Barco HDQ 4K35 Operating manual

ENABLING BRIGHT OUTCOMES
User and Installation manual
HDQ 4K35

Registered office: Barco NV
President Kennedypark 35, 8500 Kortrijk, Belgium
www.barco.com/en/support
www.barco.com
Barco NV
President Kennedypark 35, 8500 Kortrijk, Belgium
www.barco.com/en/support
www.barco.com

Copyright ©
All rights reserved. No part of this document may be copied, reproduced or translated. It shall not otherwise be
recorded, transmitted or stored in a retrieval system without the prior written consent of Barco.
EMC notices
EN55032/CISPR32 Class A MME (MultiMedia Equipment)
Warning : This equipment is compliant with Class A of CISPR 32. In a residential environment this equipment
may cause radio interference.
GB/T 9254 Class A ITE (Information Technology Equipment)
Warning : This is a class A product. In a domestic environment this product may cause radio interference in
which case the user may be required to take adequate measures.
BSMI Taiwan Class A statement:
警告使用者 :此為甲類資訊技術設備，於居住環境中使用 ，可能會造成射頻擾動，在此情況下，使用者會被要
求採取某些適當的對策。
Federal Communications Commission (FCC Statement)
This equipment has been tested and found to comply with the limits for a class A digital device, pursuant to
Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial environment. This equipment generates, uses,
and can radiate radio frequency energy and, if not installed and used in accordance with the instruction
manual, may cause harmful interference to radio communications. Operation of this equipment in a residential
area may cause harmful interference, in which case the user will be responsible for correcting any interference
at his own expense
Changes or modifications not expressly approved by the party responsible for compliance could void the
user's authority to operate the equipment
FCC responsible: Barco Inc.
3059 Premiere Parkway Suite 400
30097 Duluth GA, United States
Tel: [phone]
Trademarks
Brand and product names mentioned in this manual may be trademarks, registered trademarks or copyrights
of their respective holders. All brand and product names mentioned in this manual serve as comments or
examples and are not to be understood as advertising for the products or their manufacturers.
Changes
Barco provides this manual 'as is' without warranty of any kind, either expressed or implied, including but not
limited to the implied warranties or merchantability and fitness for a particular purpose. Barco may make
improvements and/or changes to the product(s) and/or the program(s) described in this publication at any time
without notice.
This publication could contain technical inaccuracies or typographical errors. Changes are periodically made
to the information in this publication; these changes are incorporated in new editions of this publication.
The latest edition of Barco manuals can be downloaded from the Barco web site www.barco.com or from the
secured Barco web site https://www.barco.com/en/signin.
Guarantee and Compensation
Barco provides a guarantee relating to perfect manufacturing as part of the legally stipulated terms of
guarantee. On receipt, the purchaser must immediately inspect all delivered goods for damage incurred during
transport, as well as for material and manufacturing faults Barco must be informed immediately in writing of
any complaints.
The period of guarantee begins on the date of transfer of risks, in the case of special systems and software on
the date of commissioning, at latest 30 days after the transfer of risks. In the event of justified notice of

complaint, Barco can repair the fault or provide a replacement at its own discretion within an appropriate
period. If this measure proves to be impossible or unsuccessful, the purchaser can demand a reduction in the
purchase price or cancellation of the contract. All other claims, in particular those relating to compensation for
direct or indirect damage, and also damage attributed to the operation of software as well as to other services
provided by Barco, being a component of the system or independent service, will be deemed invalid provided
the damage is not proven to be attributed to the absence of properties guaranteed in writing or due to the
intent or gross negligence or part of Barco.
If the purchaser or a third party carries out modifications or repairs on goods delivered by Barco, or if the
goods are handled incorrectly, in particular if the systems are operated incorrectly or if, after the transfer of
risks, the goods are subject to influences not agreed upon in the contract, all guarantee claims of the
purchaser will be rendered invalid. Not included in the guarantee coverage are system failures which are
attributed to programs or special electronic circuitry provided by the purchaser, e.g. interfaces. Normal wear
as well as normal maintenance are not subject to the guarantee provided by Barco either.
The environmental conditions as well as the servicing and maintenance regulations specified in this manual
must be complied with by the customer.

