Foreword
InstallationmanualforiXT10A
Foreword
All operator panels are developed to satisfy the demands of human-machine
communication. Built-in functions such as displaying and controlling text,
dynamic indication, time channels, alarm and recipe handling are included.
The operator panel works primarily in an object-oriented way, making it easy to
understand and use. Configuration is carried out on a PC using the iX Developer
configuration tool. The project can then be transferred and stored in the operator
panel itself.
Various types of automation equipment such PLCs, servos or drives can be
connected to the operator panels. In this manual, the term “the controller” refers
to the connected equipment.
This manual explains how to install the operator panel. Please refer to the
iX Developer reference manual for further information.
Order no: MAEN017F
Copyright © 2013-09 Beijer Electronics AB. All rights reserved.
The information in this document is subject to changewithoutnoticeandisprovidedasavailableatthe
time of printing. Beijer Electronics AB, including all its group companies, reserves the right to change any
information without updating this publication. Beijer Electronics AB, including all its group companies,
assumesnoresponsibilityforanyerrorsthatmayappearinthisdocument. Readtheentireinstallation
manual prior to installing and using this equipment. Only qualified personnel may install, operate or repair
this equipment. Beijer Electronics AB, including all its group companies, are not responsible for modified,
altered or renovated equipment. Because the equipment has a wide range of applications, users must acquire
the appropriate knowledge to use the equipment properly in their specific applications. Persons responsible
for the application and the equipment must themselves ensure that each application is in compliance with
all relevant requirements, standards and legislationinrespecttoconfigurationandsafety. Onlypartsand
accessories manufactured according to specifications set by Beijer Electronics AB, including all its group
companies, may be used.
BEIJER ELECTRONICS AB, INCLUDING ALL ITS GROUP
COMPANIES, SHALL NOT BE LIABLE TO ANYONE FOR ANY
DIRECT, INDIRECT, SPECIAL, INCIDENTAL OR CONSEQUENTIAL
DAMAGES RESULTING FROM THE INSTALLATION, USE OR
REPAIR OF THIS EQUIPMENT, WHETHER ARISING IN TORT,
CONTRACT, OR OTHERWISE. BUYER'S SOLE REMEDY SHALL
BE THE REPAIR, REPLACEMENT, OR REFUND OF PURCHASE
PRICE, AND THE CHOICE OF THE APPLICABLE REMEDY SHALL
BE AT THE SOLE DISCRETION OF BEIJER ELECTRONICS AB,
INCLUDING ALL ITS GROUP COMPANIES.
BeijerElectronics, MAEN017F

Contents
Contents
1 SafetyPrecautions ....................................................... 4
1.1 General ........................................................... 4
1.2 UL and cUL Installation ......................................... 4
1.3 DuringInstallation .............................................. 6
1.4 DuringUse ....................................................... 6
1.5 Service and Maintenance ........................................ 6
1.6 Dismantling and Scrapping ..................................... 6
1.7 Appearance of Air in Touch Screen ............................. 7
2 Installation ............................................................... 8
2.1 SpaceRequirements ............................................. 8
2.2 InstallationProcess .............................................. 9
2.2.1 ConnectionstotheController ..................................11
2.2.2 OtherConnectionsandPeripherals .............................11
3 TechnicalData ........................................................... 12
4 ChemicalResistance .................................................... 14
4.1 MetalCasing ..................................................... 14
4.2 Touch Screen and Overlay ....................................... 15
4.2.1 AutoflexEBA180L ..............................................15
4.2.2 TouchScreenSurface ............................................16
4.2.3 AutoflexEBA180L ..............................................16
5 OperatorPanelDrawings .............................................. 17
5.1 Connectors ....................................................... 17
5.2 CommunicationPorts ........................................... 17
5.3 iXT10AOutline ................................................. 19
6 Additional Installation Tips ............................................ 20
6.1 Grounding the Operator Panel ................................. 20
6.2 Ethernet Connection in the Operator Panel ................... 21
6.3 To Achieve Better EMC Protection ............................. 23
6.4 AmbientTemperature ........................................... 24
6.5 Safety ............................................................. 25
6.6 GalvanicIsolation ................................................ 26
6.7 Cable and Bus TerminationRS485 ............................. 27
BeijerElectronics, MAEN017F

