Bartscher KV1 User manual

KV1 Comfort
190031

Bartscher GmbH
Franz-Kleine-Str. 28
D-33154 Salzkotten
Germany
Phone: [phone]
Fax: [phone]
Technical Support Hotline: [phone]
www.bartscher.com
Version: 2.0
Date of preparation: 2020-05-14
EN

190031 1 / 44
Original instruction manual
1Safety............................................................................................................2
1.1 Explanation of Signal Words....................................................................2
1.2 Safety instructions....................................................................................3
1.3 Intended Use ...........................................................................................6
1.4 Unintended Use.......................................................................................6
2General information.......................................................................................6
2.1 Liability and Warranty ..............................................................................6
2.2 Copyright Protection ................................................................................7
2.3 Declaration of Conformity ........................................................................7
3Transport, Packaging and Storage................................................................8
3.1 Delivery Check.........................................................................................8
3.2 Packaging................................................................................................8
3.3 Storage....................................................................................................8
4Technical Data...............................................................................................9
4.1 Technical Specifications ..........................................................................9
4.2 Functions of the Appliance.....................................................................11
4.3 List of Components of the Appliance .....................................................12
5Installation and operation ............................................................................13
5.1 Installation..............................................................................................13
5.2 Operation...............................................................................................16
6Cleaning and Descaling...............................................................................28
6.1 Safety Instructions for Cleaning.............................................................28
6.2 Cleaning.................................................................................................28
6.3 Descaling...............................................................................................36
7Possible Malfunctions..................................................................................41
8Disposal....................................................................................................... 42

Safety
2 / 44 190031
EN
Diese Bedienungsa nleitung beschreibt di eI nstallation, Bedienu ngu nd Wartung des G erätsu ndg ilt als wichtige Infor mationsquelle und N achschlagewer k.Die Ke nntnis aller enthaltene nSic herheitshin weise und Handlungs anweisungen schaf ft dieV oraussetzung f ürd as sichere und sachger echte Arbeiten mit d emG erät.D arüber hin aus müssen die für den Eins atzbereich des Geräts gelt enden örtlichen Unfall verhütungsvorsc hriften und allgemeine n Sicherheitsbesti mmungen eing ehalten werden. Diese Bedi enungsanleitung is t Bestandteil des Prod ukts und muss in unmitt elbarerN ähe des Geräts für das In¬stall ations-, Bedienungs- , Wartungs- und Reinigu ngspersonal jederzeit z ugänglich auf¬b ewahrt werden. Wenn das Ger ät an eine dritte Person
weitergegeben wird , muss die Bedienungsa nleitung mit ausgehä ndigt werden.
Read this instruction manual before using and keep it available
at all times!
This instruction manual contains information about installation, operation and
maintenance of the appliance and constitutes an important source of information
and reference guide. The knowledge of all operational and safety instructions
included in this manual is a prerequisite for safe and proper handling of the
appliance. Additionally, accident prevention, occupational health and safety, and
legal regulations in force in the area the appliance is used apply.
Before you start using the appliance, especially before turning it on, read this
instruction manual in order to avoid personal injuries and property damages.
Improper use may cause damage.
This instruction manual forms and integral part of the product and must be stored in
an immediate vicinity of the appliance and be available at all times. The instruction
manual should be transferred together with the appliance.
1 Safety
This appliance has been manufactured in accordance with technical standards
currently in force. However, the appliance may be a source of hazards if used
improperly or contrary to its intended purpose. All persons using the appliance must
consider information included in this instruction manual and observe safety
instructions.
1.1 Explanation of Signal Words
Important safety instructions and warning information are indicated in this
instruction manual with appropriate signal words. You must strictly follow the
instructions, to prevent accidents, personal injuries and property damages.
DANGER!
The signal word DANGER warns against hazards that lead to severe
injuries or death if the hazards are not avoided.

Safety
190031 3 / 44
EN
WARNING!
The signal word WARNING warns against hazards that may lead to
moderate or severe injuries or death if the hazards are not avoided.
CAUTION!
The signal word CAUTION warns against hazards that may lead to
light or moderate injuries if the hazards are not avoided.
,di e
IMPORTANT!
The signal word IMPORTANT indicates possible property damages,
which may occur if safety instructions are not observed.
NOTE!
The symbol NOTE indicates subsequent information and guidelines
for the user on usage of the appliance.
1.2 Safety instructions
Electrical Current
•Too high a mains voltage or incorrect installation may cause electric shock.
•The appliance may be connected only if data on the rating plate correspond with
the mains voltage.
•To avoid short-circuit, the appliance should be kept dry.
•If there are malfunctions during operation, disconnect the appliance from the
power supply.
•Do not touch the appliance’s plug with wet hands.
•Never take hold of the appliance if it has fallen into water. Immediately
disconnect the appliance from the power supply.
•Any repairs or housing opening may be carried out by professionals and
relevant workshops only.
•Do not transport the appliance, holding it by the power cord.
•Do not allow the power cord to come into contact with heat sources or sharp
edges.
•Do not bend, pinch nor knot the power cord.

