Baumatic BAO6009-P User manual

ww 1
BAO6009-P
60 cm Multifunction
self-cleaning pyrolytic
built in oven.

User Manual for your Baumatic
BAO6009-P 60 cm 9 Function self-
cleaning pyrolytic built in oven.
NOTE: This User Instruction Manual contains important
information, including safety & installation points, which will
enable you to get the most out of your appliance. Please keep it
in a safe place so that it is easily available for future reference; for
you or any person not familiar with the operation of the appliance.
DD 03/03/11
2

2
Contents
Environmental note 4
Important safety information 5 – 8
Specifications 9
Product dimensions 9
Product specifications 9
Standard accessories 10
Electrical details 10
Control panel 11
Oven programmer/timer display 11
Setting and using the oven programmer/timer 12
Selecting manual operation mode 12
Setting the time of day 12
Setting the minute minder function 12 – 13
Setting the duration function 13
Selecting the end cook function 14
Setting the start and end time function 15
Adjusting the audible signal 15
Selecting a cooking function and temperature 16
Selecting manual operation mode 16
Selecting an oven function 16
9 oven functions 16 – 17
Thermostat control knob 17
Oven operating light 18
Cooking guidelines 18
Warnings 18 – 19
Cleaning and maintenance 20
Pyrolytic cleaning 20 – 21
General cleaning instructions 21 – 22
Removable oven roof liner 22
Replacing the oven bulb 22
Removing the oven door for cleaning 23
Installation 24
Installing the oven into the kitchen cabinet 25
Positioning the appliance 25
Ventilation requirements 26
My appliance isn’t working correctly 27 – 28
Contact details 29
Welcome to Think appliances letter 3

Dear Customer,
Congratulations on purchasing your new product from Think Appliances.
To register your parts and labour warranty (some conditions apply please refer to your
warranty card for more details) please contact out Customer Care team on:
1800 444 357
Our Customer Care centre is there to ensure you get the most out of your appliance. For
example, should you want to learn more about recommended cooking temperatures, the
various cooking functions available, how to set and program your LED clock, and importantly
taking care of your appliance when cleaning, please call us because we are here to help you.
It is important that you read through the following use and care manual thoroughly to
familiarize yourself with the installation and operation requirements of your appliance to
ensure optimum performance.
We also carry a complete range of spare parts for all Think products. For all your spare parts
enquiries please contact our team at Pronto Parts on:
1300 306 973
Again, thank you for choosing an appliance brought to you by Think Appliances and we look
forward to being of service to you.
Kind regards
Management
Think Appliances

4
Environmental note
oThe packaging materials that Baumatic uses are environmentally
friendly and can be recycled.
oPlease discard all packaging material with due regard for the
environment.

5
IMPORTANT SAFETY INFORMATION
Your safety is of the utmost importance to Baumatic.
Please make sure that you read this instruction booklet
before attempting to install or use the appliance. If you
are unsure of any of the information contained in this
booklet, please contact the Baumatic Technical
Department.
General Information
oThis appliance is designed for domestic household use and can
be built into a standard kitchen cabinet or housing unit.
oIMPORTANT: The adjacent furniture or housing and all
materials used in the installation must be able to withstand a
minimum temperature of 85°C above the ambient temperature
of the room it is located in, whilst in use.
oCertain types of vinyl or laminate kitchen furniture are
particularly prone to heat damage or discolouration at
temperatures below the guidelines given above.
oAny damage caused by the appliance being installed in
contravention of this temperature limit, or by placing adjacent
cabinet materials closer than 4mm to the appliance, will be the
liability of the owner.
oFor use in leisure accommodation vehicles, please refer to
the appropriate information given in the installation instructions
for this appliance.
oThe use of this appliance for any other purpose or in any other
environment without the express agreement of Baumatic Ltd.
will invalidate any warranty or liability claim.
oYour new appliance is guaranteed against electrical or
mechanical defects, subject to certain exclusions that are noted
in Baumatic’s Conditions Of Guarantee. The foregoing does not
affect your statutory rights.
oRepairs may only be carried out by Baumatic Service
Engineers or their authorised service agent.

