Beko BKK 2304 User manual

BKK 2304
Iron
User Manual
Ütü
Kullanma Kılavuzu
Fer à repasser
Manuel d’utilisation




Please read this user manual first!
Dear Customer,
Thank you for prefering a Beko product. We hope that you get the best re-
sults from your product which has been manufactured with high quality and
state-of-the-art technology. Therefore, please read this entire user manual
and all other accompanying documents carefully before using the product
and keep it as a reference for future use. If you handover the product to
someone else, give the user manual as well. Follow all warnings and infor-
mation in the user manual.
Remember that this user manual is also applicable for several other models.
Differences between models will be identified in the manual.
Explanation of symbols
Throughout this user manual the following symbols are used:
CImportant information or useful hints
about usage.
AWarning for dangerous situations with
regard to life and property.
BWarning for electric shock.
Warning for danger of fire.
Warning for hot surfaces.
This product has been produced in environmentally friendly, modern facilities.

3 / 94 EN
Iron / User Manual
CONTENTS
1 Important instructions
for safety and environment 4-11
1.1 General safety . . . . . . . . . . . . . . . . . . . . . . . 4
1.1.1 Electrical safety . . . . . . . . . . . . . . . . . . . . . 5
1.1.2 Product safety . . . . . . . . . . . . . . . . . . . . . . 7
1.2 Intended use. . . . . . . . . . . . . . . . . . . . . . . . . 9
1.3 Child safety . . . . . . . . . . . . . . . . . . . . . . . . . 9
1.4 Compliance with the WEEE Directive
and disposal of waste products . . . . . . . . . . 11
1.5 Package details . . . . . . . . . . . . . . . . . . . . . 11
2 Your steam iron 12
2.1 Overview . . . . . . . . . . . . . . . . . . . . . . . . . . 12
2.1.1. Controls and parts . . . . . . . . . . . . . . . . . 12
2.1.2. Technical data. . . . . . . . . . . . . . . . . . . . . 12
3 Preparation 13-15
3.1 Initial use . . . . . . . . . . . . . . . . . . . . . . . . . . 13
3.2 Energy saving . . . . . . . . . . . . . . . . . . . . . . 14
3.3 Ironing tips . . . . . . . . . . . . . . . . . . . . . . . . 14
4 Operation of the Appliance 16-18
4.1 Filling the water tank. . . . . . . . . . . . . . . . . . 16
4.2 Setting the temperature. . . . . . . . . . . . . . . . 16
4.3 Steam ironing. . . . . . . . . . . . . . . . . . . . . . . 17
4.4 Dry ironing . . . . . . . . . . . . . . . . . . . . . . . . . 17
4.5 Shock steam. . . . . . . . . . . . . . . . . . . . . . . . 17
4.6 Water spray . . . . . . . . . . . . . . . . . . . . . . . . 18
4.7 Vertical steam. . . . . . . . . . . . . . . . . . . . . . . 18
5 Cleaning and maintenance 19
5.1 Cleaning. . . . . . . . . . . . . . . . . . . . . . . . . . . 19
5.2 Lime removing feature (Self-Clean) . . . . . . . 19
5.3 Lime protection system (Anti-Calc). . . . . . . . 20
5.4 Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
6 Troubleshooting 21

4 / 94 EN Iron / User Manual
This section includes the safety instructions
that will help providing protection against
personal injury and material loss risks. Failure
to follow these instructions invalidates the
granted warranty.
1.1 General safety
•Do not use the appliance outdoors or in the
bathroom.
•No responsibility shall be assumed for dam-
ages arising from misusage or improper
handling of the appliance.
•Do not leave this appliance unattended while
it is in use. It is highly recommended to be
very careful when the appliance is being
used nearby children and people with lim-
ited physical, sensorial or mental capacities.
•Do not open the casing of the appliance
under any condition. No responsibility shall
be assumed for damages arising from im-
1 Important instructions for safety and environment

5 / 94 EN
Iron / User Manual
proper usage.
•Beko Household Appliances comply with
the applicable safety standards; there-
fore, in case of any damage on the appli-
ance or power cord, it should be repaired
or replaced by the dealer, service center or
a specialist and authorized service alike to
avoid any danger. Faulty or unqualified re-
pair work may be dangerous and cause risk
to the user.
•Only use the original parts or parts recom-
mended by the producer.
1.1.1 Electrical safety
•Never use this appliance with damp and wet
hands.
•Iron must always be unplugged before filling
the water tank with water.
•Make sure that your supply power source
complies with the information supplied on
1 Important instructions for safety and environment

