Important Safety
Instructions
Terminals marked with this
symbol carry electrical current
of sucient magnitude to
constitute risk of electric shock. Use only
high-quality professional speaker cables
with ¼"TS or twist-locking plugs
pre-installed. Allother installation or
modication should be performed only by
qualiedpersonnel.
This symbol, wherever it
appears, alerts you to the
presence of uninsulated
dangerous voltage inside the enclosure -
voltage that may be sucient to constitute
a risk ofshock.
This symbol, wherever it
appears, alerts you to
important operating and
maintenance instructions in the
accompanying literature. Please read
themanual.
Caution
To reduce the risk of electric
shock, do not remove the
top cover (or the rear section). No user
serviceable parts inside. Refer servicing to
qualiedpersonnel.
Caution
To reduce the risk of re or
electric shock, do not expose
this appliance to rain and moisture.
Theapparatus shall not be exposed to
dripping or splashing liquids and no
objects lled with liquids, such as vases,
shall be placed on the apparatus.
Caution
These service instructions are
for use by qualied service
personnel only.Toreduce the risk of electric
shock do not perform any servicing other
than that contained in the operation
instructions. Repairshave to be performed
by qualied servicepersonnel.
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation
openings. Install in accordance with the
manufacturer’s instructions.
8. Do not install near any heat sources
such as radiators, heat registers, stoves,
orother apparatus (including ampliers)
that produce heat.

4GUITAR LINK UCG102 User Manual
9.
Do not defeat the safety purpose of
the polarized or grounding-type plug.
Apolarized plug has two blades with one
wider than the other. A grounding-type
plug has two blades and a third grounding
prong. The wide blade or the third prong
are provided for your safety. Ifthe provided
plug does not t into your outlet, consult
an electrician for replacement of the
obsolete outlet.
10. Protect the power cord from being
walked on or pinched particularly at plugs,
convenience receptacles, and the point
where they exit from the apparatus.
11. Use only attachments/accessories
specied by themanufacturer.
12. Use only with
the cart, stand,
tripod, bracket,
or table specied by
the manufacturer,
orsold with the
apparatus. When a cart is used, use caution
when moving the cart/apparatus
combination to avoid injury from tip-over.
13. Unplug this apparatus during lightning
storms or when unused for long periods
of time.
14. Refer all servicing to qualied service
personnel. Servicing is required when
the apparatus has been damaged in any
way, such as power supply cord or plug is
damaged, liquid has been spilled or objects
have fallen into the apparatus, the apparatus
has been exposed to rain or moisture, does
not operate normally, or has beendropped.
15. The apparatus shall be connected to
a MAINS socket outlet with a protective
earthing connection.
16. Where the MAINS plug or an
appliance coupler is used as the disconnect
device, the disconnect device shall remain
readily operable.
17.
Correct disposal
of this product:This
symbol indicates that
this product must
not be disposed of
with household waste, according to the
WEEE Directive (2012/19/EU) and your
national law.This product should be taken
to a collection center licensed for the
recycling of waste electrical and electronic
equipment (EEE).The mishandling of
this type of waste could have a possible
negative impact on the environment
and human health due to potentially
hazardous substances that are generally
associated with EEE. At the same time, your
cooperation in the correct disposal of this
product will contribute to the ecient use
of natural resources. For more information
about where you can take your waste
equipment for recycling, please contact
your local city oce, or your household
waste collection service.

5GUITAR LINK UCG102 User Manual
LEGAL DISCLAIMER
LIMITED WARRANTY
MUSIC Group accepts no liability for any
loss which may be suered by any person
who relies either wholly or in part upon
any description, photograph, or statement
contained herein.Technical specications,
appearances and other information
are subject to change without notice.
All trademarks are the property of their
respective owners. MIDAS, KLARKTEKNIK,
TURBOSOUND, BEHRINGER, BUGERA and
DDA are trademarks or registered trademarks
of MUSIC Group IP Ltd. © MUSIC Group IP
Ltd. 2015 All rights reserved.
For the applicable warranty terms and
conditions and additional information
regarding MUSIC Group’s Limited Warranty,
please see complete details online at
music-group.com/warranty.

