Beko DE 8635 RX0 User manual

Dryer
User Manual
DE 8635 RX0
DE 8635 CSRX0
2960311429_EN/060218.0912
EN
Suščky
Návod k použtí
Suščka
Užívateľská príručka
CZ SK

Please read this user manual first!
Dear Customer,
Thank you for prefering a Beko product. We hope that your product which has been
manufactured with high quality and technology will give you the best results. We advise you
to read through this manual and the other accompanying documentation carefully before
using your product and keep it for future reference. If you transfer the product to someone
else, give its manual as well. Pay attention to all details and warnings specified in the user
manual and follow the instructions given therein.
Use this user manual for the model indicated on the cover page.
Read the instructions.
Explanation of symbols
Throughout this user manual the following symbols are used:
CImportant information or useful hints about usage.
AWarning for hazardous situations with regard to life and property.
BWarning against electric shock.
Warning against hot surfaces.
Warning against fire hazard.
Packaging materials of the product are manufactured from recyclable materials in
accordance with our National Environment Regulations.
Do not dispose of the packaging wastes with the domestic waste or other wastes, discard
them to the dedicated collection points designated by the local authorities.
This product was manufactured using the latest technology in environmentally friendly conditions.

3 / EN
Dryer / User Manual
1 Important instructions for safety and
environment
Ths secton contans safety nstructons that wll help
protect from rsk of personal njury or property damage.
Falure to follow these nstructons shall vod any warranty.
1.1 General safety
•The dryer can be used by chldren at and above 8
years old and by persons whose physcal, sensory or
mental capabltes were not fully developed or who
lack experence and knowledge provded that they are
supervsed or traned on the safe usage of the product
and the rsks t brngs out. Chldren should not play wth
the product. Cleanng and mantenance works should not
be performed by chldren unless they are supervsed by
someone.
•Chldren of less than 3 years should be kept away unless
contnously supervsed.
•Adjustable feet should not be removed. The gap between
the dryer and the floor should not be reduced wth
materals such as carpet, wood and tape. Ths wll cause
problems wth the dryer.
•Always have the nstallaton and reparng procedures
carred out by the Authorzed Servce.Manufacturer
shall not be held lable for damages that may arse from
procedures carred out by unauthorzed persons.
•Never wash the dryer by sprayng or pourng water onto t!
There s the rsk of electrc shock!

4 / EN Dryer / User Manual
Important instructions for safety and
environment
1.1.1 Electrcal safety
AElectrcal safety nstructons should be followed
whle electrcal connecton s made durng the
nstallaton.
AThe applance must not be suppled through an
external swtchng devce, such as a tmer,or
connected to a crcut that s regularly swtched on
and off by utlty.
•Connect the dryer to a grounded outlet protected by a
fuse at the value specfed on the type label. Have the
groundng nstallaton performed by a qualfed electrcan.
Our company shall not be lable for any damages that
wll arse when the dryer s used wthout groundng n
accordance wth the local regulatons.
•The voltage and allowed fuse protecton s stated on the
type label plate.
•The voltage specfed on the type label must be equal to
your mans voltage.
•Unplug the dryer when t s not n use.
•Unplug the dryer from the mans durng nstallaton,
mantenance, cleanng and repar works.
•Do not touch the plug wth wet hands! Never unplug by
pullng on the cable, always pull out by grabbng the plug.
•Do not use extenson cords, mult-plugs or adaptors to
connect the dryer to power supply n order to decrease the
rsk of fre and electrc shock.
•Power cable plug must be easly accessble after
nstallaton.
BDamaged mans cable should be changed notfyng
the Authorzed Servce.

5 / EN
Dryer / User Manual
Important instructions for safety and
environment
BIf the dryer s faulty, t must not be operated unless
t s repared by an authorzed servce agent! There s
the rsk of electrc shock!
1.1.2 Product safety
Superheatng of the clothes nsde of the dryer can
occur f you cancel the programme or n the event
of a power falure whlst the dryer s runnng, ths
concentraton of heat can cause self-combuston and
fre so always actvate the ventlaton programme
to cool down or quckly remove all laundry from the
dryer n order to hang them up and dsspate the
heat.
Ponts to be taken nto consderaton for fre
hazard:
Below specfed laundry or tems must not be dred n
the dryer consderng fre hazard.
•Unwashed laundry tems
•Items soled wth ol, acetone, alcohol, fuel ol,
kerosene, stan removers, turpentne, paraffn or
paraffn removers must be washed n hot water
wth plenty of detergent before beng dred n the
dryer.
For ths reason especally the tems contanng the
above specfed stans must be washed very well, to
do ths use adequate detergent and choose a hgh
washng temperature.

