BDS MAB 825 V Quick guide

MAB 825 V/ MAB 845 V
Translation of the Original
Operating Instructions
GB

Fig. 1
21
23
22
23
5
12
9
7
10
6
8
4
3
2
1
11
Fig. 2
31
32
13
14
16
17
18
19
15

3MAB 825 V/845 V
GB
Table of contents
General instructions ................3
Safety ............................5
Components / delivery contents .....10
Before using for the rst time .......11
Preparation. . . . . . . . . . . . . . . . . . . . . . .11
Using............................16
Eliminating blockages. . . . . . . . . . . . . .22
Cleaning/maintenance .............22
Storage ..........................23
Troubleshooting ..................24
Technical data ....................25
EC Declaration of Conformity .......26
Dear Customer,
Before using the machine, please read the
operating instructions contained in these
operating instructions on startup, safety,
intended use as well as cleaning and care.
The links and illustrations in these instruc-
tions refer to the illustrations on the inside
of the cover.
Keep these operating instructions for later
use and pass them onto the next owner of
the machine.
General instructions
Copyright
This document is subject to copyright. Du-
plication or reprinting, even in part as well
as reproduction of the illustrations, even
if modied, is only permitted with written
consent of the manufacturer.
Liability disclaimer
All technical information, data and in-
structions contained in these operating
instructions for startup, operation and care
correspond to the latest requirements at the
time of printing.
The manufacturer assumes no liability for
damage or injury resulting from failure to
observe the operating instructions, use for
other than the intended purpose, unprofes-
sional repairs, unauthorised modications
or use of non-approved spare parts and
accessories, tools and lubricants.
Instructions on disposal
The packaging materials used can be
recycled. When no longer required,
dispose of the packing materials according
to local environmental regulations.
This product may not be disposed of
in the European Union via the normal
household refuse. Dispose of the
device via communal collection points.
The lubricant used can contain
substances dangerous to the
environment. Dispose of the lubricant
according to local regulations. Observe the
disposal instructions from the lubricant
manufacturer.
General instructions

4MAB 825 V/845 V
GB
Safety warning structure
The following warnings are used in these
operating instructions:
DANGER
A warning of this category indicates
an impending dangerous situation.
If the dangerous situation is not avoid-
ed, it may lead to serious injury or even
death.
►Follow the instructions in this warning
to avoid possible danger of serious
injury or even death.
WARNING
A warning of this category indicates a
potentially dangerous situation.
If the dangerous situation is not avoid-
ed, it may lead to serious injury or even
death.
►Follow the instructions in this warning
to avoid the danger of serious injury
to persons.
ATTENTION
A warning of this category indicates
potential danger to property.
If the situation is not avoided, it may lead
to material damage.
►Follow the instructions in this warning
to avoid material damage.
NOTE
►A note indicates additional information
that simplies the use of the machine.
Intended use
The machine is intended solely for drilling
operations in magnetic and non-magnetic
metals, and for cutting threads, counter-
sinking and reaming within the limits speci-
ed in the technical data.
Any use other than previously stated is
considered as improper use.
WARNING
Danger due to improper use!
If not used for its intended purpose and/
or used in any other way, the machine
may be or become a source of danger.
►Use the machine only for its intended
purpose.
►Observe the procedures described in
these operating instructions.
No claims of any kind will be accepted for
damage resulting from use of the system
for other than its intended purpose.
The risk must be borne solely by the user.
NOTE
►If used commercially, pay attention to
compliance with the accident preven-
tion and occupational safety regula-
tions.
General instructions

