BEA Obsolete MAGIC SWITCH MS08 User manual

MS08 MAGIC SWITCH
Microwave, contactless switch for automatic doors
ENGLISH
SINGLE-GANG DOUBLE-GANG
75.5265.05 MS08 20180913 Page 1 of 4
DESCRIPTION
1. Microwave motion sensor
2. Adapter ring
3. Faceplate
4. Screws
3
4
4
11
23
4
4
TECHNICAL SPECIFICATIONS
Technology: microwave motion sensor
Radiated frequency: 24.125 GHz
Radiated power density: 5 mW/cm2
Supply voltage: 12 – 24 VAC ±10%
12 – 24 VDC +30% / -10%
Supply frequency: 50 – 60 Hz
Power consumption: < 1.5W
Output
relay contact rating (max. voltage):
relay contact rating (max. current):
Max. switching power:
relay with switch-over contact (voltage-free)
60 VDC / 125 VAC
1A (resistive)
30W DC / 60 VAC
Detection range: 4 – 24” (adjustable)
Detection mode: motion (bidirectional)
Output hold time: 0.5 sec (in pulsed mode)
Temperature range: -4 – 131 °F (-20 – 55 °C)
Immunity: immune to electrical and radio frequency interference
Weight: 0.34 lbs
Material: ASA, nylon, PC
Certification: Electromagnetic compatibility (EMC) according to 2004/108/EC
FCC: G9B-MS08
IC: 4680A-MS08
Specifications are subject to change without prior notice.
All values measured in specific conditions.
OBSOLETE

Page 2 of 4 75.5265.05 MS08 20180913
9When wiring multiple devices together to create a system configuration, it is best to ensure that each
device works independently. This will reduce troubleshooting if a discrepancy occurs.
9Prior to installing any equipment in either new or existing circuits, verify correct line voltage and line
stability. Always remember to shut off the power before performing circuit wiring.
INSTALLATION
1
PRECAUTIONS
FCC
PREINSTALLATION CHECK
Shut off all power going to header before attempting any wiring procedures.
Maintain a clean and safe environment when working in public areas.
Constantly be aware of pedestrian traffic around the door area.
Always stop pedestrian traffic through the doorway when performing tests that may result in unexpected reactions
by the door.
ESD (electrostatic discharge): Circuit boards are vulnerable to damage by electrostatic discharge. Before handling any
board, ensure you dissipate your body’s ESD charge.
Always check placement of all wiring before powering up to ensure that moving door parts will not catch any wires
and cause damage to equipment.
Ensure compliance with all applicable safety standards (i.e. ANSI A156.10) upon completion of installation.
DO NOT attempt any internal repair of the components. All repairs and/or component replacements must be
performed by BEA, Inc. Unauthorized disassembly or repair:
1. May jeopardize personal safety and may expose one to the risk of electrical shock.
2. May adversely affect the safe and reliable performance of the product resulting in a voided warranty.
Gang Box
(metal/plastic)MS08
Assembly
Gang Box
(metal/plastic)MS08
Assembly
Adapter Ring
Foam Gasket
The Touchless Actuator may be mounted in
conventional metal or plastic electrical gang boxes.
Ensure that the unit sensor does not come in contact
with the metal gang box to avoid shorting out the
unit.
Do not place the sensor in the door’s opening range,
where the sensor may see door movement.
Do not place moving objects in front of the sensor.
Depending on the door installation, the weather-resistant
foam gasket or plastic adapter ring may be used. The
weather resistant gasket is used as a protective barrier
against the elements. The plastic adapter ring is designed
to enable the double-gang face plate to attach to various
plastic and metal gang boxes.
FCC APPROVAL
This device complies with Part 15 of the FCC Rules and with RSS-210 of Industry Canada.
Operation is subject to the following two conditions:
*this device may not cause harmful interference, and
*this device must accept any interference received, including interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
*Reorient or relocate the receiving antenna
*Increase the separation between the equipment and receiver
*Connect the equipment into an outlet on a circuit different from that to which the receiver is connected
*Consult the dealer or an experienced radion/TV technician for help
WARNING: CHANGES OR MODIFICATIONS TO THIS EQUIPMENT NOT EXPRESSLY APPROVED BY BEA INC. MAY VOID THE FCC
AUTHORIZATION TO OPERATE THIS EQUIPMENT.
OBSOLETE

75.5265.05 MS08 20180913 Page 3 of 4
WIRING
2
SET-UP
3
NC NO COM POWER
1. Wire the 4-conductor cable to the door
operator according to manufacturer
specifications (see appendix for wiring
diagrams).
2. Attach the 4-conductor cable connector
to the Touchless Actuator (see right).
Two adjustments can be made to the sensor. The potentiometer is used to adjust the size of the
unit’s sensing field (see below, left) and the Output Mode switch is used to select Toggle or Pulse
mode (see below, right).
Rotate potentiometer clockwise to increase the
sensing field. It may be adjusted from 4” to 24”.
Adjust Output Mode by moving switch in the up
position (Toggle Mode) or in the down positon
(Pulse Mode).
Toggle Mode: Recommended for switch
applications. In Toggle mode, a detection activates
the relay and a second detection deactivates the
relay.
Pulse Mode: Recommended for automatic door
applications. In Pulse mode, a detection activates
the relay for a short period of time, depending on
the duration of movement in front of door.
empty (NC) Green (NO) Red (12 – 24 VAC/VDC) Black (12 – 24 VAC/VDC) White (COM at door control)
NC NO COM POWER
4”
24”
sensor
sensing field
Potentiometer
Output Mode Switch

24”
4”
Toggle Mode
Pulse Mode
TROUBLESHOOTING
Door does not open when
swiping hand in front of
sensor
Bad or no power Check power supply. If LED switches on or
flashes, power connections are okay.
Detection range too short Adjust detection zone. Remove any metal
plates in front of sensor.
Incorrect wiring/connection Check wiring and relay connection.
Sensor stays in detection Environmental conditions
influencing sensor
Remove moving objects from around sensor.
Incorrect wiring/connection Check wiring and relay connection.
Door remains open after
deteciton/activation
Wrong output mode Switch output mode to Pulse.
Incorrect wiring/connection Check wiring and relay connection.
OBSOLETE

Page 4 of 4 75.5265.05 MS08 20180913
BEA, the sensor manufacturer, cannot be held responsible for incorrect installations or inappropriate adjustments of the sensor/device; therefore, BEA
does not guarantee any use of the sensor outside of its intended purpose.
BEA strongly recommends that installation and service technicians be AAADM-certified for pedestrian doors, IDA-certified for doors/gates, and factory-
trained for the type of door/gate system.
Installers and service personnel are responsible for executing a risk assessment following each installation/service performed, ensuring that the sensor
system installation is compliant with local, national, and international regulations, codes, and standards.
Once installation or service work is complete, a safety inspection of the door/gate shall be performed per the door/gate manufacturer recommendations
and/or per AAADM/ANSI/DASMA guidelines (where applicable) for best industry practices. Safety inspections must be performed during each service
call – examples of these safety inspections can be found on an AAADM safety information label (e.g. ANSI/DASMA 102, ANSI/DASMA 107).
Verify that all appropriate industry signage and warning labels are in place.
BEA INSTALLATION/SERVICE COMPLIANCE EXPECTATIONS
PLEASE KEEP FOR FURTHER USE – DESIGNED FOR COLOR PRINTING
Tech Support: 1-800-407-4545 | Customer Service: 1-800-523-2462
General Tech Questions: T[email protected] | Tech Docs: www.BEAinc.com
©BEA | Original Instructions | 75.5265.05 MS08 20180913
