Beam IsatDock MARINE User manual
IsatDock MARINE
User Manual
2
Inmarsat IsatDock MARINE
Installation and User Manual
Product name: IsatDock MARINE
Manual revision: 01
Part Number: USRMAN006201
Release date: November 2010
BEAM Communications Pty Ltd
8 Anzed Court, Mulgrave,
Victoria, 3170, AUSTRALIA
Information furnished by BEAM Communications Pty Ltd (BEAM) is believed to be
accurate and reliable. However, no responsibility is assumed by BEAM for its use, or for any
infringement of patents or other rights of third parties, which may result from its use. No
license is granted by implication or otherwise under any patent or patent rights of BEAM.
BEAM reserves the right to change specications at any time without notice.
Copyright © 2010 BEAM Communications Pty Ltd. All rights reserved
IsatDock MARINE - Installation & User Manual 3
About Beam Communications
Beam Communications, a wholly owned subsidiary of World Reach
Limited (WRR), listed on the Australian Stock Exchange, is a world leader
in design, manufacture and distribution of specialised communications
equipment for the Inmarsat Satellite Network.
Beam’s commitment to be at the forefront has continued to increase its share
of the global satellite communications market. Its premium distribution
network spans the world.
Recognized as a leading provider of satellite communication solutions,
Beam specializes in Voice, Data, Tracking and customized solutions.
Beam develops innovative products and services to meet market
demands and niche applications.
Beam’s leading edge products are deployed in a wide range of vertical markets
including Maritime, Transport, Government, Defence, Mining, Construction,
Forestry, Emergency Services, Relief Aid, Telemetry and Rural Telephony.
Supported by a dedicated team of professionals, Beam has developed
solid relationships with its peers and network of distributors worldwide.
BEAM Communications Pty Ltd
8 Anzed Court, Mulgrave,
Victoria, 3170, AUSTRALIA
Web: www.beamcommunications.com
Information: info@beamcommunications.com
Tel: +61 3 8588 4500
Fax: +61 3 9560 9055
4
These notes will appear throughout this manual
and should be taken into consideration.
Warning or Caution
This symbol and associated text indicate a
warning note providing information to prevent
damage to equipment or personal injury.
Note/Important/Tip Header
This symbol and associated text indicate a note
providing general operating information.
Interference Header
All wireless phones may get interference, which
could aect performance.
Record Header
Write details of your unit for easy reference when
required. Ideal when troubleshooting.
Terminology
TERM DESCRIPTION
IDMS IsatDock Management System - MS Windows Install
SMS Short Message Service
Mobile Originating Describes a call initiated by the IsatDock
Mobile Terminating Describes an incoming call being answered by the IsatDock
IsatPhone Pro The Inmarsat IsatPhone Pro handset
®The ® symbol, mark and logos are owned by the respective companies
of which the symbol follows. Any use of such marks by Beam
Communications is under license. Other trademarks and trade names
are those of their respective owners.
RF Radio Frequencies
SMA Sub Miniature version A co-axial RF connection
RJ11 Connector type and reference for the POTS telephone port
RJ9 4P4C connector for the privacy handset
POTS Plain Old Telephone Service
GPS Global Positioning System
GSPS Inmarsat’s Global Satellite Phone Service
PABX Private Analogue Branch Exchange
Conventions in this Manual
IsatDock MARINE - Installation & User Manual 5
Package Contents
Check that your IsatDock MARINE package
contains all of the following items:
F 1 x IsatDock MARINE docking station
F 1 x 110-240V AC Plug Pack
F 1 x Privacy Handset
F 1 x 10-32V DC Power Cable
F 1 x 2m Alert wiring loop
F 2 x Handset Locking Keys
F 1 x Wall Mounting plate
F User Manual & Quick Start Guide
IsatDock Management System (IDMS)
is available for download from:
http://www.beamcommunications.com/
support/isatdock/IDMS
Optional Accessories
The following optional accessories are available
for your IsatDock MARINE
Active Antennas
• ISD710 Maritime Active Antenna
• ISD710 Transport Bolt Antenna
• ISD715 Transport Magnetic Antenna
Passive Antennas
• ISD700 Directional/Fixed Passive Antenna
Antenna Cable Kits for Passive Antennas
• ISD936 10m Passive Cable Kit
• ISD937 20m Passive Cable Kit
Antenna Cable Kits for Active Antennas
• ISD932 6m Active Cable Kit
• ISD933 13m Active Cable Kit
• ISD934 18m Active Cable Kit
• ISD935 31m Active Cable Kit
Additional Accessories
• RST410 Alert Pendant Kit
• LTO - LeoTRAK-Online
• RST975 RJ11/POTS phone
See your service provider for pricing and
availability of these quality BEAM accessories.
