Bartec Agile S Series Installation guide

BARTECGmbH
Max-Eyth-Straße 16 Fon: [phone] Support: [email protected]om
97980 Bad Mergentheim Fax: [phone] Download: http://automation.bartec.de
GERMANY Internet: www.bartec.com
FAQ - Frequently Asked Questions
10.1" Industry Tablet PC
PXE boot on Agile S and Agile S NI
series
 Required hardware
 BIOS setup
Relevant for
 Agile S
 Agile S NI
Status: November 2020
Reservation: Technical data subject to change without notice. Changes, errors and
misprints may not be used as a basis for any claim for damages.

Table of content Agile S and Agile S NI series
FAQ: PXE boot
1/9 Subject to technical changes.
09/2020
Subject to technical changes.
10/2020
1.Information of this FAQ........................................................................................................................2
1.1Reference documents......................................................................................................2
2.About PXE .............................................................................................................................................4
3.Notes to PXE ......................................................................................................................................... 4
4.Required software and hardware ........................................................................................................4
4.1Required software............................................................................................................4
4.2Required hardware...........................................................................................................5
5.PXE – BIOS setup .................................................................................................................................6

Agile S and Agile S NI series
FAQ: PXE boot FAQ
Subject to technical changes.
10/2020
2/9
1. Information of this FAQ
Read carefully before commissioning the device.
The FAQ is an additional description to the available user manual and part of the device.
The FAQ is directed at all persons who are entrusted with handling the device.
Knowledge of the safety instructions and warnings in this FAQ and strict compliance with them
is essential for safe handling.
‒ Carefully read the FAQ and especially the safety instructions before using the device.
‒
Make the FAQ accessible to all people who are entrusted with handling the device.
Warnings are used in this User Manual to warn of the risks of damage to property and personal
injuries.
1.1 Reference documents
All documents are available online from the following websites:
‒
BARTEC: www.bartec.com or http://automation.bartec.de
Document BARTEC Explanation
Quick Start Guide of:
 Agile S
 Agile S NI
It contains:
 Guidelines on commissioning and the safe use of
hand-held scanners (including installation, safety
information related to explosion protection and
information regarding programming)
Symbol Explanation
Important advice and information for the effective, efficient and environmentally
sound use of the product.
Condition that must be met before the subsequent actions can be performed.
Individual steps you must take.
1., 2., … Various steps to be performed in the order specified.
Indication of the results of a step or of several steps for monitoring success.

FAQ Agile S and Agile S NI series
FAQ: PXE boot
3/9 Subject to technical changes.
09/2020
Subject to technical changes.
10/2020
Document BARTEC Explanation
User Manual of:
 Agile S
 Agile S NI
It contains:
 All essential information for the user to make full use
of the device. This manual includes a description of
the system functions and capabilities, contingencies
and modes of operation, and step-by-step
procedures for system access and use.
 Guidelines on commissioning and the safe use of
hand-held scanners (including installation, safety
information related to explosion protection and
information regarding programming)

Agile S and Agile S NI series
FAQ: PXE boot FAQ
Subject to technical changes.
10/2020 4/9
2. About PXE
PXE = Preboot Execution Environment
The Agile S and Agile S NI series support the PXE boot mode.
The following instruction provides information about required equipment and BIOS setup.
3. Notes to PXE
First, check that your PXE server supports UEFI or LEGACY or both.
This information is required for correct setup.
The settings on Agile S and Agile S NI series and your PXE server must be identical that PXE boot can work
correct.
4. Required software and hardware
Agile S and Agile S NI series only support Ethernet and must use one of the following accessories to setup
and proceed PXE.
4.1 Required software
We recommend to use the latest available BIOS version for this devices.
The latest version is listed on BARTEC support & Download page.
https://automation.bartec.de/tabletpcE.htm
Select your product and go to section Driver. There you will find a Note what BIOS version is currently
available.
If you have an older version you can use the contact information on same page to request the latest BIOS
version.

FAQ Agile S and Agile S NI series
FAQ: PXE boot
5/9
Subject to technical changes.
09/2020
Subject to technical changes.
10/2020
4.2 Required hardware
Docking station
Type 03-9914-0022
SAP 407990
Compatible with:
 Agile X series
 Agile S series (only with latest hardware version)
 Agile X IS series
Docking station
Type 03-9915-0017
SAP 374918
Note: only supported with BIOS version v1.34 or later.
Compatible with:
 Agile X series
 Agile S series (only with latest hardware version)

Agile S and Agile S NI series
FAQ: PXE boot FAQ
Subject to technical changes.
10/2020 6/9
5. PXE – BIOS setup
1. Connect external keyboard to the Agile X IS via docking station.
2. Start or restart the device and enter BIOS.
Press “DEL”/”ENTF” key in start screen with BARTEC logo.
3. Check that BIOS version is v1.29 or later.
(picture shows example for BIOS version v1.29)
4. Go to “Boot” and select “Network Stack”.
 Set “Network Stack” to “Enable”
 Default setting is Default

FAQ Agile S and Agile S NI series
FAQ: PXE boot
7/9
Subject to technical changes.
09/2020
Subject to technical changes.
10/2020
Change the boot capability to UEFI to “Ipv4/Ipv6” that support both network protocols.
5. Go to “Exit”.
Select “Save Changes and Exit” or press “F10” key to save and exit BIOS.
6. Device automatically perform restart and auto connects media server.
7. If settings are not correct and matching with server side then you will see one of the following
screens.
In this case please check your server settings.

Agile S and Agile S NI series
FAQ: PXE boot FAQ
Subject to technical changes.
10/2020
8/9
8. Press “ESC” key to go into the boot manager.
If you have more LAN available then you can choose the correct LAN for PXE boot.

FAQ Agile S and Agile S NI series
FAQ: PXE boot
9/9 Subject to technical changes.
09/2020
Subject to technical changes.
10/2020
9. Select your LAN and press “Enter” to confirm your selection.
Or press “ESC” key to leave the menue.