5MAB 825 V/845 V
GB
Safety
NOTE
When using electrical tools, the following
fundamental precautions must be taken
to protect against electric shock, re,
injuries and damage to property!
Fundamental safety instructions
■Do not use the machine in potentially
ammable or explosive environments.
■Persons, who are unable to safely op-
erate the machine due to their physical,
mental or motor abilities, my only use
the machine under the supervision or
instruction of a person responsible.
■Persons with heart pacemakers or other
medical implants must not use this
machine.
■Children are not permitted to use the
machine.
■Inspect the machine for visible signs of
damage before use. Do not operate a
damaged machine.
■Before beginning work, check the condi-
tion of the safety chain.
■Before beginning work, check the con-
dition of the machine and the function of
the operating elements.
■Repairs to the connecting cable may
only be performed by a qualied elec-
trician.
■Repairs to the machine may only be
performed by an authorised specialist
workshop or factory customer service.
Unqualied repairs can lead to consid-
erable danger for the user.
■Repairs to the machine during the guar-
antee period may only be performed by
a customer service authorised by the
manufacturer, otherwise the guarantee
is invalid.
■Defective parts may only be replaced
with original spare parts. Only these
parts ensure that the safety require-
ments are met.
■Do not leave the machine unsupervised
during operation.
■Store the machine in a dry, temperate
location out of the reach of children.
■Do not allow the machine to stand out-
side and do not expose to moisture.
■Make sure that your work area is su󰀩-
ciently lit (>300 Lux).
■Do not use low-power machines for
heavy working.
■Pay attention to cleanliness at the
workplace.
■Keep the machine clean, dry and free of
oil and grease.
■Follow the instructions on lubricating
and cooling the tool.
Safety

6MAB 825 V/845 V
GB
Danger from electric current!
DANGER
Danger to life from electrical current!
Contact with live wires or components
can lead to serious injury or even
death!
Observe the following safety precautions
to avoid any danger from electric current:
►Do not open the housing of the
machine. Risk of electric shock from
touching live connections.
►Never immerse the machine or mains
plug in water or other liquids.
►Only use extension cables or cable
drums with a cable cross-section of at
least 1.5 mm².
►Only use extension cables that are
approved for the location of use.
►Check the condition of the extension
cable regularly and replace if dam-
aged.
►Avoid bodily contact with grounded
parts (e.g., pipes, radiators, steel
girders) to reduce the risk of electric
shock in the event of a defect.
►When using the machine outside or in
a humid environment, an RCD (resid-
ual circuit device) must be used.
Risk of injury!
WARNING
Risk of injury from engine starting
unintentionally!
Pay attention to the following safety
notes to avoid danger from motor starting
unintentionally:
For safe stopping of the motor:
►Press the red button (O) of the motor
switch (21).
►Switch o󰀨 the machine with the ON/
OFF switch (main switch) (23).
►Disconnect the voltage supply (pull
out the mains plug).
WARNING
Improper handling of the machine
increases the risk of injury!
Pay attention to the following safety
instructions in order not to injure others
or yourself:
►Operate the machine only with the
protective equipment specied in
these instructions (see section “Per-
sonal protective equipment”).
►Do not wear protective gloves when
the machine is running. A glove can
be caught by the drilling machine and
torn o󰀨 the hand. Risk of losing one
or more ngers.
►Remove loose jewellery before begin-
ning work.
►Wear a hair net if you have long hair.
Safety

7MAB 825 V/845 V
GB
WARNING
►Always switch o󰀨 the machine before
changing tools, performing main-
tenance or cleaning. Wait until the
machine has come to a complete
standstill.
►Always remove the plug from the
mains socket before changing tools,
cleaning or performing maintenance
work in order to avoid unintentional
starting of the machine.
►Do not put your hand into the ma-
chine while it is in operation. Remove
swarf only when the machine is at
a standstill. Wear protective gloves
when removing swarf.
►When working on sca󰀨olding, the op-
erator must be secured with a safety
belt as the machine can oscillate dan-
gerously in the event of interruption to
the power supply.
►Check for secure clamping of the
electromagnets on the substrate be-
fore every use (see section “Prepa-
ration”).
►Secure the machine with the safety
chain (D) supplied when working in
an inclined or vertical position and
during overhead work. The machine
could fall down if the magnet is loos-
ened or the power fails.
►Check that the tool is tightened
securely before using (see section
“Inserting the tool”).
►Do not allow the connecting cable to
hang over edges (trip e󰀨ect).
Transporting the machine
WARNING
Danger resulting from the heavy
weight of the machine!
Due to the heavy weight of the machine,
observe the following instructions
►Only transport the machine with a
suitable means of transport.
►Lifting the machine manually should
be carried out by two persons.
►When transporting the machine with a
crane, use suitable lifting equipment.
Pay attention to the carrying capacity
of the lifting equipment.
Preventing damage
ATTENTION
Potential damage to property if the
machine is improperly used!
Observe the following instructions to
avoid damage to property:
►Before connecting the machine, com-
pare the connection data (voltage and
frequency) on the rating plate with
those of your mains power supply.
The data must correspond in order to
avoid damage to the machine.
►Always use the handle to carry the
machine and not the connecting
cable.
►Do not pull the mains cable to remove
the plug from the mains socket.
Safety