Additional Information
For the latest in supporting software and
documentation for IsatDock please contact
www.beamcommunications.com/support
Alert / Tracking
To congure the alert / tracking functionality on
your IsatDock, you must rst install the IsatDock
Management System (IDMS) software, which
also includes the Beam USB Drivers for Microsoft
Windows based operating systems.
Other Resources Available Online
- Advanced Conguration – inbuilt to IDMS
- Quick Start Guide & Manual
- Antenna Installation Guide
- IsatPhone Pro rmware upgrade if required
6
CONTENTS
Inmarsat IsatDock MARINE Part
Number 2
About Beam Communications 3
Conventions in this Manual 4
Terminology
Package Contents 5
Optional Accessories
Additional Information
Alert/Tracking
Other Resources Available Online
Safety Information 7
Safety Inmarsat Transceiver
IsatPhone Pro
IsatDock FCC Information
Electronic Devices
Pacemakers
Other Medical Devices
Vehicles
Posted Facilities
Aircraft
IsatDock MARINE Key Features 11
Tracking/Alert Monitoring
LeoTRAK-Oline Global Tracking Portal
Equipment Overview 13
Installation Guidelines 14
Routing Cables
(for vehicle installations)
Guidelines for Electrical Connections
Installation Procedure 15
Installing the IsatDock MARINE Cradle
IsatDock MARINE Usage 24
Docking & undocking the IsatPhone
Pro handset
Tracking & Alert Conguration (optional)
Operation of the IsatPhone Pro
Placing Voice Calls
Mute Mode
USB Driver Installation
Tracking and Alert Operations
IsatDock Key Lock
IsatDock MARINE Front Panel
IsatDock MARINE Buttons/LED lights
Assuring Quality of Inmarsat Service
Specification Summary 32
Electrical & Environmental
Specications - IsatDock MARINE
(1) Physical Dimensions - MARINE Dock
(2) Physical Dimensions - Privacy Handset
Trouble Shooting 34
Beam Warranty Conditions 35
IsatDock MARINE - Installation & User Manual 7
Safety Information
IMPORTANT!
Please read the following information carefully
before installing and using the IsatDock MARINE.
Failing to follow instructions may compromise the
safety of the product and may result in personal
injury and/or equipment damage. Please consult
your supplier if you have any further questions.
The IsatDock MARINE is a low power docking
station for the IsatPhone Pro handset. When ON,
it will charge the IsatPhone Pro handset whilst
docked in the IsatDock MARINE.
Refer to the appropriate section of this
IsatDock MARINE Installation & User Manual for
additional safety information.
• Store the system in a cool and dry area.
• Do not submerge the system in water.
• Do not place foreign metal objects or debris
in the system. If debris enters into the system,
please return to the manufacturer for service.
WARNING
DO NOT open equipment. There are no user-
serviceable parts inside.
If a DC power supply is to be used, its output must
comply with the Safety Extra Low Voltage (SELV)
requirements of IEC60950.
All connectors must only be connected to equipment
ports which comply with the Safety Extra Low
Voltage (SELV) requirements of IEC60950.
POTENTIALLY EXPLOSIVE ATMOSPHERES
• Turn your phone OFF and DO NOT remove
your battery or remove the IsatPhone Pro
handset from the cradle when you are in any
area with a potentially explosive atmosphere.
