Bartscher WEH1500 User manual

WEH1500
109901

Bartscher GmbH
Franz-Kleine-Str. 28
D-33154 Salzkotten
Germany
Phone: [phone]
Fax: [phone]
Service hotline: [phone]
www.bartscher.com
Version: 1.0
Date of preparation: 2023-12-01
EN
2

109901 1 / 30
Original instruction manual
1Safety............................................................................................................2
1.1 Explanation of Signal Words....................................................................2
1.2 Safety instructions....................................................................................3
1.3 Intended Use ...........................................................................................5
1.4 Unintended Use.......................................................................................5
2General information.......................................................................................6
2.1 Liability and Warranty ..............................................................................6
2.2 Copyright Protection ................................................................................6
2.3 Declaration of Conformity ........................................................................6
3Transport, Packaging and Storage................................................................7
3.1 Delivery Check.........................................................................................7
3.2 Packaging................................................................................................7
3.3 Storage....................................................................................................7
4Technical Data...............................................................................................8
4.1 Technical Specifications ..........................................................................8
4.2 List of Components of the Appliance .......................................................9
4.3 Functions of the Appliance.....................................................................10
5Installation and operation ............................................................................15
5.1 Installation..............................................................................................15
5.2 Electrical Connection.............................................................................20
5.3 Operation...............................................................................................20
5.4 Settings..................................................................................................23
6Cleaning and Maintenance..........................................................................28
7Possible Malfunctions..................................................................................28
8Disposal....................................................................................................... 30

Safety
2 / 30 109901
EN
Diese Bedienungsa nleitung beschreibt di eI nstallation, Bedienu ngu nd Wartung des Geräts u ndg ilt als wichtige Infor mationsquelle un dN achschlagewer k.Di e Kenntnis aller enthalt enenSic herheitshinw eiseu ndH andlungs anweisungen schaff t die Voraussetzu ngf ürd as sichere und sac hgerechte Arbeiten mit d emG erät.D arüber hin aus müssen die für den Einsatz bereich des Gerät sg eltenden örtlichen Un fallverhütungsvorsc hriften und allgemein en Sicherheitsb estimmungen eingehalt en werden. Diese Be dienungsanleitung is t Bestandteil des Prod ukts und muss in unmitt elbarerN ähe des Geräts für d as In¬stallations-, Bedienungs- , Wartungs- und Reinigu ngspersonal jederzeit z ugänglich auf¬b ewahrt werden. Wenn das Ger ät an eine dritte Person
weitergegeben wird , muss die Bedienungsa nleitung mit ausgehä ndigt werden.
Read this instruction manual before using and keep it available
at all times!
This instruction manual contains information about installation, operation and
maintenance of the appliance and constitutes an important source of information
and reference guide. The knowledge of all operational and safety instructions
included in this manual is a prerequisite for safe and proper handling of the
appliance. Additionally, accident prevention, occupational health and safety, and
legal regulations in force in the area the appliance is used apply.
Before you start using the appliance, especially before turning it on, read this
instruction manual in order to avoid personal injuries and property damages.
Improper use may cause damage.
This instruction manual forms and integral part of the product and must be stored in
an immediate vicinity of the appliance and be available at all times. The instruction
manual should be transferred together with the appliance.
1 Safety
This appliance has been manufactured in accordance with technical standards
currently in force. However, the appliance may be a source of hazards if used
improperly or contrary to its intended purpose. All persons using the appliance must
consider information included in this instruction manual and observe safety
instructions.
1.1 Explanation of Signal Words
Important safety instructions and warning information are indicated in this
instruction manual with appropriate signal words. You must strictly follow the
instructions, to prevent accidents, personal injuries and property damages.
DANGER!
The signal word DANGER warns against hazards that lead to severe
injuries or death if the hazards are not avoided.
WARNING!
The signal word WARNING warns against hazards that may lead to
moderate or severe injuries or death if the hazards are not avoided.

