Beko DP 8045 CW Installation instructions

Condenser
Sensor Dryer
Dry & Save
DP 8045 CW

2960310575_EN/161211.1600
Please read this user manual first!
Dear Customer,
We hope that you get the best results from the product which has been manufactured
in state-of-the-art plants and passed through a strict quality control procedure.
Therefore, please read the entire user manual carefully before using the product and
keep it as a reference for future use. In case of transferring the product to someone
else, give the manual as well.
The user manual will help you use your product in a fast
and safe way.
• Read the user manual before installing and starting your product.
• Always follow the safety instructions.
• Keep this user manual within easy reach for future reference.
• Read also the other documents supplied with the product.
Remember that this user manual is also applicable for several other models.
Differences between models will be identified in the manual.
Explanation of symbols
Throughout this user manual the following symbols are used:
Read the instructions.
CImportant information or useful hints about usage.
AWarning for hazardous situations with regard to life and property.
BWarning for electric shock.
Warning for fire hazard.
Warning for hot surfaces.
This appliance’s packaging material is recyclable. Help recycle it and protect the environment
by dropping it off in the municipal receptacles provided for this purpose. Your appliance
also contains a great amount of recyclable material. It is marked with this label to indicate
the used appliances that should not be mixed with other waste. This way, the appliance
recycling organised by your manufacturer will be done under the best possible conditions,
in compliance with European Directive 2002/96/EC on Waste Electrical and Electronic
Equipment. Contact your town hall or your retailer for the used appliance collection points
closest to your home. We thank you doing your part to protect the environment.

3EN
1 Dryer 4
Overview .............................................4
Technical specifications .......................5
2 Important safety
instructions 6
General safety .....................................6
Intended use .......................................8
Children's safety..................................8
3 Installation 9
Appropriate installation location ...........9
Removing the transportation safety
assembly.............................................9
Under counter installation ....................9
Mounting over a washing machine.....10
Connecting to the drain .....................10
Adjusting the feet...............................10
First use ............................................11
Disposing of packaging material ........11
Transportation of the product.............11
Disposing of the old product..............11
Warnings about sounds.....................12
4 Electrical Connection 13
Attention!...........................................13
Electrical requirements.......................13
Fitting a different plug .......................13
Washer/dryer combination.................14
5 Preparations for drying 15
Things to be done for energy saving ..15
Laundry suitable for drying in the
machine ............................................15
Laundry unsuitable for drying in the
machine ............................................15
Preparing laundry for drying...............16
Correct load capacity ........................16
Loading the laundry...........................16
6 Selecting a Programme and
Operating Your Machine 18
Preparing the machine.......................19
Programme selection.........................19
Main programmes .............................19
Additional programmes .....................19
Auxiliary functions..............................22
Warning symbols ...............................22
Starting the programme.....................24
Progress of programme.....................24
Child-proof Lock................................24
Changing the programme after it has
started...............................................24
Cancelling the programme.................25
End of programme ............................26
7 Maintenance and cleaning 27
Lint Filter / Loading Door Inner Surface27
Cleaning the sensors ........................27
Draining the water tank......................28
Cleaning the filter drawer ..................28
Cleaning the evaporator.....................30
8 Troubleshooting 31
9 Guarantee 33
What is covered?...............................33
What is not covered?.........................33
Important notes .................................33
10 Service 34
TABLE OF CONTENTS

4EN
1
8
7
6
11
4
9
2
3
10
5
1. Top panel
2. Control panel
3. Loading door
4. Kick plate opening tab
5. Ventilation grids
6. Adjustable feet
7. Kick plate
8. Type label
9. Lint filter
10. Water tank drawer
11. Power cable
1 Dryer
Overview

5EN
Technical specifications
Specifications of this appliance may change without notice to improve the quality of the
product. Figures in this manual are schematic and may not match your product exactly.
Values stated on the machine labels or in the documentation accompanying it are
obtained in laboratory in accordance with the relevant standards. Depending on
operational and environmental conditions of the appliance, values may vary.
Height (adjustable) 84.6 cm
Width 59.5 cm
Depth 59.8 cm
Capacity (max) 8 kg
Weight (net) 49 kg
Voltage
See type labelPower
Main Model Code
Type label is behind the loading door.
Congratulations on purchasing the new ‘Dry & Save’ tumble dryer from Beko. Using
the latest energy efficient heat pump technology means it can dry the same load at
around half the energy cost of popular Beko ‘C-rated’ Condenser models. The gentle
drying will also take more care of even the most delicate garments.

