Baumatic MEGA5SS User manual

MEGA 5SS
R
How to get the most
from your
Washing Machine
SM1253 Imp 4-07-2003, 12:031

SM1253 Imp 4-07-2003, 12:032

3
SM1253
ENGLISH
INDEX
MODEL: ..........................................................................................................................................................................
PRODUCTION CODE: ...............................................................................................................................................
DATE OF PURCHASE: ........................................................................................................................................................
NOTES AND USEFUL ADVICE FOR THE USER 4
DESCRIPTION OF THE MACHINE 4
INSTALLING THE MACHINE 5-7
•Unblocking the machine 5
•Positioning and levelling the machine 5
•Connecting to the water supply system 6
•Connecting to the power supply 6-7
USING THE WASHING MACHINE 7-9
•Using the machine 7
•Use of detergents 7-8
•How to eliminate stains 8-9
•International clothing care symbols 9
MAINTENANCE 9-11
•Cleaning the machine 9
•Removing the detergent drawer 10
•Cleaning the filter 10
•Troubleshooting 10-11
TECHNICAL DATA 11
MAIN MACHINE FUNCTIONS 12
DESCRIPTION OF FUNCTIONS 12
•On/off knob or button 12
•No-drain button 12
•No-spin button 12
•Half-load button 12
•Extra rinse button 12
•550/max spin speed button 12
•Temperature limit button 12
•Timer knob 12
•Variable spin 13
USING THE MACHINE 14
•Starting the machine 14
WASHING PROGRAMMES 14-15
GB
Dear customer,
Thank you for choosing our product.
Please read these instructions carefully before connecting and using the machine.
An awareness of how the machine operates will help guarantee its correct and safe use.The instructions
also contain some useful information on the machine’s functions that will help you get the most out of its
use.
If you decide to sell or give the washing machine to someone else,remember to give the instruction book
to the new owner.
SM1253 Imp 4-07-2003, 12:033

GB
4
SM1253
NOTES AND USEFUL ADVICE FOR THE USER
DESCRIPTION OF THE MACHINE
❃The machine must not be in-
stalled outdoors,even if pro-
tected by a roof, in that at-
mospheric agents may
cause irreparable damage
❃This appliance has been de-
signed for use as a domestic
washing machine.Any other
use is considered as im-
proper and therefore dan-
gerous.
❃The appliance must only be
used by adults.
❃The appliance is very heavy
and requires utmost care
when being moved.
❃If the machine is to stand on
acarpeted floor,ensure that
thereis sufficientspaceforair
to circulate between the
floor and the bottom of the
machine.
❃The appliance must not be
used or touched barefoot or
with wet or damp hands or
feet.
makes the selection of any
wash or dry programme
quick and simple (see con-
trol panel and table of pro-
grammes).
▼The ample glass door makes
loading and unloading
easier.
▼The perfect machine bal-
ance is the result of many
years of research aimed at
finding the correct balance
between thevariousmoving
parts.
A-Glass door
B-Filter
C-Adjustable feet
D-Top cover
E-Drum
F-Control panel
The washing machine is a house-
hold appliance that can wash
any type of fabric whenever you
want.
▼Thestructure of themachine
is fabricated in steel sheet,
which has been worked us-
ing a special process and
then enamelled in order to
maintainitsexternal appear-
ance and protect it against
corrosion.
▼The motor and all the other
moving parts are built to en-
sure noiseless machine op-
eration.
▼Thelargestainlesssteeldrum
is well placed to guarantee
a good wash quality and
prolong the life of the wash-
ing.
▼Theeasy tousecontrolpanel
❃When positioning the appli-
ance,ensurethatthepower
supplycable is not kinkedor
squashedandisaccessible.
❃fitbecomesnecessarytore-
place the power supply ca-
ble, refer exclusively to an
authorised service centre.
❃Do not use extension leads,
especiallyin a dampatmos-
phere.
❃Donotpullthe power cable
or appliance to remove the
plug from its socket.
❃Do not use detergents de-
signed for hand washing,in
that the excessive suds pro-
duced could damage the
internal components.
❃Whenthe applianceis inop-
eration, avoid any contact
with the water being dis-
charged through the drain
hose,as it may be very hot.
❃Donottouch the doorglass,
as this will tend to heat up
during a wash.
❃At the end of the wash,wait
approximatelythree minutes
before opening the door,as
itis fittedwith asafetydevice
that prevents it from being
opened accidentally.
❃It is advisable to leave the
door open after completion
of the wash cycle.
❃In the case of faulty opera-
tion, switch off the machine
by removingthe plugfromits
socket using dry hands.
Never try to access internal
components or attempt to
repair the machine, instead
referexclusivelytoanauthor-
ised assistance centre.
THE MANUFACTURER WILL NOT
BE HELD RESPONSIBLE FOR
ANY ACCIDENTS THAT MAY RE-
SULT FROM NON-COMPLIANCE
WITH THE REQUIREMENTS OF
SAFETY STANDARDS OR THIS IN-
STRUCTION MANUAL
SM1253 Imp 4-07-2003, 12:034