Safety
109901 3 / 30
EN
CAUTION!
The signal word CAUTION warns against hazards that may lead to
light or moderate injuries if the hazards are not avoided.
,di e
IMPORTANT!
The signal word IMPORTANT indicates possible property damages,
which may occur if safety instructions are not observed.
NOTE!
The symbol NOTE indicates subsequent information and guidelines
for the user on usage of the appliance.
1.2 Safety instructions
Electrical Current
•Too high a mains voltage or incorrect installation may cause electric shock.
•The appliance may be connected only if data on the rating plate correspond with
the mains voltage.
•To avoid short-circuit, the appliance should be kept dry.
•If there are malfunctions during operation, disconnect the appliance from the
power supply.
•Do not touch the appliance’s plug with wet hands.
•Never take hold of the appliance if it has fallen into water. Immediately
disconnect the appliance from the power supply.
•Any repairs or housing opening may be carried out by professionals and
relevant workshops only.
•Do not transport the appliance, holding it by the power cord.
•Do not allow the power cord to come into contact with heat sources or sharp
edges.
•Do not bend, pinch nor knot the power cord.
•Always completely unwind the power cord.
•Never place the appliance or other objects on the power cord.
•Always take hold of the plug to disconnect the appliance from the power supply.

Safety
4 / 30 109901
EN
•Check the power cord regularly for damage. Do not use the appliance if the
power cord is damaged. If this cable is damaged, it must be replaced by
customer service or a qualified electrician in order to avoid dangers.
Operating Personnel
•The appliance may only be operated by qualified personnel and trained
specialist personnel.
•This appliance may not be operated by persons (including children) with limited
physical, sensory or mental capabilities, nor by persons with limited experience
and/or limited knowledge.
•Children should be supervised to ensure that they are not playing with or
switching on the appliance.
Improper Use
•Unintended or prohibited use may cause damage to the appliance.
•The appliance may only be used when its technical condition is flawless and
allows for safe operation.
•The appliance may only be used when all connections are executed according
to rules of law in force.
•The appliance may only be used when it is clean.
•Use only original spare parts. Never attempt to repair the appliance on your own.
•Do not introduce any changes in the appliance nor modify it.

Safety
109901 5 / 30
EN
1.3 Intended Use
As described below, every use of the appliance for a purpose differing and/or
diverging from its intended standard use, is prohibited and considered to be an
unintended use.
The following is an intended use:
–Reduces limescale build-up in an appliance and on washed items by
reducing water hardness.
1.4 Unintended Use
An unintended use may lead to personal injuries or property damages caused by
hazardous voltage, fire or high temperature. The appliance may only be used to
perform tasks described in this instruction manual.

General information
6 / 30 109901
EN
2 General information
2.1 Liability and Warranty
All information and instructions in this instruction manual account for legal
regulations in force, current level of technical engineering knowledge as well as our
expertise and experience, developed over the years. If special models or additional
options are ordered, or state-of-the-art technical solutions were implemented, the
actual scope of delivery of the appliance may, in some circumstances, differ from
descriptions and numerous drawings in this instruction manual.
The manufacturer is not liable for any damages nor faults stemming from:
–failure to observe instructions,
–unintended use,
–technical alterations introduced by the user,
–usage of unapproved spare parts.
We reserve the right to introduce technical modifications to the product, intended for
improvement of the appliance and its performance.
2.2 Copyright Protection
This instruction manual, and texts, drawings and images included in it, as well as its
other components are copyright protected. It is prohibited to reproduce this
instruction manual (including its excerpts), in any form and by any means, and to
use and/or transfer its content to third parties without manufacturer’s written
permission. Violation of the above results in obligation to pay compensation. We
reserve the right to claim further damages.
2.3 Declaration of Conformity
The appliance meets the currently applicable standards and guidelines of the
European Union. We confirm the above in the EC Declaration of Conformity. We
may provide relevant Declaration of Conformity upon request.