8MAB 825 V/845 V
GB
ATTENTION
►Do not crush the connecting cable.
►Do not subject the connecting cable
to heat or chemical liquids.
►Do not pull the connecting cable
across sharp edges or hot surfaces.
►Lay the connecting cable in such
a way that it cannot be caught and
wound up in the rotating part of the
machine.
Safety equipment
Restart protection
NOTE
►The machine stops automatically
when the magnetic clamp is switched
o󰀨 or if the power supply is interrupt-
ed.
In order to prevent the machine from
starting unexpectedly after switching on the
magnetic clamp again or after reconnection
following interruption to the power supply
("restart protection"), the machine must be
switched on using the ON/OFF switch.
Magnet indicator
The magnet indicator (22) provides a visual
indication of the magnetic clamping force.
■Magnet indicator (22) lights up GREEN:
The magnetic clamping force satises
the minimum requirements.
Machining can be carried out.
■Magnet indicator (22) lights up RED:
Insu󰀩cient magnetic clamping force.
Do not operate the machine. This can
be the case in the event of insu󰀩cient
material thickness, uneven surface or
due to paint, scale or zinc coatings.
Overheat protection
The machine is also protected against
overheating. If the machine becomes too
hot, it switches o󰀨 automatically.
Perform the following steps before continu-
ing to work with the machine:
■Remove any blockages that may have
occurred.
(see section “Eliminating blockages”)
■Allow the machine to run at idle for
approx. 2 minutes.
The machine is then ready for operation
again.
Safety

9MAB 825 V/845 V
GB
Slip clutch
If the drill blocks, the gearbox is protected
by a slip clutch.
"Safety Control" shutdown
The "Safety Control" switches the machine
o󰀨 as soon as the magnet is triggered by
the automatic feed.
This is designed to prevent the machine
from running without magnetic holding
force.
There is no pressure monitoring for the
automatic feed.
This safety equipment is not designed as
protection against tool breaking.
Perform the following steps before continu-
ing to work with the machine:
■Reduce the feed rate and restart the
drilling process (see section “Automat-
ic feed”).
Symbols on the machine
The symbols on the machine have the
following meaning:
Symbol Meaning
Electric shock hazard!
Heavy load
Read the operating instructions
before beginning work!
Wear protective goggles and
ear protection!
Personal protective equipment
Wear the following protective equipment at
all times when operating the machine:
Symbol Meaning
Close-tting work protection
clothing with a low tear strength
Goggles for protecting eyes
against ying parts and liquids
and ear protection in areas with
noise emission >80 dB(A)
Safety shoes for protecting feet
against falling objects.
Also wear the following protective equip-
ment during special work:
Symbol Meaning
Helmet for protecting your head
against falling objects
Wear a harness where there is
a danger of falling.
Gloves for protection against
injuries
Safety

10 MAB 825 V/845 V
GB
Components / delivery con-
tents
Machine overview
1 Magnetic foot
2 Control panel for "Automatic Feed" (see
g.3)
3 Handle
4 Lubrication/coolant tank
5 Filling neck with cap
6 Tool holder
7 MK3 spindle taper
8 Opening for ejector pin
9 Selection lever right (gear stage)
10 4-speed gearbox with selector
11 Engine drive
12 Hand lever
13 Control for engaging the "Automatic
Feed"
(see g. 6 and 7)
14 Operating panel (see g. 1)
15 Rotating mechanism (MAB 845V only)
16 Speed and torque control (see g. 2)
17 Selection lever left (gear stage)
18 Machine slide and guide
19 Connection for internal lubrication
Operating panel
(see g. 1)
21 Motor ON/OFF switch
22 Magnet indicator (Magnet Power)
23 Magnet ON/OFF switch
(main switch)
24 Direction of rotation switch
(see g. 2)
31 Speed setting
32 Torque setting
(see g. 3)
41 "POWER - Automatic Feed"
indicator
42 "ALARM - Automatic Feed"
indicator
43 "Automatic Feed LOW/HIGH"
speed selection rotary control
Scale mark 0 - 3:
Feed rate
Scale mark 4 - 10:
Rapid feed
44 "Automatic Feed"
RUN/STAND-BY selector switch
45 "Automatic Feed" UP/DOWN
direction of motion selector switch
Scope of supply
MAB 825 V/845 V core drilling ma-
chine
A Industrial holder with automatic inter-
nal lubrication:
MK3/19 mm Weldon (ZIA 319-KN)
and
MK3/32 mm Weldon (ZIA 332-KN)
B ZAK 075 ejector pin
C ZAK 090 ejector pin
D ZAK 100 ejector pin
E ZAK 120 ejector pin
F Safety chain
G MK3 ejector pin
H Hexagonal screwdriver, SW6 + SW8,
SW10 (MAB 845V only)
Transport case (not illustrated)
Operating instructions/guarantee card
(not illustrated)
Components / delivery contents

