0038 Twin Bed
Assembly Instructions
Page 1 of 8
Assembled View
1
Note: Do not assemble
using power tools.
This can cause the bolts
to be overtightened
Use 2 People
Parts List
2
AHeadboard Panel x1
BFootboard Panel x1
Set of Bed Slats x1
Parts in Box A:
Parts in Box B:
FSide Rail x2
G
WII-0120
DHeadboard Post
(Left Hand)
x1
EHeadboard Post
(Right Hand)
x1
CHeadboard Support Rail x1

Page 2 of 8
Parts List
2
Wood Screw
(M4 x 16mm)
x12
Hardware List
3
1M4 Allen Key
x1
10 CSK Cap Wood Screw
(M6 x 50mm) x24
42 'L' Bracket
x8 3Barrel Nut x10
Wood Screw
(M4 x 32mm)
x12
5Wood Dowel
(M8 x 30mm)
x8
6Wood Dowel
(M10 x 40mm)
x6
7Spring
Washer
x4
8
11 M6 x 15mm
JCB x16 12 M6 x 30mm JCB x8
14 M6 x 60mm JCB
x8 15 M6 x 90mm JCB x10
Parts in Box C:
Storage Side Panel
(Left Hand)
x2
Storage Foot
x4
L
Storage Divider
x6
HStorage Back Panel x2
JStorage Bottom Panel x2
KStorage Support Rail x4
Storage Side Panel
(Right Hand)
x2
M
N O
Flat Washer
x4
9
WII-0120
13 M6 x 40mm JCB
x22
0038 Twin Bed
Assembly Instructions

Page 3 of 8
Fit the Lower Headboard Post (D & E) to the
Headboard Support Rail (C).
4
15
E
D
C
3
7
3
15
7
Fit the Headboard Panel (A) to the
Headboard Post (D & E).
5
A
C
D
E
WII-0120
13
8
9
0038 Twin Bed
Assembly Instructions

Page 4 of 8
Fit the 'L' Bracket (2) to the End of the
Storage Bottom Panel (J) with
M6 x 15mm JCB (11).
6
x2
Tap the Wood Dowel to the end of the
Storage Support Rail (K).
7
K
6
K
WII-0120
11
2
J
0038 Twin Bed
Assembly Instructions
N
N
N
10
10
10
10
10
10
K
J
Assemble the Storage Bottom Panel (J) &
Support Rail (K) to the Storage Divider (N).
8

2
11
Fit the Storage Foot (O) to the Storage Bottom Panel (J).
Page 5 of 8
Assemble the Storage Side Panel (L & M) to the
Storage Bottom Panel & Support Rail (J & K).x2
9
10
WII-0120
K
L
M
J
13
OBack
0038 Twin Bed
Assembly Instructions
14
L
14
J
M
K
Back

Slide the Storage Back Panel (H) into the groove.
Page 6 of 8
Fit the Storage Back Panel (H) in place.
12
11
12
WII-0120
H
K
L
M
Back
4
0038 Twin Bed
Assembly Instructions
H
JL
M
O
O

Page 7 of 8
Assemble the Side Rail (F) to the
Headboard / Footboard (A & B).
13
Bolt & screw the Bed Slats (G) to the Side Rail (F).
14
WII-0120
13
G
F
5
13
13
13
13
13
13
5
5
5
5
5
13
5
13
13
5
5
7
15
3
A
F
B
F
0038 Twin Bed
Assembly Instructions

Page 8 of 8
Fit the Assembled
Storage under the
Bed Frame.
15
Assembled Storage
NOTE: Open shelves
facing outside!
Assembled Storage
NOTE: Open shelves
facing outside!
Assembled
Storage
Bolt the Assembled Storage to
the Bed Frame with
M6 x 30mm JCB (12).
16
12
WII-0120