6GUITAR LINK UCG102 User Manual
1. Introduction
Thank you for expressing your condence in us by purchasing
the GUITAR LINK UCG102. Your computer will become the
ultimate working platform on which you can use the classic
eects, inthe studio as well as on stage. With a notebook,
aguitar and the UCG102, it is now possible to work on the go,
be it train or hotel. The GUITAR LINK UCG102’s scope of delivery
includes a rst-class modeling software with virtual amps
and eects pedals. Accompany songs in MP3-, WAV- andAIFF-
format which you can play from your PC or Mac computer.
Aheadphone connection with a volume regulator is also
available so that you can enjoy the session with your favorite
volumes undisturbed, entirely after the motto“Plug‘n Rock”.
1.1 Before you get started
1.1.1 Shipment
Your GUITAR LINK UCG102 was carefully packed at the assembly
plant to assure secure transport. Should the condition of the
cardboard box suggest that damage may have taken place,
pleaseinspect the unit immediately and look for physical
indications of damage.
◊ Damaged equipment should NEVER be sent directly
to us. Please inform the dealer from whom you
acquired the unit immediately as well as the
transportation company from which you took delivery.
Otherwise, all claims for replacement/repair may be
rendered invalid.
◊ Please always use the original packaging to avoid
damage due to storage or shipping.
◊ Never let unsupervised children play with the device
or with its packaging.
◊ Please dispose of all packaging materials in an
environmentally friendly fashion.
1.2 Online registration
Please register your new BEHRINGER equipment right after your
purchase by visiting http://behringer.com and read the terms
and conditions of our warranty carefully.
Should your BEHRINGER product malfunction, it is our intention
to have it repaired as quickly as possible. To arrange for
warranty service, please contact the BEHRINGER retailer from

7GUITAR LINK UCG102 User Manual
whom the equipment was purchased. Should your BEHRINGER
dealer not be located in your vicinity, you may directly contact
one of our subsidiaries. Corresponding contact information is
included in the original equipment packaging (Global Contact
Information/European Contact Information). Should your
country not be listed, please contact the distributor nearest
you. A list of distributors can be found in the support area of our
website (http://behringer.com).
Registering your purchase and equipment with us helps us
process your repair claims more quickly and eciently.
Thank you for your cooperation!
2. Controls and Connections
You can connect the UCG102 directly to an amp by means of
the jack connector and to your PC or Mac computer by using
the USB connector. The USB connection supplies the power for
theUCG102.
(1) (2) (3)
(5) (4)
(6)
Fig. 2.1: Control elements and connections
(1) You can connect the guitar to your computer via USB
connection. The blue control LED (6) indicates that a
connection to the computer has been established.
(2) The VOLUME control adjusts the volume level of the
headphones output. Turn the control fully to the left
before you connect the headphones. Thishelps you avoid
the damage that is caused by high volumesettings.

8GUITAR LINK UCG102 User Manual
(3) You can use a commercially available ¼" jack for
the -connection.
◊ We would like to draw your attention to the fact
that extremely loud sound levels may damage your
hearing as well as your headphones/loudspeakers.
Turn the VOLUME control fully clockwise before you
switch on the unit. Be careful to select a suitable
volume at all times.
(4) You can connect the UCG102 to your guitar via the guitar
input (¼"jack). Use a commercial ¼" mono jack cable.
(5) You can modify the guitar signal with the LEVEL switch.
Athigh signal levels, the CLIP LED (above the BEHRINGER
LOGO) will light up red in which case you should set the
LEVEL switch to LOW.
(6) The blue LED indicates the status of the USB connection.
3. Application Example
You can connect the UCG102 directly to your computer in order to
record, play along to a playback or play directly over the modeling
amps and eects. The UCG102 lets you get started immediately,
wherever you are. Simply hook up and start to rock.
3.1 Operation of the connector
UCG102
PC/Mac
Monitor
MS16
(optional)
HPS3000 Guitar
Fig. 3.1: Wiring of the UCG102
Use the USB cable to connect the GUITAR LINK UCG102
toyourcomputer. The USB unit of the UCG102 is bus
powered—noseparate power supply is needed. The blue LED
(6) lights up and the system indicates the connection of a USB
audio unit.