5R5905823 /05 HDQ 4K35
1 Safety...................................................................................................................................................................................................................7
1.1 General considerations ..................................................................................................................................................................8
1.2 Important safety instructions........................................................................................................................................................9
1.3 High Brightness precautions: Hazard Distance .............................................................................................................13
1.4 HD for fully enclosed projection systems...........................................................................................................................15
1.5 HD in function of modifying optics .........................................................................................................................................16
2 General............................................................................................................................................................................................................17
2.1 Installation requirements ............................................................................................................................................................18
2.2 Unpacking the projector ..............................................................................................................................................................19
2.3 Initial inspection ...............................................................................................................................................................................21
2.4 Air inlets and outlets ......................................................................................................................................................................22
2.5 Installation process overview ...................................................................................................................................................23
3 Physical installation.............................................................................................................................................................................25
3.1 Installation of the Lamp House................................................................................................................................................26
3.2 Access to the power connection.............................................................................................................................................27
3.3 Power input setup of the HDQ 4K35 .................................................................................................................................... 28
3.4 Connecting the projector with the power net ...................................................................................................................29
3.5 Connecting a UPS to the projector electronics ..............................................................................................................31
3.6 Landscape and portrait mode ..................................................................................................................................................32
3.7 Stacking multiple projectors......................................................................................................................................................34
3.8 Adjusting the multifunctional frame.......................................................................................................................................36
3.9 Aligning the projected image on the screen.....................................................................................................................39
3.10 Aligning stacked projectors .......................................................................................................................................................41
4 Lenses & Lens Holder.......................................................................................................................................................................45
4.1 Available lenses...............................................................................................................................................................................46
4.2 Lens selection...................................................................................................................................................................................47
4.3 Lens installation...............................................................................................................................................................................47
4.4 Lens removal.....................................................................................................................................................................................50
4.5 Installing the lens fixation mechanism.................................................................................................................................50
4.6 Removing the lens fixation mechanism..............................................................................................................................51
4.7 Lens shift, zoom & focus.............................................................................................................................................................52
4.8 Additional vertical shift of the Lens Holder........................................................................................................................53
4.9 Scheimpflug adjustment..............................................................................................................................................................54
Table of contents

R5905823 /05 HDQ 4K356
4.10 Fixation of the Lens Holder front plate ................................................................................................................................57
5 Input and Communication.............................................................................................................................................................61
5.1 Introduction.........................................................................................................................................................................................62
5.2 Local keypad of the HDQ projector ......................................................................................................................................63
5.3 Communication ports of the HDQ projector.....................................................................................................................64
5.4 Source input ports of the Barco HDQ 4K35 projector.................................................................................................65
5.5 ICMP status LEDs ..........................................................................................................................................................................68
5.6 ICMP reset..........................................................................................................................................................................................69
6 Starting up ....................................................................................................................................................................................................71
6.1 Switching ON the HDQ................................................................................................................................................................72
6.2 Switching OFF the HDQ..............................................................................................................................................................72
7 Maintenance...............................................................................................................................................................................................73
7.1 Cleaning the front dust filter ......................................................................................................................................................74
7.2 Cleaning the bottom dust filters ..............................................................................................................................................74
7.3 Cleaning the lens ............................................................................................................................................................................75
7.4 Cleaning the exterior of the projector...................................................................................................................................76
7.5 Checking cooling liquid level ....................................................................................................................................................76
7.6 Topping up the cooling liquid reservoir ...............................................................................................................................77
7.7 Removal of the Lamp House....................................................................................................................................................78
7.8 Realignment of the lamp in its reflector ..............................................................................................................................79
7.9 Authorization to clear security warning on the projector ...........................................................................................80
8 Removal and installation of the projector covers....................................................................................................83
8.1 Removal of the lamp cover........................................................................................................................................................85
8.2 Installation of the lamp cover....................................................................................................................................................85
8.3 Removal of the input cover........................................................................................................................................................86
8.4 Installation of the input cover....................................................................................................................................................86
8.5 Removal of the front cover.........................................................................................................................................................87
8.6 Installation of the front cover.....................................................................................................................................................88
8.7 Removal of the back cover ........................................................................................................................................................89
8.8 Installation of the back cover....................................................................................................................................................89
8.9 Removal of the left cover............................................................................................................................................................90
8.10 Installation of the left cover........................................................................................................................................................91
A Dimensions and specifications.................................................................................................................................................93
A.1 Dimensions of the Barco HDQ 4K35 ...................................................................................................................................94
A.2 Specifications of the Barco HDQ 4K35...............................................................................................................................94
A.3 Technical Regulations ..................................................................................................................................................................96
B Environmental information............................................................................................................................................................97
B.1 Disposal information......................................................................................................................................................................98
B.2 RoHS compliance...........................................................................................................................................................................98
B.3 Production address..................................................................................................................................................................... 100
B.4 Importers contact information ............................................................................................................................................... 100
Glossary ..................................................................................................................................................................................................... 101
Index .............................................................................................................................................................................................................. 103

