TCD-361
High-Bright 24” Tower Control Display
The growing reliance on advanced software tools in today’s ATC towers creates a need
for larger HMI display surfaces. At the same time, ATC control towers are typically
characterized by strict spatial limitations and a wide scale of ambient light conditions,
ranging from bright daylight to dimmed night time.
In answer to this, Barco has created the TCD-361, a 24” wide-screen display that
brings optimum reading quality, reliability and user-comfort to the tower control
environment. The TCD-361 offers excellent brightness (more than 350 cd/m2, peak typ.
500 cd/m2) and a wide dimming ratio (up to 100:1). The display’s integrated Ambient
Light Compensation function automatically adjusts brightness settings in function
of the ambient light conditions. Barco’s unique Automatic Phase Adjust technology
guarantees artifact-free images over time.
The TCD-361 has a slimline, low-height design to allow for high spatial efficiency in the
tower and an excellent view outside. Built on Barco’s near-zero maintenance concept, the
display is easy to set up, and provides internal stabilization, calibration and several Built-In
Test (BIT) patterns for easy diagnostics. Thanks to its thermal management design, the
TCD-361 offers long-lifetime and low-noise operation. In addition, the optional health and
configuration software continuously checks the registered TCD-361 displays for their online
status and warns system administrators for preventive maintenance actions.
Main features:
•24” wide-screen AMLCD
•2.3 MegaPixel resolution
(1920 x 1200, WUXGA)
•Optically stabilized brightness
(up to 350 cd/m2/ max. 500 cd/m2)
•High contrast (typ. 450:1)
•High dimming ratio (up to 100:1)
•Continuous Automatic Phase Adjust
for artifact-free images over time
•Long lifetime backlight (typ. 40,000
hours in mixed tower use)
•Low noise and low heat design
•Multiple inputs for flexible control
•Sleek bezel design, maximizing
display surface in tower setup
TCD-361.indd 1 03-03-2008 15:22:23

www.barco.com/airtrafficcontrol
ELECTRO OPTICAL
Panel type: Active Matrix LCD (Silicon TFT)
Panel diagonal: 24” / 61 cm
Image dimensions: 518 x 324 mm
20.4 x 12.76”
Pixel dimensions: 0.27 x 0.27 mm
Panel resolution: 1920 x 1200 pixels (WUXGA)
Screen specifications: 16 million colors /
256 grayscales per color
Protective front filter: Hard coated front panel: 3H
Reflection: Low reflective front panel:
haze type typ. 20%
Light output: stabilized up to 350 cd/m2
(100 fL) at 10 to 35°C ambient
unstabilized typ. 500 cd/m2
(145 fL) at 10 to 30°C ambient
Dimming ratio: Up to 100:1
Panel contrast ratio: typ. 450:1
Color temperature: White point selectable between
6000° K - 10000° K
Automatic color calibration: Via optional external calibration tool
Calibration tool (USB) + software
required
Viewing angle: Horizontal and vertical > ± 80°
(CR = 10, dark room)
INTERFACES
3 selectable video inputs: One DVI – two analog inputs
(Automatic upscaling for typical
lower resolutions)
Auto-sync: Separate H&V / Ext. Combined /
Sync on Green
Connector type:
DB9 for RS232 link
2 x USB for optional tools & functions:
    • Host function: connect to e.g.
optional control box for picture
and background settings
    • Peripheral function: connects to
workstation for optional tools, e.g.
consistency management and
calibration tools
Mini Din for control purposes
Ethernet RJ45 for maintenance & control purposes
CONTROLS
On bezel: standard 5 control keys: UP; DOWN,
ENTER, EXIT, STANDBY
OSD: Menu driven On-Screen Display
Remote control: RS232 link (Barco Protocol) /
Barco keypad / USB control
POWER
Power supply: External power supply box
Input: 100 - 240 VAC - 2.5 A
Frequency limits: 45-65Hz
Power consumption: typical 80W (max. 130W)
GENERAL DATA
Bezel: sleek design
Weight: 8.3 kg / 18 lbs
MTTR: LRU based less than 0.5 hrs
ENVIRONMENTAL
Temperature:
Operating: 0°C/+35°C (+32°F/+95°F)
Storage: -20°C/+60°C (-4°F/+140°F)
Humidity: 10 - 85% max (non-condensing)
@ 35°C (95°F)
Altitude (pressure):
Operating: 15,000 ft (57.16 kPa)
Storage: 35,000 ft (23.84 kPa)
EMC
Emission: FCC class A vol. II part 15 subpart J
Immunity: EN50082-2, EN55022 limit A
APPROVALS
IEC 950, UL 1950, c-UL 950, CE 2001
OPTIONS
•Flexible remote control box for picture and background control via
2 rotary digitizers for “analog control touch and feel”. Might require
optional external software. Allows for a tracked control between
multiple TCD-361s.
•USB based color sensor for color calibrations
•VESA arm / foot
Please contact factory for more details.
Ref. K5906019SSE0308R001
Application photo by courtesy of Belgocontrol
Technical specifications are subject to change without prior notice
Barco
Pres. Kennedypark 35 - B-8500 Kortrijk, Belgium
Phone: [phone] - Fax: [phone]
E-mail: [e-mail]
BarcoView, LLC
3059 Premiere Parkway - Duluth, Georgia, 30097-4905, USA
Phone: [phone] - Fax: [phone]
E-mail: [e-mail]
Technical specifications
In search of continuous improvement
324 mm (Active area)
366 mm
564 mm
518,4 mm (Active area)
67 mm