6EN
2 Important safety instructions
This section contains safety instructions
that will help protect from risk of personal
injury or property damage. Failure to
follow these instructions shall void any
warranty.
General safety
• Never place the product on a carpet-
covered floor; otherwise, lack of
airflow beneath the machine will
cause electrical parts to overheat.
This will cause problems with your
product.
• Do not operate the product if the
power cable / plug is damaged. Call
the Authorised Service Agent.
• Do not make any changes on the
plug supplied with the product. If it is
not compatible with the socket, have
a qualified electrician change the
socket with a suitable one.
• Never touch the plug with wet hands!
Never unplug by pulling on the cable,
always pull out by gripping the plug.
• Connect the product to a grounded
outlet protected by a fuse of suitable
capacity as stated in the technical
specifications table.
• Power cable of this product is
equipped with a conductor and
a grounding plug that allows for
grounding the product. This plug
must be inserted into a socket
which is installed and grounded in
accordance with the local laws and
regulations. Grounding installation
decreases the risk of electric shock
by opening a path with low resistance
for the electricity flow in case of a
malfunction or failure. Do not neglect
to have the grounding installation
made by a qualified electrician.
If you have any suspect about
the grounding installation, have it
checked by a qualified electrician.
Our company shall not be liable for
any damages that will arise when the
product is used without grounding in
accordance with the local regulations.
• The product should not be plugged
in during installation, maintenance,
cleaning and repair works.
• Always have the repair procedures
carried out by the Authorised Service
Agent. Manufacturer shall not be
held liable for damages that may
arise from procedures carried out by
unauthorised persons.
• Do not use electrical devices in the
product.
• You must provide enough ventilation
in order to prevent gases exiting from
devices operating with other types of
fuels including the naked flame from
accumulating in the room due to the
back fire effect.
• Items cleaned or washed with
gasoil/fuel oil, dry-laundry solvents
and other combustible or explosive
materials as well as the items that are
contaminated or spotted with such
materials should not be dried in the
product since they emit flammable or
explosive vapor.
• Do not dry the laundry cleaned with
industrial chemicals in the dryer.
• Underwear that contains metal
reinforcements should not be dried in
the dryer. Dryer can get damaged if
metal reinforcements come loose and
break off during drying.
• Never attempt to repair the product
yourself. Do not perform any
repair or replacement procedures
on the product even if you know
or have the ability to perform the
required procedure unless it is

