignition Proof 1) (Europe/International) ATEX II 1D, 1/2D, 2D
IECEx SIR 09.0149X
Ex ta IIIC T139 oC Da
Dust Ignition Proof 2) (US/Canada) FM/CSA
Class II, Div. 1, Groups E, F, G
Class III T4
Non-incendive2) (US/Canada) FM/CSA Class I, Div. 2,
Groups A, B, C, D, T4
Pressure Application
Pressure Equipment Directive, PED, 97/23/EC
SITRANS LR560 Radar Level Measurement instrument falls below the limits of Article 3,
sections 1 & 2 of the Pressure Equipment directive (PED, 97/23/EC), as a category I pressure
accessory. However, in accordance with PED, 97/23/EC, Article 3, section 3, this equipment has
been designated and manufactured in accordance with Sound Engineering Practice (SEP) (see
EU Commission Guideline 1/5).
Notes:
• The device label lists the approvals that apply to your device.
• Use appropriate conduit seals to maintain IP or NEMA rating.
1) See also
Non-Sparking/Energy Limited wiring (Europe) and Dust Ignition Proof wiring (Europe/Inter-
national) on page 20.
2) See also
Non-incendive and Dust Ignition Proof wiring (US/Canada) on page 21.
WARNINGS:
• Do not attempt to loosen, remove, or disassemble process connection or instru-
ment housing while vessel contents are under pressure.
• Improper installation may result in loss of process pressure.
Note: Pertains to pressure-rated version only.

Page EN-6 SITRANS LR560 (FF) 7ML19985XR82
mmmmm
English
Installation
Nozzle location
Beam angle
• Beam angle is the width of the cone
where the energy density is half of the
peak energy density.
• The peak energy density is directly in front
of and in line with the antenna.
• There is a signal transmitted outside the
beam angle, therefore false targets may
be detected.
Emission cone
• Keep emission cone free of interference
from ladders, pipes, I-beams or filling
streams.
• Avoid central locations on tall, narrow ves-
sels.
Environment
• Provide easy access for viewing the dis-
play and programming via the hand pro-
grammer.
• Provide an environment suitable to the
housing rating and materials of construc-
tion.
WARNINGS:
• Installation shall be performed only by qualified personnel and in accor-
dance with local governing regulations.
• Never attempt to loosen, remove, or disassemble process connection or
instrument housing while vessel contents are under pressure.
• The user is responsible for the selection of bolting and gasket materials
which will fall within the limits of the flange and its intended use and which
are suitable for the service conditions.
• Improper installation may result in loss of process pressure.
Note: SITRANS LR560 units are pressure tested, meeting or exceeding the requirements of
the ASME Boiler and Pressure Vessel Code and the European Pressure Equipment Directive.
emission
cone
4°

7ML19985XR82 SITRANS LR560 (FF) Page EN-7
mmmmm
English
Sun Shield
The LR560 display can be protected by an
optional sun shield if the instrument will be
mounted in direct sunlight
Aimer Adjustment
3" flange 4 and 6" flange
1) For 4" and 6" Aimer: loosen the set screws in the locking ring.
Holding the electronics enclosure firmly, loosen the Aimer locking ring using the supplied
C spanner, until the LR560 drops down slightly. The enclosure can then be turned freely.
2) Direct SITRANS LR560 so the antenna is pointed at an angle perpendicular to the
material surface, if possible.
3) When the desired position is reached, re-tighten the locking ring using the C spanner, and
tighten set screws.
4) For the 3" Aimer flange, tapered split washers with pressure rated versions are provided
to keep nuts and bolts perpendicular to the flange surface.
Aimer
Aiming is not
required for signal
optimization with
78 GHz frequency.
Aiming will assist
in measuring
material in the
cone.

Page EN-8 SITRANS LR560 (FF) 7ML19985XR82
mmmmm
English
Air Purge System
The purge airflow is designed to create a strong vortex of air that rapidly cleans the face of the
lens. See the full manual for details.
Wiring
Power
Connecting SITRANS LR560
1) Loosen locking screw.
2) Remove LR560 lid.
3) Remove optional display by gently turning the
display a quarter turn counter-clockwise until it is
free.
4) Strip the cable jacket for approximately 70 mm
(2.75") from the end of the cable, and thread the
wires through the gland 1).
5) Connect the wires to the terminals as shown.
SITRANS LR560 FF is not polarity-sensitive.
6) Ground the instrument according to local
regulations.
7) Tighten the gland to form a good seal.
8) Replace optional display.
9) After programming and device configuration,
replace device lid and secure the locking screw.
WARNINGS:
The DC input terminals shall be supplied from a source providing electrical
isolation between the input and output, in order to meet the applicable safety
requirements of IEC 61010-1.
All field wiring must have insulation suitable for rated voltages.
WARNINGS:
• Check the device label to verify the approval rating.
• Use appropriate conduit seals to maintain IP or NEMA rating.
• Read Programming SITRANS LR560 on page 10 and Instructions Specific to Hazard-
ous Area Installations on page 21.
Note: for detailed wiring instructions refer to the full Instruction Manual.
1) If cable is routed through conduit, use only approved suitable-size hubs for waterproof applications.
1)
2)
3) ¼ turn
cable gland
(or NPT cable
entry)
cable
shield
instrument
shield
connection

