Barco MDSC-2324 Series User manual

ENABLING BRIGHT OUTCOMES
MDSC-2324 LED
MDSC-2324 DDI
MDSC-2324 MNA
User Guide
MDSC-2324

Registered office: Barco NV
President Kennedypark 35, 8500 Kortrijk, Belgium
www.barco.com/en/support
www.barco.com
Barco NV
Beneluxpark 21, 8500 Kortrijk, Belgium
www.barco.com/en/support
www.barco.com

1Welcome! ................................................................................................................................................................................................................7
1.1 About the product.................................................................................................................................................................................8
1.2 What's in the box..................................................................................................................................................................................8
1.3 About this user guide .........................................................................................................................................................................9
2Product overview ........................................................................................................................................................................................... 11
2.1 Front view..............................................................................................................................................................................................12
2.2 Rear view...............................................................................................................................................................................................13
2.3 Connector view ..................................................................................................................................................................................13
2.3.1 MDSC-2324 LED version..........................................................................................................................................13
2.3.2 MDSC-2324 DDI version...........................................................................................................................................14
2.3.3 MDSC-2324 MNA version.........................................................................................................................................14
2.4 Connector pin assignments ........................................................................................................................................................15
2.4.1 Input power connector.................................................................................................................................................15
2.4.2 DVI-1 connector (DVI-I)..............................................................................................................................................16
2.4.3 DVI-2 connector (DVI-D)............................................................................................................................................16
2.4.4 DVI out connector (DVI-D)........................................................................................................................................17
2.4.5 RS232 connector ...........................................................................................................................................................17
2.4.6 USB type A connector.................................................................................................................................................18
2.4.7 Mini USB connector......................................................................................................................................................18
2.4.8 DisplayPort connector.................................................................................................................................................18
2.4.9 S-Video and S-Video-out connector....................................................................................................................19
3Display installation .......................................................................................................................................................................................21
3.1 VESA mount installation ...............................................................................................................................................................22
3.2 Cover removal ....................................................................................................................................................................................22
3.3 Video input connection ..................................................................................................................................................................23
3.3.1 MDSC-2324 LED version..........................................................................................................................................23
3.3.2 MDSC-2324 DDI version...........................................................................................................................................23
3.3.3 MDSC-2324 MNA version.........................................................................................................................................24
3.4 Video output connection ...............................................................................................................................................................25
3.4.1 MDSC-2324 LED version..........................................................................................................................................25
3.4.2 MDSC-2324 DDI version...........................................................................................................................................26
3.4.3 MDSC-2324 MNA version.........................................................................................................................................26
3.5 Nexxis OR.............................................................................................................................................................................................27
3.6 Power supply connection .............................................................................................................................................................27
3.7 Cable routing ....................................................................................................................................................................................... 28
4Daily operation.................................................................................................................................................................................................31
4.1 Keyboard activation/deactivation.............................................................................................................................................32
4.2 Keyboard backlight ..........................................................................................................................................................................32
K5903252 (451920612633) /02 MDSC-2324 3
Table of contents

