Personal wall
Immersive event based response and control
The personal wall represents an immersive and flexible workstation for the control
room. It can either be used as individual independent workstations or as a
collaborative group of flexible workstations. The latter configuration allows the
operators to respond to multiple incidents individually or manage a single incident
with multiple operators to cover different perspectives. The personal wall's display
size also allows for supervisory overviews by management without interfering with
the operator's work.
Integration of disparate displays
Allows collaboration
Increased flexibility
Cost-effective installation & maintenance
Individual situational response

The personal wall consolidates all the
display requirements for the work-
station into one managed intelligent
display solution. The personal wall
solution provides the users with an
immersive and integrated work
environment where multiple inputs
from various applications to analog or
digital video sources may be displayed
on one single large screen display
solution.
With a personal wall, this clutter of equipment may be reduced to provide a cleaner work area and
in addition provide a seamless and more flexible viewing capability - without boundaries and also
being able to simultaneously manage multiple applications and input formats
In most control room applications, the user
workstations are often cluttered with multiple
monitors displaying various different systems
as well as other video information

Next generation
work station console
Ideal for smaller control rooms where one or
two operators need to manage incidents.
Example cases, security control rooms. The
personal wall below has the ability shown to
display 2 RGB feeds, 16 videos simultaneously
and also host clients of network applications
Ideal for larger control rooms where a large number of operators need to work together or react to
specific situations in conjunction and manage a large system. Example cases, traffic, utilities,
telecom control rooms. Each of the above personal walls has the ability to display 2 RGB, 32 videos
(analog and digital streaming) and also host clients of network applications
Benefits
Reduced Disparate displays that integrate all
informational formats - video, data, RGB
(computer monitor feeds)
Allows collaboration between co-workers
Individual situational response (in addition to
common overview wall)
Flexibility to reconfigure displays for different
users or different situations
Power and cooling savings versus monitors
Installation and maintenance savings - cable
management

Barco Control Rooms has become the industry standard in the field of monitoring
solutions for Control & Operation Centers in telecom, traffic, surveillance, public utili-
ties, broadcasting, finance and service providing companies. Barco Control Rooms is
renowned for its flexible, market-specific approach, successfully implemented in over
a thousand control rooms worldwide.
Fully committed to quality, Barco Control Rooms offers full technical support as well
as on-site training. With its head offices in Belgium and Germany, Barco Control
Rooms is represented in more than 30 countries across the globe. With a yearly R&D
effort of 10% of its turnover, Barco Control Rooms ensures it remains at the forefront
of technology.