• Obey all signs and instructions.
• Sparks from your battery in such areas could
cause an explosion or re resulting in bodily
injury or even death.
• Areas with a potentially explosive atmosphere
are often but not always clearly marked.
They include, but are not limited to:
»fuelling areas such as gasoline stations
»below deck on boats;
»fuel or chemical transfer or storage
facilities;
»areas where fuel odors are present (for
example, if a gas/propane leak occurs in a
car or home);
»areas where the air contains chemicals
or particles, such as grain, dust, or
metal powders;
»any other area where you normally would
be advised to turn o your vehicle engine.
8
WARNING
ROAD SAFETY COMES FIRST!
Do not use a hand-held cellular terminal, satellite
phone or mobile when driving a vehicle, unless it
is securely mounted in a holder for speakerphone
operation. Before making a call with a handheld
terminal, satellite phone or mobile, park the vehicle
stationary. Please obey local road laws for hands-
free speakerphone operation. Speakerphones
(hands-free) must be installed by qualied
personnel. Faulty installation or operation can
constitute a safety hazard.
IMPORTANT
Cellular & Satellite terminals or mobiles operate using
radio signals and communication networks. Because
of this, the connection cannot be guaranteed at all
times or under all conditions. Therefore, you should
never rely solely upon any wireless device for essential
communications, for example emergency calls.
» International Commission on Non-Ionizing
Radiation Protection (ICNIRP) 1996
» Verband Deutscher Elektrotechniker
(VDE) DIN-0848
» United States Federal Commission, Radio
Frequency Exposure Guidelines (1996)
» National Radiological Protection Board of
the United Kingdom, GS 11, 1988
» American National Standards Institute
(ANSI) IEEE. C95. 1-1992
• Do not operate your satellite telephone
when a person is within 0.55 meters of
the antenna. A person or object within
0.55 meters of the antenna could impair
call quality and may cause the phone
to operate at a higher power level than
necessary and expose that person to RF
energy in excess of that established by the
FCC RF Exposure Guidelines.
• As a precaution, please maintain the
maximum body distance possible from the
antenna during call transmission.
Safety Inmarsat Transceiver
IsatPhone Pro
Your handset is a low power radio transmitter
and receiver. When it is ON, it receives and
also sends out radio frequency (RF) signals.
(NOTE: Refer to Inmarsat IsatPhone Pro
Manual for additional Information)
• The Inmarsat IsatPhone Pro handset has an
in-built transceiver which is designed to be
used with an external antenna. This antenna
transmits RF energy. The Inmarsat antenna
(tted via an extension coaxial cable to
the cradle) must be located more than >
0.55 meters from the human body (person)
when in operation.
• International agencies have set standards
and recommendations for the protection
of public exposure to RF electromagnetic
energy. These standards are based on
extensive scientic review by scientists,
engineers, and physicians from universities,
government health agencies, and industry
groups They review the available body of
research to develop ANSI standard. These
ANSI standards are reviewed regularly for
research development.
IsatDock MARINE - Installation & User Manual 9
IsatDock FCC Information
This equipment has been tested and found
to comply with the limits for a Class B digital
devices, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide
reasonable protection against harmful
interference in a residential installation. This
equipment generates, uses, and can radiate
radio frequency energy and, if not installed
and used in accordance with the instruction
manual, may cause harmful interference to
radio communications. However, there is no
guarantee that interference will not occur
in a particular installation. If this equipment
does cause harmful interference to radio or
television reception, which can be determined
by turning the equipment o and on, the user is
encouraged to try to correct the interference by
one of more of the following measures:
• Reorient or relocate the receiving antenna
• Increase the separation between the
equipment and receiver
• Connect the equipment into an outlet on
a circuit dierent from that to which the
receiver is connected.
• Consult the dealer or an experienced
radio/TV technician for help.
This device has been designed to operate with
antennas ISD710 AT1595-82, ISD715/ISD720
AT1595-83 and having a maximum gain of 6dB i
dB. Antennas having a gain grater than 6dBi dB
are strictly prohibited for use with this device.