6 / EN Dryer / User Manual
Important instructions for safety and
environment
Below specfed laundry or tems must not be
dred n the dryer due to the fre hazard:
•Garments or pllows bolstered wth rubber foam
(latex foam), shower bonnets, water resstant
textles, materals wth rubber renforcement and
rubber foam pads.
•Clothng cleaned wth ndustral chemcals.
Items such as lghter, match, cons, metal parts,
needle etc. may damage the drum set or may lead to
functonal problems. Therefore check all the laundry
that you wll load nto your dryer.
Never stop your dryer before the programme
completes. If you must do ths, remove all laundry
quckly and lay them out to dsspate the heat.
Clothes that are washed nadequately may gnte on
ther own and even may gnte after dryng ends.
•You must provde enough ventlaton n order to prevent
gases extng from devces operatng wth other types of
fuels ncludng the naked flame from accumulatng n the
room due to the back fre effect.
AUnderwear that contans metal renforcements
should not be dred n the dryer. Dryer may be
damaged f metal renforcements come loose and
break off durng dryng.
CUse softeners and smlar products n accordance
wth the nstructons of ther manufacturers.
CAlways clean the lnt flter before or after each
loadng. Never operate the dryer wthout the lnt
flter nstalled.

7 / EN
Dryer / User Manual
Important instructions for safety and
environment
•Never attempt to repar the dryer by yourself. Do not
perform any repar or replacement procedures on the
product even f you know or have the ablty to perform
the requred procedure unless t s clearly suggested n the
operatng nstructons or the publshed servce manual.
Otherwse, you wll be puttng your lfe and others’ lves n
danger.
•There must not be a lockable, sldng or hnged door that
may block the openng of the loadng door n the place
where your dryer s to be nstalled.
•Install your dryer at places sutable for home use.
(Bathroom, closed balcony, garage etc.)
•Make sure that pets do not enter the dryer. Check the
nsde of the dryer before operatng t.
•Do not lean on the loadng door of your dryer when t s
open, otherwse t may fall over.
•The lnt must not be allowed to accumulate around the
tumble dryer
•The tumble dryer s not to be used f ndustral chemcals
have been used for cleanng.
•Fabrc softeners, or smlar products.should be used as
specfed by the fabrc softener nstructons.
•Exhaust ar must not be dscharged nto a flue whch s
used for exhaustng fumes from applances burnng gas or
other fuels.
1.2 Mountng over a washng machne
•A fxng devce should be used between the two machnes
when nstallng the dryer above a washng machne. The
fttng devce must be nstalled by the authorzed servce
agent.

8 / EN Dryer / User Manual
Important instructions for safety and
environment
•Total weght of the washng machne and the dryer -wth
full load- when they are placed on top of each other
reaches to approx. 180 klograms. Place the products on a
sold floor that has suffcent load carryng capacty!
AWashng machne cannot be placed on the dryer.
Pay attenton to the above warnngs durng the
nstallaton on your washng machne.
Installation Table for Washing Machine and Dryer
Dryer
Depth
Washing Machine Depth
62 cm 60 cm 54 cm 50 cm 49 cm 45 cm 40 cm
54 cm Can be nstalled Can be
nstalled Cannot be
nstalled
60 cm Can be nstalled Cannot be
nstalled
1.3 Intended use
•Dryer has been desgned for domestc use. It s not sutable
for commercal use and t must not be used out of ts
ntended use.
•Use the dryer only for dryng laundry that are marked
accordngly.
•The manufacturer waves any responsblty arsen from
ncorrect usage or transportaton.
•The servce lfe of the dryer that you purchased s 10 years.
Durng ths perod, orgnal spare parts wll be avalable to
operate the dryer properly.
1.4 Chld safety
•Packagng materals are dangerous for the chldren. Keep
packagng materals away from chldren.
•Electrcal products are dangerous for the chldren. Keep
chldren away from the product when t s operatng. Do
not let them tamper wth the dryer. Use the chld-proof
lock n order to prevent the chldren to tamper wth the
dryer.