7EN
clearly suggested in the operating
instructions or the published service
manual. Otherwise, you will be
putting your life and others' lives in
danger.
• For failures that you cannot remedy
by applying the procedures in safety
instructions, turn off and unplug
the product and call the Authorised
Service Agent.
• Do not reach into the machine when
the drum is spinning.
• Do not use extension cords, multi-
plugs or adaptors to connect the
dryer to power supply in order to
decrease the risk of fire and electric
shock.
• Never wash the product by spreading
or pouring water onto it! There is the
risk of electric shock!
The final step of the drying
programme, namely the cool-down
step is performed without applying
heat to ensure that the laundry items
are kept at a temperature that will
not damage them. If you open the
loading door before the cool-down
step completes, hot vapour will come
out.
ANever stop the dryer before the
programme completes. If you must
do this, remove all laundry quickly
and lay them out to a suitable place
to dissipate the heat.
• Always clean the lint filter before or
after each loading. Never operate the
dryer without the lint filter installed.
• Clean ventilation grid of the product
regularly. Do not allow fibre, dust
and dirt accumulation around the
ventilation grid and at adjacent areas.
• Power cable plug must be within easy
reach after installation.
• Do not dry unwashed items in the
dryer.
• Items soiled with cooking oils,
acetone, alcohol, fuel oil, kerosene,
stain removers, turpentine, paraffin
and paraffin removers must be
washed in hot water with plenty of
detergent before being dried in the
dryer.
• Garments or pillows bolstered with
rubber foam (latex foam), bathing
caps, water resistant textiles,
materials with rubber reinforcement
and rubber foam pads should not be
dried in the dryer.
• Do not use fabric softeners and
anti-static products unless they are
recommended by the manufacturers
of the relevant product.
• Use softeners, anti-static products
and etc. in accordance with the
instructions of their manufacturers.
• Do not install the product behind a
door with a lock, sliding door or a
hinged door which can strike the
product.
• Do not install or leave the dryer in
places where it will be exposed to
outdoor conditions.
• Your product can be operated at
temperatures between +5°C and
+35°C. If the operating conditions fall
outside of this range, operation of the
product will be adversely affected and
it can get damaged.
• Do not tamper with the controls.
• Unplug the product when it is not in
use.
• Remove the loading door of
the drying compartment before
decommissioning or disposing of the
product.
• Check all garments before loading
and make sure that there is no any
lighters, coins, metal pieces, needles,
and etc. in their pockets or on them.
• Make sure that the pets do not enter

8EN
into the product. Check the drum of
the product before using it.
• Make sure that original spare parts
and accessories are used during
maintenance works.
• Do not lean on the loading door when
it is open. The product may tip over.
• Remove all objects from pockets
such as lighters and matches.
• When your machine is not in use
or when you unload the laundry
after completion of drying process,
turn the machine off with the On/
Off button. In cases where the On/
Off button is in On position (while
the machine is energized), keep the
loading door closed.
Intended use
• This product has been designed for
domestic use. It should not be used
for other purposes.
• Product must only be used for
drying of textiles that are marked
accordingly.
• Dry only those articles in your product
that are stated in this manual.
• This appliance is not intended for use
by persons (including children) with
reduced physical, sensory or mental
capabilities, or lack of experience
and knowledge, unless they have
been given supervision or instruction
concerning use of the appliance by a
person responsible for their safety.
Children's safety
• Electrical products are dangerous for
the children. Keep children away from
the product when it is operating. Do
not let them tamper with the product.
• Do not allow children sit/climb on or
enter in the product.
• Do not forget to close the loading
door when leaving the room where
the product is located.
• Packaging materials are dangerous
to children. Keep the packaging
materials out of reach of children
or dispose of them by classifying
according to waste directives.

9EN
3 Installation
To make the product ready for use,
make sure that the electricity and water
drainage system are appropriate before
installation. If they are not, call a qualified
technician and plumber to have any
necessary arrangements carried out.
CPreparation of the product’s location
as well as the electrical and waste
water installations is the customer’s
responsibility.
CManufacturer shall not be held
liable for damages that may arise
from procedures carried out by
unauthorised persons.
APrior to installation, visually check if
the product has any defects on it. If
so, do not have it installed. Damaged
products cause risks for your safety.
A
The appliance should be
transported only in a vertical
upright position.If during
the course of transport the
appliance has to be transported
horizontally, it must only be
laid on its right hand side. After
bringing it to upright position,it
must not be operated for at least
12 hours to allow the system to
settle.
Failure to comply with the
above instructions could result
in damage occurring to the
appliance. The manufacturer will
not be held responsible if these
instructions are disregarded.
Appropriate installation
location
• Install the product on a stable and
level surface.
• Dryer is heavy. Do not move it by
yourself.
• Operate your product in a well
ventilated, dust-free environment.
• Do not block the air ducts in front of
and under the product with materials
such as long pile rugs or wooden
plinths.
• Do not install the product behind a
door with a lock, sliding door or a
hinged door which can strike the
product.
• Once the product is installed, it
should stay at the same place where
its connections have been made.
When installing the product, make
sure that the rear wall of it does
not touch anywhere (tap, socket,
etc.). Also pay attention to select an
installation location which you will not
be required to change afterwards.
• Place the product at least 1.5
cm away from the edges of other
furniture.
BDo not place the product on the
power cable.
Removing the transportation
safety assembly
A
Remove the transportation safety
assembly before using the product for
the first time.
1. Open the loading door.
2. There is a nylon bag inside the drum
that contains a piece of styrofoam.
Hold it from its section marked with
XX XX.
3. Pull the nylon towards yourself and
remove the transportation safety
assembly.