7R5905823 /05 HDQ 4K35
1.1 General considerations ...................................................................................................................8
1.2 Important safety instructions............................................................................................................9
1.3 High Brightness precautions: Hazard Distance................................................................................13
1.4 HD for fully enclosed projection systems.........................................................................................15
1.5 HD in function of modifying optics ..................................................................................................16
About this chapter
Read this chapter attentively. It contains important information to prevent personal injury while installing and
using a Barco HDQ 4K35. Furthermore, it includes several cautions to prevent damage to the HDQ 4K35.
Ensure that you understand and follow all safety guidelines, safety instructions and warnings mentioned in this
chapter before installing your HDQ 4K35. After this chapter, additional “warnings”and “cautions”are given
depending on the installation procedure. Read and follow these “warnings”and “cautions”as well.
Safety 1

R5905823 /05 HDQ 4K358
1.1 General considerations
WARNING: Ensure you understand and follow all the safety guidelines, safety instructions,
warnings and cautions mentioned in this manual.
WARNING: Be aware of suspended loads.
WARNING: Wear a hard hat to reduce the risk of personal injury.
WARNING: Be careful while working with heavy loads.
WARNING: Mind your fingers while working with heavy loads.
CAUTION: High pressure lamp may explode if improperly handled.
General safety instructions
•Before operating this equipment please read this manual thoroughly and retain it for future reference.
•Installation and preliminary adjustments should be performed by qualified Barco personnel or by
authorized Barco service dealers.
•All warnings on the projector and in the documentation manuals should be adhered to.
•All instructions for operating and use of this equipment must be followed precisely.
•All local installation codes should be adhered to.
Notice on safety
This equipment is built in accordance with the requirements of the applicable international safety standards.
These safety standards impose important requirements on the use of safety critical components, materials
and insulation, in order to protect the user or operator against risk of electric shock and energy hazard and
having access to live parts. Safety standards also impose limits to the internal and external temperature rises,
radiation levels, mechanical stability and strength, enclosure construction and protection against the risk of
fire. Simulated single fault condition testing ensures the safety of the equipment to the user even when the
equipment's normal operation fails.
Notice on optical radiation
Thermal retinal eye injury is possible when exposed within the Hazard Distance (HD). The HD is defined from
the projection lens surface towards the position of the projected beam where the irradiance equals the
maximum permissible exposure as described in the chapter “Hazard Distance”.
WARNING: No direct exposure to the beam within the hazard distance shall be permitted, RG3
(Risk Group 3) IEC EN 62471-5:2015
CAUTION: Use of controls or adjustments or performance of procedures other than those specified
herein may result in hazardous radiation exposure.
Light beam related safety labels
ATTENTION! NE PAS REGARDER LE FAISCEAU
EVITER TOUTE EXPOSITION DIRECTE DES YEUX AU FAISCEAU
RG3 IEC EN 62471-5:2015
DISTANCE DE SECURITE: CONSULTER LE MANUEL DE SECURITE
WARNING! DO NOT LOOK INTO THE BEAM
NO DIRECT EYE EXPOSURE TO THE BEAM IS PERMITTED
RG3 IEC EN 62471-5:2015
HAZARD DISTANCE: CONSULT SAFETY MANUAL
RG3 IEC EN 62471-5:2015RG3 IEC EN 62471-5:2015
Image 1–1
Safety