9 / EN
Dryer / User Manual
Important instructions for safety and
environment
CChld-proof lock s on the control panel.
(See Chld lock)
•Keep loadng door closed even when the dryer s not n
use.
1.5 Complance wth the WEEE regulaton
and dsposng of the waste product
Ths product comples wth EU WEEE Drectve
(2012/19/EU). Ths product bears a classfcaton
symbol for waste electrcal and electronc equpment
(WEEE).
Ths product has been manufactured wth hgh
qualty parts and materals whch can be reused
and are sutable for recyclng. Do not dspose of the waste
product wth normal domestc and other wastes at the end
of ts servce lfe. Take t to the collecton center for the
recyclng of electrcal and electronc equpment. Please
consult your local authortes to learn about these collecton
centers.
1.6 Complance wth RoHS Drectve:
The product you have purchased comples wth EU RoHS
Drectve (2011/65/EU). It does not contan harmful and
prohbted materals specfed n the Drectve.
1.7 Package nformaton
Packagng materals of the product are manufactured
from recyclable materals n accordance wth our Natonal
Envronment Regulatons. Do not dspose of the packagng
materals together wth the domestc or other wastes. Take
them to the packagng materal collecton ponts desgnated
by the local authortes.

10 / EN Dryer / User Manual
Cthe product.
Cmatch the product exactly.
C
may vary.
EN
Height (Min. / Max.) 84,6 cm / 86,6 cm*
Width 59,7 cm
Depth 65,4 cm
Capacity (max.) 8 kg**
Net weight (± 4 kg) 51 kg
Model code
See type label***Voltage
Rated power input

11 / EN
Dryer / User Manual
2Your Dryer
2.1 Package Contents
12 3 5
4
1. Water drain hose *
2. Filter drawer spare sponge*
3. User Manual
4. Drying basket*
5. Drying basket user manual*
*It can be supplied with your machine depending on its model.

12 / EN Dryer / User Manual
3 Installaton
Before the calling the nearest Authorized
Service for the installation of the dryer,
ensure that electrical installation and water
drain is appropriate referring to the user’s
manual. (See 3.3 Connecting to the
drain and 3.5 Electrical connection) If
they are not suitable, contact a qualified
electrician and technician to make necessary
arrangements.
CPreparation of the dryer's location
as well as the electrical and
waste water installations is under
customer's responsibility.
APrior to installation, visually check
if the dryer has any defects on
it. If the drier is damaged, do
not have it installed. Damaged
products cause risks for your
safety.
ALet your dryer wait for 12 hours
before starting to use it.
3.1 Appropriate installation
location
Install the dryer on a stable and level surface.
Dryer is heavy. Do not move it by yourself.
• Operate your dryer in a well ventilated,
dust-free environment.
• The gap between the dryer and the
surface should not be reduced by the
materials such as carpet, wood and tape.
• Do not cover the ventilation grills of the
dryer.
• There must not be a lockable, sliding or
hinged door that may block the opening
of the loading door in the place where
your dryer is to be installed.
• Once the dryer is installed, it should stay
at the same place where its connections
have been made. When installing the
dryer, make sure that its rear wall does
not touch anywhere (tap, socket, etc.).
• Place the dryer at least 1 cm away from
the edges of other furniture.
• Your dryer can be operated at
temperatures between +5°C and +35°C.
If the operating conditions fall outside
of this range, operation of the dryer
will be adversely affected and it can get
damaged.
• The rear surface of the tumble dryer
shall be placed against a wall.
BDo not place the dryer on the
power cable.
3.2 Removing the
transportation safety
assembly
ARemove the transportation safety
assembly before using the dryer
for the first time.
• Open the loading door.
• There is a nylon bag inside the drum that
contains a piece of styrofoam. Hold it
from its section marked with XX XX.
• Pull the nylon towards yourself and
remove the transportation safety
assembly.
ACheck that no part of the
transportation safety assembly
remains inside the drum.
3.3 Connecting to the drain
In products equipped with condenser
unit, water accumulates in the water tank
during the drying cycle. You should drain
accumulated water after each drying cycle.
You can directly drain accumulated water
through the water drain hose supplied with
the product instead of periodically draining
the water collected in the water tank.

