Bartec Agile X General instructions

B1-A234-7N0003 Rev.A– Version: 22 May 2019
Update Guide Create a Bootable Installation USB Flash Drive
for Agile X and Agile X IS
EN GmbH
Max-Eyth-Straße 16
97980 Bad Mergentheim
GERMANY
Phone: [phone]
Fax: [phone] [email protected] www.bartec.de Disclaimer We reserve the right to make technical changes. Changes, errors and misprints shall not justify
any claim for damages. 1/4
Introduction
This guide will describe how to create a bootable USB Flash
Drive to update the Operating System of your BARTEC
tablets.
Notes for installations
(1) Only install Operating Systems which are provided from
BARTEC. Installing an Operating System that is not
designed for a BARTEC device may not work correctly
with them.
(2) Using the Format and Bootlce utility will delete all data
currently on the USB flash drive.
(3) Make sure that PC, Notebook or Tablet (referred to in
the following as the “computer”) is running on AC Power
during the preparation process. Do not unplug the AC
Adapter, or any other connected external devices during
the process. Do not restart or turn off the computer
during the process as it may cause permanent damage
to the file system structure of the USB Flash Drive.
Requirements
 Computer with a Windows 7/8/10 operating system
 USB flash drive (16GB or more)
 BootIce utility
Format USB flash drive
 Insert the USB-Sticks your Computer.
 Start Windows Explorer and select the USB Flash
Drive
 Open the drop-down menu with right mouse click on
the USB-Stick
 Select the “Format“ option in the menu
 A new “Format” window with format options will appear.
Choose following:
NTFS “File system”
type RDVD for the “Volume label”
Activate check box for Quick format
 Press “Start” button to begin the process

B1-A234-7N0003 Rev.A– Version: 22 May 2019
Update Guide Create a Bootable Installation USB Flash Drive
for Agile X and Agile X IS
EN GmbH
Max-Eyth-Straße 16
97980 Bad Mergentheim
GERMANY
Phone: [phone]
Fax: [phone] [email protected] www.bartec.de Disclaimer We reserve the right to make technical changes. Changes, errors and misprints shall not justify
any claim for damages. 2/4
 Press “Ok” button in the next message to continue the
process
 When the formatting process is complete, the message
"Formatting was successful" (Format Complete)
appears.
 Press the “Ok” button to close this message. The
Format partition window closes automatically.
Creating a bootable USB flash drive
 Insert an USB flash drive into a running computer
 Start the 32-bit or 64-bit BootIce’s version depending on
the system you are running
 Make sure that the USB flash drive is selected as the
destination in the “Destination Disk” area. If not, select
the right USB flash drive from the drop-down list
 Press “Activate” button to mark the partition as active

B1-A234-7N0003 Rev.A– Version: 22 May 2019
Update Guide Create a Bootable Installation USB Flash Drive
for Agile X and Agile X IS
EN GmbH
Max-Eyth-Straße 16
97980 Bad Mergentheim
GERMANY
Phone: [phone]
Fax: [phone] [email protected] www.bartec.de Disclaimer We reserve the right to make technical changes. Changes, errors and misprints shall not justify
any claim for damages. 3/4
 A message “Successfully activated this partition” will
appear after completing the process
 Press “Ok” button to close this message
 Press “Close” button to return to the main menu
 Press “Process MBR” button
 Make sure that the “Windows NT 5.x / 6.x MBR” option
is selected. If not, choose this option manually
 Press “Install / Config” button
 The new “Choose MBR” window will appear
 Press “Windows NT 6.x MBR” button to begin the
process

B1-A234-7N0003 Rev.A– Version: 22 May 2019
Update Guide Create a Bootable Installation USB Flash Drive
for Agile X and Agile X IS
EN GmbH
Max-Eyth-Straße 16
97980 Bad Mergentheim
GERMANY
Phone: [phone]
Fax: [phone] [email protected] www.bartec.de Disclaimer We reserve the right to make technical changes. Changes, errors and misprints shall not justify
any claim for damages. 4/4
 A message “Successfully changed the MBR of this disk”
will appear after completingthe process
 Press “Ok” button to close this message
 Press “Close” button to close the “Master Boot Record”
window
 Press “Exit” button in the main menu to close the
application
Copying installation files
 Save all folders and files from the custom image to the
root of the USB flash drive
Example picture of how a boat stick looks like when it is finished.