5
GB
5
SM1253
V
INSTALLING THE MACHINE
(ACCORDING TO MODEL)
The machine must be installed by
professionally qualified technicians,
according to the manufacturer’s indi-
cations.
23
Incorrect installation may result in
damage to persons and property.
The machine can be installed any-
where, provided the temperature in
the place of installation is not be-
low 3°C and the cables and hoses
at the rear of the machine are not
crushed in any way.
UNBLOCKING THE MACHINE MOD.A
UNBLOCKING THE MACHINE MOD. B
6
SETTING THE MACHINE LEVEL
Afterselecting a suitableposition,
level the machine carefully using
the adjustable feet .
Particular care must be taken
when selecting the position, lev-
elling the washing machine and
ensuring the safety of lock nuts.
If levelling is not carried out cor-
rectly, the washing machine will
be unstable and noisy during op-
eration,which may result in dam-
age.
Ifthemachinestandsona carpet
floor,make sure that air can circu-
late freely between the washing
machine and the floor itself.
It is not recommended that the
machine be installed in locations
wherethe temperatureis liable to
drop below freezing.
45
For transport purposes the swing-
ing unit in the machine is blocked
using 4 spacers with screws. Be-
fore starting the machine these
spacers and lock screws must be
removed,and stored foruseinthe
event of a possible change of lo-
cation.
Block off the holes with the plugs
provided, which can be found in
the bag containing the docu-
ments.
N.B. If the spacers fall into the in-
side of the machine,open the rear
panel, recover them and then re-
place the panel.
For transport purposes the swing-
ing unit in the machine is blocked
using 4 spacers with screws. Be-
fore starting the machine these
screws must be removed using a
screwdriver.
Insert a screwdriver in the holes
and proceed as shown in the fig-
ure to recover the 4 plastic
spacers.
N.B. If the spacers fall into the in-
sideof the machine,open the rear
panel,recover them and then re-
place the panel.
SM1253 Imp 4-07-2003, 12:035

GB
6
SM1253
INSTALLING THE MACHINE
CONNECTING TO THE POWER SUPPLY
CONNECTION TO THE WATER SUPPLY SYSTEM
78
▼Check that the voltage indi-
catedonthe technical data
plate on the back of the
washing machine is the
same as that of the mains
power supply (fig.7).
▼The fuses, electric cables
and wall socket must be
rated to withstand the maxi-
mum power load indicated
on the data plate.
▼Thepowersupply socketinto
which the washing machine
will be plugged must be
earthed. Otherwise, the
manufacturer will not be
held responsible for any ac-
cidents (fig.8).
▼If the socket to which the
machine will be connected
is faulty or does not comply
withthe requirements,it must
be replaced by a qualified
electrician.
▼Thewashingmachinemustnot
be connected to the electric-
itysupplyusingextensionleads
or multi-plug adapters.
▼During maintenance the
washing machine must be
unplugged from the power
supply socket.
▼Do not plug-in or unplug the
machine with wet hands.
▼If the power cable is dam-
aged in any way, contact
the specialised technical
service centre.
▼Position the appliance so
that the power supply cable
can be accessed with ease,
enabling it to be discon-
nected when required.
910/A
MIN. 60 CM
MAX.90 CM
A
11
10/B
▼The mains water pressure
must be between 0.05 and
1.00 MPa (0.5 - 10 bar.)
▼Before connectingthewater
fill hose,open the valve and
allow a quantity of water to
flow.This will censurethatthe
supply pipes are free from
impurities, such as sand or
rust (this operation is very
important whenthe washing
machine is being con-
nected to a new supply sys-
tem or if the system has not
been used for a long period
of time).
▼Connect the hose from the
hot water tap to the valve
withredfilter (if present) and
the hose from the cold wa-
tertaptotheothervalve(fig.
10/B).
▼Place the filter washer sup-
pliedbetweenthehoseand
the valve and hand tighten
the connection as much as
possible (fig.9).
▼Fit the washer on the other
end of the supply hose, and
screw it onto the washing
machine (fig.10/A).
▼Thewatersupplytapmustbe
SM1253 Imp 4-07-2003, 12:036

