$UUDQJHPHQWRI&RQWUROV
2345678
19
10
11
1 Volume control
2 On / off switch ( )
3 Tone button ( )
4 Road traffic announcement button ( )
5 Operating mode selector button ( 0ode)
6 Function button ( )
7 Waveband selector button ( %an )
8 Tape/CD eject button ( )
9 Right rotary control
10 Multifunction buttons
11 Display

42
$QWLWKHIW'HYLFH
&R HQXPEHUHQWU\
If the car radio is disconnected from the power supply, it is theft-protected upon
reconnection. After switching on at the button, the prompt &2'( follo-
wed by 4 stars is displayed.
The four-digit code must then be entered using the multifunction buttons “-”.
([DPSOH Code number 1530 (the code number can be found on the enclosed
CODE CARD).
Enter code number using the multifunction buttons.
The first star is extinguished after entry of the first digit. The second star is
extinguished after entry of the second digit, etc. The unit switches on automa-
tically after entry of the 4th digit, if this and all other digits have been correctly
entered.
1RWH It is essential that the CODE CARD be kept in a safe place outside
the vehicle. Thus, illegal use is not possible. The accompanying
sticker should be attached to the inside of the vehicle windscreen/
window.
If an incorrect code number is entered, the prompt &2'( with the four stars is
displayed again. After entering incorrect code three times :$,7 is displayed
and the unit is disabled for approx. 60 minutes. Three further incorrect entries
block the unit again for 60 minutes.
$WWHQWLRQ The waiting time applies only to ignition and unit switched on.


43
$QWLWKHIW'HYLFH
5HPRYHSRUWDEOHSDQHO
As effective anti-theft device, the portable panel ($) can be removed from the
unit.
For this purpose, press and hold button. The display folds forwards.
The portable component can then be pulled out.
The volume is limited to a maximum value after the display has been folded
down. After 20 seconds an audible signal indicates that the control component
is folded down. The unit is switched to mute. The unit switches off after a fur-
ther 10 seconds.
1RWH For safety reasons, it is not permitted to leave the portable panel
open when driving
$WWHQWLRQPlease insert the portable panel in the accompanying protective
cover after removal.
Do not touch the metal contacts on the portable panel or on the
radio.
,QVHUWLQJSRUWDEOHSDQHO
Insert the portable panel so that it engages first in the lower left catch and then
in the lower right. Then press the portable panel into the upper catches.
Or position portable panel directly over all four catches and press in firmly to
engage.
For proper functioning, ensure that the portable panel is firmly engaged in all
four catches.
If a new portable panel or one from another unit is utilised, the code number
must be entered, as previously described, in order to activate the unit.

$

44
*HQHUDO2SHUDWLRQ
6ZLWFKRQRII
Press button.
Further on / off switching possibilities: Via ignition. In order to switch on via
the ignition, the unit must previously have been switched off via the ignition.
After switching off the ignition, the unit can be prevented from switching off
by pressing the button within 3 seconds.
1RWH The unit can also be switched on with the ignition switched off via
the button, but will switch off automatically after 1 hour.
$ MXVWYROXPH
Turn volume control to right / left. The volume is increased or decreased. The
current volume level is shown on the display.
0XWHIXQFWLRQ
The unit can be switched to mute in each operating mode by pressing the
volume control. In the display 087( or 73,1)2will appear.
The mute function is cancelled by pressing the volume control, changing the
operating mode or inserting tape / CD.
$FWLYDWHWRQHPHQX
Press button. The tone menu is activated. The following functions can be
called up: %$66 (Bass), 75(% (Treble), %$/ (Balance), )$' (Fader),
/28' (Loudness) and 67(5(2 (Reception optimisation).
Bass and treble settings for the AM/FM wavebands, for road traffic announce-
ments and tape/CD operation are stored separately (values from -7 to +7). The
settings for fader, balance and loudness (no loudness with AM) are stored toge-
ther for all operating modes (values from -7 to +7).

45
*HQHUDO2SHUDWLRQ
$ MXVWEDVV
Press button and then multifunction button “” or “”. %$66 and the set
value are displayed. Set the desired bass via both buttons.
&HQWUHVHWWLQJ Press both buttons simultaneously.
$ MXVWWUHEOH
Press button and then multifunction button “” or “”. 75(% and the set
value are displayed. Set the desired treble via both buttons.
&HQWUHVHWWLQJ Press both buttons simultaneously.
$ MXVWEDODQFH
Press button and then multifunction button “ ” or “ ”. %$/ and the set
value are displayed. Set the desired balance via both buttons.
&HQWUHVHWWLQJPress both buttons simultaneously.
)D HU
Press button and then multifunction button “ ” or “ ”. %$66 and the set
value are displayed. Set the desired fade level via both buttons.
&HQWUHVHWWLQJ Press both buttons simultaneously.

