Behringer MIDI FOOT CONTROLLER FCB1010 Guide

Using a Behringer FCB1010 with a Korg Pa2X
1
Korg Pa2X Pro
Using a Behringer FCB1010 MIDI Foot Controller
Contents
Overview................................................................................................................................................2
Behringer FCB1010 MIDI Foot Controller............................................................................................3
FCB1010 Manager.................................................................................................................................4
Korg Pa2X –Remote control of the Style Elements ......................................................................10
Load SysEx Data into the FCB1010 Manager.................................................................................12
Check Global Configuration............................................................................................................15
Send SysEx Data to the FCB1010 device........................................................................................16
Set the FCB1010 in MIDI MERGE MODE........................................................................................18
Korg Pa2X PRO Setup ..........................................................................................................................19
Mode = STYLE PLAY.........................................................................................................................19
Set the Split Point on the Pa2X.......................................................................................................22
Open the STYLE MENU ...................................................................................................................26
GLOBAL SETTINGS...........................................................................................................................31
GLOBAL MIDI settings.....................................................................................................................32
Roland RD-700GX Setup .....................................................................................................................36
Connect the FCB1010 and the RD-700GX to the Pa2X .....................................................................38

Using a Behringer FCB1010 with a Korg Pa2X
2
Overview
This document explains how to use a Behringer FCB1010 MIDI Foot Controller with the Korg
Pa2X PRO 76-Key Arranger Keyboard.
You can control the essential Style Elements on the Pa2X remotely by using the FCB1010 device.
Additionally, you can connect a weighted 88-key Stage Piano like the Roland RD-700GX utilizing
the MIDI Merge function of the FCB1010 device.
By setting a split point on the RD-700GX you can trigger fingered chords on the Pa2X right from
your RD-700GX Keyboard Controller.
This allows complete hands free operation of the Pa2X.

Using a Behringer FCB1010 with a Korg Pa2X
3
Behringer FCB1010 MIDI Foot Controller
https://www.sweetwater.com/store/detail/FCB1010--behringer-midi-foot-controller-fcb1010
There are two free Editors for this device:
FCB1010 Manager
FCB1010 PC Editor
The FCB1010 PC Editor lets you detect the EPROM version of your device without opening the
back plate.
http://www.mtnsys.com/?path=faq-fcb/PCEditorBeta.htm%3f
The latest firmware as of 5/13/2017 is 2.5.1E
You will be using the FCB1010 Manager for this tutorial.

Using a Behringer FCB1010 with a Korg Pa2X
4
FCB1010 Manager
Download the FCB1010 Manager from:
https://mountainutilities.eu/fcb1010
Run fcbman-2.2.1-install.exe

Using a Behringer FCB1010 with a Korg Pa2X
5
Install Folder = C:\Program Files\Mountain Utilities\FCB1010 Manager\

Using a Behringer FCB1010 with a Korg Pa2X
6

Using a Behringer FCB1010 with a Korg Pa2X
7

Using a Behringer FCB1010 with a Korg Pa2X
8

Using a Behringer FCB1010 with a Korg Pa2X
9
View | MIDI | Input Messages

Using a Behringer FCB1010 with a Korg Pa2X
10
Korg Pa2X –Remote control of the Style Elements
Download the Korg Pa2X Owner’s Manual.
https://www.korg.com/us/support/download/manual/1/186/2212/
Open Page 280

Using a Behringer FCB1010 with a Korg Pa2X
11
Note: Korg uses a numbering scheme based on 0-127.
However, the FCB1010 uses a numbering scheme based on 1-128.
This means you must increment the Korg values by 1
Here is the translation table:
Program Change Function Program Change (Based on 1-128)
80 Intro 1 81
81 Intro 2 82
82 Intro 3 83
83 Variation 1 84
84 Variation 2 85
85 Variation 3 86
86 Variation 4 87
87 Fill 1 88
88 Fill 2 89
89 Fill 3/Break 90
90 Ending 1 91
91 Ending 2 92
92 Ending 3 93
93 Fade In/Out 94
94 Memory 95
95 Bass Inversion 96
96 Manual Bass 97
97 Tempo Lock 98
98 Single Touch 99
99 Style Change 100
100 Start/Stop Style 101
101 Play/Stop (Player 1) 102
102 Play/Stop (Player 2) 103
64 STS 1 65
65 STS 2 66
66 STS 3 67
67 STS 4 68

Using a Behringer FCB1010 with a Korg Pa2X
12
Load SysEx Data into the FCB1010 Manager
Download this ZIP file:
http://davidapps.net/fcb1010/fcb1010_pa2x.zip
Open the SysEx file = FCB1010+Pa2X.syx
Bank 0 and Bank 1 contain the most useful presets.
Expression Pedal A is set to Modulation (CC# = 1)
Expression Pedal B is set to Expression (CC# = 11)

Using a Behringer FCB1010 with a Korg Pa2X
13
Open the FCB1010 Emulator
Bank 0
Bank 1
This has the 4 One Touch Voice Settings

Using a Behringer FCB1010 with a Korg Pa2X
14
Banks 4, 5 and 6 contains the complete list of remote functions recognized by the Pa2X.

Using a Behringer FCB1010 with a Korg Pa2X
15
Check Global Configuration
View | Global Configuration
Note:
PC 1 must be set to MIDI Channel 16
MIDI Channel 16 = Control Channel on Pa2X
EXP A and EXP B must be set to MIDI Channel 1
MIDI Channel 1 = Global Channel on Pa2X

Using a Behringer FCB1010 with a Korg Pa2X
16
Send SysEx Data to the FCB1010 device
Send this SysEx data to the FCB1010
Turn on the POWER on the FCB1010 unit while pressing the DOWN button.
The FCB1010 will power up in DIRECT SELECT MODE.
You can see the Green LED.
The Global Configuration has 4 Modes:
DIRECT SELECT
MIDI Function
MIDI Channel
CONFIG
Press the DOWN button.
You are now under CONFIG MODE.
The green LED under CONFIG will be lit.
Press the 7 button to make the FCB1010 ready to receive SysEx data.
Press OK

Using a Behringer FCB1010 with a Korg Pa2X
17
Press and hold the DOWN button until the LED counts down to 00.
Your SysEx data is now saved in the device.

Using a Behringer FCB1010 with a Korg Pa2X
18
Set the FCB1010 in MIDI MERGE MODE
You want the MIDI OUT from the Roland RD-700GX to feed the MIDI IN of the FCB1010.
You want the merged output from the FCB1010 to feed the Korg Pa2X Pro.
Open the GLOBAL CONFIGURATION –CONFIG page:
Make sure the LEDs on Pedal 8 and 9 are ON.
Pedal 8 = Red LED ON = MIDI MERGE Enabled
Pedal 9 = Red LED ON = Running Status Enabled

Using a Behringer FCB1010 with a Korg Pa2X
19
Korg Pa2X PRO Setup
You must make the following settings on the Korg Pa2X to make it work with the Behringer
FCB1010 MIDI Foot Controller.
Mode = STYLE PLAY
Press the STYLE PLAY button.
The Pa2X is now in STYLE PLAY MODE.

Using a Behringer FCB1010 with a Korg Pa2X
20
Press the MEMORY button
Press the SYNCHRO START button