Transport, Packaging and Storage
109901 7 / 30
EN
3 Transport, Packaging and Storage
3.1 Delivery Check
Immediately upon reception, check the delivery for completeness and possible
shipping damage. In the case of visible transport damage refuse to accept the
appliance or accept it conditionally. Mark and note the scope of damage in shipping
documents/consignment list of the shipping company and lodge a complaint.
Concealed damage must be reported immediately upon its discovery, as
compensation claims may only be filed within applicable time limits.
If you find that parts or accessories missing, please contact our Customer Service
Department.
3.2 Packaging
Do not dispose of the appliance cardboard box. It may be used to store the
appliance when relocating or when shipping the appliance to our service point in the
case of any damages.
The packaging and its elements are made of recyclable materials. Particularly,
these are: plastic films and bags, cardboard box.
When disposing of the packaging, observe applicable domestic regulations.
Recyclable packaging materials should be recycled.
3.3 Storage
Leave the packaging closed until installation of the appliance; observe external
indications concerning method of placing and storage. Store the packaging in the
following conditions only:
–in closed rooms;
–in dry and dust-free surrounding;
–away from aggressive agents;
–in a location protected against sunlight;
–in a location protected against mechanical shocks.
In the case of extended storage (over three months), make sure you check the
condition of the packaging and the parts regularly. If needed, replace the packaging
with a new one.

Technical Data
8 / 30 109901
EN
4 Technical Data
4.1 Technical Specifications
Name:
Water softening system
WEH1500
Art. No.:
109901
Material:
plastic
Output capacity:
1.500 litres/day at 10° dH (total
hardness)
Water connection:
3/4“
Water temperature at inlet, in °C:
1 - 30
Connection capacity, appliances:
1
Return value per cartridge:
0
Operating pressure:
2 - 6
Salt stock in brine tank, in kg:
20
Salt consumption, in kg / regeneration:
0,7
Regeneration duration, in min:
45
Dimensions (W x D x H), in mm:
238 x 465 x 478
Weight, in kg:
9,2
We reserve the right to implement technical modifications.
Version / Characteristics
•Designed for: industrial dishwashers
•Digital display
•Setting options:
–interval
–hour
–day of the week
–water hardness
–regeneration
•Regeneration: flow rate or period

Technical Data
109901 9 / 30
EN
4.2 List of Components of the Appliance
Fig. 1
1. Control valve with digital display
2. Filter cartridge
3. Brine tank cover
4. Brine tank
5. Housing
6. Connections

Technical Data
10 / 30 109901
EN
4.3 Functions of the Appliance
How the Appliance Works
Hard water contains a combination of calcium (Ca), magnesium (Mg) and iron (Fe).
Softening is used to remove positively charged ions using an ion exchange resin.
When the ion exchange resin loses its effectiveness, it is activated through a
regeneration process.
Regeneration
Regeneration is carried out by rinsing the sludge with a salt solution and flushing
the absorbed calcium and magnesium ions into the wastewater.
Regeneration is carried out automatically in an intelligent, logical way: based on the
water consumption of the previous 7 days, the system itself selects the day of
regeneration at the set time. During regeneration (60 min), unsoftened water is
available.
The regeneration process consists of 4 cycles:
1. Regenerating agent replenishment
2. Rinsing with the regenerating agent solution
3. Backwashing
4. Quick rinsing
Water Softening System Structure
The system is configured for 0.7 kg of regenerating agent per regeneration. The
amount of water softened between regenerations is calculated with the formula:
Z = 1350x10 / Y
Z—means the amount of softened water between regenerations,
Y—means the hardness of the tested water based on dH (German degrees of
hardness).
Example of calculation of the amount of softened water between regeneration
processes:
The tested water hardness is 15°dH.
The amount of water Z between regeneration processes is calculated as follows:
Z = 1350 x 10/15 = 900 litres.
With a water hardness of 15°dH, 900 litres of softened water will be obtained.

