Bayliner 185 User manual

Engine Serial Number: _____________________________________________
Hull Identification Number:__________________________________________
Hull Identification Number
•The Hull Identification Num-
ber (HIN) is located on the
starboard side of the transom.
•Record the HIN (and the
engine serial numbers) in the
space provided above.
•Please refer to the HIN for any
correspondence or orders.
© 2003 Bayliner Technical Publications. All rights reserved.
No part of this publication may be reproduced, stored in any retrieval system, or transmitted in any form by any means, electronic, mechanical, photocopying,
recording or otherwise, without prior written permission of Bayliner.
Printed in the United States of America.
General Notes
The material in this document is for information only and is subject to change without notice. While reasonable efforts have been made in the preparation of this
document to assure its accuracy, Bayliner assumes no liability resulting from errors or omissions in this document, or from the use of information contained herein.
Due to our commitment to product improvement, Bayliner reserves the right to make changes in the product design, specifications, and equipment at any time
without notice or obligation. Illustrations and/or photos may show optional equipment.
All Bayliner products meet or exceed USCG (Unites States Coast Guard) and/or NMMA (National Marine Manufacturer’s Association) construction standards.
Manufactured with 1,1,1 Trichloroethane, a substance which harms public health and environment during the manufacturing process by destroying ozone in the
upper atmosphere.
Proprietary Rights
This document discloses subject matter in which Bayliner has proprietary rights. The information and design disclosed herein were originated by and are the prop-
erty of Bayliner. Neither receipt nor possession thereof confers or transfers any right to reproduce, copy, alter or disclose the document or any part thereof, any
information contained therein, or to construct boats or any item from it, except by written permission from or written agreement with Bayliner. This document is to
be returned upon request to Bayliner.
HIN LOCATION

CONTENTS
1 Chapter 1: Welcome Aboard!
1 Dealer Service
1 Warranty Information
1 Boating Experience
2 Safety Standards
2 Engine & Accessories Guidelines
3 Engine & Accessories Literature
3 Qualified Maintenance
3 Special Care For Moored Boats
4 Carbon Monoxide (CO)
4 Facts about CO
5 Where and How CO Can Accumulate
5 How to Protect Yourself and Others From CO
6 Trip Checklist
6 Monthly Checklist
6 Annual Checklist
6 More Information
7 Chapter 2: Product Specifications
7 185
8 205
9 225
10 Chapter 3: Locations
10 Exterior Views
10 Hull Views
11 Extended Swim Platform (If Equipped)
12 185 Deck View
13 205 Deck View
14 225 Deck View
15 Component Locations
16 Chapter 4: Propulsion &
Related Systems
16 Engine
16 Engine Room Ventilation System
17 Fuel System
17 Fuel Fill and Vent
17 Fuel Filters
18 Chapter 5: Controls & Gauges
18 Steering
18 Shift/Throttle Lever
18 Power Trim and Tilt
18 Gauges
18 Cleaning Gauges
18 Gauge Fogging
18 Radio Transmission Interference
18 Fuel Gauge
19 Chapter 6: Plumbing
19 Bilge Pump
21 Auto-float Switch (225 Only)
22 Freshwater Transom Shower (If Equipped -
225 Only)
24 Chapter 7: Deck Equipment
24 Cleats and Tow Eyes
24 Ski Tow Ring
25 Ski-Tow Tower (If Equipped)
25 Attaching the Ski-Tow Rope
26 Folding Ski-Tow Tower (205 & 225 Only)
27 Canvas (If Equipped)
27 Convertible Top
28 Side Curtains (If Equipped)
29 185 Bimini Top (If Equipped)
30 205/225 Bimini Top (If Equipped)
31 Bow Cover (If Equipped)

