Baratza Maestro Installation and user guide

How to: On/Off Switch Replacement
Maestro, Encore.
Time: 10 min
Difculty: Easy
Tools/supplies: Flat head screwdriver. Phillip’s screwdriver. T10 screwdriver. Narrow pick tool or other
poker
Parts: On/Off Switch (SKU: 6037)
Additional Resources: Case Removal (PDF/video)
*** Unplug the grinder from power supply ***
www.baratza.com sup[email protected]m rev. 4/9/2019
Remove the case using our Case Removal Guide.
Flat head screwdriver
Pliers
Pick
T10 driver
Switch (6037)
Nut
ver. 1.1

www.baratza.com sup[email protected]m rev. 4/9/2019
Lift the microswitch off
of the posts.
Remove the 3 screws
securing the gearbox/
motor assembly to the
chassis. Note: two of the
three screws may thread
into a nut.
Unplug the motor and
lift the gearbox/motor
assembly from the
chassis.
*If the motor wires are
attached to the circuit
board and can only be
unplugged from the
bottom of the motor,
mark which color wire
goes to each terminal
to prevent the burr from
spinning the wrong way
after reassembly (it
should spin clockwise).
T-10 or Phillips Screws
Unplug this
Pg. 2

www.baratza.com sup[email protected]m rev. 4/9/2019
Remove the on/off
switch nut by using
pliers.
Remove the PCB from
the chassis by removing
the two lower mounting
screws. Let it dangle
to the side, or unplug it
entirely.
Remove the screw which
mounts the switch to
the chassis. The switch
should come free easily.
The on/off switch ports
are labeled on the back
of the switch. Transfer 1
connection at a time to
avoid confusion. A wiring
diagram is at the end of
this guide for reference.
The wires are secured
in the switch by push-
grip connectors. Insert
a paperclip or straight
pick into a port on the old
switch, which will loosen
the connector’s grip
on the wire and allow
removal. Locate the
correct port on the new
switch and push the wire
in to insert.
PCB mount screws
Pg. 3

www.baratza.com sup[email protected]m rev. 4/9/2019
Repeat until all wires are
transferred to the new
switch. Tug gently on
each wire to ensure rm
installation.
Insert the switch into
the chassis. Secure the
screw and install and
tighten the switch nut.
Re-install the PCB. Be
sure to plug the power
cord into the connector.
Plug in
Ensure discharge
chute is aligned
with chassis
Install the gearbox/motor
assembly, taking care to
keep the chute gasket in
place.
* The board uses Molex
connectors which are
keyed. Be aware of the
correct orientation *
Pg. 4

www.baratza.com sup[email protected]m rev. 4/9/2019
Reinstall the case and
knob to return the unit to
operation.
If you have questions,
or encounter any issues
with this guide, please
reach out to
suppor[email protected]
Secure the safety
interlock switch onto it’s
posts.
Plug in Screws
Plug the motor cable
into the PCB, then secure
the three screws which
mount the assembly into
the chassis.
Pg. 5

www.baratza.com sup[email protected]m rev. 4/9/2019
1
3
L
2
PCB
Safety Interlock
Pulse Button
Switch
Wiring Diagram