11MAB 825 V/845 V
GB
Before using for the rst time
Transport inspection
As standard, the machine is supplied with
the components indicated in the “Scope of
supply” section.
NOTE
►Check for visible signs of damage or
missing items on delivery. Report an
incomplete or damaged delivery to
your dealer/supplier immediately.
Preparation
This section contains important instructions
on the required preparation before begin-
ning any work.
Additional safety measures for
certain work
Additional safety precautions must be
taken for the following operations with the
machine:
Non-horizontal work position
WARNING
Risk of injury from a falling machine.
When working in inclined or vertical
position and during overhead work, the
machine must be secured to prevent it
from falling using the safety chain (F)
supplied.
►Check the safety chain for proper
function before every use. A dam-
aged safety chain must not be used.
Replace a damaged safety chain
immediately.
WARNING
►Attach the safety chain in such a way
that the machine moves away from
the operator in the event of slipping.
►Lay the safety chain as tightly as
possible around the handle of the
machine.
►Check the secure tting of the safety
chain and lock before starting work.
►Use the protective equipment stipulat-
ed in the section “Personal protec-
tive equipment”.
Work on sca󰀨olding
WARNING
Risk of falling from sudden oscillating
movements of the machine.
When working on sca󰀨olding, the
machine can make a sudden oscillating
movement on starting or in the event of
interruption to the power supply.
►Secure the machine with the en-
closed safety chain (F).
►Wear a safety harness to protect
yourself against falling.
Before using for the rst time

12 MAB 825 V/845 V
GB
Check the condition
of the substrate
The magnetic holding force is dependent
on the condition of the substrate. The
clamping force is signicantly reduced by
paint, zinc and scale coatings and rust.
The substrate must satisfy the following
conditions in order to achieve su󰀩cient
magnetic holding force:
■The substrate must be magnetic.
■The clamping surface and the magnetic
foot (1) must be clean and grease-free.
■The clamping surface must be com-
pletely smooth and level.
NOTE
►Clean the substrate and the magnetic
foot (1) of the machine before use.
►Remove any unevenness and loose
rust from the substrate.
►The BDS range of accessories in-
cludes special holding devices.
The best clamping e󰀨ect is obtained on
low-carbon steel substrate with a thickness
of at least 20 mm.
Steel with low thickness
When drilling into low thickness steel, an
additional steel plate (minimum dimensions
100 x 200 x 20 mm) must be placed under
the workpiece. Secure the steel plate to
prevent it from falling.
NF metals or workpieces with an uneven
surface
A special holding device must be used
when drilling into NF metals or into work-
pieces with an uneven surface.
NOTE
►BDS o󰀨ers a range of accessories
with special clamping devices for
tubes and non-magnetic materials.
Preparing