7
GB
7
SM1253
INSTALLING THE MACHINE
Attention: Before running the ma-
chine loaded for the first time, we
re-commend that you run a short
washing cycle with the machine
empty.
Thismakes itpossible to check op-
eration of the machine and clean
the drum.
Each time you use the machine:
▼check that all water connec-
tions are tight,the drain hose is
positioned correctly (see con-
nection to the water supply)
and the supply tap is open.
▼make sure that your hands
are dry, then insert the plug
USING THE MACHINE
ADVICE BEFORE USING
into the power socket.
▼divide the washing accord-
ingtofabrictype(checkthe
labels on the clothes).
▼check that the clothes to be
washedhavenothing intheir
pockets that might damage
the washing, the washing
machine or the filter
Thewashingmachinehasathree-
compartment detergent drawer.
compartment for pre-wash
or soak powder detergent
(1)
compartment for normal
wash powder detergent (2)
compartment for fabric sof-
tener, perfume, starching or
bleaching agents (3)
use a low-foam detergent and
softener(ifnecessary),ofthe type
indicated for automatic washing
machines. Use the doses recom-
USE OF DETERGENTS
mended on the package.
N.B. Excessive amounts of deter-
gent may result in too much foam,
and give a poor quality wash.
Insufficient amounts of detergent
may mean that the washing does
12
CLOSED OPEN
13 14
15
YES
NO
16
fully open when washing.
▼Thewaterdrainhosemustbe
placed at least 60 cm and
not more than 90 cm from
the floor (fig.11).
▼If the drain hose is con-
nected to a fixed drainage
system,the free end must be
inserted in a pipe of mini-
mum internal diameter 40
mm.
▼The drain hose water con-
nection to the drainage sys-
tem must not be herme-
tically sealed, as this would
cause air to accumulate
and the water to siphon out.
▼Ifthe wastewateristo bedis-
charged into a sink or wash-
basin, insert the hose in the
specialbracketsuppliedand
hook it over the edge of the
sink or washbasin. Then tie
the hose and bracket to a
tap orsimilar(fig.12).Toavoid
overflowing, the sink drain
mustbeclear of obstructions
and must be able to empty
quickly.
SM1253 Imp 4-07-2003, 12:037

