Barco CDMS-3000 User manual

CDMS-3000
Control Display & Management System
CDMS-3000 is the next generation Control Display & Management System, featuring
a pioneering 3 x 4 inch AMLCD panel with VGA resolution. Equipped with the latest
display technology, the advanced CDMS-3000 combines high brightness and contrast
with compact dimensions, low weight and excellent energy efficiency.
The CDMS-3000 comes as a complete product family, including the civil CDMS-3739
(ARINC 739), the military-oriented CDMS-3753 (combo ARINC-429 and MIL-STD-1553),
and the versatile CDMS-3702, which hosts Barco’s unique MOSArt platform. This
MOSArt-equipped version allows customers to develop or integrate their own
application (e.g. FMS or mission solution) on the flexible CDMS-3000 platform. What's
more, the CDMS-3000 can also be operated as a data loader, thanks to its wide variety
of high-speed interfaces.
Various keyboards with different engravings and/or colors are available to facilitate
integration into a diversity of new and retrofit cockpit configurations. A cold wall air
cooling system ensures optimum reliability and a low life cycle costs, even in the
harshest operating environments.
Main features:
•3 x 4 inch sunlight-readable color
display
•640 x 480 standard resolution (VGA)
•NVG compatible
•Compact 6.75" high design
•Various interface capabilities:
- Front mini-USB and/or remote USB
- Video composite input
- ARINC 429
- MIL-STD-1553B
-Ethernet (100/10 Mbit)
•Unique LED backlight technology
•Usable as data loader
•Extensive Built-In-Testing (BIT)
•MOSArtTM support (CDMS-3702)
•Compatible with customer-specific
software
•Optional 7s memory hold
(CDMS-3702)

www.barcoaerospace.com
K5906171 rev. 02 0208 © 2008 Barco
Technical specifications are subject to change without prior notice
Barco
Pres. Kennedypark 35 - B-8500 Kortrijk, Belgium
Phone: [phone] - Fax: [phone]
E-mail: [e-mail]
Barco, Inc.
3059 Premiere Parkway, Duluth, GA 30097
Phone: [phone] - Fax: [phone]
Email: [e-mail]
Technical specifications
ELECTRO OPTICAL
Panel type: Active Matrix LCD (Silicon TFT)
Panel active area: 12.7 cm / 5 inch diagonal
Pixel dimensions: 0.16 mm H x 0.16 mm V
Vertical stripe RGB, 160 PGPI
Panel resolution: 640 x 480 pixels (VGA)
Image dimensions: 102.2 x 74.8 mm / 4.02” x 2.94” (4/3)
Screen specifications: 262,144 colors - 64 grayscales
Brightness: 160 fL
White Luminance: 656 cd/m2
Contrast ratio: > 400:1 @ dark environment
> 10:1 @ 10,000 fC
Anti reflection: Multilayer coating, MIL-C-14806
NVG: MIL-STD-3009 Type I, Class B NVIS (option)
Viewing angle: Hor: ± 45°
Vert: +30°/-15°
INTERFACES
Ethernet: 2 (option)
USB: 1 front/1 rear (option)
Discrete I/O: 8 I / 4 O (up to 32 as option)
CDMS-3739: 8 A429 Inputs
3 A429 Outputs
CDMS-3753: Single dual redundant MIL-STD-1553B
(double DR as option)
8 A429 Inputs
3 A429 Outputs
(24 A429 I / 8 A429 O as option)
CDMS-3702: 24 A429 I / 8 A429 O
32 discrete
2 A708 Inputs
CONTROLS
Controls (front): Brightness, Up/Down rocker switch
Function keys: 15
Annunciators: Up to 6 above the display
1 on each side of the first line of function keys
Softkeys: 12 (6 left, 6 right of the display)
Keyboard: Full alphanumeric keyboard
Automatic light contr.: 2 light sensors
PROCESSING
Processor: PowerPC
Memory: 128 MB SDRAM ECC memory,
256 MB (CDMS-3702)
128 MB Flash memory,
256 MB (CDMS-3702)
128kB NVRAM
GENERAL DATA
Power supply: Dual 28 Vdc, MIL-STD-704/RTCA/DO-160E
Keyboard light cont.: 5 Vdc
Annunc. light cont.: 5 Vdc
Power consumption: 35 W (nominal) / 70 W (cold start)
Weight: 3 kg / 6.6 lb (CDMS-3739)
Cooling: Forced air cooling via cold wall
MTTR: Less than 0.5 hours
MTBF (calculated): 11,500 hrs (CDMS-3702 - AIC 35°C)
5,300 hrs (CDMS-3702 - ARW 35°C)
Built-In Testing: IBIT, CBIT, PBIT
Software: RTCA/DO-178B level B
ENVIRONMENTAL
Compliance: RTCA/DO-160E (MIL-STD-810E as option)
High temperature: +70°C operational, DO-160E Sect. 4 Cat B2
Low temperature: -45°C operational, DO-160E Sect. 4 Cat B2
Operational at -45°C: 1 min usable
5 min. full specs
Temp. storage: -55°C/-67°F up to +85°C/+185°F
Altitude: DO-160E Sect. 4 50,000 ft
Humidity: DO-160E Sect. 6 Cat B
Shock: 20 G - 11 ms, DO-160E Sect. 7 Cat B
Vibration: DO-160E Sect. 8 Cat R (G), S (M)
EMI/EMC: DO-160E
TSO C113
OPTIONS (common to all versions)
•USB interface and ARINC 615/ARINC 615 A data loading
•Ethernet interface
•NVIS compatibility
•Keyboard color and engraving change
•Additional discretes
•50 ms power drop
•7 sec. application backup
•For other custom options, please contact Barco.
5“
6.75
inch
171.45
mm
5.75 inch
146.0 mm
5“
5.97 inch
151.7 mm
0.74 inch
18.9 mm
8.62
inch
219
mm