13MAB 825 V/845 V
GB
Dismantling/assembling the tool
holder
WARNING
Risk of injury!
►Only dismantle/mount the tool holder
when the machine is switched o󰀨 and
at a standstill. Pull the plug out of the
mains socket.
►After mounting, check for secure
seating of the tool holder.
►Only use the tool holders appropriate
to this machine.
Dismantling the tool holder
Turn the tool holder (6) until the ejec-
tor pin (G) slips into the opening for
the ejector (8).
Lever out the tool holder with the
ejector (G) or loosen the by knocking
the ejector pin.
Remove the tool holder (6) out of the
spindle taper (7) from below.
NOTE
►Keep the tool holder in the transport
case for later use.
Assemble the tool holder
Before inserting, clean the shank
of tool holder (6) and the spindle
taper (7).
Insert the tool holder (6) from below
into the spindle taper (7) of the ma-
chine.
Inserting the tool
WARNING
Risk of injury!
►Do not use damaged, soiled or worn
tools.
►Change tools only when the machine
is switched o󰀨 and at a standstill. Pull
the plug out of the mains socket.
►After inserting, check that the tool is
engaged securely.
►Only use tools, adapter and accesso-
ries that match the machine.
The machine is equipped with an MK tool
holder.
Depending on the type of tool to be used,
corresponding tool holders, drill chucks or
adapters must be employed.
Tool
with:
Tool holder
to be used
MK3 cone Insert directly into the spindle
taper (7).
MK2 cone Use a MK3:2 adapter sleeve
and insert directly into the
spindle taper (7)
(available as accessory).
19 mm Wel-
don shaft
Use MK3/Weldon 19mm (A)
tool holder (ZIA 319).
32 mm Wel-
don shaft
Use MK3/Weldon 32mm (A)
tool holder (ZIA 332).
Preparing

14 MAB 825 V/845 V
GB
Straight
shank
Use drill chuck with MK3/B16
tapered mandrel
(available as accessory).
Thread
tap
Use tool holder with Weldon
shank and suitable adapter
for thread taps
(available as accessory).
NOTE
►To insert the tools, the tool holder
must be mounted or dismantled
(see section “Dismantling/assem-
bling the tool holder”).
Weldon industrial tool holder (Fig. 4)
Inserting the tool
Push the MK3 industrial holder/
Weldon 32 mm (6) into the spindle
taper (7) of the machine.
Before inserting, clean the Weldon
shank of the tool and the tool holder.
Loosen both hexagonal socket screws
in the tool holder (g.4) using the hex-
agonal screwdriver supplied.
Insert the tool into the tool holder from
below.
NOTE
►For tools with 19 mm Weldon shank,
use the MK3/Weldon 19 mm tool
holder.
►Insert the appropriate ejector pin
(B, C, D, E) before inserting a core
drill.
Tighten both hexagonal socket screws
in the tool holder using the hexagonal
screwdriver (H) supplied.
Removing the tool
Loosen both hexagonal socket screws
in the tool mount using the hexagonal
screwdriver (H) supplied and remove
the tool from below.
MK tool/industrial tool holder
Inserting the tool
Before tting, clean the tool shank,
adapter or industrial tool holder and
the spindle taper (7) of the machine.
Insert the tool into the spindle taper (7)
of the machine from below.
NOTE
►When using tools/adapters with MK2
taper, use MK3:2 adapter sleeve.
Removing the tool
Turn the tool until the ejector pin (G)
slips into the opening for the ejector
pin (8).
Lever out the tool with the ejector
pin (G) or loosen the tool by tapping
against the ejector pin.
Preparing

15MAB 825 V/845 V
GB
Using the drill chuck
WARNING
Risk of injury!
An insu󰀩ciently secured tool can lead to
serious injuries.
►Turn the drill chuck only with the
chuck key provided.
►Always remove the chuck key from
the drill chuck after tightening or
loosening.
Inserting the drill chuck
Insert the drill chuck onto the tapered
mandrel and insert the combination
into the spindle taper (7) of the ma-
chine. If necessary, use an adapter
sleeve.
Open the drill chuck and insert the tool
into the drill chuck.
Close the drill chuck by hand and then
turn the drill chuck with the chuck key.
Removing the drill chuck
Loosen the drill chuck with the chuck
key and remove the tool.
Turn the drill chuck until the ejector
pin (G) slips into the opening for the
ejector pin (8).
Lever out the drill chuck with the ejec-
tor pin (G) or loosen the drill chuck by
tapping against the ejector pin.
Adapter for drill taps (Fig. 5)
Inserting the tool
Insert the tool holder with Weldon
shank into the spindle taper (7) of the
machine.
Insert the drill tap into its matching
adapter.
Insert the drill tap with adapter into the
industrial tool holder.
Tighten both hexagonal socket screws
in the tool holder.
Removing the tool
Loosen both hexagonal socket screws
in the tool holder and remove the
adapter with thread tap from below.
Remove the drill tap by pulling it down-
wards out of its adapter.
Preparing