10 EN
A
Make sure that no part of the
transportation safety assembly
remains inside the drum.
Under counter installation
• This product can be installed under a
counter if the height of the counter is
sufficient.
A
Never operate the dryer without the
top trim is in place.
• Leave at least 3 cm of space around
the sides and the rear wall of the
product when installing it under a
counter or in a cupboard.
Mounting over a washing
machine
• A fixing device should be used
between the two machines when
installing the dryer above a washing
machine. The fixing device can
usually be obtained from a specialist
retailer.
• Total weight of the washing machine
and the dryer -with full load- when
they are placed on top of each other
reaches to approx. 180 kilograms.
Place the products on a solid floor
that has sufficient load carrying
capacity!
• Do not stack washing machine
on top of the tumble dryer. This
would damage both appliances and
guarantees would become void.
Connecting to the drain
In products equipped with condenser
unit, water accumulates in the water tank
during the drying cycle. You should drain
accumulated water after each drying
cycle.
You can directly drain accumulated water
through the water drain hose supplied
with the product instead of periodically
draining the water collected in the water
tank.
Connecting the water drain hose
1. Pull hose in the product by hand in
order to disconnect it from where it is
connected. Do not use any tools to
remove the hose.
2. Connect one end of the drain hose
supplied separately with the product
to the connection point from where
you removed the hose of the product
in previous step.
3. Connect the other end of the drain
hose directly to the wastewater drain
or to the washbasin.
A
Hose must be securely fixed to
prevent leaks. Your house will be
flooded if the hose comes loose
during water discharge.
CWater drain hose should be attached
to a height of maximum 80 cm.
CMake sure that the water drain hose
is not stepped on and it is not folded

11 EN
between the drain and the machine.
Adjusting the feet
In order to ensure that the product
operates more silently and vibration-free,
it must stand level and balanced on its
feet. Balance the machine by adjusting
the feet.
Turn the feet to left or right until the
machine stands level and firmly.
C Never remove the adjustable feet
from their housings.
First use
Before starting to use the product, make
sure that all preparations are made in
accordance with the instructions in
sections “Important safety instructions”
and “Installation”.
Disposing of packaging
material
Packaging materials are dangerous to
children. Keep packaging materials in
a safe place away from reach of the
children.
Packaging materials of the product are
manufactured from recyclable materials.
Dispose of them properly and sort
in accordance with recycled waste
instructions. Do not dispose of them with
normal domestic waste.
Transportation of the product
1. Unplug the product before
transporting it.
2. Remove the water drain (if any).
3. Drain the water in the product
completely.
A
We recommend carrying the product
in upright position. If it is not possible
to carry the machine in the upright
position, we recommend carrying
it by tilting towards the right side
when looked from the front. After the
product is moved to its new place,
you should wait for 12 hours before
starting it.
Disposing of the old product
Dispose of the old product in an
environmentally friendly manner.
Refer to your local dealer or solid waste
collection centre in your area to learn how
to dispose of your product.
For children’s safety, cut the power
cable and break the locking mechanism
of the loading door so that it will be
nonfunctional before disposing of the
product.

12 EN
Warnings about sounds
C
It is normal to hear metallic noise from
the compressor sometimes during
operation.
C
Water collected during operation is
pumped to water tank. It is normal
to hear pumping noise during this
process.

