BCP SKY2788 User manual

SKY2788 + SKY3688
Ver. 2
INSTRUCTION
MANUAL
Lift-Top Coee Table

Pg. 2
Please retain these instructions for future reference.
NOTICE
The following safety hazards may result in serious injury or death:
• Firmly secure all bolts, screws and knobs before use.
• Reconfirm that all bolts, screws, and knobs are secure every 90 days.
• Do not use or store this item in the proximity of open flame or flammable/combustible chemicals.
• Always lay components on a clean, soft-cushioned surface during assembly.
• Improper installation may cause damage to the product.
• Product is intended for indoor use only.
• If any parts are missing, broken, damaged, or worn, stop using this item until repairs are made and/or
factory replacement parts are installed.
• Do not use this item in a way inconsistent with the manufacturer’s instructions as this could void the
product warranty.
• To wipe down the furniture, use a damp cloth. Then, wipe it down once more with a dry cloth.
• Reconfirm that all bolts, screws, and knobs are secure every 90 days.
• Be aware that extra hardware may be included.

Pg. 3
APPROXIMATELY
45 MIN.
45LY
1 PERSON
ASSEMBLY APPROXIMATELY
45 MIN.
ASSEMBLY
1 PERSON
ASSEMBLY
PHILLIPS
SCREWDRIVER ELECTRIC DRILL
TOOLS REQUIRED
PARTS
HARDWARE
TABLETOP
PAD
M1
6PCS
WOOD SCREW CORNER
BRACKET
E4
44PCS
S1
4 PCS
1
1 PC
TABLETOP
INNER SHELF
5
1 PC
LEG
9
2 PCS
CAM COVER
40PCS
A
32 PCS
B
40 PCS
C
40 PCS
DOWEL CAM BOLT CAM LOCK
2
2 PCS
BOTTOM SHELF
END PANEL
6
1 PC
3
2 PCS
DIVIDER
BASEBOARD
7
2 PCS
4
2 PCS
SIDE PANEL
LEG
8
2 PCS
P
2 PCS
LIFT HINGE
10

Pg. 4
Insert four part A dowels, four part B cam bolts, and four part C cam locks into each part 2 end panel.
Insert four part A dowels and four part C cam locks into part 3 dividers.
TOOLS REQUIREDPRODUCT ASSEMBLY
1
2
C
3
A
B
C
2
A

Pg. 5
Insert two part B cam bolts and four part C cam locks into each part 4 side panel.
Insert eight part A dowels, four part B cam bolts, and eight part C cam locks into part 5 inner shelf.
TOOLS REQUIREDPRODUCT ASSEMBLY
3
4
5
B
C
4
A
C
B

Pg. 6
Insert four part A dowels and four part B cam bolts into the top end of part 6 bottom shelf.
Then insert four part A dowels, four part B cam bolts, and four part C cam locks into the bottom end of
part 6 bottom shelf.
Insert two part A dowels and two part C cam locks per baseboard.
Align two part S1 corner brackets with dowel housings. Then, use drill to attach brackets to
baseboard with two part E4 wood screws per bracket. Repeat with remaining baseboard.
TOOLS REQUIREDPRODUCT ASSEMBLY
5
6
B
B
C
6
6
A
A
BOTTOM
TOP
A
C
7
E4
S1

Pg. 7
Insert five part B cam bolts into each part 8 and 9 legs.
Attach part 8 and 9 table legs to part 2 end panels.
TOOLS REQUIREDPRODUCT ASSEMBLY
7
8
8
9
B
B
9
2
8

Pg. 8
Use drill to attach part 10 lift hinges to end panels with eight part E4 wood screws each.
Insert part 4 side panels into part 5 inner shelf.
TOOLS REQUIREDPRODUCT ASSEMBLY
9
10
10
E4
4
4
5

Pg. 9
Use drill to attach part 7 baseboards to part 6 bottom shelf with four part E4 wood screws.
Connect part 5 inner panels to part 6 bottom shelf with two part 3 dividers.
TOOLS REQUIREDPRODUCT ASSEMBLY
11
12
6
7
6
5
3
7
E4
E4

Pg. 10
Attach part 2 end panels to inner shelf and bottom shelf.
Place part M1 tabletop pads on the tops of each part 8 and 9 legs. Then apply part P cam covers
over each exposed cam lock.
TOOLS REQUIREDPRODUCT ASSEMBLY
13
14
2
2
9
9
8
8
M1
M1
M1
M1
M1
M1
P
