BCF Technology Easi-Scan User manual

Quick Guide
CH
CH4CH4
OVA R Y / E A R LYOVARY/EARLY
www.bcftechnology.com
Tel: [phone]
M10309010
Signal strength
Vent and
drainage holes
Keep clear of
debris
Low
High
Antenna area
Keep clear of
metal objects
Easi-Scan mode
Remote display
battery level
Low
High
Current channel
Switch through
available channels
Power LEDLong press: toggle on/off
Short press: flip image
Easi-Scan
battery level
Low High
Easi-Scan
battery doc
Stand
attachment
point
Serial number
Vent and
drainage holes
Keep clear of
debris
easi remote leaflet:Layout 1 14/10/10 16:10 Page 1

Care instructions
We have built the Easi-Scan remote display to be rugged and splash resistant, however,
it does contain sensitive electronics. With a little care and maintenance you will get many
years of excellent imaging.
Care
The Easi-Scan remote display will be damaged if you:
• Drop it.
• Hose it down.
• Wipe the screen with your hand.
For a long and happy life:
• Clean immediately after use — before any debris dry solid.
• Grit/mud should first be removed by rinsing gently — do not rub screen.
• Dry excess water off the housing with clean soft cloth — do not rub the screen.
• Only wipe the screen with a clean cloth.
• Secure in protective carry case or neoprene sleeve once clean and dry.
Specifications
Display size: 8.2" or 21cm diagonal
Luminance: 800 cd/m2
Contrast ratio: 1000:1
Battery life: 5 hours
Power source: Easi-Scan battery
Environmental proofing: IP65
Temperature range: –20°C to 50°C or –4°F to 122°F
Weight (with Easi-Scan battery): 1.65kg/3.64Ib
To be used with: Easi-Scan and Duo-Scan
Easi–Scan remote display has been designed to operate as a component of BCF ultrasound scanners and
as such the combined system conforms with the requirements of European Directive 89/336/EEC
relating to electromagnetic compatibility (EMC) and also 2002/95/EC relating to eduction of
Hazardous Substances ( oHS). If you require any further information regarding these directives please
contact us directly.
Note: All BCF Technology products are to be used for animal applications only.
For a list of BCF product distributors visit www.bcftechnology.com
© BCF Technology Ltd October 2010
UK Te : [phone] USA Te : [phone]