Technical Data
109901 11 / 30
EN
Water Hardness Performance Table (°)
Degree of hardness
Softened
water (L)
English
hardness
French
hardness
PPM
German
hardness
12,5
18,0
178,6
10
1500
13,8
19,8
196,5
11
1364
15,0
21,6
214,3
12
1250
16,3
23,4
232,2
13
1154
17,5
25,2
250,0
14
1071
18,8
27,0
267,9
15
1000
20,0
28,8
285,8
16
938
21,3
30,6
303,6
17
882
22,5
32,4
321,5
18
833
23,8
34,2
339,3
19
789
25,0
36,0
357,2
20
750
26,3
37,8
375,1
21
714
27,5
39,6
392,9
22
682
28,8
41,4
410,8
23
652
30,0
43,2
428,6
24
625
31,3
45,0
446,5
25
600
32,5
46,8
464,4
26
577
33,8
48,6
482,2
27
556
35,0
50,4
5001
28
536
36,3
52,2
517,9
29
517
37,5
54,0
535,8
30
500
38,8
55,8
553,7
31
484
40,0
57,6
571,5
32
469
41,3
59,4
589,4
33
455
42,5
61,2
607,2
34
441
43,8
63,0
625,1
35
429
45,0
64,8
643,0
36
417
46,3
66,6
660,8
37
405

Technical Data
12 / 30 109901
EN
47,5
68,4
678,7
38
395
48,8
70,2
696,5
39
385
50,0
72,0
714,4
40
375
Tab. 1
Standards, Rules and Regulations
•The water used to supply the appliance must be of drinking water quality and
conform to the requirements of the regulations for the use of water of the public
utility at a site.
•All parts in contact with the treated water must be made of waterproof material.
•Ensure that a soil drainage is installed at the water treatment site. The
purchaser is responsible for the drainage.
•The maximum temperature of the supplied water should not exceed 30°C.
•Do not remove the water softening system during use.
•Do not open the water softening system, otherwise the warranty will be voided.

Technical Data
109901 13 / 30
EN
Control Function
Control Valve
Before starting, set the current time and water hardness in degrees.
The valve is set by default to regenerate at 2:00 AM at 20 German degrees.
Salt Replenishment Reminder
The system automatically detects the salt level in the brine tank each time after
regeneration. If the salt level is below normal, the low salt sensor will relay this to
the intelligent control system, and a "SALT" alarm will be displayed in the screen.
The buzzer will sound daily from 7:30 PM to 10:30 PM to remind the user to
replenish the salt.
Salt should be replenished on time to avoid using unsoftened water. When the
display shows the "SALT" alarm, the salt in the brine tank can be used for 2 or 3
more regenerations.
Bypass
The bypass connection allows for convenient installation and maintenance. There
are three different types of states when the bypass handle is rotated.
Service position
Bypass position
Shut-off position
Inlet
Discharge
Inlet
Discharge
Inlet
Discharge
Fig. 2
DRY Brine Tank
The system fills the brine tank each time just a few hours before regeneration to
keep the brine tank largely dry, preventing salt from accumulating above the tank or
leaking out.
INTELLIGENT Control
•The water softening system is equipped with the latest intelligent control valve,
described below.

Technical Data
14 / 30 109901
EN
Upflow regeneration system. Unlike downflow systems, a water softening
system with the upflow system directs the water flow upward. Water flows from
the bottom of the brine tank in an upward swirling motion through the resin. The
upflow system is a high-efficiency system. Thanks to regeneration with the water
stream directed upward, the system can use 30% less salt.
Proportional regeneration. The system regenerates the used resin only
according to the water consumption condition. This saves salt and keeps the
resin fresh.
Holiday mode When the system is not going to be used for a long time, the
holiday mode can keep the resin fresh. Holiday mode can be activated by
pressing and holding the button in softening mode until HOLIDAY appears
in the display. To switch the holiday mode off, press the button until the
HOLIDAY message is no longer displayed.
•If the control valve does not detect water consumption greater than 6 LPM (litres
per minute) or 85 LPD (litres per day) in the next 4 days, the control valve will
initiate 100% regeneration at the set time of the 4th day, and then remain in
standby mode in the operating position.
•If the control valve does not detect water consumption greater than 6 LPM (litres
per minute) or 85 LPD (litres per day) in the next 4 days, the controller will only
perform a 5-minute backwash and quick rinse at the programmed time on the
2nd and 4th day, respectively.
•If the control valve detects water consumption greater than 6 LPM (litres per
minute) or 85 LPD (litres per day), the holiday mode is discontinued and the
control valve switches to normal mode based on previous conditions. The
amount of water consumed is added via the control valve to the records.