GB
8
SM1253
not come properly clean.
N.B. When filling the detergent
compartment it is important that
the detergent does not overflow
into the compartment used for
fabric softener,as this would result
in a rinse cycle containing soap,
which might leave the washing
with white stains.
Equally, do not allow the fabric
softener to overflow into the deter-
gent compartment, as this would
reduce the cleaning capacity.
IF THE MODEL HAS A LIQUID DETERGENT COMPARTMENT
N.B. When using liquid detergent
(recommended for programs that
do not use the pre-wash cycle),
insert the special container (if
there is one) in centre compart-
ment ”2” (as shown opposite),
then pour in liquid detergent up to
the maximum level indicated.
Remember to remove the liquid
detergent compartment when
using powder detergent.
▼close the detergent drawer
before starting the wash.
Attention! Never remove the de-
tergent drawer when the machine
is running,as water may come out
of it.
Some stains cannot be removed
by just washing in a washing ma-
chine.
Before trying to remove any type
of stain by hand, first try the re-
moval procedure on a small area
of hidden fabric starting from the
edge of the stain and working in-
wards,this will prevent a dark ring
fromforming aroundthesiteofthe
stain.
Afewmethodsfor removingstains
are reported below.
●W
AX :scrape the wax using a
blunt point in order not to
damage the fabric. Then,
with the fabric placed be-
tweentwopiecesofabsorb-
entpaper,run ahotironover
the stain.
●B
ALL - POINT PENS AND FELT - TIP PENS :
clean using a soft cloth
soakedin ethylalcohol. Take
HOW TO REMOVE STAINS
carenotto spread the mark.
●D
AMP AND MOULD :if the fabric
supports the use of bleach,
perform a wash cycle add-
ing bleach to the appropri-
ate compartment in the dis-
penser (see table of pro-
grammes). Other-wise, soak
the soiled part in hydrogen
peroxide (10 volumes) and
leave for 10 to 15 minutes.
●L
IGHT SCORCH MARKS CAUSED BY IRON -
ING :follow the instructions for
mould and damp.
●R UST :use products specially
designed for rust stains, fol-
lowingthemanufacturer’sin-
structions written on the
packet.
●C
HEWING GUM :rub ice over the
mark,scrape away as much
aspossible and thenrub with
a cotton cloth soaked in ac-
etone (alternatively,use nail
varnish remover).
●P
AINT :do not allow the paint
to dry.Rub the area with the
solvent recommended by
thepaintmanufacturer (e.g.
water, turps, trichloroethyl-
ene), apply soap and then
rinse.
●L
IPSTICK :stains on cotton or
wool can be eliminated us-
ing a cloth soaked in ether.
Stains on silk require the use
of trichloroethylene.
●N
AIL VARNISH :place a sheet of
absorbent paper on the
stained material, then
dampen the back of the
fabric with acetone, fre-
quentlychangingthepaper
placed over the stain. Con-
tinue like this until the stain
has disappeared.
18 19
USING THE MACHINE
17
SM1253 Imp 4-07-2003, 12:038

9
GB
9
SM1253
USING THE MACHINE
MAINTENANCE
The washing machine has been de-
signed to reduce maintenance to a
minimum.
However, it is important that you re-
member to clean it regularly.
Before cleaning, make sure that the
appliance has been disconnected
from the power supply and that the
water supply tap has been turned off.
The external structure and the
parts of the washing machine in
plasticmustbecleanedwithasoft
damp cloth only.
WARNING!! Never use chemicals,
abrasive products, alcohol, soap,
petrol or other solvents to clean
the appliance as these may
cause damage. (fig.20)
After washing, leave the door
open for a little while to allow rub-
ber parts to dry.
Wash outthedetergentcompart-
CLEANING THE WASHING MACHINE
Before placing the clothes in the
washing machine and selecting the
wash programme, examine the sym-
INTERNATIONAL CLOTHING CARE SYMBOLS
bols on the manufacturer’s label.
The table reported below will provide
l●T
AR OR DIRT :spread some fresh
butteroverthestain,allowto
stand and then wash with oil
of turpentine.
●G
RASS : delicately soap the
stain, use diluted bleach.
Good results can be ob-
tainedonwoollenfabricsus-
ing 90% alcohol.
●B LOOD : put into soak in cold
mentsfromtimeto time.To do this,
extract the detergent compart-
ment and rinse it under running
water,(fig.21) then replace it.
20 21
water with added salt, then
wash with washing soap.
a useful guide to reading the symbols.
SM1253 Imp 4-07-2003, 12:039