13 EN
Make sure that you have an earthed
power outlet socket rated at 13 amps
(minimum).
Attention!
If you use your dryer as built-in,
the socket must be reachable after
installation, or a separate switch (which
can disconnect the two poles) must
be used in the installation. Check for
suitability.
For a permanent connection, a master
switch with at least 3mm contact
clearance and minumum 13 A rating
must be used.
Electrical requirements
Before you insert the plug into the wall
socket make sure that the voltage and
the frequency shown in the rating label
corresponds to your electricity supply.
We recommend that this appliance be
connected to the mains supply via a
suitable switched and fused socket in a
readily accessible position.
Should the mains lead of the appliance
become damaged or need replacing at
any time, it must be replaced by a special
purpose made mains lead which can only
be obtained from a Authorised Service
Agent.
A Warning
This appliance must be earthed
If the fitted moulded plug is not suitable
for your socket, then the plug should be
cut off and an appropriate plug fitted.
The moulded plug on this appliance
incorporates a 13A fuse. Should the fuse
need to be replaced an ASTA approved
BS1362 fuse of the same rating must
be used. Do not forget to refit the fuse
cover. In the event of losing the fuse
cover, the plug must not be used until a
replacement fuse cover has been fitted.
Colour of the replacement fuse cover
must be the same colour as that visible
on the pin face of the plug. Fuse covers
are available from any good electrical
store.
In order to avoid hazards, damaged
supply cord should be replaced by the
manufacturer, its service agent or similarly
qualified people.
A Important
Fitting a different plug
As the colours of the wires in the mains
lead of this appliance may not correspond
with the coloured markings identifying
the terminals on your plug, proceed as
follows:
1 Connect the green - yellow or green
(earth) wire to the terminal in the plug
marked ‘E’ or with the symbol or
coloured green and yellow or green.
2 Connect the blue (neutral) wire to
the terminal in the plug marked ‘N’ or
coloured black.
3 Connect the brown (live) wire to
the terminal in the plug marked ‘L’ or
coloured red.
With the alternative plugs a 13A fuse
must be fitted either in the plug or
adaptor or in the main fuse box. If in
doubt contact a qualified electrician.
Green and yellow
or green
N
Blue or black L
Brown or red
4Electrical Connection

14 EN
5 Preparations for drying
Things to be done for energy
saving
Following information will help you use
the product in an ecological and energy-
efficient manner.
• Operate the product at a capacity
suitable for the programme you have
selected and pay attention not to
overload.
• Spin your laundry at the highest
speed possible when washing them.
Thus, the drying time is shortened
and energy consumption is reduced.
• Dry the same type of laundry
together.
• Follow the instructions in the user
manual for programme selection.
• Leave sufficient clearance at the
front and rear side of the dryer for
air circulation. Do not block the
ventilation grills at the front side of the
product.
• Do not open the loading door of
the machine during drying unless
necessary. If you must certainly open
the loading door, do not to keep it
open for a long time.
• Do not add new (wet) laundry during
drying.
• Lint and fibres released from the
laundry to the air during the drying
cycle are collected in the Lint Filter.
Clean the lint filter before or after each
drying cycle.
• Clean the filter drawer regularly either
when the Filter Drawer Cleaning
warning symbol appears or after
every 5 drying cycles
• Ventilate the room, where the dryer is
located, well during drying.
• For models with lamp, keep the door
closed if the On/Off button is pressed
(if the machine is energized) when
machine is not in use.
Laundry suitable for drying in
the machine
C Always obey the instructions given
on the garment tags. Dry only the
laundry having a label stating that
they are suitable for drying in a dryer
and make sure that you select the
appropriate programme.
A B C
l mn
o p q
D
Laundry unsuitable for drying
in the machine
• Laundry and items stated below are
not suitable for drying in a dryer:
• Laundry items with metal
attachments such as metal buttons,
metal reinforcements or belt buckles.
• Woollen or silk garments, nylon
stockings, delicate embroidered
fabrics and sleeping bags.
• Garments made of delicate and
valuable fabrics.
• Fine net or voile curtains.
• Items made of hermetic fibres such
as pillows and quilts.
• Very wet laundry items.
• Unwashed dirty laundry items.
• Laundry items containing rubber
foam or rubber.