32 Chapter 8: Entertainment Systems
32 Audio System
33 Chapter 9: Convertible Seats,
Beds, & Tables
33 Sleeper Seats (If Equipped - 185/205 Only)
33 Operating Positions
33 Lounge positions
34 Jump Seat To Sunlounge Conversion (If
Equipped - 185/205 Only)
35 Passenger Seat to Lounge Conversion
(225 Only)
37 Chapter 10: Lights
37 Care and Maintenance
37 Navigation Lights
38 Chapter 11: Electrical System
39 12-Volt DC System
39 Battery
39 Fuses and Circuit Breakers
39 Alternator
39 12-Volt Accessory Outlet(s)
40 Electrical Routings
40 185 & 205 Deck Electrical Harness
41 225 Deck Electrical Harness
42 Hull Electrical Harness
43 Wiring Diagrams
43 185 & 205
44 225
45 Important Records
46 Float Plan

Hazard Boxes & Symbols
The hazard boxes and symbols shown below are used throughout this supplement to call attention to potentially dan-
gerous situations which could lead to either personal injury or product damage. Read ALL warnings carefully and
follow all safety instructions.
DANGER!
!
This box alerts you to immediate hazards which WILL cause severe personal injury or death if
the warning is ignored.
This box alerts you to hazards or unsafe practices which COULD result in severe personal
injury or death if the warning is ignored.
WARNING!
!
This box alerts you to hazards or unsafe practices which COULD result in minor personal
injury or cause product or property damage if the warning is ignored.
CAUTION!
!
NOTICE
This box calls attention to installation, operation or maintenance information, which is impor-
tant to proper operation but is not hazard related.
EXPLOSION
HAZARD! NO OPEN FLAME! HOT HAZARD!
ROTATING
PROPELLER HAZARD!
FALLING
HAZARD!
ELECTRICAL
HAZARD!
CO POISONING
HAZARD!
FIRE
HAZARD!
RUN BILGE BLOWERS
FOR 4 MINUTES!

1
185, 205 & 225 •Owner’s Manual Supplement
Chapter 1: Welcome Aboard!
This Owner’s Manual Supplement provides specific information about your boat that is not covered in the Sport Boat
Owner’s Manual. Please study the Sport Boat Owner’s Manual and this supplement carefully. Keep the Sport Boat
Owner’s Manual and this supplement on your boat in a secure, yet readily available place.
Dealer Service
•Your dealer is your key to service.
•Ask your dealer to explain all systems before taking delivery of your boat.
•Contact your dealer if you have any problems with your new boat.
•If your dealer cannot help, call our customer service hotline: [phone] or send us a FAX: [phone].
•Buy replacement parts from any authorized Bayliner dealer.
Warranty Information
•Bayliner offers a Limited Warranty on each new Bayliner purchased through an authorized Bayliner dealer.
•A copy of the Limited Warranty was included in your owner’s packet.
•If you did not receive a copy of the Limited Warranty, please contact your dealer or call 360-435-8957 for a copy.
Boating Experience
If this is your first boat or if you are changing to a type of boat you are not familiar with, for your own comfort and
safety, obtain handling and operating experience before assuming command of the boat.
Take one of the boating safety classes offered by the U.S. Power Squadrons or the U.S. Coast Guard Auxiliary. For
more course information, including dates and locations of upcoming classes, contact the organizations directly:
•U.S. Power Squadrons: 1-888-FOR-USPS (1-888-367-8777) or on the Internet at: http://www.usps.org
•U.S. Coast Guard Auxiliary: 1-800-368-5647 or on the Internet at: http://www.cgaux.org
Outside the United States, your selling dealer, national sailing federation or local boat club can advise you of local
sea schools or competent instructors.
CONTROL HAZARD!
A qualified operator must be in control of the boat at all times. DO NOT operate your boat
while under the influence of alcohol or drugs.
WARNING!
!