13 / EN
Dryer / User Manual
Installation
Connecting the water drain hose
1-2 Pull hose at the behnd of the dryer
by hand n order to dsconnect t from
where t s connected. Do not use any
tools to remove the hose.
3Connect one end of the dran hose
suppled wth the dryer to the
connecton pont from where you
removed the hose of the product n
prevous step.
4Connect the other end of the dran hose
drectly to the wastewater dran or to
the washbasn.
1
3 4
2
AHose connection should be made
in a safe manner. Your drain
house will be flooded if the hose
comes out of its housing during
water discharge.
CWater drain hose should be
attached to a height of maximum
80 cm.
CMake sure that the water drain
hose is not stepped on and it is
not folded between the drain and
the machine.
3.4 Adjusting the feet
• In order to ensure that the dryer
operates more silently and vibration-
free, it must stand level and balanced
on its feet. Balance the machine by
adjusting the feet.
• Turn the feet to left or right until the
dryer stands level and firmly.
CNever unscrew the adjustable
feet from their housings.
3.5 Electrical connection
For specific instructions for electrical
connection required during installation (see
1.1.1 Electrical Safety)
3.6 Transportation of the dryer
Unplug the dryer before transporting it.
Drain all water that has remained in the dryer.
If direct water drain connection is made, then
remove the hose connections.
A
We recommend carrying the
dryer in upright position. If it is
not possible to carry the machine
in the upright position, we
recommend carrying it by tilting
towards the right side when
looked from the front.

14 / EN Dryer / User Manual
Installation
3.7 Warnings about sounds
CIt is normal to hear a metallic
noise from the compressor
sometimes during operation.
CWater collected during operation
is pumped to water tank. It is
normal to hear pumping noise
during this process.
3.8 Changing the illumination
lamp
In case an illumination lamp is used in your
laundry dryer.To change the Bulb/LED used
for illumination of your tumble dryer, call your
Authorized Service.
The lamp(s) used in this appliance is not
suitable for household room illumination.
The intended purpose of this lamp is to
assist the user to place laundry in the tumble
dryer in a comfortable way. The lamps used
in this appliance have to withstand extreme
physical conditions such as vibrations and
temperatures above 50 °C

15 / EN
Dryer / User Manual
4. Preparaton
4.1 Laundry suitable for drying in the dryer
Always obey the instructions given on the garment tags. Dry only the laundry having a label
stating that they are suitable for drying in a dryer and make sure that you select the
appropriate programme.
Drying
Settings
At any temperature At high temperature At medium temperature At low temperature Without heating Hang to dry Lay to dry Hang wet to dry Lay in shadow to dry Dry-cleanable
Iron -
IRON
Dry or Steam Iron at high
temperature
Iron at medium
temperature Iron at low
temperature
Do not iron
Iron without
steam
Maximum temperature 200 0C150 0C110 0C
LAUNDRY DRYING SYMBOLS
Drying
Symbols Suitable for
dryer No Iron Sensitive /
Delicate dry
Do not dry
with dryer
Do not dry Do not dry-
clean
4.2 Laundry not suitable for
drying in the dryer
CDelicate embroidered fabrics,
woolen, silk garments, delicate
and valuable fabrics, airtight
items and tulle curtains are not
suitable for machine drying.
4.3 Preparing laundry for
drying
• Laundry may be tangled with each other
after washing. Separate the laundry
items before placing them into the dryer.
• Dry garments having metal accessories
such as zippers, inside out.
• Fasten the zippers, hooks and buckles
and button sheets.
4.4 Things to be done for
energy saving
Following information will help you use the
dryer in an ecological and energy-efficient
manner.
• Spin your laundry at the highest speed
possible when washing them. Thus, the
drying time is shortened and energy
consumption is reduced.
• Sort out the laundry depending on their
type and thickness. Dry the same type
of laundry together. For example thin
kitchen towels and table clothes dries
earlier than thick bathroom towels.
• Follow the instructions in the user
manual for programme selection.
• Do not open the loading door of the
machine during drying unless necessary.
If you must certainly open the loading
door, do not to keep it open for a long
time.