WARNING
To ensure the oven shelves operate safely, correct placement of the shelves between the side rails
(items 1 to 4) is imperative. This will ensure that during removal of the shelf or tray, hot food
items should not slide out completely.
6

7
Warning and safety instructions
oThis appliance complies with all current European safety
legislation. Baumatic do wish to emphasise that this compliance
does not remove the fact that the appliance surfaces will
become hot during use and retain heat after operation.
Child Safety
oBaumatic strongly recommend that babies and young children
are prevented from being near to the appliance and not allowed
to touch the appliance at any time.
oIf it is necessary for younger family members to be in the
kitchen, please ensure that they are kept under close supervision
at all times.
General Safety
oDo not place heavy objects on the oven door or lean on the
oven door when it is open, as this can cause damage to the oven
door hinges.
oDo not leave heated oil or fat unattended, as this is a fire risk.
oDo not place pans or baking trays directly on the base of the
oven cavity, or line it with aluminium foil.
oDo not allow electrical fittings or cables to come into contact
with areas on the appliance that get hot.
oDo not use the appliance to heat the room it is located in or to
dry clothing.
oDo not install the appliance next to curtains or soft furnishings.
oDo not attempt to lift or move cooking appliances by using the
oven door or handle, as this may cause damage to the appliance
or result in injury to the person lifting the appliance.
Cleaning
oCleaning of the oven should be carried out on a regular basis.
oGreat care should be taken whilst using this appliance and when
following the cleaning procedure.
oIMPORTANT: The appliance must be disconnected from the
mains before following the cleaning procedure.

8
Installation
This appliance must be correctly installed by a
suitably qualified person, strictly in accordance
with the manufacturer’s instructions.
oBaumatic Ltd. declines any responsibility for injury or
damage, to person or property, as a result of improper
use or installation of this appliance.
oHeat, steam and moisture will be created during use of the
appliance, take care to avoid injury and ensure that the room is
adequately ventilated. If the appliance is going to be used for
prolonged periods of time, then additional ventilation may be
required.
o Please consult with your qualified installer if you are in any doubt
about the amount of ventilation that you will require.
Declaration of conformity
oIn the parts destined to come into contact with foodstuffs, this
appliance is in accordance with the requirements of the EC
directive 89/109 transposed in the Italian Legislative Decree No.
108 of 25/01/92.
oCE: Appliance conforming to the European directives
89/336/EEC, 93/68/EEC, 73/23/EEC and subsequent revisions
and “RoHS” directive 2002/95/CE.*
parts 1 and 2.6
oThe manufacturer declares that the oven is built using certified
materials and requires the appliance to be installed in
accordance with the standards currently in force. This appliance
must be used by a trained person for domestic purposes only.
*The RoHS directive stands for “the restriction of the use of
certain hazardous substances in electrical and electronic
equipment”. This directive bans the placing on the EU market of
new electrical and electronic equipment containing more than
the agreed levels of lead, cadmium, mercury, hexavalent
chromium, polybrominated biphenyl (PBB) and polybrominated
diphenyl ether (PBDE) flame retardants.
o The appliance conforms to Australian Standards AS/NZS60335,

9
Specifications
Product Dimensions Aperture Dimensions
Height: 591 mm 580 mm – 583 mm
Width: 597 mm 560 mm
Depth: 525 mm 550 mm
Product specifications
o9 functions
oEnergy efficiency class: A
oOven capacity: 57 litres
oLED full programmer
oCooling fan
oMark resistant coating
oThermostatically controlled grill
oTriple-glazed removable door
oAutomatic safety door-lock (when in pyrolytic cleaning mode)
oCatalytic exhaust
Standard accessories:
2 x Safety shelves
Enamelled baking tray with handle
Trivet