9R5905823 /05 HDQ 4K35
WARNING! DO NOT LOOK INTO THE BEAM NO DIRECT EYE EXPOSURE TO THE BEAM IS PERMITTED
RG3 IEC EN 62471-5:2015 HAZARD DISTANCE: CONSULT SAFETY MANUAL
ATTENTION! NE PAS REGARDER LE FAISCEAU EVITER TOUTE EXPOSITION DIRECTE DES YEUX AU
FAISCEAU RG3 IEC EN 62471-5:2015 DISTANCE DE SECURITE: CONSULTER LE MANUEL DE
SECURITE
警告！勿观看光束 眼睛勿直接接触可允许暴露的光束 RG3 IEC EN 62471-5:2015 危害距离：请参考安全手册
警告！請勿注視光源。 禁止眼睛曝露在光源照射範圍 RG3 IEC EN 62471-5:2015 危害距離：請參考安全手
冊。
Hazard RG3: optical radiation warning symbol
Hazard RG3: not for household use symbol
Users definition
Throughout this manual, the term SERVICE PERSONNEL refers to persons having appropriate technical
training and experience necessary to be knowledgeable of potential hazards to which they are exposed
(including, but not limited to HIGH VOLTAGE ELECTRIC and ELECTRONIC CIRCUITRY and HIGH
BRIGHTNESS PROJECTORS) in performing a task, and of measures to minimize the potential risk to
themselves or other persons. The term USER and OPERATOR refers to any person other than SERVICE
PERSONNEL, AUTHORIZED to operate professional projection systems.
A Barco HDQ 4K35 is intended "FOR PROFESSIONAL USE ONLY" by AUTHORIZED PERSONNEL familiar
with potential hazards associated with high voltage, high intensity light beams, ultraviolet exposure and high
temperatures generated by the lamp and associated circuits. Only qualified SERVICE PERSONNEL,
knowledgeable of such risks, are allowed to perform service functions inside the product enclosure.
1.2 Important safety instructions
To prevent the risk of electrical shock
•This projector should be operated from an AC power source. Ensure that the mains voltage and capacity
matches the projector electrical ratings.
•Installation according to the local electrical code and regulations by qualified technical personnel only.
•This product is equipped with a five-terminal barrier strip for the connection of a 3W+N+PE or 3W+PE
three phase power system. If you are unable to install the AC Requirements, contact your electrician. Do
not defeat the purpose of the grounding.
•The cross-sectional area of the conductors in the power supply cord shall not be less than 4 mm2or AWG
10.
The cross-sectional area of the UPS inlet cord and external fan power cord shall be not less than 0.75 mm²
or AWG 18.
•The electronics of the projector (UPS INLET) must be powered either from a suitable UPS unit or from the
power outlet socket (UPS OUTLET) provided on the projector. An adapted short power cord (2-pole 3-wire
grounding) is added to the projector accessories to loop through the power from UPS OUTLET to UPS
INLET.
•The provided power output socket (UPS OUTLET) on the projector may only be used to provide power to
the projector electronics. Never connect other devices to this power output socket.
•The building installation has to be provided with a circuit breaker of max. 40A to protect the complete unit.
•A readily accessible disconnect device must be incorporated externally to the equipment for removal of the
power to the projector mains terminals.
•Disconnect the power to the projector mains terminals and unplug the power cord at UPS INLET for
removal of all power from the projector.
•Warning: High leakage current. Earth connection essential before connecting supply.
Safety

