ASSEMBLY INSTRUCTIONS
MODEL : 7008T
Read this instruction carefully, remove all wrapping material, staples and straps from the carton. See hardware and furniture part list.
For guidance. Be sure you have all wooden furniture parts on a clean and soft surface to prevent from being scratched. Follow the figure to
start assembling.
Caution:
1. Do not FULLY –TIGHTEN the nut or bolt until all nut or nut bolt is ready to assembled.
2. Do not OVER- TIGHTEN the nut or nut bolt to avoid causing damages to the thread.
3. Keep all hardware part out of reach of children.
PART LIST
No.
B
A
DESCRIPTION
TABLE TOP
TABLE LEG
QTY
1 PC
4 PCS
No.
4
3
2
1
STEP 1
HARDWARE LIST
DESCRIPTION
FLAT WASHER 6/19"
SPRING WASHER 6/13"
JCBC SCREW M6 X 70MM
M4 ALLEN KEY
QTY
8 PCS
8 PCS
8 PCS
1 PC
STEP 2
COMPLETED TABLE ASSEMBLY

PART LIST
No.
B
A
DESCRIPTION
CHAIR TOP
TABLE LEG
QTY
1 PC
4 PCS
No.
4
3
2
1
STEP 1
HARDWARE LIST
DESCRIPTION
FLAT WASHER 6/19"
SPRING WASHER 6/13"
JCBC SCREW M6 X 70MM
M4 ALLEN KEY
QTY
8 PCS
8 PCS
8 PCS
1 PC
STEP 2
COMPLETED TABLE ASSEMBLY
Read this instruction carefully. Remove all wrapping material, staples and straps from the carton. See hardware and
furniture part list
For guidance. Be sure you have all wooden furniture parts on a clean and flat soft surface, such as a carpet or rug,
to prevent from being scratched.Follow the figure to start assembling.
CAUTION :
1. Do not FULLY - TIGHTEN the nut or screw untill all is ready to assemble.
2. Do not OVER - TIGHTEN the nut or screw to avoid causing damages to the thread.
3. Keep all hardware part out reach of children.
MODEL : 036 BENCH
ASSEMBLY INSTRUCTION
4
B
A
3
1
2
A
B
B
B