9GUITAR LINK UCG102 User Manual
Connect your headphones to the PHONES connector on
theUCG102.
If you don’t want to use your headphones, you can also
connect a pair of active monitors to the PHONES connector—
theBEHRINGER MONITOR SPEAKERS Series, MS16,MS20, MS40,
B2030A or B2031A are perfect choices forthisapplication.
4. Audio Connections
With the integrated USB interface, you can change your
computer to an ultimate recording studio. Whetheryou
rehearse at home or in the studio, the used audio connections
always remain the same.
4.1 Wiring
You connect the UCG102 to your guitar via a standard
instrumentcable.
strain relief clamp
strain relief clamp
sleeve
sleeve
tip
tip
sleeve
ground/shield
sleeve
ground/shield
tip
signal
tip
signal
Fig. 4.1: Unbalanced instrument cable with ¼" TS connector

10 GUITAR LINK UCG102 User Manual
4.2 Headphone connection
The UCG102 provides a connection for head-phones. Youcan
connect any standard com-mercial headphone with a
¼" TRS jack plug. Formini TRS jack plugs, you will need a
suitableadapter. Youcan see the required pin allocation from
thefollowingdiagram.
strain relief clamp
sleeve
ring
tip
sleeve
ground/shield
For connection of balanced and unbalanced plugs,
ring and sleeve have to be bridged at the stereo plug.
Balanced ¼" TRS connector
ring
cold (-ve)
tip
hot (+ve)
Fig. 4.2: TRS stereo connector
4.3 USB cable
The UCG102 comes with a USB cable for connecting
USB-compatible devices like notebooks.
Fig. 4.3: USB connector cable

11 GUITAR LINK UCG102 User Manual
5. Specications
Guitar In
Connector ¼" TRS
Input Impedance (High) 250 k
Input Impedance (Low) 400 k
Phones Out
Connector ¼" TRS
Output impedance approx. 50 
Max. output pegel -2 dBu,2 x 3.7 mW @ 100 
USB 1.1
Connector type A
Digital Processing
Converter 16-bit converter
Sample rate 32.0 / 44.1 / 48 kHz
Power Supply
USB connection 5 V , 100 mA max.
Dimensions / Weight
Dimensions (H x W x D) approx. 1 x 2 x 3 ¾"
approx. 24.6 x 50.8 x 95.6 mm
Cable length approx. 5 ⁄" / 15 cm
Weight approx. 0.198 lbs / 0.09 kg
System Requirements (PC / Mac)
Operating system Win XP / Win 7 / Win 8 /
Win 8.1 / Mac OS X
Processor min. (PC) Pentium 700 MHz /
Athlon XP 1.33 GHz
Processor min. (Mac) G4 733 MHz /
Intel Core Duo 1.66
RAM (PC) 256 MB
RAM (Mac) 512 MB

12 GUITAR LINK UCG102 User Manual
Software
Applications please see “Software
Installation Guide”
Driver (Windows) high-performance driver
BEHRINGER USB AUDIO for
Win 98 (SE) / ME / 2000 /
XP/Vista / Win 7 / Win 8 /
Win 8.1
Driver (Mac OS X) Core Audio
BEHRINGER is constantly striving to maintain the highest professional standards.
As a result of these efforts, modifications may be made from time to time to existing
products without prior notice. Specifications and appearance may differ from those listed
or illustrated.

13 GUITAR LINK UCG102 User Manual
FEDERAL COMMUNICATIONS
COMMISSION COMPLIANCE
INFORMATION
Responsible Party Name: MUSIC Group Services NV Inc.
Address: 5270 Procyon Street
Las Vegas, NV 89118
USA
Phone Number: [phone]
GUITAR LINK UCG102
complies with the FCC rules as mentioned in the followingparagraph:
This equipment has been tested and found to comply with the limits
for a ClassB digital device, pursuant to part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee
that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment o and
on, the user is encouraged to try to correct the interference by one or
more of the followingmeasures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent from
that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician forhelp.
This device complies with Part 15 of the FCC rules. Operation is subject
to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including
interference that may cause undesired operation.
Important information:
Changes or modications to the equipment not expressly approved by
MUSIC Group can void the user’s authority to use the equipment.
GUITAR LINK UCG102

We Hear You
