Barco LC-5621 User manual

LC-5621
56" - quad full HD LCD display
User manual
K5960013-00

2 ________________________________________________________ Barco - LC-5621 - User manual
Intentionally left blank

Barco - LC-5621 - User manual ________________________________________________________ 3
About the manual
1Aboutthemanual
1.1 Contents of the user manual
This manual consists of the following chapters:
Chapter 1: About the manual
Chapter 2: Important notice
Chapter 3: Safety precautions
Chapter 4: Package and storage
Chapter 5: About the product
Chapter 6: Installation
This chapter describes how the monitor should be installed and connected into
the system. It incorporates the pin layout of all the connectors.
Chapter 7: Operation
This chapter describes the function and the general operation of all function keys
and indicators. How to power up the unit, how to adjust brightness and other
adjustments.
Chapter 8: Troubleshooting
This chapter lists some troubleshooting tips for common problems.
Chapter 9: Technical specifications
This chapter tabulates the technical specifications and the dimensions of the
display module.
Chapter 10: List of abbreviations
1.2 Change record
Revision Date Description
00 Mar-08 Initial Release

4 ________________________________________________________ Barco - LC-5621 - User manual
About the manual
1.3 Notation convention
Following notations are applicable to this manual and should be respected
through the manual.
WARNING :
Warnings – presented in this manual, provide information, which if not adhered to, may result
in personal injury or death.
CAUTION :
Cautions – presented in this manual, provide information, which if not adhered to, may result
in damage to the equipment.
NOTE :
Notes – presented in this manual, provide information, which emphasize points, significant to
understand and operate the unit.
IMPORTANT :
Important – presented in this manual, provide information, which is important to highlight.

Barco - LC-5621 - User manual ________________________________________________________ 5
Important notice
2 Important notice
2.1 Commercial In Confidence
The information contained herein is Barco confidential information. No part of
the information contained herein may be disclosed outside of the organization of
the recipient, its sub-contractors, and customers in any form or by any means
and/or stored in a database or retrieval system without the prior written consent
of Barco.
2.2 Notice
The technical specifications mentioned in this manual shall under no
circumstances be used as proof or item of evidence.
Only the technical specifications defined in the Barco technical
specifications document (which is not part of this manual) can be used
as a base for contract negotiations.
Note that the DVI-D connectors are not always used according to the standard
DVI-D regulations, carefully follow the instructions of this user manual in order
to make the proper connections.
2.3 Federal Communication Commission (FCC) notice
This equipment has been tested and found to comply with the limits of an FCC
class (refer to the technical specifications of the specific unit for more details
about the corresponding class). These limits are designed to provide reasonable
protection against harmful interference when the equipment is operated in a
commercial environment. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the interference at
his own expense.
2.4 Disposal information
WARNING :
The fluorescent tubes inside the backlight of the LCD contain a small amount of mercury that is
considered hazardous to a person's health. Please follow local regulation or laws for disposal.
The LCD panel is composed of multiple layers of glass and protective glass with a small amount
of liquid in between. Rough handling or dropping can cause the LCD panel to break. If any part
of the skin or body comes in direct contact with the liquid, immediately wash the affected areas
with plenty of water for at least 15 minutes. If any symptoms are present after washing, get
medical care.

6 ________________________________________________________ Barco - LC-5621 - User manual
Important notice
2.5 Copyright
No parts of this book may be reproduced in any form, by print, photo printing,
microfilm or any other means without written permission from Barco NV.
This manual could include inaccuracies or typographical errors. Manual change
supplements are revised as often as necessary to keep manuals as current and
accurate as possible.
Copyright © Barco NV

Barco - LC-5621 - User manual ________________________________________________________ 7
Safety precautions
3 Safety precautions
3.1 Safety warning
WARNING :
Electric shock or fire hazard can be caused if critical components are replaced by non-
conforming components. These components are marked in this guide by a sign.
Replace
with conform types only!
3.2 Product safety notice
WARNING :
Many electrical and mechanical parts in display units have special safety-related
characteristics. These characteristics are often not evident from visual inspection nor can the
protection afforded by them necessarily be obtained by using replacement components rated
for higher voltage, wattage, etc. Replacement parts that have these special safety
characteristics are identified in this data and its supplements and bulletins. Electrical
components having such features are identified by or * on the schematics and on the
parts lists in this data and its supplements and bulletins. The use of a substitute replacement
that does not have the same safety characteristics as the recommended replacement part
shown in the parts lists in this data and its supplements and bulletins, may create shock or fire.