Safety Precautions
1SafetyPrecautions
Both the installer and the owner and/or operator of the operator panel must read
and understand this installation manual.
1.1 General
•Read the safety precautions carefully.
•Check the delivery for transportation damage. If damage is found, notify the
supplier as soon as possible.
•Do not use the operator panel in an environment with high explosive hazards.
•The supplier is not responsible for modified, altered or reconstructed
equipment.
•Use only parts and accessories manufactured according to specifications of
the supplier.
•Read the installation and operating instructions carefully before installing,
using or repairing the operator panel.
•Neverallowfluids,metalfilingsorwiringdebristoenteranyopeningsinthe
operator panel. This may cause fire or electrical shock.
•Only qualified personnel may operate the operator panel.
•Storing the operator panel where the temperature is lower/higher than
recommended in this manual can cause the LCD display liquid to
congeal/become isotopic.
•The LCD display liquid contains a powerful irritant. In case of skin contact,
wash immediately with plenty of water. In case of eye contact, hold the eye
open,flushwithplentyofwaterandgetmedicalattention.
•Thefiguresinthismanualservesanillustrativepurpose. Becauseofthemany
variables associated with any particular installation, the supplier cannot
assume responsibility for actual use based on the figures.
•The supplier neither guarantees that the operator panel is suitable for your
particular application, nor assumes responsibility for your product design,
installation or operation.
•It is recommended to turn on and shut down the operator panel at least once
before installing any components/cards or before connecting the operator
panel to external devices, like for example serial devices.
1.2 ULandcULInstallation
Caution:
ThissectionisonlyvalidforULlabelediXT10Apanels.
•This equipment is suitable for use in Class 2 non-hazardous locations only.
[Combinations of equipment in your system are subject to investigation by
the local authority having jurisdiction at the time of installation].
BeijerElectronics, MAEN017F 4

Safety Precautions
•All devices have to be supplied by a Class 2 power supply.
Warning:
Donotdisconnectequipmentunlesspowerhasbeenremovedortheareais
knowntobenon-hazardous
•For Canada also AVERTISSEMENT – AVANT DE DECONNECTER
L’EQUIPEMENT, COUPER LE COURANT OUS’ASSURER QUE
L‘EMPLACEMENT EST DESIGNE NON DANGEREUX.
Warning:
OnlyULandcULapprovedexpansionunitsareallowedtobeconnectedto
theportdesignated“EXPANSION”. Atthemomenttherearenosuchunits
evaluatedorallowed.
Warning:
Donotreplaceexpansionunitunlesspowerhasbeenswitchedofforthearea
isknowntobenon-hazardous.
•This product contains a battery; this must only be changed in an area known
to be non-hazardous.
•Replace the battery with a BR 2032 battery. Use of another type of battery
may present a risk of fire or explosion.
Warning:
Batterymayexplodeifmistreated. Donotrecharge,disassembleordispose
ofinfire.
•For use on a flat surface of a type 4X enclosure indoor use only.
•Use 75 degree conductors only
•Use copper conductors only
•To make wiring connections to the power supply connector, follow the table
with cable and torque specifications below:
TerminalBlockNo. WireSizeAWG TQLb.In.
X1/X100Phoenixconnectors AWG30–12 5–7
X1/X100Anytekconnectors AWG24–12 3.5
•These devicesareClass2suppliedprogrammablecontrollers(industrialPCs)
for the use in industrial control equipment and are intended to be (front)
panel mounted (Type 1 and 4x for indoor use only).
BeijerElectronics, MAEN017F 5

Safety Precautions
1.3 DuringInstallation
•The operator panel is designed for stationary installation on a plane surface,
where the following conditions are fulfilled:
–no high explosive risks
–no strong magnetic fields
–no direct sunlight
–no large, sudden temperature changes
•Install the product according to the accompanying installation instructions.
•Ground the product according to the accompanying installation instructions.
•Only qualified personnel may install the operator panel.
•Separate the high voltage, signal and supply cables.
•Make sure that the voltage and polarity of the power source is correct before
connecting the product to the power outlet.
•Peripheral equipment must be appropriate for the application and location.
1.4 DuringUse
•Keep the operator panel clean.
•Emergency stop and other safety functions may not be controlled from the
operator panel.
•Do not use too much force or sharp objects when touching the keys,
touchscreen etc.
1.5 ServiceandMaintenance
•Only qualified personnel should carry out repairs.
•The agreed warranty applies.
•Before carrying out any cleaning or maintenance operations, disconnect the
equipment from the electrical supply.
•Clean the display and surrounding front cover with a soft cloth and mild
detergent.
•Replacing the battery incorrectly may result in explosion. Only use batteries
recommended by the supplier. During the warranty period, the battery needs
to be replaced by an authorized Beijer Electronics service center.
1.6 DismantlingandScrapping
•The operator panel or parts thereof shall be recycled according to local
regulations.
•The following components contain substances that might be hazardous
to health and the environment: lithium battery, electrolytic capacitor and
display.
BeijerElectronics, MAEN017F 6