16 MAB 825 V/845 V
GB
Using
Activating/deactivating the mag-
netic clamp
Activating the magnetic clamp
ATTENTION
►To prevent the magnet from overheat-
ing, switch on the magnetic clamp
only when the machine is standing on
a magnetic substrate.
Switch the magnet (23) ON/OFF
switch on. The indicator lamp in the
magnet (23) ON/OFF switch on.
Check the magnet holding force with
the magnet indicator ("MAGNET
POWER" (22) indicator light).
MAGNET POWER
indicator light
Magnetic holding
force condition
GREEN Su󰀩cient
magnetic holding
force
RED Insu󰀩cient magnet-
ic holding force
ATTENTION
►The maximum magnetic holding force
is only available after switching on the
motor.
Deactivating the magnetic clamp
Hold the handle tightly (3) to stop the
machine from slipping.
Turn the magnet ON/OFF switch (23)
o󰀨. The indicator lamp in the magnet
ON/OFF switch (23) extinguishes.
Switching the machine ON/OFF
Using the ON/OFF switch (21), turn
the machine ON with the green
button (I) and OFF with the red but-
ton (O).
NOTE
►The machine can only be switched on
when the magnetic clamp has been
switched on.
►Allow a severely overheated machine
to run on at idle speed for approx.
2 minutes.
►The machine switches o󰀨 automati-
cally in the event of a power failure or
if the magnetic clamp is switched o󰀨.
Selecting the speed range
ATTENTION
►Switch the gear stages only with the
machine at standstill.
NOTE
►Select the speed range according to
the material and drilling diameter.
The machine is equipped with a gearbox
that has four mechanical gear stages.
The gear stage is set using both selec-
tor levers (9, 17) on the side of the gear
box (10).
Using

17MAB 825 V/845 V
GB Using
To select the desired gear stage,
switch the machine o󰀨 and set both
selector levers (9, 17) to the desired
speed as shown in the table below.
Gear
level
max.
speed
Selector lever
left right
Level 1 110 rpm ● ●●
Level 2 175 rpm ● ●
Level 3 370 rpm ●● ●●
Level 4 600 rpm ●● ●
Setting the speed
In addition to the mechanical gearbox, the
machine is also equipped with full-wave
control electronics for stepless variable
speed adjustment.
First set the appropriate gear stage,
then adapt the speed using the elec-
tronic speed control (31).
Gear stage Speed range
Level 1 40 - 110 rpm
Level 2 65 - 175 rpm
Level 3 140 - 370 rpm
Level 4 220 - 600 rpm
NOTE
►If possible, always select a setting
with low gear stage and high motor
speed. The motor is then set with a
higher torque and therefore protect-
ed against overheating under heavy
load.
Setting the
torque cut-o󰀨
ATTENTION
►Do not use this function to switch o󰀨
the machine when cutting threads in
blind holes.
In order to protect the tool, the maximum
torque of the machine can be set using the
controller (32).
The machine switches o󰀨 when it reaches
the maximum set torque. After switching o󰀨,
the machine must be switched o󰀨 and on
again using the ON/OFF switch (21).
Automatic feed
ATTENTION
►Only use this function for drilling.
ATTENTION
►Select the automatic feed rate
according to the tool used to avoid
breaking the tool.
The automatic feed unit (g.3) is located
in the side of the housing. There is a limit
switch at the bottom and the top of the
machine. When the machine slide reaches
one of the end positions, the feed motor is
switched o󰀨 automatically.

18 MAB 825 V/845 V
GB
Using
Using feed:
To use the automatic feed, proceed as
follows.
Prepare the machine as described.
- Insert the tool
- Position the machine
- Switch on the clamping magnet
(For this, see also section “Drilling
with the machine”).
Make sure that the feed unit is disen-
gaged.
The hand lever (12) is in the extended
position (see g. 6).
Set the rotary control (43) for selection
of the feed rate to the "LOW" position
(scale mark 0).
Switch on the automatic feed unit
using the "RUN/STAND-BY" selector
switch (44).
The "POWER - Automatic Feed" indi-
cator (41) lights up.
"RUN/STAND-BY"
selector switch
Feed unit
status
RUN Automatic feed unit
switched on.
STAND-BY Automatic feed unit
switched o󰀨.
Select the "Lower machine slide"
feed direction (↓) using the selector
switch (45).
"UP/DOWN"
selector switch
Direction of
motion
Arrow direction
downwards (↓)
Lower the machine
slide.
Arrow direction
upwards (↑)
Raise the machine
slide.
Engage the feed unit.
For this, move the hand lever (12) to
the inserted position (see g. 7).
Switch on the machine as described
(for this, see also section “Drilling
with the machine”).
Set the feed rate using the rotary
control (43)
(Scale mark 0 (LOW) to scale mark 2).
"LOW/HIGH"
rotary control
Selection range
Scale mark 0
(LOW)
to
scale mark 3
"Selectable
feed rate"
range
Scale mark 4
to
scale mark 10
(HIGH)
"Rapid feed":
range
ATTENTION
►The "Selectable feed rate" range
(scale mark 0 (LOW) to scale mark 3)
may not be exceeded for workpiece
processing!
►The "Rapid feed" range is only for the
rapid feed function.