7ML19985XR82 SITRANS LR560 (FF) Page EN-9
mmmmm
English
Installing Foundation Fieldbus Devices
• Foundation Fieldbus must be terminated at both extreme ends of the cable for it to work
properly.
• Please refer to the Foundation Fieldbus System Engineering Guidelines (AG-181)
Revision 2.0 , available from www.fieldbus.org, for information on installing FF (H1) devices.
Basic PLC configuration with Foundation Fieldbus (H1)
(For hazardous area installations, see Wiring setups for hazardous area installations on
page 18.)
controller
HSE/H1
Linking Device
NI-FBUS
Configurator
LR560 FF LR560 FF
PC/laptop
FF (H1)
Configuration via
Linking Device
FF (HSE)
FC375
FC375
H1 Interface
LR560 FF LR560 FF
PC/laptop
FF (H1)
Configuration via
PCI/PCMCIA Card
PCI/PCMCIA bus
FC375 FC375
NI-FBUS
Configurator

Page EN-10 SITRANS LR560 (FF) 7ML19985XR82
mmmmm
English
Programming SITRANS LR560
•See Quick Start Wizard on page 12.
•See Quick Start Wizard via AMS Device Manager on page 17.
Activating SITRANS LR560
Power up the device. At initial startup, SITRANS LR560 will not begin measurements and all
blocks will be Out of Service until the instrument has been configured either locally or from a
remote location.
• Completing the Quick Start Wizard or writing any configuration parameter via the local
user interface causes the device to begin measuring. The Resource Block (RES) and
Level Transducer Block (LTB) will move to Automatic mode.
• AIFB 1 and AIFB 2 will remain Out of Service (as displayed on the LCD). These blocks can
only be configured and scheduled using a network configuration tool. For more details,
see System Integration in manual
Foundation Fieldbus for Level Instruments
(7ML19985MP01)
• A transition screen showing first the Siemens logo and then the current firmware revision
is displayed while the first measurement is being processed.
• The first time the device is configured you will be prompted to select a language (English,
German, French, Spanish or Chinese).
Local Display Interface (LDI)
Modify parameters using the LDI push buttons.
(Siemens infrared handheld programmer can be ordered
separately: [Part No. 7ML1930-1BK]).
The LCD Display
Measurement mode display( (((normal operation)
1)
Fault present indicators
1) Press or to switch.
1 – toggle indicator1) for AIFB 1 or AIFB 2
2 – identifies which AIFB is source of displayed value
3 – measured value (level, space, or distance)
4 – units
5 – bar graph indicates level
6 – text area displays status messages
7 – device status indicator
6
7
1342
5
S: 0 LOE When a fault is present the fault code and an error message are
displayed in the text area (7), and a service-required icon appears in the
device status location (8)

7ML19985XR82 SITRANS LR560 (FF) Page EN-11
mmmmm
English
Program mode display
Navigation view
• A visible menu bar indicates the
menu list is too long to display all
items.
• The depth of the item band on the
menu bar indicates the length of the
menu list: a deeper band indicates fewer items.
• The position of the item band indicates the approximate position of the current item in the
list. A band halfway down the menu bar indicates the current item is halfway down the
list. A deeper band indicates fewer items.
PROGRAM mode
Using the LDI push buttons, press to enter Program Mode and open menu level 1. Scroll
through the menu using , , , .
To edit a number
1) Navigate to the desired parameter and press twice to open
and edit it. The value will be highlighted.
2) Press or to delete the highlighted value.
3) With the Enter icon highlighted press to add a digit.
4) Use or to modify the highlighted digit. Scroll up past 9 to
reach the decimal point.
5) Press to select the + or - sign and highlight it. Use or to modify it.
6) With the Enter icon highlighted press to add a digit on the right.
7) When the value is complete, press until the Enter icon is highlighted , then press
to accept the value.
Note: For a complete list of parameters, refer to the full manual.
Notes: With the Enter icon highlighted, press to insert a digit on the right; press to
delete the right-most digit; press to accept the value; press to cancel.
current
item
number
current
item
current
menu
item
band
menu
bar
parameter
value/
selection
parameter
number
parameter
name
Edit viewParameter view