K5903252 (451920612633) /02 MDSC-2324
4
4.3 On/Off switching ................................................................................................................................................................................33
4.4 Power led status................................................................................................................................................................................33
4.5 OSD menu activation......................................................................................................................................................................33
4.6 OSD menu navigation .................................................................................................................................................................... 34
4.7 Shortkey functions............................................................................................................................................................................34
4.7.1 Main source selection..................................................................................................................................................35
4.7.2 Multi-image configuration..........................................................................................................................................35
4.7.3 Zoom factor selection ..................................................................................................................................................36
4.7.4 Brightness adjustment ................................................................................................................................................36
4.8 Extended keyboard functions.....................................................................................................................................................36
4.8.1 Main source selection..................................................................................................................................................37
4.8.2 Second source selection............................................................................................................................................37
4.8.3 Multi-image configuration..........................................................................................................................................38
4.8.4 Common Functions: Transfer function selection..........................................................................................38
4.8.5 Common Functions: Image size selection.......................................................................................................39
4.8.6 Common Functions: Zoom factor selection ....................................................................................................39
4.9 Menu locking/unlocking.................................................................................................................................................................39
5Advanced operation.....................................................................................................................................................................................41
5.1 OSD picture menu............................................................................................................................................................................42
5.1.1 Profile....................................................................................................................................................................................42
5.1.2 Brightness..........................................................................................................................................................................42
5.1.3 Contrast...............................................................................................................................................................................43
5.1.4 Saturation...........................................................................................................................................................................43
5.1.5 Color temperature..........................................................................................................................................................43
5.1.6 Gamma................................................................................................................................................................................44
5.1.7 Sharpness..........................................................................................................................................................................44
5.2 Picture Advanced menu................................................................................................................................................................44
5.2.1 Black Level ........................................................................................................................................................................44
5.2.2 Smart Video ......................................................................................................................................................................45
5.2.3 Image Position.................................................................................................................................................................45
5.2.4 Auto Adjustment .............................................................................................................................................................45
5.2.5 Phase....................................................................................................................................................................................46
5.2.6 Clock/Line ..........................................................................................................................................................................46
5.3 Display Format menu .....................................................................................................................................................................46
5.3.1 Main Source (Primary Source)...............................................................................................................................47
5.3.2 Component Mode .......................................................................................................................................................... 47
5.3.3 Zoom.....................................................................................................................................................................................48
5.3.4 Image Size.........................................................................................................................................................................48
5.3.5 2nd Picture Mode.............................................................................................................................................................48
5.3.6 2nd Picture Source .........................................................................................................................................................49
5.3.7 2nd Picture Position .......................................................................................................................................................49
5.3.8 Picture Swap ....................................................................................................................................................................50
5.4 Configuration menu .........................................................................................................................................................................50
5.4.1 Information.........................................................................................................................................................................50
5.4.2 Language ...........................................................................................................................................................................51
5.4.3 Failover mode .................................................................................................................................................................. 51
5.4.4 Extended keyboard.......................................................................................................................................................51
5.4.5 OSD setting.......................................................................................................................................................................52
5.4.5.1 OSD Horizontal Position..................................................................................................................52
5.4.5.2 OSD Vertical Position........................................................................................................................52
5.4.5.3 OSD Time-out........................................................................................................................................52
5.4.6 Recall Profile ....................................................................................................................................................................53
5.4.7 Save Profile.......................................................................................................................................................................53

K5903252 (451920612633) /02 MDSC-2324 5
5.5 System menu ......................................................................................................................................................................................53
5.5.1 Power on DVI 1 ............................................................................................................................................................... 54
5.5.2 Power on DVI 2 ............................................................................................................................................................... 54
5.5.3 DVI Output .........................................................................................................................................................................54
5.5.4 DVI Output .........................................................................................................................................................................55
5.5.5 Keyboard lock .................................................................................................................................................................. 57
5.5.6 Keyboard backlight .......................................................................................................................................................57
5.5.7 Power Saving...................................................................................................................................................................57
6Important information.................................................................................................................................................................................59
6.1 Safety information.............................................................................................................................................................................60
6.2 Environmental information...........................................................................................................................................................62
6.3 Biological hazard and returns ....................................................................................................................................................64
6.4 Regulatory compliance information........................................................................................................................................64
6.5 EMC notice...........................................................................................................................................................................................65
6.6 Cleaning and disinfection ............................................................................................................................................................. 68
6.7 Explanation of symbols..................................................................................................................................................................68
6.8 Legal disclaimer.................................................................................................................................................................................71
6.9 Technical specifications.................................................................................................................................................................72
6.10 Open source license information .............................................................................................................................................76

K5903252 (451920612633) /02 MDSC-2324
6

7
K5903252 (451920612633) /02 MDSC-2324
Welcome! 1

K5903252 (451920612633) /02 MDSC-2324
8
1.1 About the product
Overview
Barco's MDSC-2324 is a 24-inch surgical display. Purpose-built for the operating room, the MDSC-2324 offers
an easy-clean design, smart mechanics and the most detailed images in the operating room today.
Ease of mind
Perfect hand-eye coordination: The display’s high brightness, high contrast and full HD resolution provide
surgeons with excellent depth perception and the most accurate images. The MDSC-2324 presents images
with unrivaled color and grayscale accuracy and with near-zero latency, making it perfectly suited for use with
today’s state-of-the-art endoscopy camera systems.
Multi-source, multi-display imaging: With its broad input connectivity, the MDSC-2324 also offers flexible multi-
modality imaging (PiP & PaP) in new integrated operating rooms. Thanks to its high-bright LED backlight, the
surgical display also ensures a long lifetime and low power consumption.
Ease of installation
The MDSC-2324 comes with a smart cable management system that hides the cables for a clutter-free set-up.
Its lightweight design allows easy mounting on surgical booms and spring arms. Available in different models,
this surgical display also features a host of connectivity options and remote control.
Ease of use
Barco’s MDSC-2324 allows easy cleaning and complete disinfection thanks to its smooth surface, sealed
housing, and protective screen cover. The fanless design avoids the spread of contaminants.
Features
•24-inch wide-screen LCD with full HD resolution and 10–bit per color
•Wide viewing angle
•High-brightness LED backlight
•Advanced, full 10-bit image processing algorithms with 12–bit LUT
•Widest range of SD and HD input signals, including 3G-SDI and DisplayPort
•Light weight to easily mount onto a boom
Innovative features are also available to give maximum flexibility when installing the display as: Configurable
DVI-out and Failover Mode
1.2 What's in the box
Overview
Your MDSC-2324 display comes with:
•MDSC-2324 user guide
•DVI cable
•AC power cords
•external power supply
•4 screws, 4 dented washers and an Allen key
Keep your original packaging. It is designed for this display and is the ideal protection during
transport.
The user guide is available in other languages on www.barco.com.
Welcome!