Safety
4 / 44 190031
EN
•Always completely unwind the power cord.
•Never place the appliance or other objects on the power cord.
•Always take hold of the plug to disconnect the appliance from the power supply.
Flammable Materials
•Never subject the appliance to contact with high temperature sources, e.g.:
oven, furnace, open flame, heat generating devices, etc.
•To avoid fire hazard, clean the appliance regularly.
•Do not cover the appliance with, e.g., aluminium foil or cloths.
•Use the appliance only with materials designated to this end and with correct
temperature settings. Materials, groceries and left-overs remaining in the
appliance may catch fire.
•Never use the appliance near flammable or inflammable materials, e.g.: petrol,
spirit, alcohol, etc. High temperature triggers evaporation of these materials,
and, as a result of contact with sources of ignition, an explosion may occur.
•In case of fire, disconnect the appliance from the power supply before
attempting suitable fire-extinguishing actions.
•Never attempt to extinguish fire with water if the appliance is connected to the
power supply. Following extinction of fire, ensure sufficient fresh air inflow.
Hot Surfaces
•Surfaces of the appliance become hot during operation. Burning hazard! High
temperature remains for some time after switching the appliance off.
•Do not touch any hot surfaces of the appliance. Use the provided handling
elements and holders.
•You may transport and clean the appliance after it cools down entirely.
•It is prohibited to sprinkle hot surfaces with cold water or flammable liquids.

Safety
190031 5 / 44
EN
Health hazard due to germs!
•The water tank must be regularly emptied and disinfected to eliminate the
possibility of accumulation of harmful and dangerous germs.
Supervised Usage only
•Only supervised appliance may be used.
•Always remain in an immediate vicinity of the appliance.
Operating Personnel
•The appliance may only be operated by qualified personnel and trained
specialist personnel.
•This appliance may not be operated by persons (including children) with limited
physical, sensory or mental capabilities, nor by persons with limited experience
and/or limited knowledge.
•Children should be supervised to ensure that they are not playing with or
switching on the appliance.
Improper use
•Unintended or prohibited use may cause damage to the appliance.
•The appliance may only be used in a technically flawless condition, providing for
safe use.
•The appliance may only be used with connections in a technically flawless
condition, providing for safe use.
•The appliance may only be used clean.
•Use only original spare parts. Never attempt to repair the appliance on your
own.
•Do not attempt to modify nor alter the appliance.

General information
6 / 44 190031
EN
1.3 Intended Use
As described below, every use of the appliance for a purpose differing and/or
diverging from its intended standard use, is prohibited and considered to be an
unintended use.
The following is an intended use:
–Preparation of various types of coffee beverages, for example: coffee,
cappuccino, espresso, etc.
1.4 Unintended Use
An unintended use may lead to personal injuries or property damages caused by
hazardous voltage, fire or high temperature. The appliance may only be used to
perform tasks described in this instruction manual.
2 General information
2.1 Liability and Warranty
All information and instructions in this instruction manual account for legal
regulations in force, current level of technical engineering knowledge as well as our
expertise and experience, developed over the years. If special models or additional
options are ordered, or state-of-the-art technical solutions were implemented, the
actual scope of delivery of the appliance may, in some circumstances, differ from
descriptions and numerous drawings in this instruction manual.
The manufacturer is not liable for any damages nor faults stemming from:
–failure to observe instructions,
–unintended use,
–technical alterations introduced by the user,
–usage of unapproved spare parts.
We reserve the right to introduce technical modifications to the product, intended for
improvement of the appliance and its performance.

General information
190031 7 / 44
EN
Our coffee makers are constructed with components that are subject to wear and
tear. As a rule, with correct maintenance of coffee makers, the following
components that are subject to wear and tear sustain dispensing of the following
amounts of beverages:
–pumps: 12.000 dispensing instances
–drain valve: 15.000 dispensing instances
–brewing unit, grinder and seals: 20.000 dispensing instances
Failures of these components that are subject to wear and tear after their reaching
reference dispensing amounts are not considered to be coffee maker flaw.
2.2 Copyright Protection
This instruction manual, and texts, drawings and images included in it, as well as its
other components are copyright protected. It is prohibited to reproduce this
instruction manual (including its excerpts), in any form and by any means, and to
use and/or transfer its content to third parties without manufacturer’s written
permission. Violation of the above results in obligation to pay compensation. We
reserve the right to claim further damages.
2.3 Declaration of Conformity
The appliance meets the currently applicable standards and guidelines of the
European Union. We confirm the above in the EC Declaration of Conformity. We
may provide relevant Declaration of Conformity upon request.