Installation and operation
109901 15 / 30
EN
5 Installation and operation
CAUTION!
Incorrect installation, positioning, operation, maintenance or misuse of
the appliance may lead to personal injury or property damage.
Positioning and installation, as well as repairs may be performed by
authorised technical service only and in compliance with the applicable
national law.
NOTE!
The manufacturer disclaims all liability and provides no warranty for
damages, which may be attributed to non-observance of regulations or
incorrect installation.
5.1 Installation
Information for Installer
•All installation and maintenance work on the water softening system must be
performed only by trained and authorized specialized personnel.
•Unpack the appliance and discard the entire packing material. Never remove the
rating plate or any warning signs from the appliance.
•Before installing the water softening system, the appliance working with it
(dishwasher) must be free of lime and gypsum deposits.
•Do not install the appliance in the vicinity of heat sources and open flames.
Protect the appliance from sunlight.
•Protect the appliance from mechanical damage.
•If the water pressure in the water supply line exceeds 6 bar, it is necessary to
install a pressure reducer to the appliance.
•Accessories for the water softening system in contact with water must be made
of material suitable for this purpose.
•All parts must be installed in accordance with the country's guidelines for the
installation of drinking water systems.
•The ambient temperature at the installation site must be at least 10°C.
•Protect the appliance from frost.

Installation and operation
16 / 30 109901
EN
•The installation site of the appliance must be protected from damage caused by
water (e.g., by an existing floor drain). The manufacturer is not responsible for
damage caused by water.
ATTENTION!
After storage and transportation at temperatures below 0°C, the appliance
must be kept in its open original packaging for at least 24 hours before it is
put into operation at the specified ambient temperature.
Preparation for Installation
The user must make the following preparations at the installation site
1. Water supply line with 3/4" connection and shut-off valve.
2. Water discharge line (sewer) with a maximum height of 100 mm,
DN50 connection.
3. Socket 230 V / 50 Hz, 16 A.
4. Floor drain in the installation room.
5. Mechanical fine filter must be installed upstream of the system.

Installation and operation
109901 17 / 30
EN
Installation Diagram
Fig. 3
1. Water supply line with 3/4"
connection and shut-off valve
2. Cold water supply
3. Mechanical cleaning filter
4. Electrical socket
5. Control valve
6. Brine tank
7. Overflow drain elbow
8. Flexible regeneration hose
9. Air gap
10.Sewage network
11.Floor drain
12.Softened water

Installation and operation
18 / 30 109901
EN
Water Softening System Installation
1. After preparation for installation, place the appliance in the designated room
according to the installation plan.
2. Connect all supply and drain lines. The appliance's connections are shown in
the following figure:
Fig. 4
–Connect the water supply line (2) and drain pipe (1) to the appliance.
–Connect the flexible sewage pipe (1/2") to the connection pipe (5) and to
the drain or sewage system.
ATTENTION!
The sewage pipe must be large enough to allow 5 l/m of rinse water to
drain. The drain pipe must be rigid enough not to break and lead to
blockages and overflowing of the brine tank, as well as to the malfunction
of the regeneration process.
–A mechanical fine filter should be installed in front of the water softening
system to protect the appliance from mechanical damage caused by
sediment from water pipes.
–Fill the brine tank of the water softening system with salt tablets.
–Then add 3 litres of water.
–Check all connections to the appliance and tighten them if necessary.
–Connect the water softening system to a single grounded outlet.
