SHARK® DSP110
www.behringer.com
Version 1.1 June 2000
Technical Specifications
ENGLISH

2
DSP110
SHARK®
Easy-to-use automatic FEEDBACK DESTROYER with additional learn function for reliable feedback suppression
sVariable delay line with up to 2.5 seconds of delay, adjustable in msec, meters or feet
sUltra-musicalcompressorwithadjustabledensityandspeedparameter
sExtremely fast automatic noise gate with learn function and optional manual setting
sMusicallow-cutfilterwithadjustablecut-offfrequency
sUltra-lownoisemicrophonepre amp with 60 dB gain control and +48 Vphantompower
sLevelconversionfromlinetomicrophone levelandviceversa
sStatus LED’s for all 12 filters
sTwo24-bitA/D and D/A converters
sServo-balancedinputs and outputs with XLR and 1/4" phoneconnectors
sRuggedexternalpowersupply for maximum signal integrity and headroom
s6-segmentcliplevelmeterwithclippingindicator
s4-digitmulti-functiondisplay
s19"rack-mountingkit for 5 SHARKs (optional)
sManufacturedunder ISO9000 certfied managementsystem

3
SPECIFICATIONS
AUDIOINPUTS
Connectors XLRand 1/4"phone
Type RFfiltered, servo-balancedinput
Impedance 6 kΩbalanced, 3 kΩunbalanced
NominalOperatingLevel microphoneorline level source (switchable)
Max.Input Level +19 dBu at microphone level and line level
AUDIOOUTPUTS
Connectors XLRand 1/4"phone
Type electronicallyservo-balanced outputstage
Impedance 60 Ωbalanced,30Ωunbalanced
NominalOperatingLevel microphonelevelsourceor+4dBu (switchable)
Max.Output Level +20 dBuat +4 dBu nominal level, -12 dBu at microphone level
SYSTEMSPECIFICATIONS
FrequencyResponse 10 Hz to 21 kHz
Noise > 92 dB at line level, unweighted, 22 Hz to 22 kHz
> 89 dB at microphone level, unweighted, 22 Hz to 22 kHz
THD 0.007 % typ. @ +4 dBu, 1 kHz, gain 1
DIGITALPROCESSING
Converters 24-bitSigma-Delta, 64/128-times oversampling
SamplingRate 46.875 kHz
DISPLAY
Type 4-digitnumeric LED display
POWERSUPPLY
MainsVoltages USA/Canada 120 V ~, 60 Hz, PSU DSP110UL
U.K./Australia 240 V ~, 50 Hz, PSU DSP110UK
Europe 230 V ~, 50 Hz, PSU DSP110EU
Japan 100 V ~, 60 Hz, PSU DSP110JP
Generalexport model 100 - 120 V ~, 200 - 240 V ~, 50 - 60 Hz
PHYSICAL
Dimensions (H * W * D) app. 2 .2" (56 mm) x 3.5" (88 mm) x 5.1" (130 mm)
NetWeight app. 0.5 kg
BEHRINGER is constantly striving to maintain the highest professional standards. As a result of these efforts, modifications may be made from time
to time to existing products without prior notice. Specifications and appearance may differ from those listed or illustrated.

4
The information contained in this sheet is subject to change without notice. No part of this sheet may be reproduced or
transmitted in any form or by any means, electronic or mechanical, including photocopying and recording of any kind, for any
purpose, without the express written permission of BEHRINGER Spezielle Studiotechnik GmbH.
BEHRINGER,SHARKandFEEDBACK DESTROYERare registeredtrademarks. ALLRIGHTS RESERVED.
©2000 BEHRINGERSpezielle Studiotechnik GmbH.
