bbf A151949E User manual

Part Number A151949E Keep manual for future reference.
Lot Code #
Half Heig t Door Kit

A151949E
Get Ready to Assemble

Warning Do Don't Why it's
important
Serious
injury may
occur.
• Assemble following all instructions using all
indicated parts and hardware provided.
• Install every indicated nail and/or screw.
Verify furniture is stable on it's own.
• Place heaviest items in the lower drawers or
shelves.
• Remove items that might tempt kids to climb,
such as toys and remote controls from the top
and upper shelves of furniture.
• Do not move unit when
loaded.
• Do not load with a television
or other heavy equipment.
• Do not exceed the maximum
load limits stated in the
instructions.
• Do not allow children to
stand, climb, or hang on
furniture.
Improper
assembly, use
or loading can
lead to product
instability, tip-over
or collapse.
Advertencia Hacer No Por qué es
importante
Se pueden
producir
lesiones
graves.
• Ensamble siguiendo todas las instrucciones
utilizando todas las piezas y ferretería indicados
provistos.
• Instale todos los clavos y / o tornillos indicados.
• Verique que los muebles sean estables por sí
mismos.
• Coloque los artículos más pesados en los
cajones o estantes inferiores.
• Retire los artículos que puedan tentar a los
niños a trepar, como juguetes y controles
remotos de los estantes superiores y superiores
de los muebles.
• No mueva la unidad
cuando esté cargada.
• No cargue con un televisor
u otro equipo pesado.
• No exceda los límites
máximos de carga
establecidos en las
instrucciones.
• No permita que los niños se
paren, trepen o cuelguen
de muebles.
El ensamblaje,
uso o carga
inadecuados
pueden provocar
inestabilidad del
producto, vuelco o
colapso.
PLEASE READ WARNINGS
Improper use can cause safety hazards, or damage
to your furniture and household items.
IMPORTANT SAFETY INFORMATION

A151949E
Get to know your Boards
Have an assembly question or need a replacement part? Just call
1-800-950-4782, we are ere to elp.
A

A151949E
Get to know your Hardware
Have an assembly question or need a replacement part? Just call
1-800-950-4782, we are ere to elp.
Hardware not to scale.
H77351 [ 1 ]
Bumper (4) per pack
H29206 [ 1 ]
Bumper (4) per pack
H126359 [ 4 ]
Hinge
H126364 [ 4 ]
Mounting Plate
H28917 [ 8 ]
#6 x 1/2"
[ 2 ]
Handle
[ 4 ]

1
STEP A151949E
Have an assembly question or need a replacement part? Just call
1-800-950-4782, we are ere to elp.
Assembly Options
WCxxx12
Left mounting option
Opción para montura izquierda
Option gauc e de montage
Rig t mounting option
Opción para montura derec a
Option droite de montage
Go to Step 3.
Proceda al paso 3.
Allez à l'étape 3.

2
STEP A151949E
Have an assembly question or need a replacement part? Just call
1-800-950-4782, we are ere to elp.
Assembly Option
WCxxx14
SCB136xx
Go to Step 6.
Proceda al paso 6.
Allez à l'étape 6.

3
STEP A151949E
Have an assembly question or need a replacement part? Just call
1-800-950-4782, we are ere to elp.
Prepare Door
H28917 [ 4 ]
#6 x 1/2"
H126359 [ 2 ]
Hinge
H77351 [ 2 ]
Bumper
[ 1 ]
Handle
A
[ 2 ]
H28917
H28917

4
STEP A151949E
Have an assembly question or need a replacement part? Just call
1-800-950-4782, we are ere to elp.
Attac Hardware
Left mounting option
Opción para montura izquierda
Option gauc e de montage
Rig t mounting option
Opción para montura derec a
Option droite de montage
H126364 [ 2 ]
Mounting Plate
Or
O
Ou

5
STEP A151949E
Have an assembly question or need a replacement part? Just call
1-800-950-4782, we are here to help
Install Door
A
Left mounting option
Opción para montura izquierda
Option gauche de montage
Team Lift
Congratulations! You are all done If you
have any questions or concerns, please call
Gently clean surfaces with
a damp sponge eraser

6
STEP A151949E
Have an assembly question or need a replacement part? Just call
1-800-950-4782, we are ere to elp.
Prepare Doors
H126359 [ 4 ]
Hinge
H28917 [ 8 ]
#6 x 1/2"
H29206 [ 2 ]
Bumper
A
A
[ 2 ]
Handle
[ 4 ]

7
STEP A151949E
Have an assembly question or need a replacement part? Just call
1-800-950-4782, we are ere to elp.
Attac Hardware
H126364 [ 4 ]
Mounting Plate

8
STEP A151949E
Have an assembly question or need a replacement part? Just call
1-800-950-4782, we are ere to elp.
Install Doors
A
A
Team Lift
Congratulations! You are all done. If you
ave any questions or concerns, please call.
Gently clean surfaces wit
a damp sponge eraser.

PARTS LIST A151949E
Have an assembly question or need a replacement part? Just call
1-800-950-4782, we are ere to elp.
H83027 [ 4 ]
M4 x 22mm
H92848 [ 4 ]
M4 x 25mm
H83027 [ 4 ]
M4 x 22mm
H128158 [ 2 ]
Handle
Z92376 [ 2 ]
Handle
H184439 [ 2 ]
Handle
WC12911,
WC24411,
WC36711
WC72411
SCB236WH, SCB236SG, SCB236PG,
SCB236BW, SCB236WH

PARTS LIST A151949E
Have an assembly question or need a replacement part? Just call
1-800-950-4782, we are ere to elp.
WC12911
A[ 2 ] W213918
WC24411
A[ 2 ] W213919
WC36711
A[ 2 ] W213920
WC72411
[ 2 ] W213921
A
A[ 2 ] W191952
SCB236WH
SCB236SG
[ 2 ] W189345
A
SCB236PG
A[ 2 ] W191695
SCB236BW
[ 2 ] W205562
A
SCB236MH
[ 2 ] W205563
A