Page EN-12 SITRANS LR560 (FF) 7ML19985XR82
mmmmm
English
To modify a text string
1) Navigate to the parameter you wish to modify and press to edit it. The string will be
highlighted.
2) Follow the same steps as above, to add, delete, or modify characters.
Quick Start Wizard
1. Quick Start
1.1. Quick Start Wizard
1) Press twice to navigate to Quick Start (1.) and open
Quick Start Wizard (1.1.)
2) At each step, press to accept default values and move
directly to the next item,
or to open Edit mode: the current selection is
highlighted.
3) Scroll to desired item and press to store the change, then press to continue.
4) At any time, you can press to go back, or to cancel and return to
Measurement mode.
Vessel
Response Rate
Use a setting just faster than the maximum vessel filling or vessel emptying rate (whichever is
greater).
Note: Default values are indicated by an asterisk (*) in the tables below, unless explicitly
described.
Response Rate Vessel Fill Rate or Empty Rate per minute
SLOW 0.1 m/min (0.32 ft/min)
MED *1.0 m/min (3.28 ft/min)
FAST 10.0 m/min (32.8 ft/min)
Parameter View Edit mode Select vessel construction material.
Options * STEEL
CONCRETE
Sets the reaction speed of the device to
measurement changes in the target range.

7ML19985XR82 SITRANS LR560 (FF) Page EN-13
mmmmm
English
Units
Operation
Low Calibration Point
High Calibration Point
Wizard Complete
To transfer Quick Start values to the device and return to Program menu, press (Finish).
Then press to return to Measurement mode.
Operation Description
LEVEL (1) *Distance from Low Calibration Point to material surface
SPACE (2) Distance from High Calibration Point to material surface
DISTANCE(3) Distance from Sensor Reference Point to material surface
Options BACK, CANCEL, FINISH (Display returns to 1.1 Quick Start Wizard menu when Quick
Start is successfully completed.)
Sensor measurement units.
Values m, cm, mm, ft, in
Default: m
sensor reference point
(flange face)
High Cal.
Pt. DistanceSpace
Low Cal. Pt.
Level
Distance from Sensor Reference Point to Low
Calibration Point: usually process empty level.
Values
Range: 0.000 to 40.000 m or
0.000 to 100.000 m
Default: 40.000 or 100.000 m
Distance from Sensor Reference Point to High
Calibration Point: usually process full level.
Values
Range: 0.000 to 40.000 m or
0.000 to 100.000 m
Default: 0.000 m

Page EN-14 SITRANS LR560 (FF) 7ML19985XR82
mmmmm
English
Device Address
To view the unique address of the device on the network:
• In PROGRAM mode, navigate to: Level Meter > Communication (5.) > Device Address (5.2)
to view the device address.
• Press to return to Measurement mode.
Communications via Foundation Fieldbus
AMS Device Manager
AMS Device Manager is a software package used to commission and maintain SITRANS
LR560 and other process devices. Please consult the operating instructions or online help for
details on using AMS Device Manager version 9.0. (You can find more information at
http://www.emersonprocess.com/AMS/.)
Electronic Device Description (EDD)
Check the product page of our website at: www.siemens.com/LR560, under Support >
Software Downloads, for the latest version of EDD: SITRANS LR560 FF - Foundation Fieldbus -
AMS V9.0.
1) Check that you have the latest version of the EDD for AMS Device Manager. If necessary
download the EDD from the product page listed above.
2) Save the files to your computer, and extract the zipped file to an easily accessed location.
3) Launch AMS Device Manager – Add Device Type, browse to the unzipped EDD file and
select it.
4) If desired, enter a new device tag. The device is shipped with a unique tag, consisting of a
manufacturer id and serial number 1). It is not necessary to change the device tag to make
the device operational.
To change Device Tag:
a) Launch AMS Device Manager – AMS Device Manager.
b) From Device Connection View, right click on the FF Network icon and select Rebuild
Hierarchy.
c) Right click on the device icon, and choose Rename from the menu.
d) Enter a device tag and press Enter.
Note: The address can only be changed from a remote master such as NI-FBUS Configurator
or DeltaV. For further details see Addressing in the manual, Foundation Fieldbus for Level
instruments (7ML19985MP01) .
Notes:
• The following instructions assume that the user is familiar with Foundation Fieldbus.
• You will need the full manual to acquire the list of applicable parameters.
• Application Guides for setting up Foundation Fieldbus devices with SIMATIC PDM can be
downloaded from the product page of our website at: www.siemens.com/LR560. Go to
Support > Software Downloads.
Note: SITRANS LR560 requires the EDD for AMS Device Manager version 9.0.
1) The device tag is read-only via local operation.
Note: The Device Tag described above is distinct from the Tag that describes each block type
(located in the
Identification folder of each block).