15 EN
Items cleaned, washed or spotted
with gasoil/fuel oil, dry-laundry
solvents, industrial chemicals or other
combustible or explosive materials
should not be dried in the dryer.
Items soiled with cooking oils,
acetone, alcohol, fuel oil, kerosene,
stain removers, turpentine, paraffin
and paraffin removers must be
washed in hot water with plenty of
detergent before being dried in the
dryer.
Preparing laundry for drying
• Check all garments before loading
and make sure that there is no any
lighters, coins, metal pieces, needles,
and etc. in their pockets or on them.
• Laundry may be tangled after
washing. Separate the laundry items
before placing them into the dryer.
• Sort the laundry according to their
types and thicknesses. Dry the same
type of laundry together. For instance,
thin kitchen towel and table cloths get
dry earlier than the thick bath towels.
CLaundry must be spun at the highest
spin speed that the washing machine
allows on basis of the fabric type.
Correct load capacity
Follow the instructions in the “Programme
selection and consumption table”. Do not
load more than the capacity values stated
in the table.
C
It is not recommended to load the
dryer with laundry exceeding the
level indicated in the figure. Drying
performance will degrade when the
machine is overloaded. Furthermore,
dryer and the laundry can get
damaged.
Following weights are given as examples.
Home articles Approximate
weights (g)
Cotton quit covers
(double) 1500
Cotton quit covers
(single) 1000
Bed sheets (double) 500
Bed sheets (single) 350
Large tablecloths 700
Small tablecloths 250
Tea napkins 100
Bath towels 700
Hand towels 350
Garments Approximate
weights (g)
Blouses 150
Cotton shirts 300
Shirts 200
Cotton dresses 500
Dresses 350
Jeans 700
Handkerchiefs (10
pieces) 100
T-Shirts 125

16 EN
Loading the laundry
1. Open the loading door.
2. Place the laundry in the machine
without compressing.
3. Push the loading door to close.
AEnsure that no items are caught in
the door.

17 EN
Spin speed / Timer programmes*
Operation symbol
Pause symbol
Water Tank warning symbol
Filter cleaning warning symbol
Filter Drawer Cleaning warning symbol
Remaining Time indicator**
Child-proof Lock warning symbol
Time Delay mode
Loading door open warning symbol
Anti-creasing mode
Audio Warning Level / Cancel Audio Warning
Dryness Level
Anti-creasing is activated
* Spin speed is used to show the remaining time more accurately. It does not
affect the performance of your machine.
** Time that appears on display indicates the remaining time until the end of the
programme and changes according to the dampness level of the laundry.
6 Selecting a Programme and Operating Your Machine
Control panel
1. Washing Machine Spin Speed / Timer
Programme Selection button
2. Display
3. Start / Pause / Cancel button
4. Programme Selection knob
5. On / Off button
6. Anti-creasing button
7. Dryness Level button
8. Cancel Audio Warning button
9. Time Delay buttons
1 2 3 4 5
6789