Transport, Packaging and Storage
8 / 44 190031
EN
3 Transport, Packaging and Storage
3.1 Delivery Check
Immediately upon reception, check the delivery for completeness and possible
shipping damage. In the case of visible transport damage refuse to accept the
appliance or accept it conditionally. Mark and note the scope of damage in shipping
documents/consignment list of the shipping company and lodge a complaint.
Concealed damage must be reported immediately upon its discovery, as
compensation claims may only be filed within applicable time limits.
If you find that parts or accessories missing, please contact our Customer Service
Department.
3.2 Packaging
Do not dispose of the appliance cardboard box. It may be used to store the
appliance when relocating or when shipping the appliance to our service point in the
case of any damages.
The packaging and its elements are made of recyclable materials. Particularly,
these are: plastic films and bags, cardboard box.
When disposing of the packaging, observe applicable domestic regulations.
Recyclable packaging materials should be recycled.
3.3 Storage
Leave the packaging closed until installation of the appliance; observe external
indications concerning method of placing and storage. Store the packaging in the
following conditions only:
–in closed rooms;
–in dry and dust-free surrounding;
–away from aggressive agents;
–in a location protected against sunlight;
–in a location protected against mechanical shocks.
In the case of extended storage (over three months), make sure you check the
condition of the packaging and the parts regularly. If needed, replace the packaging
with a new one.

Technical Data
190031 9 / 44
EN
4 Technical Data
4.1 Technical Specifications
Name:
Automatic coffee machine KV1
Comfort
Item No.:
190031
Material:
Plastic
Grinder material:
Steel
Number of brewing unit groups:
1
Water tank volume, in l:
6
Coffee container volume, in g:
1.000
Programs with the possibility of
individual settings:
23
Pump pressure, in bar:
19
Outlet, height regulation, from–to, in
mm:
110 - 165
Dregs container volume, no. of cups,
approx.:
35
Designed for cups/day:
80
No. of cups of 120 ml/h, max.:
40
Minimum brewing volume, in ml:
25
Power supply:
2,7 kW / 230 V / 50-60 Hz
Dimensions (W x D x H) in mm:
511 x 390 x 582
Weight in kg:
22,0
We reserve the right to implement technical modifications!

Technical Data
10 / 44 190031
EN
Version / Characteristics
•Fully automatic
•Control: touch
•Settable parameters: grinding coarseness with 5-level scale, coffee dosing,
amount of water, water temperature, amount of milk, video display
•Programs:
–23, pre-set, individual write-over possible
–Programming: password protected
•Operating system: Android
•Video display:
–individually savable via USB
–up to 10 videos may be saved
–during coffee preparation and during breaks
–1 video may be selected for all processes
•USB port
•Detachable water tank
•Display:
•programs, status, volume, maintenance messages, error messages,
volume
–Size: 7"
–Advertising recordings, individually programmable
•Automatic switch-off
•Grinder: conical burr grinder
•Pressure system: piston pressure
•Descaling signal
•Fill level indicator
•ON/OFF switch
•Hot water function
•Hot milk function
•Milk frother
•Cleaning program
•Dregs container is dishwasher safe
•Ground coffee option: no
•2 cups function
•Water supply: 3 options
–Water tank

Technical Data
190031 11 / 44
EN
–Fixed water connection ½"
–Water supply from external water tank
•Milk supply: external via a milk hose
•Other features:
–Cup counter (per program and total)
–Cleaning cycles memory
–Milk temperature settable in individual programs
–Possibility of concurrent preparation of coffee and milk frothing
–Base plate with a cut-out for automatic residue removal (in combination
with KV1 dregs container with discharge opening —available as an
option)
•The set includes:
–2 milk hoses, 50 cm;
–1 water supply hose, 150 cm;
–1 water supply hose, 200 cm
4.2 Functions of the Appliance
The appliance is designed for preparing various coffee beverages, for example:
coffee, espresso, cappuccino, or latte macchiato, with the use of coffee beans and
cold water, and it is ideal for cafés, cafeterias and offices.

