Baratza Encore User manual

Conical Burr Coffee Grinder
Operations Manual
TM

Skilled in the art of grinding
Operations manuals are available in the following languages at
www.baratza.com
English.pdf Spanish.pdf
French.pdf German.pdf
Troubleshooting Guide available at:
www.baratza.com/troubleshooting/

1
Thank you for purchasing the EncoreTM Conical Burr Coffee Grinder. With the EncoreTM, it’s now easier than ever to make
professional quality coffee. Below are detailed descriptions of
the features that make the EncoreTM stand out from other grinders
in its class.
Conical burrs
The slow rotating conical burrs of the EncoreTM preserve the
aroma and avor of the freshly ground beans. Forty steps of
adjustment provide the ne tuning needed for Espresso, Drip, and
French Press Coffee.
Front mounted pulse button
The front-mounted pulse button makes it easy to grind directly
into an espresso brew basket. The discharge chute is designed to
accommodate any home or commercial espresso brew basket.
Innovative burr calibration system
The range of grind and the accuracy of the settings is truly
impressive. The EncoreTM has 40 distinct settings to enable grind-
ing from to Espresso to French Press. An innovative calibration
system allows all the manufacturing tolerances of the grinder to
be eliminated, resulting in identical, accurate performance from
each grinder.

2
Table of Contents
Introduction ............................................................................................. 1
Table of Contents .................................................................................... 2
Parts Identication .................................................................................. 3
Safety Information.................................................................................... 4
Initial Operation ....................................................................................... 5
Setting the Grind Control ........................................................................ 6
On/Off Switch .............................................................................. 7
Front Mounted Pulse Button ....................................................... 7
Automatic Cleaning .................................................................... 8
Care and Cleaning........................................................................ 8
Cleaning the Housing and Hopper .............................................. 8
Cleaning the Burrs ...................................................................... 9
Remove the Ring Burr ................................................................ 9
Cleaning the Ring Burr ............................................................... 9
Replacing the Ring Burr ............................................................10
. Replacing the Bean Hopper .......................................................10
Warranty and Service ........................................................................... 11
Notes .....................................................................................................12
Troubleshooting guide: ....................... www.baratza.com/troubleshooting/

3
Whole Bean Hopper
Grind Adjustment Scale
Pulse Button
On/Off Switch
Ground Coffee Bin
Hopper Lid
Grind Setting Indicator
•
•
•
•
•
•
•
Weighted Base
•
Grind Adjustment Ring
Parts Identication
Grind Adjustment Tab
Center Cone Burr
Burr Alignment and Lifting Tabs
Removable Ring Burr
Silicone Seal (cutaway)
•
•
••
•
•
•

4
Safety Information
Please read the information below very carefully. It contains important tips for the
use, the safety, the maintenance and care of this appliance. Please keep these
operating instructions for future reference.
• Use only with AC current and the correct voltage. See the label on the
base of the grinder to determine the correct voltage.
• Only clean the grinder housing with a dry or slightly damp cloth.
• Do not use this grinder for anything other than its intended use (i.e. grinding
whole roasted coffee beans).
• Disassemble your grinder only as directed in the Care and Cleaning
Section of this manual. If you cannot remedy a malfunction check www.
baratza.com and visit our Troubleshooting page. If you need further assis-
tance e-mail us at [email protected] or call us at
425-641-1245.
• Baratza will not accept any liability for damage or injury if the grinder is
used other than for its intended purpose or is improperly operated or re-
paired. All warranty claims will be void.
• Do not operate the grinder with a damaged cord or plug, or if the grinder
malfunctions.
• Do not leave your grinder unattended while turned ON.
• Shut off and unplug the grinder from the electrical outlet when not in use and
before cleaning.
• To unplug, grasp plug and remove from the outlet-never pull on cord.
• Keep your grinder out of the reach of children.
• Do not immerse the grinder, plug or cord in water or any other liquid.
Caution
• ALWAYS unplug the electrical supply cord prior to cleaning the grinder.

5
Before Using Your Grinder
Prior to using your EncoreTM grinder for the rst time you should wash the
bean hopper and ground coffee bin in warm soapy water. See the sec-
tion on Care and Cleaning for instruction on how to remove and reinstall
these parts. There may be some rust on the burrs when you receive
your grinder. This is normal and will disappear after a small amount of
coffee has been ground. To remove the rust and season the burrs, grind
1/4 pound of coffee and discard.
Initial Operation
Place the EncoreTM on a level surface and plug into a correct voltage,
AC outlet only. Remove the lid from the hopper by lifting off. Pour the
desired quantity of roasted whole coffee beans into the hopper up to a
maximum of 8 oz. Replace the lid. Ensure the ground coffee bin is fully
inserted.