To reduce potential radio interference to other
users, the antenna type and its gain should
be so chosen that the equivalent isotropically
radiated power (EIRP) is not more than that
required for successful communication
WARNING
Changes or modications not expressly approved
by Beam Communications could void the user’s
authority to operate the equipment.
10
Other Medical Devices
If you use any other personal medical device,
consult the manufacturer of your device to
determine if it is adequately shielded from
external RF energy. Your physician may be able
to assist you in obtaining this information.
Turn your phone OFF in health care facilities
when any regulations posted in these areas
instruct you to do so. Hospitals or health care
facilities may be using equipment that could be
sensitive to external RF energy.
Posted Facilities
Turn your phone OFF in any facility where
posted notices require such as hospitals and
on-board aircraft.
Aircraft
Airline regulations prohibit using your phone
while in the air. Consult the local Aviation
Authority for guidelines on use of the
equipment on board an aircraft.
Electronic Devices
Most modern electronic equipment is shielded
from RF signals. However, certain equipment
may not be shielded against the RF signals from
your wireless phone.
Pacemakers
The Health Industry Manufacturers Association
recommends that a minimum separation of six
inches (6”) be maintained between a wireless
phone’s antenna and a pacemaker to avoid
potential interference with the pacemaker.
These recommendations are consistent with the
independent research by and recommendations
of Wireless Technology Research.
Persons with pacemakers:
• Should ALWAYS keep the phone more than
six inches from their pacemaker when
phone is turned ON.
• Should turn the phone OFF immediately if
you have any reason to suspect interference
is taking place.
IsatDock MARINE - Installation & User Manual 11
Installation
• Supports 10 - 32V DC power input
• Flexible installation via wall or desk
mounting option
• Supplied with 110 - 240V AC/DC Plug pack
Quality
• Professional industrial design
• 2 year replacement guarantee
• 100% factory tested
• Full certied, Inmarsat Approved, FCC,
RoHS, CE, IEC60945, AS/EN60950
IsatDock MARINE Key Features
IsatDock MARINE is an intelligent docking
station specically designed for the Inmarsat
IsatPhone Pro satellite handset.
IsatDock MARINE allows the IsatPhone Pro
handset to be used in a wide variety of
applications. It enables you to use an intelligent
RJ11/POTS connection with a standard corded,
cordless or DECT handset. Alternatively, it can
also be interfaced with a PABX system.
IsatDock MARINE has an in-built speakerphone for
convienent handsfree operation.
Equipped with internal GPS, the IsatDock
MARINE provides an intelligent tracking and
alert reporting system that can be easily
congured to support periodic polling or
emergency alert reporting.
IsatDock Design
• Securely holds IsatPhone Pro handset
• Robust design and construction
• Key lockable & secure mount to wall/desk
• IP54 Rated enclosure
• Charges IsatPhone Pro handset ready for use
• Integrated antenna connection
• Integrated USB connectivity
• Cable routing LHS/TOP/BOTTOM
POTS/RJ11
• Supports standard cordless & corded
telephones (5 REN)
• The POTS phone can be run 600m
(1800 ft from unit)
• Easily integrated to PABX system
• Ring, busy & dial tones
• Superior voice quality
Tracking & GPS
• In-built GPS engine
• Tracking & alert monitoring capable
• Periodic position reports or remotely polled
• Triggered position status message
• Interfaces to Beam’s LeoTRAK-Online
• Compatible with other tracking applications
Panic & Alerts
• Panic Alert button in-built to cradle
• Option of additional wired alert buttons
• Interfaces to Beam’s LeoTRAK-Online
www.leotrak.com
In-Built Speakerphone
• In-built speaker and microphone
12
Tracking / Alert Monitoring
IsatDock MARINE has an in-built GPS module
that can provide tracking, monitoring and alert
management in various land and sea based
applications within various types of vehicles,
vessels or xed site locations.