GB
10
SM1253
•If the softener compart-
ment “3” has the word
“PUSH” written on it:
-open the detergent
drawer;
-press on the word“PUSH”
with the right hand and
pull out the drawer with
the left hand (fig.22)
•If the softener compart-
ment “3” does not have
theword“PUSH”written on
it:
ATTENTION!! Before starting the
operations described below,
make sure that the washing ma-
chine is empty.
Do not remove the filter while the
machine is running,or when full of
water.
Place a cloth or flat plate under
the filter to collect any water that
may still be inside it.
Open the filter door, unscrew the
CLEANING THE FILTER
filter and remove it, turning in an
anticlockwise direction (fig.24).
Thefilter mustbe cleaned periodi-
cally.
Rinse the filter under running wa-
ter to eliminate all waste.
Replace the filter, screwing in a
clockwise direction and making
sure it is hermetically sealed.
TROUBLESHOOTING
If the appliance is not working
properly,checkthroughthe follow-
ingtroubleshootinglist beforecall-
ing for technical assistance.
Thewashingmachinedoesnotwork
(warning lights are off)
•check that:
1)The mains power supply is
working
2)The plug is inserted correctly
in the socket
3)The On/Off button is pressed
or, if there is no On/Off but-
ton,the programmer knob is
pulled outwards.
Thewashingmachinedoesnotwork
(warning lights are off)
•check that:
1)The programmer knob is set
to the selected program
2)The glass door is properly
closed
3)The ”Start” button has been
pressed (electronic models
only)
4)check the indications pro-
vided under ”The washing
machine does not fill with
water”
The washing machine does not fill
with water
•check that:
1)There is water in the water
supply system
2)Thewatersupply hose iscon-
nected to the washing ma-
chine
3)The water supply tap is open
4)Thefilterisnot blocked. Ifit is,
clean the filter after unplug-
ging the appliance from the
power supply
The washing machine continuously
fills and drains the water:
•check that:
1)The drain hose has been in-
stalled at the proper height
(60-90 cm)
2)The end of the drain hose is
not under water
Thewashingmachinedoesnotdrain
or spin
•check that:
REMOVING THE DETERGENT DRAWER (FIG. 22 OR 23, ACCORDING TO THE MODEL).
22 23
24
MAINTENANCE
-open the detergent
drawer;
-grasp it with both hands,
push down slightly and
pull the drawer outwards
(fig.23).
SM1253 Imp 4-07-2003, 12:0310

11
GB
11
SM1253
1)The drain hose is properly
connected
2)The drain hose is not bent
3)The drainage filter is not
blocked
4)The no-spin function has not
been selected
The washing machine vibrates and
is noisy
•check that:
1)All the blocking elements
used for transportation have
been removed.
2)the washing machine is level
3)Bulkyitemssuchas sheets,ta-
blecloths etc. are not all in
one part of the drum
The glass door does not open
1)Wait for 3 minutes after the
end of the cycle or, in the
caseof electronicmachines,
untilthe”End”indicator lights
up
The washing has not been properly
spun
•check that:
1)The washing is evenly distrib-
uted in the drum
2)The correct spin speed has
been selected
The washing machine stops during
the wash
•check that:
1)The mains power supply is
working
There is still a lot of detergent in the
compartment
•check that:
1)The water supply tap is open
2)The filter between the tap
and the supply hose is clean
The washing is not clean at the end
of the wash cycle
•check that:
1)The drum is not overloaded
2)Thecorrectamount ofdeter-
gent has been used
3)The correct programme has
been selected
The washing has shrunk or faded
•check that:
1)The correct washing pro-
gramme has been selected
2)The correct washing tem-
perature has been selected
The washing machine does not dry
(washer-dryer models only)
•Make sure that:
1)The water supply tap is open
2)The drainage filter is clean
3)The washing machine is
turned on (control light on)
4)The program dial is posi-
tioned on one of the stop
points with the dryer symbol.
5)Thedryingtimeregulatordial
assistance
pump
model
220 V
N °204276237
kg wash
kg dry
A
total w
heating wash
heating dryer
wash motor
spin motor
dryer motor
Hz
5 / 100 N/cm
2
25
MAINTENANCE
is not set to“0”
6)The “Half Load” button is
pressed.
7)The “No Spin” button is not
pressed
If,after trying the above remedies,
the machine still does not work,
refer the fault to the nearest au-
thorised service centre.
When calling the service centre,
inform them of the machine
model, the serial number and the
type of fault.The data relating the
appliance can be found on the
rating plate affixed to the filter
door.
Thisinformation willallowthe tech-
nical service staff to select the
appropriate spare parts, thus
making the repair service quicker
and more efficient.
TECHNICAL DATA
MODEL
width cm.:
height cm.:
depth cm.:
5,0 Kg
2,5 Kg
1,0 Kg
1200
min. 0,05 MPa - max. 1 MPa
Dimension:
Spin max: (rpm)
Maximum
recommended washing
load:
Water pressure
Total power consumption/ Power supply
see plate with technical feature
MEGA 5SS
59.5
85.0
53.0
SM1253 Imp 4-07-2003, 12:0311