16 / EN Dryer / User Manual
Preparation
• Do not add wet laundry while the dryer is
in operation
• Clean the lint filter before or after each
drying cycle. (See 6.1 Cleaning Lint
Filter / Loading Door Inner Surface)
• Clean the filter periodically when there
is visible air collection on it or when
the symbol lights up, if there is a filter
drawer cleaning warning symbol « »
available. (See 6. 4 Cleaning the filter
drawer)
• Ventilate the room, where the dryer is
located, well during drying.
4.5 Correct load capacity
Follow the instructions in the “Programme
selection and consumption table”. Do not
load more than the capacity values stated in
the table.
CIt is not recommended to load
the dryer with laundry exceeding
the level indicated in the figure.
Drying performance will degrade
when the machine is overloaded.
Furthermore, dryer and the laundry
can get damaged.
Following weights are given as examples.
Laundry Approximate
weights (g)*
Cotton quit covers
(double) 1500
Cotton quit covers
(single) 1000
Bed sheets (double) 500
Bed sheets (single) 350
Large tablecloths 700
Small tablecloths 250
Tea napkins 100
Bath towels 700
Hand towels 350
Blouses 150
Cotton shirts 300
Shirts 250
Cotton dresses 500
Dresses 350
Jeans 700
Handkerchiefs (10
pieces) 100
T-Shirts 125
*Dry laundry weight before washing.

17 / EN
Dryer / User Manual
5Operatng the product
5.1 Control panel
1. Programme Selection knob
2. Dryness Level Adjustment button
3. Audio Warning Level button
4. Display
5. On /Off/Cancel button
6. Start/Pause button
7. End Time button
8. Favourite button
9. Timer Programmes Selection button
10. Anti-creasing button
1 32 4 5 6
78910
Remaining time indicator*
Filter drawer cleaning warning symbol
Filter cleaning warning symbol
Smart grid symbol
Child lock warning symbol
Water tank warning symbol
End time symbol
Start / Pause symbol
Steam tank warning symbol
Dryness level
*Time that appears on display indicates the
remaining time until the end of the programme
and changes according to the dampness level
of the laundry and model of the dryer.
Programme progress bar
Audio warning smbol
5.2 Display symbols

18 / EN Dryer / User Manual
Operating the product
5.3 Preparing the machine
1. Plug in your machine.
2. Place the laundry in the machine.
3. Press the On/Off/Cancel button for 1
second (long).
4. When your machine is operated for the
first time, it starts with the declaration
programme (wardrobe dryness for
cottons.)
CPressing the On/Off/Cancel
button does not mean that the
programme has started. Press
Start / Pause button to start the
program.
5.4 Programme selection
1. Decide the appropriate programme from
the table below which includes drying
levels.
2. Select the desired programme with the
Programme Selection knob.
Extra Dry
Only the cotton laundry is
dried at normal temperature.
Thick and multi layered
laundry (towels, linens, jeans
and etc.) are dried in a way
that they do not require
ironing before being placed in
the wardrobe.
Cupboard
Dry
Normal laundry (tablecloths,
underwear and etc.) are dried
in a way that they do not
require ironing before being
placed in the wardrobe.
Iron Dry Normal laundry (shirts, dresses and etc.) are dried
ready to be ironed.
CFor further programme details,
see "Programme selection and
consumption table"..
5.5 Main programmes
Depending on the fabric type, the following
main programmes are available.
• Cottons
Dry durable laundry with this programme.
Dries at normal temperature. It is
recommended to use for your cotton items
(bed sheets, quilt covers, towels, bathrobes,
etc.).
• Synthetcs
Dry less durable laundry with this
programme. Recommended for synthetics.
5.6 Additional programmes
For special cases, following additional
programmes are available in the machine.
CAdditional programs may differ
according to the features of your
machine.
CTo obtain better results from
your dryer, your laundry must be
washed at suitable programmes
and spun at the recommended
spin speeds in the washing
machine..
• Jeans
Use this programme to dry your jeans that
are spun at high speeds in the washing
machine.
• Mx
Use this programme to dry non-pigmenting
synthetic and cotton laundry items together.
• Shrts 30’
Use this programme to make 2 shirts ready
for ironing in 30 minutes.
• BabyProtect
Ths programme s used for baby clothes that
bear machne dryable approval on ts label.