7ML19985XR82 SITRANS LR560 (FF) Page EN-15
mmmmm
English
Startup
1) Launch AMS Device Manager
a) Launch AMS Device Manager – AMS Device Manager.
b) From Device Connection View, right click on the FF Network icon and select Rebuild
Hierarchy.
c) If you wish to rename the device, right-click on the device icon and select Rename
from the menu, enter a new device tag, and click Enter.
d) Double-click the device icon. The Configure/Setup menu opens at the device
Identification dialog window. At initial startup, the Block Status is Out of Service.
2) Master Reset
a) Navigate to Configure/Setup > Resource Block > Operation and click Methods to
open the dialog window.
b) In the General field, click Master Reset then click Next to perform a reset to factory
defaults. Click Next to accept the default reset to Factory Defaults.
c) Click FINISH, then scan the device (see step 3).
After a master reset to factory defaults is performed, the device will reset and the LCD will
display the Quick Start Wizard until the device is configured.
3) Scan Device
Scan Device uploads parameters from the device to AMS Device Manager. This synchronizes
parameters between the device and AMS.
a) From the menu bar, open the pull-down menu Actions – Scan Device.
b) If you are adding a new device, configure the device via the Quick Start wizard.
Notes:
• We recommend performing a Master Reset before configuring a new device.
• RESOURCE and LTB Blocks must be in Out of Service Mode before a Master Reset can be
performed.

Page EN-16 SITRANS LR560 (FF) 7ML19985XR82
mmmmm
English
Configuring a new device 1)
Changing Block Modes
To change any block mode follow the same procedure as for changing Resource Block mode.
To change Resource Block mode
1) Navigate to Configure/Setup > Resource Block > Operation > Block Mode and click Block
Mode to open the dialog window.
2) Select the desired Target mode and deselect the other option. Click Apply (the Apply
button is activated when a change is made).
3) Return to the main menu.
Notes:
• The LR560 FF is shipped with RESOURCE and LTB blocks in Out of Service mode.
• After completing the Quick Start Wizard, via AMS or via local operation, you must
manually put the RESOURCE and LTB blocks into AUTO mode. (An exception is the first
time the Quick Start Wizard is completed via local operation1).)
• Please consult the operating instructions or online help for details on using AMS Device
Manager.
1) Then the RESOURCE and LTB blocks are automatically returned to AUTO mode.
Note: Resource Block overrides Level Transducer Block. Changing Resource Block mode will
also change Level Transducer Block mode.
Target Mode deselected
Target Mode selected
Apply

7ML19985XR82 SITRANS LR560 (FF) Page EN-17
mmmmm
English
Quick Start Wizard via AMS Device Manager
Quick Start Wizard steps
• Launch AMS Device Manager and double-click the device icon from Device Connection
View to open the startup screen. 1)
• Navigate to Configure/Setup > Resource Block > Wizards > Quick Start.
• In the navigation window, click on the Quick Start steps in order.
Step 1 – Identification
If you wish to accept the default values, go directly to Step 2 (Descriptor, Message, and Date
fields can be left blank). Or if desired, make changes then click Apply.
• At each step, if you do not wish to change the default values in the dialog window that
opens, click on the icon for the next Quick Start step.
• If you modify a parameter in any step, the Apply button is activated. Click Apply to write
changes to the device.
• In Step 4 – Summary, review all parameter settings. Return to any step to make required
changes, and click Apply.
• The Quick Start is now complete. Put Resource Block into Automatic Mode (see Chang-
ing Block Modes on page 16).
Notes:
• When performing a Quick Start via AMS, the Resource and LTB blocks must be in Out of
Service mode before any configuration changes1) can be written. (See
Changing Block
Modes on page 16.)
• After completing the Quick Start wizard via AMS, you must manually place the RESOURCE
block in Automatic mode. This will also change LTB to Automatic mode.
• Values set using the Quick Start Wizard via AMS are saved and recalled each time it is
initiated.
1) Changes to parameters that affect the block output.

Page EN-18 SITRANS LR560 (FF) 7ML19985XR82
mmmmm
English
Maintenance
SITRANS LR560 requires no maintenance or cleaning under normal operating conditions. If
cleaning becomes necessary:
1) Note the antenna material and the process medium, and select a cleaning solution that
will not react adversely with either.
2) Remove the device from service and wipe the antenna clean using a cloth and suitable
cleaning solution.
Unit Repair and Excluded Liability
For detailed information, please see the inside back cover.
Temperature De-Rating Curve
Wiring setups for hazardous area installations
The following wiring options are available for hazardous area installations:
• Non-Sparking/Energy Limited wiring (Europe) and Dust Ignition Proof wiring (Europe/
International)
on page 20
• Non-incendive and Dust Ignition Proof wiring (US/Canada) on page 21
In all cases, check the device label on your instrument, and confirm the approval rating.
WARNING: Never attempt to loosen, remove or disassemble process
connection or instrument housing while vessel contents are under pressure.
Process Temperature (°C)
Ambient Temperature (°C)
high
temperature
version
standard
version