46
*HQHUDO2SHUDWLRQ
/RX QHVVRQRII
Press button and then multifunction button “/'”. /28'21 or /28'
2)) are displayed. The loudness can be switched on or off alternately by pres-
sing the multifunction button.
/LQHDUD MXVWPHQW
Press and hold button for more than 2 seconds. The tone values for the set
signal source (e.g. radio/FM) are set to an average value )0/,1($5.
Press and hold button for more than 4 seconds. All tone values for the
signal sources radio and tape / CD are set to an average value $///,1($5.
$ MXVWPRQRVWHUHR
Three different reception optimisation settings can be set in order to suppress
reception dependent interference and reflections.
Repeatedly press multifunction button “67” in tone menu until the desired
optimisation is set.
$872Setting for normal operation - i.e., the unit switches from stereo to
mono and back depending upon reception location (provides the optimum set-
ting for almost all reception areas).
67(5(2 Setting for unusal reception situations - i.e. the unit is set perma-
nently to stereo (e.g. for private radio stations in city areas)
0212Setting for reception conditions in which reflections constantly occur
- i.e., the unit is set constantly to mono.
The setting is effective immediately after pressing the multifunction button
“67” and is also retained on switching off.


47
5D LR2SHUDWLRQ
6HOHFWRSHUDWLQJPR H
Press button. The operating modes 5D LR, &' or 7$3(, &'0'
FKDQJHU (for connected CD/MD changer) or $8; can be selected.
The last selected operating mode is set after the button is pressed for the first
time. If the other operating modes are to be selected, the button is quickly
and repeatedly pressed until the desired operating mode is selected.
1RWH If you switch often between )0 and &', first select )0 and then
through quick pressing &'. Subsequently, press the button
after a pause of more than 2 seconds, switching only takes place
between FM and CD.
6HOHFWZDYHEDQ
Press button repeatedly until desired waveband )0,)0, $0 or /:
is selected.
When changing the waveband the last selected transmitter is set.
6ZLWFKRQUD LRPHQXPR H
Press button. The radio menu mode is switched on and displayed. The unit
switches back to the normal display if no button is pressed within the next
8 seconds.



48
5D LR2SHUDWLRQ
6HWWLQJSURFH XUHVIRUWUDQVPLWWHUVHOHFWLRQ
The desired transmitter can be selected via NBC (Next Best Chain), transmitter
search, scan search, manual tuning, direct frequency entry and station buttons.
1%&1H[W%HVW&KDLQIXQFWLRQ
The NBC function features a dynamic memory.
In order to call up the NBC function, select radio menu mode in FM mode.
Then press multifunction button “$6” (Auto Select) repeatedly until $872
1%& is displayed.
The best transmitter is always displayed to the left of the normal display. Press
the right rotary control in order to select this transmitter.
Transmitters with better/worse reception quality can be selected by turning the
right rotary control to the left/right. The selected transmitter is set by pressing
the right rotary control.
After setting, the best transmitter is displayed via NBC again after 8 seconds.
)0WUDQVPLWWHUVHDUFK
Turn the right rotary control to the left/right. The radio searches in descending/
ascending order, according to selected search mode.
In order to select the various search modes, select radio menu mode in FM
mode. Then press multifunction button “$6” repeatedly until the desired
search mode is selected.
- 6((.)54 (frequency) search of the waveband
-6((.&+1(chain) search of transmitter chains in alphabetical order
Explanation of IUHTXHQF\VHDUFKPR H on page 72.
Explanation of FKDLQVHDUFKPR H on page 72



49
5D LR2SHUDWLRQ
$0/:WUDQVPLWWHUVHDUFKPR H
Turn the right rotary control to the left/right in desired waveband (AM, LW).
The radio searches for reception frequencies in descending/ascending order of
frequency.
Tuning steps of 9 kHz for AM and 3 kHz for LW are used.
6FDQVHDUFK
In the desired waveband (FM, AM or LW), press the right rotary control, 6&
is displayed. An automatic transmitter search is started. The first search is
performed on an insensitive plane, all further searches on a sensitive plane.
Receivable transmitters can be heard for 8 seconds. Press / turn the right rotary
control if the received programme should be retained.
1RWH In waveband FM, according to selected search mode, a frequency
scan (display: 6&$1)54) or a programme scan (display: 6&$1
&+1) is performed. Scan search is not possible if NBC is selected.
'LUHFWIUHTXHQF\HQWU\
Select radio menu mode and then, within 8 seconds, enter the frequency using
the multifunction buttons.