19 / EN
Dryer / User Manual
Operating the product
• WoolProtect
Use this programme to dry woolen garments
such as jumpers that are washed according to
the instructions.
It is recomended that garments would be
removed at the end of the programme.
The wool drying cycle of this
machine has been approved by
The Woolmark Company for the
drying of machine washable
wool products provided that the
products are washed and dried
according to the instructions
on the garment label and those
issued by the manufacturer
of this machine.(M1660). In
UK, Eire, Hong Kong and India
the Woolmark trade mark is a
Certification trade mark..
• Nght
In this programme the level of noise emitted
to the environment will be the lowest.
Volume level will be fifty percent lower with
respect to the ‘wardrobe dry for cottons’
programme.
• Xpress
You can use this programme to dry your
cotton laundry that you have spun at high
speeds in your washing machine. This
programme dries 1 kg cotton laundry (3 Shirts
/ 3 T-shirts) in 49 minutes.
• Daly
This programme is used to dry cottons and
synthetics daily, and lasts for 100 minutes.
CThere may be a little moisture
on the shirts at the end of the
programme. We recommend
you not to leave the shirts in the
dryer.
• Delcates
You can dry your highly delicate laundry
(silk blouses, fine underwear, etc.) that
are suitable for drying or laundry which
is advised to be hand-washed at a lower
temperature.
CIt is recommended to use a cloth
bag to avoid certain delicate
garments and laundry from
getting creased or damaged.
Take your laundry immediately
out of the dryer and hang them
after the programme ends in
order to prevent them being
creased.
• Freshen Up
Only ventilation is performed for 10 minutes
without blowing hot air. You can air the
clothes that have been kept at closed
environments for a long time and deodorize
unpleasant odors thanks to this programme.
• Tmer programmes
You can select one of the 10 min., 20 min., 30
min., 40 min., 50 min., 60 min., 80 min., 100
min.,120 min., 140 min. and 160 min. timer
programmes to achieve the desired final
drying level at low temperatures.
CWith this programme, the
machine dries for the time
selected regardless of the
dryness level.

20 / EN Dryer / User Manual
Operating the product
5.7 Programme selection and consumption table
„Cotton cupboard dry programme“ used at full and partial load is the standard
drying programme to which the information in the label and the fiche relates, that
this programme is suitable for drying normal wet cotton laundry and that it is the
most efficient programme in terms of energy consumption for cotton.
EN
Programs Capacity
(kg) Spin speed in washing machine (rpm) Approximate amount of remaining humidity Drying time
(minutes)
Cottons / Coloreds
AExtra dry 8 1000 % 60 190
ACupboard dry 8 / 4 1000 % 60 185 / 115
AIron dry 8 1000 % 60 150
Night (silent) 8 1000 % 60 220
Babyprotect 3 1000 % 60 95
Shirts 30’ 0,5 1200 % 60 30
Jeans 4 1200 % 50 130
Daily 4 1200 % 50 100
Mix 4 1000 % 60 110
Xpress 1 1200 % 50 49
Delicates 2 600 % 40 55
Wool protect 1,5 600 % 50 146
Synthetics
BCupboard dry 4 800 % 40 75
BIron dry 4 800 % 40 55
Energy consumption values
Programs Capacity
(kg) Spin speed in washing machine (rpm) Approximate amount of remaining humidity
Energy
consumption
value kWh
Cottons linen Ready to
wear* 8 / 4 1000 % 60 1,29 / 0,73
Cottons Ready to iron 8 1000 % 60 1,05
Synthetics Ready to wear 4 800 % 40 0,51
Power consumption of the off-mode for the standart cotton programme at full load,
PO (W) 0,4
Power consumption of the left-on mode for the standart cotton programme at full
load, PL (W) 1,0
Contains fluorinated greenhouse gases covered by the Kyoto Protocol. Hermetically sealed.
R134a / 0,51 kg - GWP:1430 - 0,729 tCO2e