Safety Precautions
1.7 AppearanceofAirinTouchScreen
•Thelayerstructureofthetouchscreencontainsairandinrarecases
appearance of bubbles can arise. This is purely cosmetic and does not affect
any functionality of the panel. The appearance can occur under certain
environmental conditions such as temperature, humidity, and atmospheric
pressure.
BeijerElectronics, MAEN017F 7

Installation
2Installation
2.1 SpaceRequirements
•Maximum installation plate thickness: 8 mm
•Space requirements in millimeters when installing the operator panel:
10022850
100
100
280
50
Note:
Thedimensionsonthedrawingarenotproportional.
BeijerElectronics, MAEN017F 8

Installation
2.2 InstallationProcess
The following is needed:
•A Phillips/slot screwdriver
1. Unpack and check the delivery. If damage is found, notify the supplier.
Note:
Placetheoperatorpanelonastablesurfaceduringinstallation.
Droppingthepanelorlettingitfallmaycausedamage.
2. Usethecutoutdimensionsthatareincludedontheoutlinedrawing,found
in section Operator Panel Drawings and in the Technical Data table, to cut
a correct opening in the cabinet. A separate cut out drawing is available for
download from the Beijer Electronics web site.
3. Secure the operator panel in position using all the fastening holes and the
provided brackets and screws:
x 8 0.5 - 1.0 Nm
BeijerElectronics, MAEN017F 9

Installation
4. Connect the cables in the specified order, according to the drawing and steps
below.
Caution:
•Ensurethattheoperatorpanelandthecontrollersystemhavethesameelectrical
grounding(referencevoltagelevel),otherwiseerrorsincommunicationmay
occur.
•Theoperatorpanelmustbebroughttoambienttemperaturebeforeitisstarted
up. Ifcondensationforms,ensurethattheoperatorpanelisdrybeforeconnecting
ittothepoweroutlet.
•Ensurethatthevoltageandpolarityofthepowersourceiscorrect.
•Useonlyshieldedcommunicationcables.
•Separatehighvoltagecablesfromsignalandsupplycables.
24V DC
RS232/
RS422/
RS485 24V DC
A
D
Controller
Power
B
Ethernet
C
–Connect cable A.
–Connect cable B, using an M5 screw and a grounding conductor (as short
as possible) with a cross-section of minimum 2.5 mm2.
–Connect cable C.
–Connect cable D. The recommended cross-section of the cable is
1.5 mm2.
5. Carefully remove the laminated film over the operator panel display, to avoid
static electricity that could damage the panel.
Note:
OnlyforiXT10Apanelswithpartnumber630000301:
Whenconnectingtheoperatorpaneltothepoweroutletforthefirsttime,make
surenottointerruptpowerforaminimumof48hoursinordertochargethebattery
completely. Afterthat,thebatterymaybechargedpartlyduringashorterperiodof
time.
BeijerElectronics, MAEN017F 10

Installation
2.2.1 ConnectionstotheController
For information about the cables to be used when connecting the operator panel to
the controller, please refer to the help file for the driver in question.
2.2.2 OtherConnectionsandPeripherals
Cables, peripheral equipment and accessories must be suitable for the application
and its environment. For further details or recommendations, please refer to the
supplier.
BeijerElectronics, MAEN017F 11