6
Setting the Grind Control
Slowly rotate the bean hopper clockwise or counter clockwise to align
the indicator on the bean hopper with the desired number setting on the
grind scale. Select the correct grind for the brew process you are using.
40 grind settings are available. The settings shown in the table below
can be used as a general guide-
line. The actual grind size for a
particular setting will vary depend-
ing on many factors, including:
degree of roast (light vs. dark),
freshness, humidity, type of bean,
oil content, etc. With use, you will
determine the setting that is right
for your taste, brewing style and
your favorite beans.
Note:
Partially ground coffee beans may remain between the burrs after the
grinder is turned off, adjusting the grind may be easier when the grinder
is running. Avoid running the grinder at very ne settings without beans
as it can damage the burrs.
Setting Type of Coffee Grind
1 to 14 Espresso Fine
16 to 28 Filter / Drip Medium
29 to 40 Press Coarse

7
Manual Switch Operation
You may rotate the On/Off switch clockwise or
counter clockwise from any position without dam-
aging it.
The quantity of ground coffee you need depends
on the type of bean, coarseness of the grind,
brewing method and personal taste.
Front Mounted Pulse Button
For short duration grinding, the EncoreTM is equipped
with a front mounted pulse button. It can be used for
grinding directly into an espresso-brewing basket.
Remove the grounds bin and position the espresso-
basket inside the grinder directly below the pulse but-
ton (see photo). Push and hold the pulse button to
grind. Grinding will stop when the button is released.
Note
It is important that the espresso basket
is held below the discharge chute so
the coffee powder can fall freely into the
basket. Holding the basket up tight to
the discharge chute will cause coffee to
back up and jam your grinder.

8
Automatic Cleaning
A thorough, fast, and easy CLEANING can be ac-
complished using Grindz™grinder cleaner. Grindz™
is a product designed to dislodge coffee particles
and absorb and remove odors and coffee oil residue.
Simply place one packet of Grintz™into the empty
grinder hopper. Adjust grind setting to 20, and oper-
ate as if grinding coffee beans until all of the Grindz™
has been ground. Once complete, we recommend
passing about 4 Tbs. of coffee through the grinder
to remove any Grindz™residue. Discard the ground
coffee. For additional information on Grindz™go to
www.urnex.com.
Grindz™can be purchased at www.baratza.com
Care and Cleaning
Cleaning the Housing and Hoppers
Switch the grinder off and remove the plug from
the power supply. Remove any remaining beans
from the bean hopper (it may be easiest to tip
the grinder over and pour the beans into a bowl).
Remove the hopper by twisting it in a counter-
clockwise direction as far as it will turn, and then
lift the bean hopper from the housing. Wash
the hopper, hopper lid, and ground coffee bin in
warm soapy water, rinse and dry.
Caution
Do not put the bean hopper, hopper lid, or
ground coffee bin in the dishwasher. Hand wash
only. Do not immerse the grinder housing in
water.

9
Cleaning the Burrs
If the grinder is used daily, the burrs should be
cleaned every few weeks. Cleaning enables the
burrs to achieve the most consistent grind pos-
sible. Cleaning also removes coffee oils, which
can degrade the avor of the ground coffee. Do
not wash the burr.
Remove the Ring Burr
Pull the silicone seal off the top of the ring Burr.
Remove the ring burr by lifting it straight up out
of the grinder by the lifting tabs. If the burr does
not lift out, ensure that the grind adjustment tab
is turned fully counterclockwise.
Cleaning the Ring Burr
Use the bristle brush (included with your grinder)
to remove any loose coffee residue on the ring
burr and the center cone burr mounted within
the motor housing. Wash the silicone seal in
warm soapy water and dry.

10
Replacing the Ring Burr
Ensure that the black adjustment ring is rotated
counterclockwise as far as it will go. Replace the
burr by lining up the red tab on the burr with the
rectangular cutout on the black adjustment ring.
Wiggle and push down rmly on the ring burr to
ensure that it seats properly.
After replacing the burr, replace the silicone seal
by lining up the two slots in the silicone seal with
the small tabs on the top of the ring burr and slide
the seal onto the ring burr.
Replacing the Bean Hopper
To replace the bean hopper, line up the two tabs
on the base of the hopper (with the small tab on
the right side) with their respective slots in the
top of the grinder housing and insert the hop-
per into the grinder. Once the hopper is in place
rotate it clockwise to your desired grind setting.

11
Warranty and Service
U.S. and Canadian Warranty Information
Limited Warranty for Baratza Grinders is 1 year.
This warranty covers all defects in materials or workmanship (parts and
labor) including free ground transportation to and from our repair facility
within US and Canada. This warranty does not apply to: improper use,
lack of cleaning, abuse, normal wear and tear, lack of proper adjustment,
foreign objects (stones, screws, etc) in the beans, or uses outside the
intended use of grinding whole roasted coffee beans.
If your grinder fails within one year, e-mail [email protected] or call
425-641-1245. If the problem cannot be solved over the phone and the
problem is determined to be a warranty issue, then Baratza will deliver
an identical or comparable replacement to your door, free of charge and
arrange to have your “failed” grinder returned to us. When you receive
your replacement grinder, use the carton and packing material and ship-
ping label to return your “failed” grinder by dropping if off at any UPS
pickup locations. If the grinder is outside US or Canada the customer is
responsible for the shipping of the grinder for repair.
International Warranty Information
Go to: www.baratza.com for warranty information on grinders sold out-
side the United States.
Proof of Purchase and Product Registration
You can register your grinder at www.baratza.com. Registration will en-
able us to contact you in the unlikely event of a product safety notication
and assist us in complying with the provisions of the Consumer Product
Safety Act. The serial number is located on the bottom of the grinder.
Please keep your sales receipt that shows the date of purchase.
For repairs or parts
e-mail: support@baratza. com
Parts: www.baratza.com
425-641-1245

12
Notes

© 2012
Baratza, LLC
3923-120th Ave. S.E.
Bellevue, WA. 98006
www.baratza.com
rev: 011512