8 ________________________________________________________ Barco - LC-5621 - User manual
Package & storage
4 Package & storage
4.1 General
A safe transport of the units can only be guaranteed if the original undamaged
package is used for shipping. Handle with care when transporting.
Keep your original packaging. It is designed for this unit and is the ideal
protection during transportation.
4.2 Procedure in case of damaging
All shipments should be opened and inspected for concealed damage or pilferage
as soon as possible after the arrival at destination. The shipping cartons should
be retained for the surveyor’s inspection and full and accurate reserves must be
made by a letter or a fax message.
Depending upon the used means of transport, the written protest is subject to
different time-rules:
• by sea: the protest has to be issued against the captain and/or ship within 3
days of the delivery of the goods.
• by road: the protest has to be issued against the last road-carrier within 7
days after delivery of the goods.
• by air: the protest has to be issued against the air-carrier within 14 days
after delivery of the goods.
In all cases, a claim or potential claim should be reported as soon as possible
whether or not full documentation is immediately available.
After completion of all required steps, the claim should normally be finalized
within one month. For more information about the claims handling procedure,
contact Barco NV.
4.3 Storage
Specific storage conditions can be found in the technical specifications. It is best
to store the unit in its original packaging, on a shelf in a ventilated and humidity
controlled room.
NOTE :
At least every 2 years, all boards containing electrolytic capacitors need to be powered during
24 hours minimum.

Barco - LC-5621 - User manual ________________________________________________________ 9
About the product
5 About the product
5.1 Product description
5.1.1 LC-5621
Barco’s LC-5621 display has been specifically designed for us in dedicated
professional applications. The display features quad full High Definition
(3840x2160) and delivers crisp, clear and color-accurate perfect images on a
large display size with 56” diagonal.
With the 56” Quad-HD display, operators benefit from a large display surface
without having to compromise on image quality or accuracy.
The LCD technology used in the Barco LC series offers many benefits not found
in other flat panel technologies:
• High brightness
• High contrast, even in high ambient light environments
• Lower power consumption
•Longlifetime
5.1.2 Main features
Ultra-high resolution
Barco’s LC-5621 is able to show large amounts of data in ultimate detail.
Faster response time
Thanks to its extremely fast response time (6.5 ms gray to gray), the LC-5621
reproduces fast-moving action scenes with vivid accuracy.
Wide viewing angle
The wide viewing angle (176°) and large surface are very beneficial in
collaborative environments where detailed information is viewed by multiple
participants.
Adjustable color temperature
The color temperature can be set to 5600K, 6500K, 7500K, 8500K, or 9300K to
adjust the color balance to different user requirements. User adjustment of the
color balance is also possible with R, G and B sliders.
VESA mounting structure for easy installation
Integrated mounting interfaces according to the VESA standards allow easy wall
or ceiling installation with VESA-approved standard (VESA MIS F, 800, 400, 8).
Table stands and mounting devices are optional.
Control & diagnostics
With extensive control and diagnostic functions through RS232, the LC-5621 can
be easily controlled, both on or off site or in real-time with a simple touch of a
button.

10 _______________________________________________________ Barco - LC-5621 - User manual
About the product
5.2 Recommended use
5.2.1 General precautions for all units
For optimum performance, please note the following when setting up and using
the unit(s).
• Allow adequate ventilation in case the configuration is built in a rack or a
console, so that the heat can properly dissipate.
• Make sure all units are disconnected from mains before connecting the sig-
nals.
• The power cable or connector (in case of a split design = *connection cable)
is the primary means of detaching the system from the power supply. One
of the cable ends should be easily accessible.
• Clean the screen surface of the display with a sponge or soft cleaning cloth.
Do NOT use abrasive cleaning agents, glass cleaner or tissue paper. Use
non-aggressive glass cleaning products instead. Do NOT use alcohol/sol-
vents at higher concentration > 5%.
• Avoid displaying fixed patterns on the display for long periods of time to
avoid image persistence (after-image effects).
NOTE :
Always power-down the unit before disconnecting the power cable.
IMPORTANT :
Immediately unplug if:
• Power supply cord or plug is damaged.
• If the units have been dropped or the cabinets are damaged.
• If the units don’t operate normally by following operating instructions.
*Connection cable= cable between the panel or display module and control
module
5.2.2 Image retention
The specified usage of the monitor with fixed patterns per 24 hours is maximum
2 shifts of 8 hours, with minimum 1 hour of relaxation between the shifts. The
24 months product warranty does not apply to the case of image retention
phenomena (after-image, shadows, dark lines and other image artifacts), that
may result from a usage outside of this specification.