9
lectrical details
Supply Connection: fused
m c ntact gap
:
ven Light Bulb: 25 W/500°C screw type pygmy
the oven door and looking on the right hand side of
e oven chassis.
odel Number ……………………………….
erial Number ……………………………….
ate of Purchase ……………………………….
ooling fan
f the oven stable and the external
surface temperature lower.
oven has been
switched on for and at how high a temperature.
E
Rated Voltage: 220 - 240 Vac 50 Hz
16 A (double pole switched
outlet with 3m o
Max Rated Inputs: 3.10 kW
Mains Supply Lead 3 x 1.5 mm²
O
For future reference please record the following information which can
be found on the rating plate and the date of purchase which can be
found on your sales invoice. The rating plate for your oven can be
located by opening
th
M
S
D
C
oA tangential cooling fan is fitted inside of this appliance, to make
the internal temperature o
oAfter you have finished cooking and switched off the oven, the
cooling fan will continue to run for a period of time afterwards.
The length of time will depend on how long the

11
Control Panel
1) Oven function selector knob 7) Timer “duration” button
2) Power indicator light 8) Timer “end cook” button
3) Oven programmer/timer 9) Timer “manual operation” button
4) Oven operating light 10) Timer “minus” button
5) Thermostat control knob 11) Timer “plus” button
6) Timer “minute minder” button
Oven programmer/timer display
12) “Auto” function symbol
13) “Minute minder” symbol
14) “Manual operation” symbol.

12
Setting and using the oven programmer/timer
Selecting manual operation mode
After your appliance is connected to your mains supply for the
first time, the numbers on the timer display will flash. Before
you can select a cooking function or set a temperature, you
must set the appliance into “manual operation” mode.
oTo select manual operation mode, press the “manual operation”
button (9) on the control panel.
Setting the time of day
After setting your oven for manual operation, you should also
set the time of day.
oUse the “minus” button (10) and “plus” button (11) to adjust
the time that appears in the display. After getting the display to
the correct time, release the “minus” and “plus” buttons. After
five seconds the time will fix in the display and you will be able
to use your oven.
oThe “manual operation” symbol (14) will light on the oven
programmer/timer display.
Setting the minute minder function
You are able to set the minute minder at any time, regardless
of whether an oven function has been selected. You can set a
period of time using the minute minder function and an alarm
will sound when this period of time has elapsed.
oPress the “minute minder” button (6), the display will show a
value of 00:00. Set the period of time that you wish the minute
minder to countdown for, by using the “minus” (10) and “plus”
(11) buttons.
oOnce the display has got to your desired countdown time, let go
of the “minus” and “plus” buttons. The minute minder symbol
(13) will appear on the timer display.
oOnce a countdown time has been set, it is possible to shorten or
lengthen the time by using the “minus” or “plus” buttons.
oAn alarm will sound when the countdown time has elapsed. The
alarm can be silenced by pressing the “minute minder” button or
“manual operation button”

13
oImportant: The oven will continue to heat once the alarm has
been silenced. If you have finished cooking, then you should turn
the oven function selector and thermostat control knob to 0.
Setting the duration function
This function will allow you to set a countdown time similar to
the minute minder function. However the oven will no longer
continue to heat, once the countdown period has elapsed.
oUse the thermostat control knob (5) to set the temperature that
you require. The manual operation symbol (14) will appear on
the display.
oUse the oven function selector knob (1) to select the mode of
cooking that you require.
oIt is then possible to set the duration of the cooking time that
you require.
oPress the “duration” button (7) and the display will show a value
of 00:00. Set the period of time that you wish the duration
function to countdown for, by using the “minus” (10) and “plus”
(11) buttons.
oOnce the display has got to your desired countdown time, let go
of the “minus” and “plus” buttons. The countdown will start
immediately and the word AUTO will appear on the timer display.
oOnce a countdown time has been set, it is possible to shorten or
lengthen the time by using the “minus” or “plus” buttons.
oAn alarm will sound when the countdown time has elapsed and
the oven will switch off. The word AUTO will flash and the
heating symbol will disappear.
oTo silence the audible signal and return the oven to manual
operation mode, once the duration function has been used. You
should press the “manual operation” button, the word AUTO will
disappear from the display and the manual operation symbol will
appear instead.
oImportant: If you do not turn the thermostat control knob and
oven function selector knob to 0. Then the appliance will
continue to operate as soon as you press the “manual operation”
button.