The GPS module provides accurate positioning
and enables tracking worldwide. The tracking
function has to be congured and enabled on
the IsatDock MARINE via the IDMS. Once turned
ON, tracking and alert messages can be sent to a
phone number, e-mail address, LeoTrak-Online or
any other tracking application via SMS/email.
Tracking messages can be sent from the
IsatDock MARINE in the following ways; Periodic
position reporting, which is preset during
conguration of the IsatDock MARINE.
A current location position can be sent at any
time by pressing the Track button on the front
of the IsatDock MARINE
The Alert mode can be activated on the
IsatDock MARINE in the following ways; Use the
two button press (know as the Alert button) on
the front of the cradle.
Use an external alert button/emergency push
button connected to the alert loop
Once activated, alert messages will be sent to
the preset destination continuously until the
alert is disabled either remotely or locally on the
IsatDock MARINE unit.
LeoTRAK-Online Global Tracking
Portal
LeoTRAK-Online is Beam’s own global web based
alert monitoring and tracking application, which
enables you to track, trace and monitor your
asset anywhere on earth for a small monthly fee
through a simple-to-use web portal. For more
information about LeoTRAK-Online and associated
charges please visit:
www.leotrakonline.com
NOTE
Remote alert/command functionality for disabling
and acknowledgment is scheduled to be available
by a rmware upgrade Q1 2011
IsatDock MARINE - Installation & User Manual 13
Equipment Overview
1. IsatDock MARINE unit
2. Cover Lock Clasp
3. Marine Cover
4. Mounting Cup (spring or springless cup
option)
5. Privacy Handset
6. Speaker (under handset)
7. Microphone
8. Speakerphone Button
9. Key lock
10. IsatPhone Pro Eject Button
11. IsatPhone Pro (not included)
12. Function Buttons
13. STATUS Indication LED
14. Back Panel Connectors
a. USB Data Interface
b. Alert loop connection
c. RJ11/POTS interface
d. DC power and accessory input
e. RJ9 Privacy handset
1
3
24
5
6
7
8
10
11
12
13
9
14
abe
c d
14
Installation Guidelines
This guide outlines the process for installing
the IsatDock MARINE in conjunction with an
Inmarsat IsatPhone Pro handset.
This kit must not be used with any other device
other than the Inmarsat IsatPhone Pro handset.
• Only qualied personnel should install
communication equipment.
• Ensure that the units are protected from
dirt and moisture.
• Select an area to mount components where
there is no interference with space.
• Ensure that each mounting surface is strong
enough to support the component being
mounted to prevent the component from
loosening over time.
• Mount all components securely to prevent
shifting that could cause injury or could
interfere with safe vessel operation. Always
use the supplied mounting hardware.
• Leave space around the units to allow
cooling and ensure there are adequate
clearance for cables.
• Ensure the units can be easily removed.
(0V) line. Failure to insert a fuse can cause
equipment to overheat if a wiring fault exists.
• Many parts of a vehicle can produce electrical
noise that interferes with the electrical radio
system operation. The ignition system is
the most common source of electrical noise
interference. Before you begin installation,
ensure that the ignition wiring and
connections to the vehicle battery are in
good working condition.
• Verify that low resistance connections are
present between the battery negative
terminal, the vehicle chassis, and the
engine block. All wire connections should
be clean and tight.
• For vehicle installation, install provided
fuses into the +BATT and ignition sense
(accessory) wires.
WARNING
Do not connect the IsatDock power cable to power
the unit until the full installation is completed.
Routing Cables
• Route cables so they are protected from
pinching, sharp edges, and crushing.
• Use grommets wherever a cable must pass
through a hole in a metal panel
• Keep all in-line connectors accessible.
• For an extra clean installation, a hole may
be driven through the surface directly
behind the docking station.
Guidelines for Electrical Connections
The system is designed to operate 10 to 32 Volt
DC electrical systems only.
If using the DC cable lead:
• The best power connection point for
the positive primary power lead is the
positive terminal of the vehicle battery.
Often, direct connection to the battery is
inconvenient, and you may find it easier
to connect the positive leads to the
starter solenoid. Always select a point
as close as possible to the battery.