6 / 94 EN Iron / User Manual
the rating plate. The only way to disconnect
the appliance from the power source is to
unplug it.
•For additional protection, this appliance
should be connected to a residual current
protective device with 30 mA nominal value
for home appliances. For advice, refer to
your electric technician.
•Pay attention not to step or trip on the power
cable when using the appliance.
•Always place the appliance as to reach the
power plug easily.
•Never touch the plug of the appliance with
damp or wet hands.
•Always unplug the appliance before clea-
ning and never clean the appliance when it
is in use.
•To avoid damage on the power cord, do not
allow it to be squeezed, twisted or rubbed
against sharp edges. Keep the power cord
1 Important instructions for safety and environment

7 / 94 EN
Iron / User Manual
away from hot surfaces and naked flame.
•Do not pull the power cable of the appliance
to disconnect it from its power supply and
never wrap its power cable around the ap-
pliance.
•Do not use this appliance with an extension
cord.
•Do not immerse the appliance, the power
cord or the plug in water or in any other liq-
uid.
1.1.2 Product safety
•Do not put the appliance on hot surfaces
(gas, electric or coal stove, etc.). Keep this
appliance away from all kinds of hot sur-
faces.
•To avoid injury or material damages, always
keep your hair, clothes and all other belong-
ings away from the appliance when it is in
use.
1 Important instructions for safety and environment

8 / 94 EN Iron / User Manual
•Warning - Risk of Burning! Do not touch the
hot base plate of the iron. Do not lean on the
iron when it is in use. Hot air will come out
from the appliance during operation! Hold
the iron only by its handle.
•If this appliance drops or leaks water or has
other failures, it must be checked and re-
paired by an authorized service specialist.
Do not use this appliance until it is repaired.
•Do not allow the iron to contact with zippers,
metal buttons or other metal parts as these
may damage the base plate.
•Make sure that the iron is always placed on
the storing stand and turned off before you
go away or leave the appliance unattended.
•Never direct the hot base plate of the appli-
ance to people, pets or other electrical ap-
pliances when steam is coming out.
•After using, leave the appliance to cool down
completely in a safe place away from reach
1 Important instructions for safety and environment

9 / 94 EN
Iron / User Manual
of children and people with limited physi-
cal, sensorial or mental capacities.Wait until
the appliance cools down completely before
storing it. Unattended hot irons may cause
burns and injuries!
•The surface on which you will use and place
the iron should be stable.
•Before placing the iron onto the ironing
board, make sure that the floor where you
will place the ironing board is stable.
1.2 Intended use
•This appliance is intended for household
use only.
1.3 Child safety
•Danger of suffocation! Keep all the packag-
ing materials away from children.
•Do not attempt to change the safety fea-
tures in whatsoever way in order to ensure
safe operation of the appliance.
1 Important instructions for safety and environment

10 / 94 EN Iron / User Manual
•This appliance can be used by children aged
from 8 years and above and persons with
reduced physical, sensory or mental capa-
bilities or lack of experience and knowledge
if they have been given supervision or in-
struction concerning use of the appliance
in a safe way and understand the hazards
involved. Children shall not play with the
appliance. Cleaning and user maintenance
shall not be made by children without su-
pervision.
•When the appliance is in use or left to cool
down, keep the children under the age of 8
away from the device and its power cord.
1 Important instructions for safety and environment

11 / 94 EN
Iron / User Manual
1.4 Compliance with the WEEE Directive and disposal of
waste products
This product does not include harmful and prohibited materials spec-
ified in the “Regulation for Supervision of the Waste Electric and
Electronic Appliances” issued by the Ministry of Environment and
Urban Planning. This appliance conforms to the WEEE regulation.
This appliance was manufactured from high quality parts and materials which
are recyclable and re-usable. For this reason, do not dispose of this appliance
with the domestic or other types of wastes at the end of its service life. Take
it to a collection point which is dedicated to recycling of electric and elec-
tronic appliances. Ask the local authority in your area for these collection
points. Contribute to the preservation of environment and natural sources by
taking the used products to the recycling points.
1.5 Package details
•Package of the product is made of recyclable materials in accordance with
our national legislation. Do not dispose the package waste with the domes-
tic wastes or other types of wastes, take them to the collection points which
are recommended by the local authorities.
1 Important instructions for safety and environment