Technical Data
3TechnicalData
Parameter iXT10A
Frontpanel,W×H×D 280×228×7mm
Cutoutdimensions,
W×H 262×209mm
Mountingdepth 44mm(144mmincludingclearance)
Standalonemounting VESA75×75
Note: MaximumscrewlengthforVESAmountingis4mm.
Usageoflongerscrewsmayleadtodamage.
Frontpanelseal IP65
Rearpanelseal IP20
Touchscreen
material Polyesteronglass,resistive. Overlay: AutoflexEBA180L(1).
Touchscreen
operations 1millionfingertouchoperations
Reverseside
material Powder-coatedaluminum
Framematerial Powder-coatedaluminum
Weight 1.5kg
Serialportfor
COM1RS232and
COM2RS422/RS485
9-pinD-subcontactwithRS232RTS/CTS,chassis-mounted
femalewithstandardlockingscrews4-40UNC
Serialportfor
COM3RS232and
COM4RS422/RS485
9-pinD-subcontactwithRS232RTS/CTS,chassis-mounted
femalewithstandardlockingscrews4-40UNC
Ethernet 1×10Base-T/100Base-T(shieldedRJ45)
USB 1×USBHost2.0,maxoutputcurrent200mA
Processor 400MHzARM9
Externalstorage
media 1×SDcard(optional). OnlycompatiblewiththestandardSD formatwithupto2GBstoragecapacity.
Flashmemory
(application
memory)
128MBSSD(NANDFlash)
MemoryRAM 128MB(DDR2)
LED 1×blue/redsoftwareprogrammable
Realtimeclock Yes(onchip)
Battery(2) LithiumbatterytypeBR2032,soldered
orrechargeablebattery(2) (SeikoInstrumentsPartNo.
MS920-SEorsimilar),soldered
Powerconsumption
atratedvoltage 9.6W
Fuse InternalDCfuse,2.0AT,5×20mm
BeijerElectronics, MAEN017F 12

Technical Data
Parameter iXT10A
Powersupply +24VDC(18-32VDC)
CE:Thepowersupplymustconformwiththerequirements
accordingtoIEC60950andIEC61558-2-4.
ULandcUL:Thepowersupplymustconformwiththe
requirementsforclassIIpowersupplies.
Display TFT-LCDwithLEDbacklight.640×480pixels,64kcolors
Activeareaof
display,W×H 211.2×158.4mm
Operating
temperature -10°C–+60°C
Storagetemperature -20°C–+70°C
Relativehumidity 5-85%non-condensed
Approvalsand
certifications Informationisavailableonthewebsite www.beijerelectronics.com
(1)SeesectionChemicalResistanceformoreinformation.
(2)iXT10Apanelswithpartnumber630000301usearechargeablebattery. Allother
versionsuseaBR2032battery.
BeijerElectronics, MAEN017F 13

Chemical Resistance
4 ChemicalResistance
4.1 MetalCasing
The frame and casing material is powder-coated aluminum. This powder paint
withstands exposure to the following chemicals without visible change:
Aceticacid10% Phosphoricacid4%
Citricacid10% Phosphoricacid10%
Diesel Seawater
Distilledwater Sodiumchloride2%
Edibleoil Sodiumchloride20%
Fueloil Sulphuricacid20%
Hydrogenperoxide3% Tapwater
The powder paint shows limited resistance to the following chemicals at room
temperature:
Butanol Nitricacid3%
Hydrochloricacid5% Nitricacid10%
Isopropylalcohol Phosphoricacid43%
Na-hypochlorite10% Turpentine
Note:
Ifexposuretoanyoftheabovechemicalsisdemanded,itisrecommendedtofirsttest
thechemicalinahiddenspotofthemetalcasing.
Thepowderpaintshowslittleornoresistancetothefollowingchemicalsatroom
temperature:
Aceticacid,conc. Methyl-ethylketone Toluene
Acetone Nitricacid30% Trichlorethylene
Ammonia5% Phenol Xylene
Ammonia,conc. Sodiumhydroxide5% 97octaneunleadedpetrol
Ethylacetate Sodiumhydroxide30% 98octaneleadedpetrol
BeijerElectronics, MAEN017F 14

Chemical Resistance
4.2 TouchScreenandOverlay
4.2.1 AutoflexEBA180L
Autoflex EBA 180L covers the overlay surrounding the touch screen.
SolventResistance
Autoflex EBA 180L withstands exposure of more than 24 hours duration under
DIN42115Part2tothefollowingchemicalswithoutvisiblechange:
Acetonitrile DieselDowney/Lenor(1) Phosphoricacid(<30%)
Ajax/Viminsolution Ethanol Potassiumferricyanide
Alkalicarbonate
solution(1) Glycerine Potassiumhydroxide(<30%)
Ammonia(<40%)(1) Glycol PureTurpentine
Aceticacid(<50%) Gumption(1) SBP60/95(1)
Arielpowderin
solution(1) Hydrochloricacid(<36%) Sulfuricacid(<10%)
Bleach(1) Linseedoil Tomatoketchup
Castoroil Methanol Trichloroaceticacid(<50%)
Causticsoda(<40%)(1) Nitricacid(<10%) WhiteSpirit
Cuttingoil Paraffinoil Windex(1)
Cyclohexanol Persilpowderin
solution(1) Wisk
Diacetonealcohol Petroleumspirit(1) -
(1)Extremelyfaintglossingofthetexturewasnoted.
Autoflex EBA 180L withstands DIN 42 115 Part 2 exposure of up to 1 hour
duration to glacial acetic acid without visible change.
Autoflex EBA 180L is not resistant to high pressure steam at over 100 °C or the
following chemicals:
Concentratedmineralacids Benzylalcohol
Concentratedcausticsolution Methylenechloride
BeijerElectronics, MAEN017F 15