18 EN
Preparing the machine
1. Plug in the machine.
2. Place the laundry in the machine.
3. Press the On / Off button.
CPressing the On / Off button does
not necessarily mean that the
programme has started. Press Start
/ Pause / Cancel button to start the
programme.
Programme selection
1. Decide the appropriate programme
from the table below which includes
drying levels.
2. Select the desired programme with
the Programme Selection knob.
Extra Dry
Only the cotton laundry
is dried at normal
temperature. Thick and
multi layered laundry
(towels, linens, jeans and
etc.) are dried in a way that
they do not require ironing
before being placed in the
wardrobe.
Cupboard
dry
Normal laundry
(tablecloths, underwear
and etc.) are dried in a way
that they do not require
ironing before being placed
in the wardrobe.
Iron Dry
Normal laundry (shirts,
dresses and etc.) are dried
ready to be ironed.
CFor further programme details,
see "Programme selection and
consumption table".
Main programmes
Depending on the fabric type, the
following main programmes are available:
• Cottons
Dry durable laundry with this programme.
Dries at normal temperature. It is
recommended to use for your cotton
items (bed sheets, quilt covers, towels,
bathrobes, etc.).
• Synthetics
Dry less durable laundry with this
programme. Recommended for
synthetics.
Additional programmes
For special cases, following additional
programmes are available in the machine.
C
Additional programmes may differ
according to the features of your
machine.
• Xpress 45 min.
You can use this programme to dry your
cotton laundry that you have spun at high
speeds in your washing machine. This
programme dries 1 kg cotton laundry (3
Shirts/3 T-shirts) in 45 minutes.
C
To obtain better results from your
dryer, your laundry must be washed
at suitable programmes and spun
at the recommended speed in the
washing machine.
• Shirts
This programme dries the shirts more
sensitively and creases them less and
thus, helps to iron them more easily.
CThere may be a little moisture on the
shirts at the end of the programme.
We recommend you not to leave the
shirts in the dryer.
• Jeans
Use this programme to dry your jeans
that are spun at high speeds in the
washing machine.
• Mix
Use this programme to dry colour-fast
synthetic and cotton laundry items
together.
• Sportswear
Use this programme to dry together the
synthetic and cotton laundry items and
the laundry items made of mixed fabrics.
• Wool Refresh
You can use this programme to ventilate

19 EN
and soften your woollen laundry that
can be washed in the washing machine.
Do not use this programme to dry your
laundry completely. Take out your laundry
and ventilate them immediately after the
programme is over.
• Daily Quick
This programme is used to dry cottons
and synthetics daily, and lasts for 1.5
hour.
• Baby Clothing
This programme is used for baby clothes
that bear machine dryable approval on its
label.
• Delicates
You can dry your highly delicate laundry
that are suitable for drying or laundry
which is advised to be hand-washed at a
lower temperature.
C
It is recommended to use a cloth bag
to prevent certain delicate laundry
from getting creased or damaged.
Take your laundry immediately out
of the dryer and hang them after the
programme is over in order to prevent
them from getting creased.
• Freshen Up
Only ventilation is performed for 10
minutes without blowing hot air. You can
air the clothes that have been kept at
closed environments for a long time and
deodourise unpleasant odours thanks to
this programme.
• Timer programmes
You can select one of the 10 min., 20
min., 30 min., 40 min., 50 min., 60 min.,
80 min., 100 min., 120 min., 140 min.
and 160 min. timer programmes to
achieve the desired final drying level at
low temperatures.
CWith this programme, the machine
dries for the time selected regardless
of the dryness level.

20 EN
Programme selection and consumption table
* : Energy Label standard programme (EN 61121:2005)
All values given in the table have been fixed according to EN 61121:2005 Standard.
These values may deviate from the values in the table according to the laundry type,
laundry spin speed, environmental conditions and voltage fluctuations.
EN 2
Programmes Capacity (kg) Spin speed in washing
machine (rpm)
Approximate
amount of
remaining
humidity
Drying time
(minutes)
Cottons / Coloureds
AExtra dry 8 1000 60 % 190
ACupboard dry 8 1000 60 % 175
AIron dry 8 1000 60 % 150
Baby Clothing 3 1000 60 % 80
Shirts 1.5 1200 50 % 50
Jeans 4 1200 50 % 120
Daily Quick 4 1200 50 % 90
Mix 4 1000 60 % 115
Sportswear 4 1000 60 % 105
Xpress 45 min. 1 1200 50 % 45
Delicates 2 600 40 % 55
Wool Refresh 1.5 600 50 % 8
Synthetics
BCupboard dry 4 800 40 % 70
BIron dry 4 800 40 % 55
Energy consumption values
Programmes Capacity (kg) Spin speed in washing
machine (rpm)
Approximate
amount of
remaining
humidity
Energy
consumption
value kWh
Cottons linen Ready to
wear* 8 1000 60 % 2,68
Cottons Ready to iron 8 1000 60 % 2.1
Synthetics Ready to wear 4 800 40 % 0,95