12
SM1253
ON/OFF KNOB OR BUTTON:
To start the machine, pull programmer knob or if the machine has push-button, press the
start push-button .
The indicator light will be illuminated.
DESCRIPTION OF FUNCTIONS (Available according to the model)
MAIN MACHINE FUNCTIONS
TEMPERATURE CONTROL
Rotate this knob to set the required temperature. In order to select the correct wash temperature, refer
to the “Programme Table".
Important: programme changes or the selection of the above functions must always be carried out with the appliance switched off.
ATable of programmes
BButtons
SMachine “on” indicator light
GThermostat knob
PProgrammer knob
NO-DRAIN BUTTON:
When this button is pushed, the washing machine will stop automatically at the end of the
lastrinse cycle andbefore draining thewater. In thiscase, thewashingis heldin the water-
filled drum to prevent creasing. This function only works for the delicate wash cycle.
NO-SPIN BUTTON:
Pushing this button the washing machine carries out a normal wash cycle but does not
spin.
HALF-LOAD BUTTON:
Pressing this button reduces the quantity of water used during the wash, thus saving both
water and energy.
Use this function when the quantity of items to wash is equal to half the maximum
recommended load (see table "Maximum recommended loads")
EXTRA RINSE BUTTON:
Thewashing machinehasbeen designedtoreducewaterconsumption toaminimum. Three
rinse cycles are normally sufficient. For very soft water zones or for those who are allergic
to detergent residues, press this button and the machine will carry out an extra rinse.
550/MAX SPIN SPEED BUTTON:
Push the button to vary the speed of the spin-dryer from maximum to minimum (the spin-
dryer’s maximum speed varies depending on the model). If the machine has a speed
adjustment knob, rotate until the desired speed is reached.
Warning: This is only available during intensive wash programmes. For delicates and wool, the spin speed is 550 rpm regardless
of the speed setting.
TEMPERATURE LIMIT BUTTON:
Pushing this button will limit the temperature to 60°when the temperature dial is set at a
higher temperature.
1
0
1
0
1
0
1
0
1
0
1
0
1
0
1/2
SM1253 Imp 4-07-2003, 12:0312

13
13
SM1253
DESCRIPTION OF FUNCTIONS (Available according to the model)
The washing cycle:
(By following these instructions, the
washing machine will carry out the
washing cycle, which has been
imposed).
1. Loadthe laundryintothe tubandclose
the door.
WARNING: It is prohibited to
overload the machine. It is
advisable to hand wash
garments that absorb an
enormous amount of water (for
example: rugs).
2. Pourthe washing powder(whichmust
not produce too much foam) and the
fabric softener for automatic washing
machines into the respective drawers
(see chapter entitled: “Use of
Detergent”)
3. Close the detergent drawer.
N.B. Do not remove the detergent
drawer while the machine is in
use, because this may cause the
water to flow out).
4. Choose and set the desired washing
cycle program and temperature using
the relative knobs.
WARNING!! Do not turn the
programming knob to the left. If
you pass the desired program,
continue to turn to the right until
you reach the desired position
again.
5. Pressthepushbuttons thatcorrespond
to the selected functions.
6. To startthewash, turn on the machine
by pulling out the programming knob
or(if presentonthe washingmachine)
by pressing the On/Off pushbutton
(the indicator light will turn on).
At the end of the washing cycle, the
washing machine will stop at one of the
STOP points on the programming knob.
1. Turn off the washing machine by
pushing the programming knob in or
(if present on the washing machine)
by pressing the On/Off pushbutton.
2. Take out the laundry
3. With dry hands, unplug the machine
4. Close the water tap.
WASHING PROGRAMMES
USINGTHE MACHINE
STARTINGTHE MACHINE:
VARIABLE SPIN:
The washing machine has a wide selection of spin speeds that can be selected before starting the wash
programme. To change the speed, simply rotate knob (H) to the value required. To select the no-spin function,
rotate the knob to position .
NB. Themaximumspinspeed(MAX)willvaryaccordingtothemachinemodel and that reported in the technical
characteristics table. The maximum selectable speed for each programme is indicated in the programme table
(if a higher spin speed is selected, the machine will only effect a spin at the value indicated in the table).
Spin load imbalance control:
This washing machine is equipped with a special electronic control system for correctly balancing the wash
load.
Prior to each spin, the system ensures that the washing is evenly distributed in the drum. If the washing is not
evenly distributed, the final spin speed is reduced, and if the load is very unbalanced, the spin is not effected.
90°
Knob
(P)*
Programme
Care
label
symbol
Examples and
degree of soiling Program
description
Dispenser
compartment
Knob
(T)**
1
3
4
# Reference program for power classification, in accordance with EN 60456
#
Cotton
linen
hemp
Cotton
linen
resistent
mixes
Cotton
linen
hemp
Sheets ,white and
solid colour tablecloths,
towels,underwear,
heavy soil with prewash
Prewash,main wash,
rinses,softener,
empty and final spin
90
90
60
90°
60°
INTENSIVE PROGRAMS FOR COTTON FABRICS
* Position of Programmer Knob ** Position of Adjustable Thermostat Knob
Use of supplementary buttons
(Available according to the model)
2
All the
posi-
tions
Cotton,
linen,hemp
and resistent
mixes
Fast rinse Rinses,softener,
empty and final spin
Sheets ,white and solid
colour tablecloths,
towels,underwear,
heavy soil
Coloured underwear,
shirts,bath robes,cotton
kinits,sheets;
normal soil
Main wash,
rinses,softener,
empty and final spin
Main wash,
rinses,softener,
empty and final spin
5
Whitner, scented
softener Rinse,softener,
empty and final spin
Cotton,linen,
hemp and
resistent
mixes
All the
posi-
tions
Spin
speed
500
600
MAX
700
800
900
1000
1/2
Max 1200
Max 1200
Max 1200
Max 1200
Max 1200
SM1253 Imp 4-07-2003, 12:0313