Chapter 1: Welcome Aboard! 185, 205 & 225 •Owner’s Manual Supplement
2
Safety Standards
•Your boat’s mechanical and electrical systems were designed to meet safety standards in effect at the time it
was built.
•Some of these standards were mandated by law, all of them were designed to insure your safety, and the safety of
other people, vessels and property.
In addition to this Owner’s Manual Supplement, please read the Sport Boat Owner’s Manual and all accessory
instructions for important safety standards and hazard information.
Engine & Accessories Guidelines
•Your boat’s engine and accessories were selected to provide optimum performance and service.
•Installing a different engine or other accessories may cause unwanted handling characteristics.
•Should you choose to install a different engine or to add accessories that will affect the boat’s running trim, have
an experienced marine technician perform a safety inspection and handling test before operating your boat again.
Certain modifications to your boat can result in cancellation of your warranty protection. Always check with
your dealer before making any modifications to your boat.
FALLING and ROTATING PROPELLER HAZARD!
NEVER allow anyone to ride on parts of the boat not designed for
such use.
•Sitting on seat backs, lounging on the forward deck, bow riding, gunwale riding or occupy-
ing the transom platform while underway is especially hazardous and will cause personal
injury or death.
DANGER!
!
ROTATING PROPELLER and CARBON MONOXIDE
POISONING HAZARD!
•NEVER allow anyone to occupy, or hang from, the
back deck or swim platform while the engine(s)
are running.
•Teak surfing, dragging, or water skiing within 20 feet
of a moving watercraft can be fatal.
DANGER!
!
PERSONAL SAFETY HAZARD!
ALWAYS secure the anchor and other loose objects before getting underway. The anchor and
other items that are not properly secured can come loose when the boat is moving and cause
personal injury or death.
DANGER!
!
When storing your boat please refer to your engine’s operation and maintenance manuals.
NOTICE

185, 205 & 225 •Owner’s Manual Supplement Chapter 1: Welcome Aboard!
3
Engine & Accessories Literature
•The engine and accessories installed on your boat come with their own operation and maintenance manuals.
•Read and understand these manuals before using the engine and accessories.
•Unless noted otherwise, all engine and accessory literature referred to in this supplement is included in your
owner’s packet.
Qualified Maintenance
•Failure to maintain your boat’s systems (listed in the warning above) as designed could violate the laws in your
jurisdiction and could expose you and other people to the danger of bodily injury or accidental death.
•Follow the instructions provided in the Sport Boat Owner’s Manual, this Owner’s Manual Supplement, the engine
owner’s manual and all accessory instruction sheets and manuals.
Special Care For Moored Boats
•Whether moored in saltwater or freshwater, your boat will collect marine growth on its hull bottom.
•This will detract from the boat’s beauty, greatly affect its performance and may damage the gelcoat.
•Periodically haul the boat out of the water and scrub the hull bottom with a bristle brush and a solution of soap
and water.
To maintain the integrity and safety of your boat, allow only qualified personnel to perform
maintenance on, or in any way modify: The steering system, propulsion system, engine control
system, fuel system, environmental control system, electrical system or navigational system.
WARNING!
!
•To help seal thehull bottom and reduce the possibility of gelcoatblistering on moored boats,
apply an epoxy barrier coating. The barrier coating should be covered with several coats of
anti-fouling paint.
•Many states regulate the chemical content of bottom paints in order to meet environmental
standards. Check with your local dealer about recommended bottom paints, and about the
laws in effect in your area.
NOTICE

Chapter 1: Welcome Aboard! 185, 205 & 225 •Owner’s Manual Supplement
4
Carbon Monoxide (CO)
Facts about CO
•CO poisoning causes a significant number of boating deaths each year.
•Called the "silent killer", CO is an extremely toxic, colorless, odorless and tasteless gas.
•CO can harm or even kill you inside or outside your boat.
•CO can affect you whether you’re underway, moored, or anchored.
•CO symptoms are similar to seasickness or alcohol intoxication.
•CO can make you sick in seconds. In high enough concentrations, even a few breaths can be fatal.
•Breathing CO blocks the ability of your blood to carry oxygen.
•The effects are cumulative, even low levels of exposure can result in injury or death.
Factors That Increase the Effects of CO Poisoning
•Age
•Smokers or people exposed to high concentrations of cigarette smoke
•Consumption of alcohol
•Lung disorders
•Heart problems
•Pregnancy
•Carbon monoxide gas (CO) is colorless, odorless, tasteless, and
extremely dangerous.
•All engines, generators, and fuel burning appliances produce CO
as exhaust.
•Prolonged exposure to low concentrations or very quick exposure to high
concentrations will cause BRAIN DAMAGE or DEATH.
•Teak surfing, dragging, or water skiing within 20 feet of a moving water-
craft can be fatal.
DANGER!
!
