EVS6000
PMC graphics accelerator
The EVS6000 is the next generation in Barco’s family of rugged
embedded graphics accelerators for 2D and 3D applications.
The PMC form factor graphics accelerator is based on 3Dlabs’
P9 Visual Processing Unit (VPU) and provides high-performance
graphics rendering and optimum video display functionality.
Low level programming access to the processor allows easy
optimization and fine tuning to fit customer specific
applications. With its broad video I/O capability, EVS6000 can
perform in a wide variety of applications, including vehicle
embedded computers, embedded training and simulation
systems and cockpit displays.
Barco’s EVS6000 is a PCI Mezzanine Card (PMC), available in a
standard convection-cooled format or optional conduction
cooled format for use in harsh environments. The EVS6000
mounts on industry standard VME or CPCI single board
computers running VxWorks, Unix or Windows environments.
Features
•3Dlabs’ P9 Visual Processing Unit Technology
•Fully programmable through low level access to P9
•High-speed 128-bit memory interface
•128MB DDR SDRAM frame and texture buffer
•Rich rendering functionality in silicon
•Graphics outputs:
-RGB analog output resolution up to 2048x1536 @ 85Hz
-DVI 1.0 digital output resolution up to 1600x1200
@ 60Hz
-LVDS digital output resolution up to 1024x768, open
LDI V0.95
-PAL/NTSC/RS-170A color video output
• Dual video input with graphics overlay:
-PAL/NTSC/RS-170A/STANAG 3350 color video input
- RGB, up to 800x600
-Graphics anti-aliasing to video
•Onboard PS/2 keyboard/mouse interface
•Conduction-cooled PMC version available
•Dual-head graphics output for RGB analog and DVI
Parameter Conditions Air-cooled PMC Conduction-cooled CCPMC
Min/Max Operating 0 °C to 60 °C -40 °C to 75 °C
Temperature with 140 linear fpm air thermal interface
Storage -40 °C to 100 °C -55 °C to 100 °C
Altitude Operating 20,000 feet 50,000 feet for 2 hours
Humidity Operating 5% to 90% RH 5% to 95% RH including
non-condensing condensing for 240 hours
Shock Operating 40g half-sine wave for 40g half-sine wave for
11 msec, all three axes 11 msec, all three axes
Vibration Operating 5g for 1 hour/axis, 5g for 1 hour/axis,
all three axes all three axes
EMI Operating MIL-STD-461E MIL-STD-461E
FCC Class A FCC Class A
CE compliant CE compliant
www.barcodefense.com
Technical specifications
• Form factor:IEEE P1386.1 PMC or VITA 20-200X CCPMC
• Weight: 160g
• Power consumption: 10 W
• Power variation: 3V ± 5%, 5V ± 5%
• Operating systems: MS Windows®, VxWorks, UNIX®
• 3D: OpenGL 1.3 with shader extensions
DirectX 8.0 with vertex shader 1.1 and pixel shader 1.2
Ref. D-S-EVS-0106
Technical specifications are subject to change without prior notice
Barco
Pres. Kennedypark 35 - B-8500 Kortrijk, Belgium
Phone: +32 56 233 412 - Fax: +32 56 233 013
Email: sales.defense@barco.com
BarcoView-Texen
7 Rue Roger Camboulives - BP 1226 - F-31037 Toulouse, France
Phone: +33 5 34 63 71 74 - Fax: +33 5 34 63 70 20
BarcoView, LLC
3059 Premiere Parkway - Duluth, Georgia, 30097-4905, USA
Phone: +1 678 475 8000 - Fax: +1 678 475 8100
Email: sales.barcoview-a@barco.com
Board scheme
6
Si gma
ma
In search of continuous improvement
64kB serial EPROM
128MB DDR SDRAM
Visual
processing
unit
Video in
Video out head 1
P11/P12
Video out head 2
Part of
P14
Part of
P14
J4
J1
Front panel connectors
PMC connectors