Technical Data
12 / 44 190031
EN
4.3 List of Components of the Appliance

Installation and operation
190031 13 / 44
EN
List of Components
1. Coffee container
2. Coffee container cover
3. Grinder with selector wheel
4. Control panel
5. Brewing unit
6. Hot water outlet
7. Coffee outlet
8. Milk hose
9. Grate for placing small cups
10.Drip tray
11.Drip grate
12.Dregs container
13.Water tank fill level indicator
14.ON/OFF button
15.Water tank
16.Interface
17.Mains switch
18.Power cord socket
19.Water connection
5 Installation and operation
5.1 Installation
Unpacking / Positioning
•Unpack the appliance, remove all external and internal packaging elements and
shipment safeguards.
CAUTION!
Choking hazard!
Prevent children from accessing package materials, for instance: plastic
bags and EPS.
•If the appliance is covered with a protective film, remove it. Remove the film
slowly, so no glue residues are left. Remove any glue residues with the use of a
suitable solvent.
•Be careful not to damage the rating plate and warning labels fixed on the
appliance.
•Never place the appliance in humid or wet environment.
•Place the appliance in a way making the connections easily accessible, so that
they may be quickly disconnected if such a need arises.
•The appliance should be placed on surfaces that are:
–even, with sufficient bearing capacity, resistant to water, dry and resistant
to high temperatures;

Installation and operation
14 / 44 190031
EN
–sufficiently large, and thus enabling usage of the appliance with no
problems;
–easily accessible;
–well ventilated.
•Maintain sufficient clearance from table edges. The appliance might turn over
and fall down.
•Mind the sufficient clearance from the walls and other flammable objects or
objects that are prone to discolouration. This clearance must be at least 5 cm
from the back and both sides, and 15 cm from the top. Note the fire safety
provisions at the place of installation.
•When in operation, the appliance may not be installed in a cabinet.
Power supply connection
•Verify if technical data of the appliance (see rating plate) correspond with the
local electric power grid specification.
•Connect the appliance to a single, properly grounded mains socket with
protective contact. Do not connect the appliance to a multi-socket.
•The power cord should be laid in a way preventing anyone from threading on it
or tripping against it.
•Do not use the appliance with an external timer or remote control.
Water Supply
For the purpose of supplying water, the appliance comes with a factory-installed
water tank.
If needed, the appliance may be connected to water mains system or external water
tank (which is located at the same height as the appliance).
In order to utilise the connection, consider the following information:
–max. input water pressure is 3 bar
–min. input water pressure is 1 bar
Important Indication:
Starting with water hardness of 5° dH (German degrees), a water softening
device should be installed. We recommend the following products from
our range:
–Water filtering system for coffee makers, art. No. 109881
–Water softening device, WEH1350, art. No. 109878

Installation and operation
190031 15 / 44
EN
To supply the appliance from water mains system, perform the following steps:
Step 1: Water supply hose connection
1. Connect one end of the delivered water
supply hose (with 1/4" thread) to the water
connection stub at the back face of the
appliance, and the second end (with 1/2"
thread) with the water mains system
connection.
Step 2: Setting the water supply mode
2. In 'Machine setting' menu,
select 'Water supply mode'
option.

Installation and operation
16 / 44 190031
EN
3. Select the 'Tap water supply'
option.
Step 3: Open the water mains system tap
5.2 Operation
Important indications
•Fill the water tank solely with fresh potable water.
•Never fill the water tank with warm/hot water, milk nor any other liquid.
•Never fill the coffee container (ground coffee container) any instant coffee,
cocoa nor any other powder mixtures. The appliance might get damaged.
•Never fill the coffee container with specially prepared coffee beans (e.g. coated
with cocoa or sugar), as this might cause damage to the appliance.
•The coffee container may be filled only with roasted coffee beans. Rice, soy
beans, cocoa beans, nuts, sugar, spices, etc., are prohibited.
•Always store coffee beans in dry, shaded place. Humid beans may damage the
grinder.
•Do not keep coffee beans in the coffee container if the appliance is not to be
used for a longer period of time. Coffee beans may attract humidity and clog the
grinder.
Preparation of the appliance
1. Before use, clean the appliance, observing instructions in section 'Cleaning'.

Installation and operation
190031 17 / 44
EN
2. To safely start up the appliance, read the following indications carefully.
3. Fill the water tank with fresh drinking water.
4. Mind the filling level. It may not exceed the MAX marking.
5. Fill the coffee container with coffee beans.
Appliance Start-up
1. Plug the appliance into a suitable single socket.
2. Set the mains switch at the back of the appliance to 'I'.
3. Press the ON/OFF switch at the front face of the
appliance, to switch the appliance on.
With first use, the coffee machine performs an auto-test and cleaning. This helps
the appliance to achieve better working conditions. This process cannot be omitted.
WARNING! Risk of burns!
During the cleaning process, hot water flows from the coffee outlet onto
the drip tray.
Avoid contact with the outflowing hot water.

Installation and operation
18 / 44 190031
EN
Control Panel
1. Beverage selection icons
2. Setting button
3. Time button
4. Beverage short-cut access button
Press the setting button and hold for 3 seconds to go to the short-cut access
menu and introduce the necessary settings immediately.
By swiping the short-cut access button left or right, you may go to the next
beverage selection.