• Connect the negative primary power leads to
a good ground point on the vehicle chassis or
at the battery. If you must attach the negative
primary power lead directly to the negative
pole of the battery, you may optionally insert
a 10-amp fuse (not included) into the ground
IsatDock MARINE - Installation & User Manual 15
Installation Procedure
Installing the IsatDock MARINE Cradle
Install the components in the following order.
More detailed instructions can be found in the
sections following.
1. Install the external Inmarsat antenna
2. (A) Wall Mounting Orientation
(B) Desk Mounting Orientation
3. Connect the privacy handset & cup
4. Access to rear connector bay
5. Connect POTS/RJ11 Interface
6. Connect the Alarm Loop (optional)
7. Connect USB
8. Connect power cable
9. Cable routing
10. Water Resistant IP54 Rating
1) Inmarsat Antenna Connection
To connect the IsatDock MARINE to the GSPS
inmarsat Antennas, requires the use of certied
satellite and GPS antenna cables to be used. These
cables are purpose built cables as approved by
Beam to manage the power requirements for the
antenna system. Approved cables can be found at
www.isatdock.com/marine.
1. Refer to the antennas installation guide
for antenna mounting and location
requirements.
2. Connect the antenna cable labelled “Inmarsat”
to the antenna connector labelled “ISAT” via the
SMA connector.
3. Connect the antenna cable labelled “GPS”
to the antenna connector labelled “GPS”
via the SMA connector
4. Connect the GPS-SMA (Female) cable end
to the IsatDock’s SMA connector
5. Connect the Inmarsat GSPS - TNC (Female)
antenna cable end to the IsatDock’s
satellite connector
Anntena Connection Diagram
54
32
TNC
SMA
SMA
SMA
Satellite
Antenna
Cable
GPS
Antenna
Cable
16
2a) Wall Mounting Orientation
There are nine screw holes available for mounting
the bracket to a wall. It is recommended that
a minimum of 2 screws are used to ensure the
docking station is mounted securely.
There are four keyhole shaped slots in the
mounting bracket that mate with feet on the
rear of the docking station. To attach the
bracket, the larger end of the keyhole will pass
over the feet. The bracket is then slid up to lock
the feet into the narrow section of the keyhole.
NOTE
Refer to the section “Antenna Installation” for more
information on antenna placement and installation.
Only Beam approved antenna cables should be used
with all docking stations and antennas.
WARNING
DO NOT pull with force on the cables from the rear
of the IsatDock MARINE. Please install strain relief
clamping for the antenna cables where required.
Correct installation of the antenna system is a vital
part of the IsatDock MARINE system, to ensure
reliable functionality, and drop-free calls.
WARNING
Changes or modications not expressly approved
by Beam Communications could void the user’s
authority to operate the equipment.
WARNING
To satisfy FCC RF exposure requirements for mobile
transmitting devices, a separation distance of
55cm or more should be maintained between the
antenna of this device and persons during device
operation. To ensure compliance, operations at
closer than this distance is not recommended.
ISD710
Marine Active
Antenna with Pole
Bracket ISD700
Passive Antenna
with Bracket
Transport
Active Antenna
ISD715
Magnetic
Mount
ISD720
Bolt Mount
IsatDock MARINE - Installation & User Manual 17
Security Bolts
Two security bolts ensure the MARINE docking
unit is rmly xed to the wall and only removed by
an ‘authorized’ (the security key holder) personnel.
Once the IsatDock MARINE is tted to the wall,
these two security bolts prevent the docking
station from sliding back up freeing the dock.
The security bolts are 4mm in diameter and have a
slot for a at blade screwdriver.
The bolt under the privacy handset mounting
cup must be tted prior to the cup being screwed
into place. The second bolt is placed under
the IsatPhone Pro in the recess for the handset
antenna cover. Both bolts are then covered with
plugs. As the second bolt is under the IsatPhone
Pro, access to the bolt is denied when the handset
is locked into the cradle.
Once the dock as been locked onto the mount-
ing bracket on the wall, two security bolts are
then slid into place locking the dock to the wall.
