Barco DCPB-2120 User manual

The DCPB-2120 is a PCI-Express acceleration board for performing JPEG 2000
compression. It can process one stream of 1080p60, or multiple streams at lower
resolutions, in real time.
Featuring a unique rate allocation module, the DCPB-2120 can encode untiled
images with resolutions up to 1080p. Moreover, its programmable configuration
in constant bitrate or constant quality modes allows the user to generate high-
quality JPEG 2000 codestreams at various bitrates.
Its compactness makes the DCPB-2120 an excellent alternative to PC clusters,
offering real-time encoding capability in a PCIe form factor. In addition, it is built on
FPGA technology, which offers the advantages of flexibility and upgradeability.
The DCPB-2120 can be used for various broadcast or other applications, including
Acquisition, Storage, Archiving, Production and Contribution.
DCPB-2120
JPEG 2000 HD encoder board
Features
PCIe board, 4 lanes•
Input: uncompressed images or•
video in YCbCr 4:2:2 format
Output: j2c codestream (adapted•
Digital Cinema Profile)
Custom image size up to 1920x1080•
in a single tile
Real-time encoding up to 1080p60•
Multi-stream capability•
Configurable rate allocation:•
constant bitrate or constant quality
Configurable number of quality layers•
Lossless compression support•
Windows SDK, including drivers•
and API

Requestmoreinformation
BarcoSilexN.V.
ScienticPark
RueduBosquet7
B-1348Louvain-la-Neuve
Belgium
Phone:+3210454904
Fax:+3210454636
E-mail:[e-mail]
www.barco.com/JPEG2000solutions
Rev.010308©2008Barco
Technicalspecicationsaresubjecttochangewithoutpriornotice
Technical specifications
GeneralData
Power +3.3V @ 4A maximum
+12V @ 1A maximum
Interface Revision 1.1 compliant
x1, x2 or x4 PCIe endpoint compatible
Dimensions 241mm x 111mm “three-quarter length”
max component height 15mm
Temperature Operational:
+5...+35°C, humidity <95% non-condensing
Storage:
-20...+50°C, humidity <95% non-condensing
Interfaces
Through a software API
Inputs: Uncompressed YCbCr image of any resolution
up to 1920x1080, in 4:2:2 color format
Outputs: Compressed j2c codestream
Parameters
Frame size
Sample precision, up to 12 bits
Number of wavelet decompositions, up to 6
Wavelet kernel (5/3 or 9/7)
Rate allocation mode (constant bitrate or quality) and target bitrate/quality
Number of quality layers
CSF weighting
Lossy/lossless
Performances
Single-channel
1080p60
Multi-channel
1080i60, 1080p30, 720p, 576i, 480i
Softwaresupport
PCIe drivers for Windows XP and Vista
SDK with API for controlling the compression parameters and
handshaking the image input and j2c output
Example applications
Options
Additional 4:4:4 support
Encoder + decoder functionality