14
Setting the end cook function
This function is similar to the duration function, however
instead of selecting a period of time that you wish the oven to
switch off after. You select the time of day that you wish the
oven to switch off at.
oUse the thermostat control knob (5) to set the temperature that
you require. The manual operation symbol (14) will appear on
the display.
oUse the oven function selector knob (1) to select the mode of
cooking that you require.
oPress the “end cook” button (8) and the display will show a
value of 00:00. Set the time of day that you wish the oven to
stop cooking at by using the “minus” and “plus” buttons. The
timer will calculate how long the cooking time will be, based on
the time of day that you have selected and show it on the
display.
oOnce the display has got to the time of day that you want the
oven to stop cooking at, let go of the “minus” and “plus”
buttons. The countdown will start immediately and the word
AUTO will appear on the timer display.
oWhen the time is set, it can be modified by pressing the “minus”
and “plus” buttons.
oWhen the time of day reaches the end of cooking time that you
set, the oven will switch off and an alarm will sound. The word
AUTO will flash and the heating symbol will disappear.
oTo silence the audible signal and return the oven to manual
operation mode, once the end cook function has been used. To
do this you should press the “manual operation” button, the
word AUTO will disappear from the display and the manual
operation symbol will appear instead.
oImportant: If you do not turn the thermostat control knob and
oven function selector knob to 0. Then the appliance will
continue to operate as soon as you press the “manual operation”
button.

15
Setting the start and end time function
This function will allow you to set a time in the future that the
oven switches on at and a time that the oven will switch off at.
oUse the thermostat control knob (5) to set the temperature that
you require. The manual operation symbol (14) will appear on
the display.
oUse the oven function selector knob (1) to select the mode of
cooking that you require.
oPress the “duration” button (7) and the display will show a value
of 00:00. Set the period of time that you wish to cook for, by
using the “minus” (10) and “plus” (11) buttons. The word AUTO
will appear on the timer display.
oImmediately press the “end cook” button (8) and the timer
display will show the value 00:00. Set the time of day that you
want the oven to switch off at, using the “minus” and “plus”
buttons.
oThe oven will calculate what time it needs to switch on at, so
that your food will cook for the length of time that you selected.
It will automatically switch itself on, once it reaches the time of
day that it has calculated.
oWhen the time of day reaches the end of cooking time that you
set, the oven will switch off and an alarm will sound. The word
AUTO will flash and the heating symbol will disappear.
oTo silence the audible signal and return the oven to manual
operation mode, once the start and end time function has been
used. To do this you should press the “manual operation” button,
the word AUTO will disappear from the display and the manual
operation symbol will appear instead.
oImportant: If you do not turn the thermostat control knob and
oven function selector knob to 0. Then the appliance will
continue to operate as soon as you press the “manual operation”
button.
Adjusting the audible signal
oTo adjust the level of the audible signal, when it is sounding,
press the minus button and it will adjust through the 3 sound
levels. Release the minus button and the sound level of the
audible signal will be set.

Selecting a cooking function and temperature
Selecting manual operation mode
After your appliance is connected to your mains supply for the
first time, the numbers on the timer display will flash. Before
you can select a cooking function or set a temperature, you
must set the appliance into “manual operation” mode.
oTo select manual operation mode, press the “manual operation”
button (9) on the control panel.
Selecting an oven function
The oven function selector knob should be used to select the particular
mode of cooking that you require. The appliance will utilise different
elements within the oven cavity, depending on the oven function that
you select. When a function is selected, the power indicator light will
come on.
9 oven functions
Light
The separate Light function will illuminate the oven cavity. This function is
also useful when cleaning the oven interior also will give a low heat
suitable for proving dough.
Full grill
This cooking method is normal static grilling utilising the top elements,
which directs heat downwards onto the food. Suitable for gilling medium to
large portions of sausages, bacon, steaks and fish.
Lower element only
This method of cooking uses the lower element to direct heat upward to
the food. Fro slow -cooking recipes or for warming up meals.
16