2b) Desk Mounting Orientation
The IsatDock MARINE supports a desk mount
conguration. Depending on the users
requirements the docking station supports both
a at and raised orientation on the desk.
To congure the IsatDock for a desk installation:
1. Fit the mounting bracket to the back of
the IsatDock as shown in section (2a) wall
mounting directions.
2. Flip the feet out if required and locate the
IsatDock on the desk.
When desk mounting, the security bolts are not
required to be tted.
a
b c
Slide the dock down
Fit the docks feet in the large holes of the bracket
Final lock position
18
3) Privacy Handset & Mounting Cup
The Privacy Handset is conveniently mounted
on to the IsatDock MARINE enclosure, providing
a local handset function.
The Privacy Handset connects to the docking
station via a RJ9 connector. The privacy handset
is connected beneath the rear panel of the
IsatDock. Once connected, the cable is run out
through the foam and placed in the ‘S’ channel
through the base of the phone.
RJ9 connection
See section 4 on page 19
Changing Cups
1. Unhook the privacy handset from cup.
2. Remove cup cover to expose screws.
3. Unscrew 3 screws with a phillips screwdriver.
4. Detach the cup and replace with the
spring or springless cup.
(1) Springless Cup for Normal light-use
Desk mounted cradle position.
The ‘springless’ cup is tted to the docking station
with the mounting clip in a ‘ush’ position.
Wall mounted cradle position.
The mounting clip can be slid out and
reversed, producing a protruding point that
the Privacy handset rests upon. For a wall
mounted docking station this retains the
privacy handset and the ‘spring-less’ cup has
enough height to allow the handset to rise
up off the clip and out of the mounting cup
There are two unique mounting cups for the
privacy handset. (1) springless cup for either
a desk mounted cradle position or a wall
mounted cradle position. (2) spring cup for
heavy duty use.
1
2
3
4
IsatDock MARINE - Installation & User Manual 19
a. USB Data Interface
b. Alert loop connection
c. RJ11/POTS interface
d. DC power and accessory input
e. RJ9 Privacy handset
(2) Spring Cup - Heavy duty use cup
In harsh environments, the Privacy handset is
actively retained in the mounting cup. This is
achieved by using the ‘spring’ mounting cup. To
remove the handset from the cup, the phone is
lifted up against the pressure of the spring until
it clears the lower mounting pip and can be
removed from the docking station.
4) Access to Rear Connector Bay
For the IsatDock MARINE, the external cable
interfaces are at the rear of the docking station.
The cover panel creates the IP rating for the
electrical interface and retains the cables in their
respective channels. The cover panel is xed in
place by seven screws.
a b e
cd
20
5) Connect RJ11/POTS Interface
Any standard analogue POTS (= Plain Old
Telephone Service) Telephone is supported by
the IsatDock MARINE. It supplies power to the
analogue phone as well as ring, dial and busy tones.
The analogue phone can be connected by up to
600m of cabling to the IsatDock MARINE.
RJ11 port
See section 4 on page 19
6) Connect Alert Loop (optional)
IsatDock MARINE provides a standard
Beam alert loop. This provides a Normally CLOSED
wire loop, which can be used to connect to any
passive type of button, relay, or reed switch
in which the action breaks the loop (OPEN) to
activate the alert state.
Connect the alarm cable directly to the alert
loop connection. The cable can be extended to
long runs up to 45 meters. This alert loop can
support multiple alert buttons / switches wired
in SERIES, whereby any one of these will OPEN
(activate) the loop when pressed. This provides
the same functionality as pressing the mute and
track button on the dock and manually placing
the unit into alert/emergency mode.
Alert loop connection
See section 4 on page 19
7) USB Port Connection
IsatDock MARINE has a micro USB Data Port
programming interface to enable upgrading of
the Docking station rmware.
USB Data Port
See section 4 on page 19
NOTE
Data services scheduled to be available Q1 2011.
Other manuals for IsatDock MARINE
2
Table of contents
Other Beam Handset manuals