19MAB 825 V/845 V
GB
The machine slide moves to the lower end
position and the feed motor is switched o󰀨
automatically.
Raising the machine slide:
Two variants are available for moving the
machine slide back to the upper position
after processing.
Variant 1:
The machine slide is located at the lower
position and the feed motor is switched o󰀨.
Disengage the feed unit.
For this, move the hand lever (12) to
the extended position (see g. 6).
Subsequently guide the machine side
upwards with the hand lever (12)n
Variant 2:
The machine slide is located at the lower
position and the feed motor is switched o󰀨.
Set the rotary control (43) for selection
of the feed rate to the "LOW" position
(scale mark 0).
Select the Raise machine slide"
feed direction (↑) using the selector
switch (45).
Turn the rotary control (43) to the
"Rapid feed" range (scale mark 2 to
scale mark 10).
The machine slide moves into the upper
end position and the feed motor is switched
o󰀨 automatically.
Feed unit faults:
In the event of a fault, the feed unit stops
automatically and an "ALARM" (42) error is
indicated.
This occurs, for example, when "Safety
Control" is triggered (see section ““Safety
Control” shutdown”).
Rotating mechanism (MAB 845 V only)
In order to permit optimum alignment even
in di󰀩cult positions, the model MAB 845
V is additionally equipped with a rotating
mechanism. It allows the upper part of the
machine to be rotated by 30° to both sides
and by 20 mm forwards and backwards
with the magnetic foot engaged.
Loosen the locking device of the rotat-
ing mechanism (15).
Position the upper part of the machine
laterally and longitudinally.
Lock the rotating mechanism again.
ATTENTION
►Operate the machine only with the
rotating mechanism locked.
Using

20 MAB 825 V/845 V
GB
Drilling with the machine
Drilling with twist drills
When drilling with twist drills, proceed as
follows:
Push twist drills with MK taper into the
spindle taper (7) of the machine from
below.
Push twist drills with straight shank
into the drill chuck after tting the drill
chuck (see section “Using the drill
chuck”).
Position and x the machine at the
location of use.
Switch on the clamping magnet and
check the magnetic holding force (see
section “Activating/deactivating the
magnetic clamp”).
Select a suitable speed and switch on
the machine.
Make sure that the feed unit is disen-
gaged. The hand lever (12) is in the
extended position (see g. 6).
Direct the drill to the material with the
handle (12).
Alternatively, the "Automatic Feed"
function can be used (see section
“Automatic feed”).
NOTE
Observe the following instructions when
drilling with twist drills:
►Under excessive pressure, the drill
can wear out and the machine can be
overloaded.
►Make sure that swarf is removed
regularly. With larger drilling depths,
break up the swarf.
►Use BDS 6000 cooling lubricant
concentrate.
Drilling with core drills
When drilling with core drills, proceed as
follows:
For core drills with 19 mm Weldon
shaft, mount the MK3/19 mm Weldon
industrial holder.
For core drills with 32 mm Weldon
shaft, mount the MK3/32 mm Weldon
industrial holder.
Connect the cooling lubricant system.
Insert the appropriate ejector pin into
the core drill and insert the core drill
into the tool holder.
Position and x the machine at the
location of use.
Switch on the clamping magnet and
check the magnetic holding force (see
section “Activating/deactivating the
magnetic clamp”).
Select a suitable speed and switch on
the machine.
Make sure that the feed unit is disen-
gaged.
The hand lever (12) is in the extended
position (see g. 6).
Direct the drill to the material with the
handle (12).
Using