12 / 94 EN Iron / User Manual
2.1 Overview
The values which are declared in the markings affixed on your product or the other printed documents supplied with
it represent the values which were obtained in the laboratories pursuant to the pertinent standards. These values
may vary according to the usage of the appliance and ambient conditions.
2 Your steam iron
2.1.1. Controls and parts
1- Power cord
2- Thermostat warning light
3- Temperature setting dial
4- Soleplate
5- Water spray nozzle
6- Water refill lid
7- Steam setting and self clean knob
8- Shock steam button
9- Water spray button
2.1.2. Technical data
Voltage : 220-240V~,50/60 Hz
Power consumption : 1800-2200 W
Isolation class : I
Constant steam amount : 25 g/min
Shock steam amount : 70 g/min
Thermostat heat setting :Yes
Dry Ironing :Yes
Shock steam :Yes
Water spray :Yes
Anti-drip :Yes
Thermic fuse :Yes
Vertical steaming :Yes
Self-Clean function :Yes
Anti Calc :Yes
This appliance
complies with the
European CE Directives
numbered 2004/108/
EC, 2006/95/EC,
2009/125/EC and
2011/65/EU.
1
2
3
4
5
6
7
8 9

13 / 94 EN
Iron / User Manual
3.1 Initial use
1.Remove all package materials,
labels and protective foil and
dispose of them in accordance
with the applicable legal
regulations.
2.Please clean the outer parts
of the appliance as described
in the section "Cleaning and
Maintenance".
3.Place the appliance on an even,
stable, dry and non-slip surface.
C
In the first use, a light
odor may arise from
the iron. This condition
will turn to be normal
after a couple of uses.
A
WARNING: When
your iron is filled with
excessive water, it may
overflow. To avoid this,
make sure that the
level of water in the
appliance does not ex-
ceed the MAX. line.
C
In order to generate
steam, the soleplate (4)
has to rise to a certain
level of temperature. By
means of the ‘anti-drip’
feature of your iron,
water dripping from the
soleplate of the iron
shall be prevented until
the soleplate attains
the temperature re-
quired.
•If water runs out during ironing,
after unplugging, you can top up
water without waiting it to cool
down.
•Iron your garments which
require a low temperature first
and then those requiring high
temperatures. If the temperature
is reduced when the appliance
has a high temperature setting, it
might be necessary to wait for 3
to 4 minutes for the heat to come
down to the set level.
3 Preparation

14 / 94 EN Iron / User Manual
3.2 Energy saving
To save energy:
•You should use an appropriate
temperature setting. If you
do not know the appropriate
temperature setting, start from
the lowest setting and increase
the temperature until the fabric is
ironed well.
•In order to perform a good ironing,
try to use the steam at intervals.
Using steam continuously will
cause more surplus humidity on
your products which may lead to
re-creasing of your fabric while
losing the extra humidity.
3.3 Ironing tips
•In order to learn the appropriate
ironing temperature to be used
for the garment, always read the
care label on your garment before
setting temperature.
•As the iron gets warmer in a
shorter time compared to the
time elapsing to cool it down,
synthetics, silks and other
fabrics alike should be ironed
at the beginning by using lower
temperature settings.
•If the garment is made of a
blend of different fabrics, always
start ironing by using the lowest
temperature setting first.
•Silk and other textiles which tend
to brighten must be ironed on the
reverse side. Velvets and other
lustrous fabrics must be ironed
under little pressure and in one
direction only. Always keep the
iron moving during ironing.
•Do not use the steam function
when ironing colored silk clothes.
This may cause stains.
3 Preparation

15 / 94 EN
Iron / User Manual
•Garments made of 100% pure
wool can be ironed using steam.
Set the temperature setting dial
preferably to the MAX setting
and lay a dry towel between the
garment and the iron.
•Ironing wool garments can cause
them to ‘shine’. It is therefore
recommended to iron such
garments inside out.
A
WARNING: Never iron
on metal parts, such as
zippers, rivets, or me-
tal buttons as they co-
uld damage the solep-
late. Always iron around
these metal parts.
3 Preparation

16 / 94 EN Iron / User Manual
4.1 Filling the water tank
•Always unplug the appliance.
Push the steam setting knob
(7) to left and bring to “0” (off)
position.
•Open the water refill lid (6) of the
iron and fill in water.
•Close the water refill lid (6).
•Even if you will iron your garments
without steam; water should be
available in the appliance in order
to use the water spray when you
need it.
•Do not fill the water reservoir with
perfume, vinegar, laundry starch,
lime removers or other products
or chemicals which shall facilitate
the ironing process.
•If your tap water is excessively
limy, we recommend to use a
mixture of tap water with purified
water.
4.2 Setting the
temperature
•After plugging in the iron, set
required ironing temperature by
turning the temperature setting
dial (3) to the appropriate position
(see the temperature and steam
settings table below).
•You can increase the tempera-
ture of your appliance by turning
the temperature setting dial (3)
clockwise.
When you are setting the tempera-
ture of your appliance, we recom-
mend to consider the following
table.
Fabric
Type
Temperature
Setting
Steam
Setting
Synthetic •Without
steam
Silk •Without
steam
Wool •• Steam
Cotton ••• Steam
Linen -
Jeans Max Steam
4 Operation of the Appliance