50
5D LR2SHUDWLRQ
3URJUDPPHW\SH LVSOD\VHDUFK37<
Select radio menu mode and then and press multifunction button “37´. The
selected transmitter program type is displayed for 10 seconds (e.g. 3230 =
pop music). If the selected transmitter has no PTY characteristic (see also
page 73) 1237< appears.
In order to activate search, select radio menu mode and then and press
multifunction button “37´. Pre-select a currently available PTY using the
multifunction button “ ” or “ ”. Turn the right rotary control within the next
10 seconds. 37<6((. is displayed. The previously heard programme is
selected if no transmitter with the selected PTY is receivable. Switching over
to station button plane takes place if there is no further actuation within
10 seconds.
)0)0WUDQVPLWWHUUHTXHVWVWRUH
6WRUH: 10 frequencies or programs can be stored on each of wavebands FM 1
and FM 2.
Press multifunction button for 2 - 4 seconds in order to store the desired
transmitter or program.
The frequency is stored on the station button if the multifunction button is
pressed for longer than 4 seconds (display)0),;).
5HTXHVW: Press multifunction button “- ”. The stored transmitter is
requested.
The stored frequency is set if the transmitter cannot be identified.
No diversity or programme identification is performed after request if only one
frequency is stored on the multifunction button. )0),; appears briefly on the
display.



51
5D LR2SHUDWLRQ
$0/:WUDQVPLWWHUUHTXHVWVWRUH
5HTXHVW Press multifunction button “- ”. The stored transmitter is
requested.
6WRUH 10 transmitters can be stored under station buttons. Search for the
desired transmitter and press the multifunction button until the station button
number is displayed.
$0/:DXWRVWRUH
Select desired waveband. Select radio menu mode. Then press multifunction
button “$6” repeatedly until $66((. is displayed. The 10 transmitters with
the best reception are stored under the station buttons in order of quality. The
autostore plane is identified on the display by $6.
Select radio menu mode in order to quit the autostore storage plane. Then press
multifunction button “$6”. The radio switches back to the station button plane.
0DQXDOWXQLQJ
Select radio menu mode and then turn the right rotary control.
100 kHz (FM and NBC), 9kHz (AM) or 3 kHz (LW) tuning steps are per-
formed.
Pressing the right rotary control switches to fine tuning (1kHz steps) for AM
and LW.
The function is quit if there is no further actuation within 10 seconds.



52
5D LR2SHUDWLRQ
5HJLRQDOLVDWLRQ
A regional identification is displayed if regional programmes are broadcast
within the programme range of the selected transmitter. The abbreviation 53
indicates that the selected transmitter is able to broadcast regional
transmissions. In this case, the RDS - diversity function is restricted to the
selected regional area.
Pressing the multifunction button “53” enables a choice between 5(*21
(regionalisation switched on) and 5(*2)) (regionalisation switched off).
The RDS - diversity function is independent of region. Switching between
various regional transmitters can occur in this mode. Regional operation must
be selected again if this phenomenon occurs.


53
5D LR2SHUDWLRQ
7UDIILF3URJUDP73
The traffic programme system offers the advantage that current traffic news
can be received and heard despite the fact that Tape/CD, AM, LW or FM
transmitters (which are not special traffic programme transmitters) are
selected. For this purpose, it is essential that a traffic programme or EON
(enhanced other network) transmitter is selected in the FM waveband and that
the traffic programme is activated.
The EON function is not available for AM and LW.
(21WUDQVPLWWHU LVSOD\VHOHFW
If an EON transmitter is selected, the prompt (21 appears. The transmitter
can be selected by transmitter search or by direct frequency entry.
(21WUDQVPLWWHUVZLWFKRQRII
If the selected EON transmitter is to be activated for traffic announcements in
the FM range or during tape/CD operation, the button must be pressed
until the abbreviation 73 is displayed.
If traffic announcements are not desired, the button must be pressed until
the abbreviation 73 is extinguished.
7UDIILFSURJUDPWUDQVPLWWHU LVSOD\VHOHFW
If a traffic program transmitter is selected, the abbreviation 7appears. The
transmitter can be selected by transmitter search or by direct frequency entry.




