Baumatic RUSTIC Series User manual

BOR610-BL/
IV/PP Built-in RUSTIC
Multifunction oven.

2
User Manual for your Baumatic
60 cm 9 Function multifunction oven
NOTE: This User Instruction Manual contains important
information, including safety & installation points, which will
enable you to get the most out of your appliance. Please keep it
in a safe place so that it is easily available for future reference; for
you or any person not familiar with the operation of the appliance.
JW 01/07/15

3
Contents
Environmental note 4
Important safety information 5 – 7
Specifications 8 – 10
Dimensions 8
Accessories 8
Electrical details 9
Coolingfan 9
Controlpanel 10
Before first use 10
Setting and using the oven clock/timer 11 - 12
Setting the time of day 11
Selecting manual operation mode 11
Setting the minute minder function (immediate start) 12
Setting the minute minder function (delay start) 12
Cancelling a timer function 12
Changing the time of day 12
Selecting a cooking function and temperature 13 - 16
Selecting an oven function 13-14
Thermostatcontrolknob 14
Oven operating light 14
Cooking guidelines 25
Warnings 15-16
Shelflevels 16
Cleaning and maintenance 17 - 21
Removableovenroofliner 18
Replacing the oven bulb 18
Removing the oven door for cleaning 19
Removing the inner door glass for cleaning 20
Removing the side racks 21
Installation 22 - 24
Electrical connection 22
Installing the oven into the kitchen cabinet 23
Positioning the appliance 23
Ventilation requirements 24
My appliance isn’t working correctly 25 - 26
Cooking tables 27 - 28

4
Environmental note
oThe packaging materials that Baumatic uses are environmentally
friendly and can be recycled.
oPlease discard all packaging material with due regard for the
environment.

5
IMPORTANT SAFETY INFORMATION
Your safety is of the utmost importance to Baumatic.
Please make sure that you read this instruction booklet
before attempting to install or use the appliance. If you
are unsure of any of the information contained in this
booklet, please contact the Baumatic Advice Line.
General Information
oThis appliance is designed for domestic household use and can be
built into a standard kitchen cabinet or housing unit.
oIMPORTANT: The adjacent furniture or housing and all materials
used in the installation must be able to withstand a minimum
temperature of 85°C above the ambient temperature of the room it
is located in, whilst in use.
oCertain types of vinyl or laminate kitchen furniture are particularly
prone to heat damage or discolouration at temperatures below the
guidelines given above.
oAny damage caused by the appliance being installed in
contravention of this temperature limit, or by placing adjacent
cabinet materials closer than 4mm to the appliance, will be the
liability of the owner.
oThe use of this appliance for any other purpose or in any other
environment without the express agreement of Baumatic will
invalidate any warranty or liability claim.
oYour new appliance is guaranteed against electrical or mechanical
defects, subject to certain exclusions that are noted in Baumatic’s
Conditions Of Guarantee. The foregoing does not affect your
statutory rights.
oRepairs may only be carried out by Baumatic service
engineers or their authorised service agent.
Warning and safety instructions
oThis appliance complies with all current European safety legislation.
Baumatic do wish to emphasise that this compliance does not
remove the fact that the appliance surfaces will become hot
during use and retain heat after operation.

6
oThis appliance is not intended for use by persons (including children)
with reduced physical, sensory or mental capabilities, or lack of
experience and knowledge, unless they have been given
supervision or instruction concerning use of the appliance by a
person responsible for their safety.
Child Safety
oBaumatic strongly recommend that babies and young children are
prevented from being near to the appliance and not allowed to
touch the appliance at any time.
oIf it is necessary for younger family members to be in the kitchen,
please ensure that they are kept under close supervision at all
times.
oChildren should be supervised to ensure that they do not play with
the appliance.
General Safety
oDo not place heavy objects on the oven door or lean on the oven
door when it is open, as this can cause damage to the oven door
hinges.
oDo not leave heated oil or fat unattended, as this is a fire risk.
oDo not place pans or baking trays directly on the base of the oven
cavity, or line it with aluminium foil.
oDo not allow electrical fittings or cables to come into contact with
areas on the appliance that get hot.
oDo not use the appliance to heat the room it is located in or to dry
clothing.
oDo not install the appliance next to curtains or soft furnishings.
oDo not attempt to lift or move cooking appliances by using the
oven door or handle, as this may cause damage to the appliance or
result in injury to the person lifting the appliance.