17 / 94 EN
Iron / User Manual
•In order to learn the ironing tem-
perature to be used, check the
garment’s care label.
•When the thermostat warning
light (2) turns off, your iron will
have reached the desired tem-
perature.
•If you don’t know the fabric of
your garment, first iron an invis-
ible part of your garment and
determine a correct ironing tem-
perature for it.
•In order to prevent the bright
stains that may form on the syn-
thetic fabrics such as silk, iron on
the reverse side of the fabric. Do
not use the spray feature in order
to prevent the stain formation.
4.3 Steam ironing
•Pull the steam setting knob (7)
to the right or left and bring it to
steam level “1-2” as you desire.
4.4 Dry ironing
•In order to make dry ironing, you
should bring the steam setting
knob (7) to “0” (off) position.
Having water in the iron would
be advantageous; you may use
the water spray button (9) when
necessary.
4.5 Shock steam
•During ironing, in order to remove
the tenacious creases, you can
gain strong steam by pressing on
the shock steam button (8) for
3-4 times in 5-second intervals.
•When you start to iron, shock
steam may not emit in your first
couple of presses. In order to gain
shock steam, the temperature
setting dial (3) should be at •• or
a higher level.
•You can open the creased parts
of the garments with the steam
power which is obtained by press-
ing the shock steam button (8)
during steam ironing. However if
this process is maintained without
an interruption, water may also
come from the soleplate (4) along
with the steam.
4 Operation of the Appliance

18 / 94 EN Iron / User Manual
4.6 Water spray
•Make sure there is sufficient
water in the water tank. Spray
function can be used in order
to remove tenacious creases by
pressing the water spray button
(9) during dry or steam ironing.
4.7 Vertical steam
•While the iron is in a vertical
position, by pressing the shock
steam button (8), you can remove
wrinkles and creases from your
curtains and your garments on
the hanger with the steam you
will get by pressing the shock
steam button.
A
WARNING: Never
direct the steam to the
clothes on the people
or the garments on
pets.
4 Operation of the Appliance

19 / 94 EN
Iron / User Manual
5.1 Cleaning
1.Turn off and unplug the appliance
before each cleaning process.
2.Wait until your iron cools down
completely.
3.Use a slightly damp cloth to clean
the outer surface of the iron. Then
wait until it dries out completely.
4.Wipe the sediments and residues
on the soleplate with a slightly
damp cloth and soft, nonabrasive
liquid cleaner as necessary.
A
WARNING: When you
finished ironing, unplug
the appliance. Drain
the water in the tank.
You can drain the water
in the tank by opening
the refill lid (6) and tilt-
ing the iron to the front.
A
WARNING: Never
use gasoline, solvent
and abrasive cleaning
agents or hard brush to
clean this appliance.
5.2 Lime removing feature
(Self-Clean)
Use the self-clean feature once in
every 2 to 3 weeks. If the water of
your network is very hard (if lime
particles fall down from the base of
the appliance), we recommend you
to use the self-clean function more
frequently.
•Always unplug your iron.
•Fill in the water reservoir up to
Max. level.
•Do not add vinegar etc. and other
lime removing substances into the
water reservoir.
•Pull the steam setting knob (7)
to left and bring to the steamless
ironing “0” position.
•Plug in the appliance to a
grounded outlet and bring the
soleplate temperature to maxi-
mum.
•Hold the iron over the sink and
turn the steam setting and self-
clean knob (7) to the "Self Clean"
position.
5 Cleaning and maintenance

20 / 94 EN Iron / User Manual
5 Cleaning and maintenance
•Keep the button on the self-clean
position. Gently shake the iron to
left and right. Continue this pro-
cess when the water in the water
tank finishes. Release the button
when the water is fully drained.
•During this process, the water
in the tank comes down into
the steam generation reservoir
quickly and is released through
the soleplate holes along with the
lime particles (if any).
•Unplug the appliance and gently
move it on an old cloth. Keep
ironing until the water and lime
stains left on the base are re-
moved. Wait until the iron cools
down before storing it.
5.3 Lime protection system
(Anti-Calc)
The lime protection system in the
water tank of your iron prevents
clogging of the steam holes. Lime
protection system is always active
and there is no need to replace it.
5.4 Storage
If you do not intend to use the steam
iron for a long time, please store it
carefully.
•Make sure that the iron is un-
plugged and cooled down com-
pletely before storing it.
•Empty the water reservoir.
•Please keep the steam iron and
its accessories in their original
packages.
•Store them in a cool and dry
place.
•Make sure that the appliance is
stored in a place out of the reach
of children.