54
5D LR2SHUDWLRQ
$QRXQFHPHQWVWDQ E\VZLWFKRQRII
If the selected traffic programme transmitter should interrupt the AM, LW or
tape/CD operation for traffic announcements, the button must be pressed
until the abbreviation 73 is displayed.
If traffic announcements are not desired, the button must be pressed until
the abbreviation 7appears.
If no traffic programme transmitter is selected, the automatic transmitter search
is activated by pressing the button and a traffic programme transmitter is
selected.
1RWH During the traffic announcement, the desired increase in volume
can be set via the volume button. An announcement which is
currently being heard can be terminated by pressing the button.
The unit then switches back immediately to the previously selected
operating mode in the mute condition. However, the next traffic
announcement is switched through again.
0XWHIXQFWLRQVZLWFKRQRII
After selection of a TP or EON transmitter, the mute function can be activated
by pressing the button briefly. The prompt 73,1)2 appears. Thereafter,
only traffic announcements are switched through. The mute function is
cancelled by pressing the button again or by turning the volume control.
If no TP or EON transmitter is selected, 087( is displayed on actuating the
button. For 087(, no traffic announcements are switched through.



55
5D LR2SHUDWLRQ
7HOHSKRQHPXWHIXQFWLRQ
The telephone characteristics can be set in the user menu (see also page 66) if
a telephone system is installed in the vehicle and the mute function lead for the
car telephone is connected to the car radio.
For the setting 3+2)), the radio is switched to mute if a call is received.
For the setting 3+21, the telephone call is connected through the radio unit
if a call is received.
However, this is only possible if, in addition to the telephone, a handsfree unit
with loudspeaker output is installed and connected to the radio. In both cases,
3+21( is displayed.
7LPHUHTXHVW
Select radio menu mode in FM waveband. Then press multifunction button
“7” (7ime). The current time in hours and minutes is displayed. This display
is only possible if the time signal is received via RDS. If no time signal has
been received,  is displayed.



56
7DSH2SHUDWLRQ
&DVVHWWHVLQVHUWHMHFW
Press button briefly; the display folds downwards and the cassette slot
becomes visible. Push in cassette with tape-side to the right until it engages and
press lightly. The cassette is drawn in automatically. Then fold the display up
again.
The unit switches automatically to cassette operation. 7$3( and 75$&.
are displayed.
If there is already a cassette in the cassette slot, press button repeatedly
until 7$3( appears on the display.
In order to eject a cassette, press button briefly; the display folds
downwards and the cassette is ejected and can be removed. Then fold the
display up again.
$WWHQWLRQ The cassette is not ejected when the unit is switched off but
remains in the cassette slot.
7UDFNVZLWFKLQJ
The track is changed automatically at the end of the tape.
The tape track can be switched at any desired position by pressing briefly one
of the multifunction buttons for track switching. The track currently playing is
shown on the display.
5D LRRSHUDWLRQ XULQJIRUZDU UHZLQ
During forward / rewind, the radio (FM) can be connected through by turning
the volume control. Operation of the radio functions is, however, not possible.



57
7DSH2SHUDWLRQ
)DVWIRUZDU UHZLQ
During cassette operation, fast forward / rewind can be activated using the
multifunction buttons.
In order to cancel the function, press or turn the right rotary control, or press
the track switching buttons or the fast forward / rewind buttons.
0XVLFVHDUFKIRUZDU VEDFNZDU V
In order to activate the forward music search, turn the right rotary control to the
right until the desired number of tracks to be skipped (max. 9) is set.
In order to activate the backward music search, turn the right rotary control to
the left until the desired number of tracks to be skipped (max. 9) is set.
The beginning of a track can only be found if there is a pause of at least
4 seconds between tracks. In order to cancel the function, press or turn the right
rotary control, or press the track switching buttons or the fast forward / rewind
buttons.
'ROE\15
For the playing of cassettes which have been recorded using Dolby NR, press
the multifunction button repeatedly until the desired noise reduction mode
(Dolby B or Dolby C) appears on the display.
For the playing of non-Dolby cassettes, press the button repeatedly until the
Dolby NR display is extinguished.




58
7DSH2SHUDWLRQ
6NLSEODQN
If skip blank is active, automatic forward is activated at blank tape sections
which are longer than 10 to 15 seconds.
In order to activate the function, press the multifunction button “6%” until 6%
is shown on the display.
6FDQVHDUFK
Press the right rotary control to start the scan search.
6& appears on the display. Each track is played for approx. 10 seconds.
In order to cancel the function, press the track switching buttons or the fast
forward / rewind buttons.
&OHDQLQJWKHFDVVHWWHPHFKDQLVP
After a time, the reproduction quality of cassettes is reduced due to
unavoidable dirt and dust deposits on the sound head. The drive components in
the cassette mechanism also become dirty. For this reason the cassette
mechanism should be cleaned from time to time. The prompt &/($1 appears
on the display after each 30 hours running time.
Use a cleaning cassette suitable for reverse operation for this purpose. The
cleaning cassette should be removed again after 30 seconds.



