BASE UNIT
600 Built Under Oven Housing Assembly Guide
For Internal Use: FI.WR.INS.031_WKIN00110_BASE_600_BUOH_Rev8.indd
Page 1
BASE UNIT
600 Built Under Oven Housing Assembly Guide
(F) x16
Wooden Dowel
(G) x12
Cam Dowel
(Expanding)
(H) x12
Cam Lock
(K) x4
30mm
Screw
(L) x26
15mm
Screw
(M) x4
Cover
Cap
Panel B
x2 End Panel
Panel E
x2 Rail Panel
Legs
x4 Filler F
(Packed separately) x1
Filler G
(Packed separately) x1
Panel C
x1 Base Panel
REQUIRED TOOLS
NOT to be used
with CAM DOWEL
& CAM LOCK
Large Bracket LGE
x2
L Bracket SML
(FF) x2
Dummy Fixing
Clip
x2 Inc Screws
BEFORE YOU START
INSTALLATION
SHOULD BE
PERFORMED BY A
COMPETENT
PERSON ONLY.
THIS PRODUCT COULD
BE DANGEROUS
IF INCORRECTLY
INSTALLED
Page 2
For Internal Use: FI.WR.INS.031_WKIN00110_BASE_600_BUOH_Rev8.indd
Step 3.
Attach panels (C) & (E) to panels (B),
using cam dowel (G) (in blue) and also
using dowels (F) (in orange) in positions
as shown.
Step 4.
Insert cam lock (H) and hand
tighten.
All Cam Locks (H) are to be positioned facing the
outside of the unit carcase, for ease of tightening. Do NOT use power tools with
cam dowel (G) or cam lock (H)
Dowel (F)
& Cam Dowel (G)
location detail
GG FF FF
FF F
FG
G
GG
GG
FF
FF
B
B
EE
C
B B
View from underside View from underside
BB
CC
H
H
G
G
Step 1.
Seat dowel (F)
into holes in
both end panels (B)
as shown.
Step 2.
Seat cam dowel (G) into
holes in both end panels (B)
as shown.
Seat (G)
cam dowel
into hole as
shown.
Page 3
BASE UNIT
600 Built Under Oven Housing Assembly Guide
Step 5.
Secure each of the legs into place with
4 x 15mm screws (L) as shown.
Leg position diagram
Front
C
B
B
B
B
E
B
C
Step 6.
Push leg rmly down into leg base.
Adjust legs to 155mm before turning unit upright. Once in situ
level accordingly.
LL
C
B
L
L
C
B
50mm
85mm
Page 4
For Internal Use: FI.WR.INS.031_WKIN00110_BASE_600_BUOH_Rev8.indd
Step 7.
Use 1 x 15mm screw (L) per L Bracket SML (FF) to
secure to inside face of Filler (G). Attached equally
spaced as shown.
Step 8.
Align Filler (G) to unit ensuring it is in line
with adjacent frontals.
With the Unit upside down secure Filler
(G) with 1 x 15mm Screw (L) per small L
bracket (FF) to base of unit as shown.
Flip unit upright and move into situ.
L
L
FF
FF
FF
Filler F
Filler G
24 mm
155mm 155mm
View of bottom of unit
From Top
Inside Face
inside face
G
FF
G
L Bracket
SML
G
Page 5
BASE UNIT
600 Built Under Oven Housing Assembly Guide
View from inside of unit
Worktop
Screw up through the front rail into your worktop to secure it in place.
Secure to wall
Screw through the back rail into the wall to secure the unit in place.
Securing To Adjacent Units
Screw into any side units using the 30mm screws (K) provided to secure
to unit. Screw at the top and bottom of both sides of the unit, place a
cover caps (M) on the head to conceal it.
L Brackets
Use 2 x 15mm screws (L) to secure each of the L brackets LGE to the unit
at either side.
Then screw up through into the worktop as shown.
L
L
K
Screws for attaching to walls and worktop are not provided as these vary depending on
materials, thickness and construction. Ensure appropriate xings for wall and worktop
construction are used. Please refer to the specialist worktop supplier if these are required for
solid surface worktops.
Page 6
For Internal Use: FI.WR.INS.031_WKIN00110_BASE_600_BUOH_Rev8.indd
Step 9.
Secure dummy xing clip (Parts B)
onto the inside face at the bottom
of panel (F), 56mm from the top
face and 22.5mm from the edges to
the screw hole of (Parts B), spaced
evenly either side as shown, using 1
x 21mm screw per dummy xing clip
(Parts B). Align so ller is in line with
adjacent frontals.
Step 11.
Align and push panel (F) into place.
Ensure ller is in line with adjacent
frontals. Space appropriately from
unit.
Part A
Part A
74mm
22.5mm 22.5mm
From Top
inside face
Inside Face
From Top
F
B
View from inside of unit
FB
B
Dummy Fixing Clip
Panel B
Step 10.
Secure dummy xing clip (Parts
A) onto both end panels (B)
using 2 x15mm screws (L) each,
as shown. The bottom screw hole
is to be positioned 74mm from
the top of the panel using the pre
drilled hole.
Part B
F
F
Part B
Front
L
B
E
56mm
56mm