7
Cleaning
oCleaning of the oven should be carried out on a regular basis.
oGreat care should be taken whilst using this appliance and when
following the cleaning procedure.
oIMPORTANT: The appliance must be disconnected from the mains
before following the cleaning procedure.
Installation
This appliance must be correctly installed by a
suitably qualified person, strictly in accordance
with the manufacturer’s instructions.
oBaumatic declines any responsibility for injury or damage, to
person or property, as a result of improper use or
installation of this appliance.
oHeat, steam and moisture will be created during use of the
appliance, take care to avoid injury and ensure that the room is
adequately ventilated. If the appliance is going to be used for
prolonged periods of time, then additional ventilation may be
required.
oPlease consult with your qualified installer if you are in any doubt
about the amount of ventilation that you will require.
Declaration of conformity.
This appliance complies with the following European Directives:
-2006/95/EC regarding “low voltage”
-2004/108/EC regarding “electromagnetic disturbances”
-Regulation (EC) N° 1935/2004 regarding “materials in contact with
food”
oThe above directives comply with 93/68/EEC regarding CE marking.
oThe manufacturer declares that the oven is built using certified
materials and requires the appliance to be installed in accordance
with the standards currently in force. This appliance must be used
by a trained person for domestic purposes only.

8
Specifications
Product Dimensions
Height: 590 mm
Width: 595 mm
Depth: 550 mm
Aperture dimensions
Height: 580 mm
Width: 560 mm
Depth: 550 mm
Product specifications
o9 oven functions
oEnergy efficiency class: A
oGross oven capacity: 59 litres
oNet oven capacity: 50 litres
oOven light
oCooling fan
oThermostatically controlled grill
oDouble-glazed removable door
oRemovable inner door glass
Standard accessories
oEnamelled baking tray with handle
o2 x Safety shelves
oTrivet
oRemovable side racks
oRemovable roof liner
oDeep baking tray
oPizza stone

9
Electrical details
Rated Voltage: 220 - 240 Vac, 50 Hz
Supply Connection: 15A (double pole switched fused
outlet with 3mm contact gap)
Max Rated Inputs: 3.35 kW
Mains Supply Lead: 3 x 1.5mm²
Oven Light Bulb: 25 W/300°C screw type pygmy
Cooling fan
oA tangential cooling fan is fitted inside of these appliances, to
make the internal temperature of the oven stable and the
external surface temperature lower.
oAfter you have finished cooking and switched off the oven, the
cooling fan will continue to run for a period of time afterwards.
The length of time will depend on how long the oven has been
switched on for and at how high a temperature.
For future reference please record the following information which can
be found on the rating plate and the date of purchase which can be
found on your sales invoice. The rating plate for your oven can be
located by opening the oven door and looking on the right hand side of
the oven chassis.
Model Number ……………………………….
Serial Number ……………………………….
Date of Purchase ……………………………….

10
Control Panel
1) Oven function selector knob
2) Power indicator light
3) Oven clock / timer
4) Oven operating light
5) Thermostat control knob
6) Clock control knob
Before first use
oTo remove any residue from the oven that may have been left from
the manufacturing process, you should select the fan oven function
and set the thermostat to its maximum temperature setting.
oIt is perfectly normal for a smell to be produced during this process.
oYou should make sure that any windows in the room are left open
during this process.
oIt is advisable for you not to remain in the room whilst the burning-
off process is taking place.
oYou should leave the oven on maximum setting for 30 – 40 minutes.
oAfter the oven cavity has cooled, it should then be cleaned with
warm soapy water, using either a sponge or soft cloth. No abrasive
cleaners should be used.
oOuter parts of the oven should be cleaned with warm soapy water,
using either a sponge or soft cloth. No abrasive cleaners should be
used.
50
100
150
2 0 0
2 5 0
0
12 345
6