Barco - LC-5621 - User manual _______________________________________________________ 11
Installation
6 Installation
6.1 Mounting procedure
6.1.1 LC-5621 mounted on stands
The unit is standard mounted on two stands on the rear of the unit. The stands
use the VESA mounting holes foreseen in the unit.
The stands can be mounted on two ways as shown in the drawing below.
Figure 1: Location of the stands of the LC-5621
1Stand (2x)
1 1
1 1
DVI-D(Master) DVI-D(Slave)RS232
ACIN
ON
OFF
MAIN
POWER
USBHUB
DVI-D(Master) DVI-D(Slave)RS232
CIN
ON
OFF
P
USBHUB

12 _______________________________________________________ Barco - LC-5621 - User manual
Installation
6.1.2 LC-5621 with VESA compliant mounting solution
The LC-5621 can be mounted on an arm compliant to the VESA MIS F, 800, 400,
8 standards.
The LC-5621 can also be mounted on a wall or ceiling according to the VESA MIS
F, 800, 400, 8 standards.
Figure 2: Location of the VESA mounting holes
1VESA mounting holes (8x)
11
1
1
1
1
11
DVI-D(Master) DVI-D (Slave)RS232
ACIN
ON
OFF
MAIN
POWER
USBHUB

Barco - LC-5621 - User manual _______________________________________________________ 13
Installation
6.2 Connecting the signals
6.2.1 Connector location
Figure 3: Connector location LC-5621
12
3
4
5 6
1
2
3
4
5
6
DVI-D connector (Master)
RS-232 connector
DVI-D connector (Slave)
USB Hub
Power connector (AC IN)
Power switch

14 _______________________________________________________ Barco - LC-5621 - User manual
Installation
6.2.2 Detailed connector information
6.2.2.1 Power connector
IEC connector layout
Figure 4: Power connector
Power ranging
Automatic selection between the following voltage ranges:
• 90Vac – 140Vac (100V and 115V nominal)
• 180Vac – 264Vac (230V nominal)
• Frequency: 45 – 65Hz
Mains Fuse inside the unit (T 6.3 A H), for fuse replacement procedures, refer to
the maintenance manual of the unit.
NOTE :
When connecting mains, check if the power source corresponds with the mains voltage marked
on the identification label on the display!
POWER 100 - 240 VAC

Barco - LC-5621 - User manual _______________________________________________________ 15
Installation
6.2.2.2 DVI connector
DVI-D connector layout
DVI-D receptable connector (24 pins), right angle with pegs
DVI input pinning
Pin signal
1 TMDS Data 2-
2 TMDS Data 2+
3 TMDS Data 2/4 Shield
4 TMDS Data 4-
5 TMDS Data 4+
6 DDC Clock
7 DDC Data
8NC
9 TMDS Data 1-
10 TMDS Data 1+
11 TMDS Data 1/3 Shield
12 TMDS Data 3-
13 TMDS Data 3+
14 +5V Power
15 Ground for +5V
16 Hot Plug Detect
17 TMDS Data 0-
18 TMDS Data 0+
19 TMDS Data 0/5 Shield
20 TMDS Data 5-
21 TMDS Data 5+
22 TMDS Clock Shield
23 TMDS Clock+
24 TMDS Clock-
12345678
910 11 12 13 14 15 16
17 18 19 20 21 22 23 24

16 _______________________________________________________ Barco - LC-5621 - User manual
Installation
6.2.2.3 Control connector
9 pins subD male connector layout
Control pinning
Pin signal
1Nc
2 Signal receive
3 Signal transmit
4Nc
5GND
6Nc
7Nc
8Nc
9Nc
15
69

Barco - LC-5621 - User manual _______________________________________________________ 17
Installation
6.3 First installation
6.3.1 Case 1: Customer buys NVIDIA Quadro FX 4600
6.3.1.1 System requirements
Minimum system requirements for using a NVIDIA Quadro FX 4600:
• PC compatible with Intel Pentium® or AMD Opteron® class processor or
higher
• Open PCI Express x16 lane slot with open adjacent slot
• Microsoft Windows XP
• 1 GB system memory
• 100 MB of available disk space for full installation
• CD-ROM or DVD-ROM drive
• VGA or DVI-I compatible display
• 750 W power supply (higher capacity may be required for NVIDIA SLI)
6.3.1.2 NVIDIA Quadro FX 4600
Figure 5: NVIDIA Quadro FX 4600
1
2
1
2
Master DVI slot
Slave DVI slot

18 _______________________________________________________ Barco - LC-5621 - User manual
Installation
6.3.1.3 Downloading the correct drivers
NOTE :
Before you install the LC-5621, use an additional LCD monitor to install the drivers to the
workstation.
First the correct driver should be installed on your system.
Go to http://www.nvidia.com
Go to download drivers and select the following items
Now the following screen should appear:

Barco - LC-5621 - User manual _______________________________________________________ 19
Installation
Check the checkbox and push the “Download Now” button.
Now the driver should be downloaded on your system.
6.3.1.4 Installing the drivers
Install the driver of the NVIDIA Quadro FX 4600 by double clicking the icon on
your desktop. Following image appears on the screen:
Accept the license agreement and click “Next”.

20 _______________________________________________________ Barco - LC-5621 - User manual
Installation
Click “Next”.
Following screen appears on the screen, click “Next” to install the drivers to your
computer.