K5903252 (451920612633) /02 MDSC-2324 9
1.3 About this user guide
Overview
This manual provides support to the user during the installation, set up and utilization of the MDSC-2324
display. Depending on the specific version that has been purchased, some of the features and options
described in this document may not apply to the display in user’s hands.
Welcome!

K5903252 (451920612633) /02 MDSC-2324
10
Welcome!

11
K5903252 (451920612633) /02 MDSC-2324
Product overview 2

K5903252 (451920612633) /02 MDSC-2324
12
2.1 Front view
Overview
1 2 3 4 5 6 7
Image 2-1
1. Input Selection key
2. Multi-image selection key / Down key
3. Image zoom key / Up key
4. OSD Menu key / Enter key
5. Brightness decrease / Left key
6. Brightness increase / Right key
7. Stand-by key
A 7-key capacitive keypad is located on the front of the display. By default only the stand-by key is visible.
When you touch any of the keys shortly, the front illumination of all other keys is switched on for a few
seconds. When you touch any of these other keys again while the illumination is on, the function of the key is
executed. If no further action is taken within the time-out, the front key illumination is switched off again.
The auto-dim function of the front key illumination can be disabled in the OSD menu.
For keyboard activation please refer to “Keyboard activation/deactivation”, page 32
Product overview

K5903252 (451920612633) /02 MDSC-2324 13
2.2 Rear view
Overview
4
1
5
1
1 1
3
2
Image 2-2
1. VESA mount screw holes
2. Cable routing channel
3. Cable routing channel expansion clip
4. Connector compartment cover
5. Connector compartment cover fixation screw
2.3 Connector view
2.3.1 MDSC-2324 LED version
Overview
10 11 12 13 14 15 16 17
5 6 7 8 94
321
Image 2-3
1. SDI-1 out
2. SDI-1
3. Input power connector
4. Potential Equalization pin (POAG)
5. RS232
6. Sync
7. CVBS
8. CVBS out
9. S-Video out
10.DVI out
11. DVI-1 (DVI-I: digital & analog with HDCP)
12.DisplayPort (VESA std 1.1a)
Product overview

K5903252 (451920612633) /02 MDSC-2324
14
13.R/Pr
14.G/Y –SOG
15.B
16.S-Video
17.Service
2.3.2 MDSC-2324 DDI version
Overview
13 14 15 16 17 18 19 20
8 9 10 11 127
64 5321
Image 2-4
1. DVI-2 (DVI-D: digital only)
2. SDI-2 out
3. SDI-2
4. SDI-1 out
5. SDI-1
6. Input power connector
7. Potential Equalization pin (POAG)
8. RS232
9. Sync
10.CVBS
11. CVBS out
12.S-Video out
13.DVI out
14.DVI-1 (DVI-I: digital & analog with HDCP)
15.DisplayPort (VESA std 1.1a)
16.R/Pr
17.G/Y –SOG
18.B
19.S-Video
20.Service
2.3.3 MDSC-2324 MNA version
Overview
1 3 4 6
52 9
14 15 16 17 18 19 20
107 11 12 13
21
8
Image 2-5
1. Optical 10Gb Ethernet SFP+ interface*
Product overview

K5903252 (451920612633) /02 MDSC-2324 15
2. LED1*
•Green: Link is active
•Off: No active network connection
3. LED2*
•Orange blinking: Activity = (Tx) or (Rx)
•Off: No network activity
4. LED3*
•Green: Power on, normal operation
•Off: System not powered
•Orange blinking: Error
5. Micro USB interface*
6. USB 2.0 type A interface*
7. Input power connector
8. Potential Equalization pin (POAG)
9. RS232
10.Sync
11. CVBS
12.CVBS out
13.S-Video out
14.DVI out
15.DVI-1 (DVI-I: digital & analog with HDCP)
16.DisplayPort (VESA std 1.1a)
17.R/Pr
18.G/Y –SOG
19.B
20.S-Video
21.Service
(*) Nexxis OR functionality: for more detailed information on Barco's Nexxis integrated OR solution please
refer to the dedicated user guides. Please visit my.barco.com to obtain these user guides.
2.4 Connector pin assignments
2.4.1 Input power connector
Overview
Image 2-6
1. GND
2. Not connected
3. +24 VDC
4. GND
5. Shield
6. +24 VDC
The ground and the shield connections on the power input connector have no Protective Earth
function. A Protective Earth connection is provided via a dedicated pin (see “Power supply
connection”, page 27).
Product overview