R5905823 /05 HDQ 4K3510
•Do not allow anything to rest on the power cord. Do not locate this projector where persons will walk on the
cord.
•Do not operate the projector with a damaged cord or if the projector has been dropped or damaged - until it
has been examined and approved for operation by a qualified service technician.
•Position the cord so that it will not be tripped over, pulled, or contact hot surfaces.
•If an extension cord is necessary, a cord with a current rating at least equal to that of the projector should
be used. A cord rated for less amperage than the projector may overheat.
•Never push objects of any kind into this projector through cabinet slots as they may touch dangerous
voltage points or short circuit parts that could result in a risk of fire or electrical shock.
•Do not expose this projector to rain or moisture.
•Do not immerse or expose this projector in water or other liquids.
•Do not spill liquid of any kind on this projector.
•Should any liquid or solid object fall into the cabinet, unplug the set and have it checked by qualified
service personnel before resuming operations.
•Do not disassemble this projector, always take it to a trained service person when service or repair work is
required.
•Do not use an accessory attachment which is not recommended by the manufacturer.
•Lightning - For added protection for this video product during a lightning storm, or when it is left unattended
and unused for long periods of time, remove all power from the projector. This will prevent damage to the
projector due to lightning and AC power-line surges.
To prevent personal injury
•Isolate electrically before replacing the lamp or lamp house. Caution: Hot lamp (house).
•Caution: High pressure lamp may explode if improperly handled. Refer servicing to qualified service
personnel.
•To prevent injury and physical damage, always read this manual and all labels on the system before
inserting the lamp casing, powering the projector or adjusting the projector.
•It is forbidden to lift up the projector with manpower, use a hoisting tool instead. Do not underestimate the
weight of the projector. The projector weights ±210 kg (±462 lb.).
•To prevent injury, ensure that the lens, exhausting system and all cover plates are correctly installed. See
installation instructions.
•Ensure safe fixation of the projector lens. The lens fixation mechanism must be installed. See installation
instructions.
•Warning: high intensity light beam. NEVER look into the lens ! High luminance could result in damage to
the eye.
•Warning: extremely high brightness lamps: This projector uses extremely high brightness lamps. Never
attempt to look directly into the lens or at the lamp. If the projection distance is less than 6 meter, any
person needs to be at least 4 meters away from the projected image. Avoid close range reflection of the
projected image on any reflecting surface (such as glass, metal, …) . When operating the projector, we
strongly recommend wearing suitable safety glasses.
•Before attempting to remove any of the projector's covers, disconnect the power to the projector mains
terminals and unplug the power cord at UPS INLET for removal of all power from the projector.
•The projector may not be powered when the exhaust box on top of the projector is removed. Before
attempting to remove the exhaust box, disconnect the power to the projector mains terminals and unplug
the power cord at UPS INLET for removal of all power from the projector.
•When required to remove all power from the projector, to access parts inside, always disconnect the power
to the projector mains terminals and unplug the power cord at UPS INLET.
•Do not place this equipment on an unstable cart, stand, or table. The product may fall, causing serious
damage to it and possible injury to the user.
•Never stack more than three (3) HDQ projectors in a standing configuration (table mount) and never stack
more than two (2) HDQ projectors in a hanging configuration (ceiling mount).
•When using the projector in a hanging configuration (ceiling mount), always mount 2 safety cables on the
projector frame. See installation instructions for the correct use of these cables.
•Always check the safety cables for visible damage before operating the projector. If the safety cables are
damaged, they must be replaced with new ones.
•It is hazardous to operate without lens or shield. Lenses, shields or ultra violet screens shall be changed if
they have become visibly damaged to such an extent that their effectiveness is impaired. For example by
cracks or deep scratches.
Safety