14
SM1253
WASHING PROGRAMMES
GB
PROGRAMS FOR WOOL
INTENSIVE PROGRAMS GENTLE ACTION PROGRAMS
6
7
8
9
11
12
13
AUSILIARY PROGRAMS FOR SYNTHETICS AND WOOL
60
60
60°
60°
35°
INTENSIVE PROGRAMS FOR COTTON FABRICS
* Position of Programmer Knob ** Position of Adjustable Thermostat Knob
The wool wash cycle of this machine has been approved by Woolmark for the wahing of machine
washable Woolmark products provided that the garments are washed according to the instructions on
the garment label and those issued by the manufacturer of this washing machine. M.9622
Knob
(P)*
Programme
Care
label
symbol
Examples and
degree of soiling Program
description
Dispenser
compartment
Knob
(T)**
Intensive spin Final long spin
Final long
spin
Final spin
Delicates
synthetics
Delicates
synthetics
Gentle rinse
Whitner, scented
softener
Rinses,softener,
empty and final spin
Rinse,softener,
empty and final spin
Resistent
mixes
Resistent
mixes
Shirts sheets,
baby wear, nappies
heavy soil
Shirts sheets,
baby wear, nappies
heavy soil
Prewash main wash,
rinses,softener,
empty and final spin
Main wash,
rinses,softener,
empty and final spin
Pure
wool Machine
washable
wool
High water level wash
rinses,softener,empty
and final spin
Empty and
final spin
GENTLE ACTION PROGRAMS FOR SYNTHETICS AND WOOL
All the
posi-
tions
All the
posi-
tions
All the
posi-
tions
All the
posi-
tions
Pure
wool
Use of supplementary buttons
(Available according to the model)
Spin
speed
10
Synthetics Starch, perfume,
softener Rinse, softener,
drain and final spin
All the
posi-
tions
........................................................
........................................................
........................................................
........................................................
........................................................
........................................................
........................................................
........................................................
........................................................
........................................................
........................................................
........................................................
........................................................
........................................................
........................................................
........................................................
........................................................
........................................................
........................................................
........................................................
........................................................
........................................................
........................................................
........................................................
........................................................
........................................................
........................................................
........................................................
........................................................
........................................................
........................................................
........................................................
........................................................
NOTE
1/2
Max 1200
500
500
500
500
500
500
500
FUNCTION ENABLED FUNCTION DISABLED
SM1253 Imp 4-07-2003, 12:0314

15
15
SM1253
SM1253 Imp 4-07-2003, 12:0315

461305029 CF SM1253 06/04/2003
GB
SM1253 Imp 4-07-2003, 12:0416
