Behringer Minimon Mon800 User manual

Technical Specications
MINIMON MON800
Ultra-Compact Stereo Monitor Matrix Mixer with Talkback Mic

2MINIMON MON800 Technical Specifications
MINIMON MON800
Ultra-Compact Stereo Monitor Matrix Mixer with Talkback Mic
Ultra-compact monitor matrix mixer for studio and stage applications
Dedicated input section with 4 selectable and mixable stereo inputs
Accurate 6-segment LED main stereo output meters for precise level indication
High-power phones output with dedicated Level control
3 selectable stereo speaker outputs with separate Level controls for ultimate monitoring
Professional Mute, Dim and Mono functions for ultimate exibility and phase check
Talkback section with internal microphone and comprehensive routing options
High-quality potentiometers and illuminated switches for long-term reliability
All Mini Series models can be stacked on top of each other to create an ultra-compact signal processor solution
High-quality components and exceptionally rugged construction ensure long life
Conceived and designed by BEHRINGER Germany
Specications
Mix In A + B
Type ¼" TS connectors
Impedance approx. 10 kΩ unbalanced
approx. 20 kΩ balanced
Max. input level 15 dBu
CD/Tape In C + D
Type RCA connectors
Impedance approx. 10 kΩ
Max. input level 15 dBu
2-Track Out A + B
Type ¼" TS connectors /
RCA connectors
Impedance approx. 150 Ω (TS),
approx. 150 Ω (RCA)
Max. output level 15 dBu
Cue Out
Type ¼" TS connectors
Impedance min. 150 Ω
Max. output level 15 dBu
Phones
Type ¼" TRS connector
(on front/back)
Impedance min. 100 Ω
Max. output level 10 dBu / 100 Ω (70 mW)
Speakers Out A
Type ¼" TS connectors
Impedance min. 150 Ω
Max. output level 15 dBu
Speakers Out B + C
Type RCA connectors
Impedance min. 150 Ω
Max. output level 15 dBu
System Specications
Frequency response 10 Hz to 80 kHz, ±3 dB
Dynamic range 112 dB, 20 Hz to 20 kHz
Distortion (THD) 0,005% typ. @ +4 dBu
Crosstalk -75 dB @ 1 kHz
Signal-to-noise ratio 102 dBu @ +4 dBu,
A-weighted

3MINIMON MON800 Technical Specifications
BEHRINGER makes every effort to ensure the highest standard of quality. Necessary modifications are carried out without notice. Thus, the specifications and design of the device may differ from the information
given in this manual.
Technical specifications and appearances are subject to change without notice and accuracy is not guaranteed. BEHRINGER is part of the MUSIC Group (music-group.com). All trademarks are the property
of their respective owners. MUSIC Group accepts no liability for any loss which may be suffered by any person who relies either wholly or in part upon any description, photograph or statement contained
herein. Colors and specifications may VARY FROM ACTUAL PRODUCT. MUSIC GROUP products are sold through authorized FULLFILLERS AND RESELLERS only. FULLFILLERS AND RESELLERS are not agents
of MUSIC Group and have absolutely no authority to bind MUSIC Group by any express or implied undertaking or representation. This manual is copyrighted. No part of this manual may be reproduced
or transmitted in any form or by any means, electronic or mechanical, including photocopying and recording of any kind, for any purpose, without the express written permission of MUSIC Group IP Ltd.
ALL RIGHTS RESERVED. © 2012 MUSIC Group IP Ltd. Trident Chambers, Wickhams Cay, P.O. Box 146, Road Town, Tortola, British Virgin Islands
Power Supply
Mains connection external power supply,
9 V~, 750 mA
Mains Voltage
USA/Canada 120 V~, 60 Hz
U.K./Australia 240 V~, 50 Hz
China 220 V~, 50 Hz
Europe 230 V~, 50 Hz
Japan 100 V~, 50 - 60 Hz
Power consumption approx. 6 W
Dimensions/Weight
DIMENSIONS (H x W x D) approx. 48 x 120 x 242.6 mm
Weight approx. 0.77 kg