K5903252 (451920612633) /02 MDSC-2324
16
2.4.2 DVI-1 connector (DVI-I)
Overview
Image 2-7
1. D2_Rx- (T.M.D.S.)
2. D2_Rx+ (T.M.D.S.)
3. GND (data 2 shield)
4. Not connected
5. Not connected
6. SCL (for DDC)
7. SDA (for DDC)
8. Analog vertical sync
9. D1_Rx- (T.M.D.S.)
10.D1_Rx+ (T.M.D.S.)
11. GND (data 1 shield)
12.Not connected
13.Not connected
14.+5V input (DDC supply) (*)
15.GND (cable sense)
16.Hot plug detect (*)
17.D0_Rx- (T.M.D.S.)
18.D0_Rx+ (T.M.D.S.)
19.GND (data 0 shield)
20.Not connected
21.Not connected
22.GND (clock shield)
23.CK_Rx+ (T.M.D.S.)
24.CK_Rx- (T.M.D.S.)
25.C1: Analog Red
26.C2: Analog Green
27.C3: Analog Blue
28.C4: Analog horizontal sync
29.C5: Analog GND return (analog R, G, B)
(*) +5 VDC output selectable on either pin 14 or 16 via the OSD menu. (+5V ± 10% @ 500mA (max))
PC analog (VGA) input source can be connected to the DVI-I input connector using a DVI-I to VGA
adapter. The use of an adapter cable of at least 0.15 m long will allow an easy placement inside the
cable cover.
2.4.3 DVI-2 connector (DVI-D)
Overview
Image 2-8
1. D2_Rx- (T.M.D.S.)
Product overview

K5903252 (451920612633) /02 MDSC-2324 17
2. D2_Rx+ (T.M.D.S.)
3. GND (data 2 shield)
4. Not connected
5. Not connected
6. SCL (for DDC)
7. SDA (for DDC)
8. Not connected
9. D1_Rx- (T.M.D.S.)
10.D1_Rx+ (T.M.D.S.)
11. GND (data 1 shield)
12.Not connected
13.Not connected
14.+5V input (DDC supply) (*)
15.GND (cable sense)
16.Hot plug detect (*)
17.D0_Rx- (T.M.D.S.)
18.D0_Rx+ (T.M.D.S.)
19.GND (data 0 shield)
20.Not connected
21.Not connected
22.GND (clock shield)
23.CK_Rx+ (T.M.D.S.)
24.CK_Rx- (T.M.D.S.)
(*) +5 VDC output selectable on either pin 14 or 16 via the OSD menu. (+5V ± 10% @ 500mA (max))
2.4.4 DVI out connector (DVI-D)
DVI-D
The DVI out connector is also a DVI-D connector type, see previous paragraph for more details.
2.4.5 RS232 connector
Overview
Image 2-9
1. Not connected
2. Rx (driven by host)
3. Tx (driven by display)
4. Not connected
5. Ground
6. Not connected
7. Not connected
8. Not connected
9. Not connected
Product overview

K5903252 (451920612633) /02 MDSC-2324
18
2.4.6 USB type A connector
Overview
Image 2-10
1. +5 VDC
2. Data -
3. Data +
4. GND
2.4.7 Mini USB connector
Overview
12345
Image 2-11
1. +5 VDC
2. Data -
3. Data +
4. Not connected
5. GND
2.4.8 DisplayPort connector
Overview (sink side pin-out)
19 17 15 13 11 9 7 5 3 1
20 18 16 14 12 10 8 6 4 2
Image 2-12
1. ML_Lane 3 (n)
2. GND
3. ML_Lane 3 (p)
4. ML_Lane 2 (n)
5. GND
6. ML_Lane 2 (p)
7. ML_Lane 1 (n)
8. GND
9. ML_Lane 1 (p)
10.ML_Lane 0 (n)
11. GND
12.ML_Lane 0 (p)
13.CONFIG1
14.CONFIG2
15.AUX CH (p)
16.GND
17.AUX CH (n)
18.Hot Plug
19.Return
Product overview

K5903252 (451920612633) /02 MDSC-2324 19
20.DP_PWR (+3.3 VDC @ 500 mA max)
2.4.9 S-Video and S-Video-out connector
Overview
Image 2-13
1. Ground (Y)
2. Ground (C)
3. Luminance (Y)
4. Chroma (C)
5. SG: Shielded Ground
Product overview

K5903252 (451920612633) /02 MDSC-2324
20
Product overview