Thermostat control knob
The oven thermostat control knob sets the required
temperature of the oven. It is possible to regulate
the temperature within a range of 50 - 250°C.
Turn the control knob clockwise.
Convection top and lower element
This method of cooking provides traditional cooking with heat from the top
and lower elements. Particularly suitable for traditional roasting and
baking on the centre shelf only.
Convection oven and fan assist
This method of cooking provides heat from the outer top and the lower
elements, plus the use of the fan to circulate the heat and ensure a fast
and even distribution. Suitable for baking pastries and biscuits on multiple
levels when browning is required.
Fan
This method of cooking uses the circular element located around the fan
while the heat is distributed, resulting in a faster, more efficient operation.
Cooking with the fan on allows different kinds of food to be cooked
simultaneously on different shelves, preventing the transmission of smells
and tastes from one dish onto another.
Defrost
The fan runs without heat to reduce the defrosting time of frozen foods.
The tim e required to defrost the food will depend on the room temperature,
the quantity an type of food: remove frozen portions of meat completely
from packaging and place over the grill rack to allow proper circulation.
Full grill and fan
This method of grilling uses the full top element in junction with the fan, to
grill meat without the need to turn. Suitable for steaks such as hamburgers
and alrge fillets.
Pyrolitic cleaning
This function cleans the oven cavity by raising the inner oven temperature
to approx. 500°C. The grease and cooking stains are burnt off. The
resultant ash deposits can be wiped away with a soft damp cloth once the
oven has cooled down. For best cleaning results, the oven should not be
completely cold but still slightly warm.
17
()

18
Oven operating light
This light will come on to indicate that the oven’s heating elements are
in operation. The light will turn off when the temperature set on the
thermostat control knob has been reached. It will cycle on and off
throughout the cooking time.
You should not place food inside the cavity, until the correct
cooking temperature has been reached.
Cooking guidelines
oPlease refer to the information given on food packaging for
guidance on cooking temperatures and times. Once familiar with
the performance of your appliance, temperatures and times can
be varied to suit personal preference.
oIf you are using the fan oven function, then you should follow
the information given on the food packaging for this particular
mode of cooking.
oMake sure that frozen foods are thoroughly thawed before
cooking, unless the instructions on the food packaging advise
that you can “cook from frozen”.
oYou should pre-heat the oven and not place food inside of it until
the oven operating light has gone off. You can choose not to pre-
heat when using the fan oven mode; however you should extend
the cooking time given on the food packaging by approximately
ten minutes.
oBefore cooking, check that any unused accessories are removed
from the oven.
oPlace cooking trays in the centre of the oven and leave gaps
between the trays to allow air to circulate.
oTry to open the door as little as possible to view the dishes.
oThe oven light will remain on during cooking.
Warnings
oKeep the oven door closed when using a grill function.
oDo not use aluminium foil to cover the grill pan or heat items
wrapped in aluminium foil under the grill. The high reflectivity of
the foil could potentially damage the grill element.

19
oYou should also never line the base of your oven with aluminium
foil.
oDuring cooking, never place pans or cookware directly onto the
bottom of your oven. They should always be placed on the
shelves provided.
oThe grill heating element becomes extremely hot during
operation, avoid touching it inadvertently when handling the
food which you are grilling.
oImportant: Be careful when opening the door, to avoid contact
with hot parts and steam.
oThe drip tray handle should only be used to reposition the drip
tray and NOT for removing it from the oven cavity. When
removing the drip tray, you should ALWAYS use an oven glove.
oThe drip tray handle should not be left in position when the
appliance is switched on.