Chemical Resistance
4.2.2 TouchScreenSurface
The touch screen surface on the operator panel withstands exposure to the
following solvents without visible change:
Solvents Time
Acetone 10minutes
Isopropanol 10minutes
Toluene 5 hours
4.2.3 AutoflexEBA180L
It is recommended to use the Autoflex EBA 180Ltouch display protection film,
that can be ordered from Beijer Electronics.
SolventResistance
Autoflex EBA 180L withstands exposure tothesamechemicalsasAutotexF157or
F207 according to section Autoflex EBA 180L.
OutdoorUse
In common with all polyester based films, Autoflex EBA 180L is not suitable for
use in conditions of long-term exposure to direct sunlight.
BeijerElectronics, MAEN017F 16

Operator Panel Drawings
5 OperatorPanelDrawings
5.1 Connectors
1234
COM 3/4LANCOM 1/2
Pos. Connector Description
1 Powersupply +24VDC(18-32VDC)
2 COM1/2 CommunicationPorts
3 LAN 1×10/100Base-T(shieldedRJ-45)
4 COM3/4 CommunicationPorts
5.2 CommunicationPorts
Serialport,9-pinfemale Serialport,9-pinfemale
Pin COM1 COM2 COM3 COM4
1- RS422Tx+
RS485Tx+/Rx+ -RS422Tx+ RS485Tx+/Rx+
2 RS232RxD - RS232RxD -
3 RS232TxD - RS232TxD -
4 - RS422Rx+ - RS422Rx+
5 GND GND GND GND
6- RS422Tx-
RS485Tx-/Rx- -RS422Tx- RS485Tx-/Rx-
7 RS232RTS - - RS422RTS+
8 RS232CTS - - RS422RTS-
9 - RS422Rx- - RS422Rx-
Note:
Inordertoutilizetwocommunicationportsonthesamephysicalport,theY-splitcable
CAB109mustbeused.
DrawingforexternalcableCAB109(drawing#Z7100-029E)isavailableonthewebsite:
www.beijerelectronics.com
BeijerElectronics, MAEN017F 17

Operator Panel Drawings
Note:
OnlyiXT10Apanelswithpartnumber630000301areequippedwithterminated
COM-ports.
BeijerElectronics, MAEN017F 18

Operator Panel Drawings
5.3 iXT10AOutline
USB host
SD memory
card slot
Expansion port
COM3 RS232 / COM4 RS422/RS485
COM1 RS232 / COM2 RS422/RS485
Ethernet 24 V DC
209 99
7
44
228
max. 8 mm
262 99
280
Note:
AStepCADfileisavailableonthewebsitewww.beijerelectronics.com
BeijerElectronics, MAEN017F 19

Additional Installation Tips
6 AdditionalInstallationTips
When experiencing communication problems in for example noisy environments
or when operating close to temperature limits, the following recommendations
are to be noticed.
6.1 GroundingtheOperatorPanel
1
2
3
4
5
6
5350
Door
Operator panel
Ferrite core
Mounting plate in the cabinet
Power supply
24 V DC
The operator panel’s mounting clamps do not provide a secure grounding
connection between the panel and the device cabinet, see 1 in drawing above.
1. Connect a 2.5 mm2wire between the operator panel’s quick-connect plinth
and the panel’s chassis, see 2 in drawing above.
2. Connect a 6 mm2or 4 mm2wire or grounding braid between the operator
panel’s chassis and the closest grounding point on the door, see 3 in drawing
above.
3. Connect a strong but short grounding braid between the door and the device
cabinet, see 4 in drawing above.
4. Twist the cables onto the 24 V DC feed, see 5 in drawing above. Minimum
cross-section of the cable is 2.5 mm2.
2 turns around the ferrite core provide 4 times the suppression of 1 turn.
3 turns around the ferrite core provide 9 times the suppression of 1 turn.
A ferrite core suppresses disturbances to the 24 V feed, see 6 in drawing above.
BeijerElectronics, MAEN017F 20
