Beko BKK 2174 User manual

BKK 2174
Steam Iron Station
User Manual
Buharlı Ütü İstasyonu
Kullanma Kılavuzu

Please read this user manual first!
Dear Customer,
Thank you for prefering a Beko product. We hope that you get the best results from
your product which has been manufactured with high quality and state-of-the-art
technology.Therefore, please read this entire user manual and all other accompanying
documents carefully before using the product and keep it as a reference for future
use. If you handover the product to someone else, give the user manual as well. Follow
all warnings and information in the user manual.
Explanation of symbols
Throughout this user manual the following symbols are used:
CImportant information or useful hints
about usage.
AWarning for hazardous situations
with regard to life and property.
Warning for hot surfaces.
This product has been produced in environmentally friendly, modern facilities
Complies with the WEEE Regulation. Does not contain PCB.

3 / 45 EN
Steam Iron Station / User Manual
CONTENTS
1 Important instructions for
safety and environment 4-12
1.1 General safety . . . . . . . . . . . . . . . . . . . . . 4
1.1.1 Electrical safety . . . . . . . . . . . . . . . . . . . 5
1.1.2 Product safety . . . . . . . . . . . . . . . . . . . . 8
1.2 Intended use. . . . . . . . . . . . . . . . . . . . . . 10
1.3 Children’s safety . . . . . . . . . . . . . . . . . . . 11
1.4 Compliance with WEEE regulation and disposal
of the waste product . . . . . . . . . . . . . . . .12
1.5 Package information . . . . . . . . . . . . . . . 12
2 Your steam iron station 13-14
2.1 Overview . . . . . . . . . . . . . . . . . . . . . . . . 13
2.1.1. Controls and parts . . . . . . . . . . . . . . . 13
2.1.2. Technical data. . . . . . . . . . . . . . . . . . . 14
3 Preparation 15
3.1 Initial use . . . . . . . . . . . . . . . . . . . . . . . . 15
3.3 Tips for ironing . . . . . . . . . . . . . . . . . . . . 16
3.4 Storage . . . . . . . . . . . . . . . . . . . . . . . . . 16
4 Operating the product 17-20
4.1 Dry ironing . . . . . . . . . . . . . . . . . . . . . . . 17
4.2 Filling in the water tank . . . . . . . . . . . . . . 18
4.3 Steam ironing. . . . . . . . . . . . . . . . . . . . . 18
4.4 Auto off . . . . . . . . . . . . . . . . . . . . . . . . . 20
4.5 Vertical steam ironing . . . . . . . . . . . . . . . 20
5 Cleaning and care 21-22
5.1 Cleaning. . . . . . . . . . . . . . . . . . . . . . . . . 21
5.2 Descaling . . . . . . . . . . . . . . . . . . . . . . . . 21
5.3 Handling and transportation. . . . . . . . . . . 22
01M-8938401200-3115-01

4 / 45 EN Steam Iron Station / User Manual
This section contains safety instructions that
will help protect from risk of personal injury
or property damage. Failure to follow these
instructions shall void any warranty.
1.1 General safety
•Do not use the appliance outdoors or in the
bathroom.
•No liability is accepted for damages resulting
from incorrect usage or improper handling of
the appliance.
•Do not leave this appliance unattended while
it is in use. Extreme caution is advised when
being used near children and persons who
are restricted in their physical, sensory or
mental abilities.
•Do not open the outer casing under any
circumstance. No liability is accepted for
damages caused by improper use.
1Important instructions for safety and
environment

5 / 45 EN
Steam Iron Station / User Manual
•Our Beko Household Appliances meet all
the applicable safety standards; thus if the
appliance or power cord is damaged, it
must be repaired or replaced by the dealer,
a service centre or a similarly qualified
and authorized service person to avoid any
danger. Faulty or unqualified repair work may
cause danger and risk to the user.
•Only use the original accessories or those
that are recommended by the manufacturer.
•Burns can occur from touching hot metal
parts, hot water or steam. Exercise care
when handling.
1.1.1 Electrical safety
•Never use this appliance with damp or wet
hands.
•The plug must be removed from the socket
outlet before the water reservoir is filled with
water.
1Important instructions for safety and
environment

6 / 45 EN Steam Iron Station / User Manual
•Make sure that your local power supply
corresponds to the information on the
rating plate. The only way to disconnect the
appliance from the power supply is to pull
the power plug out of the power outlet.
•For additional protection, this appliance
should be connected to a household residual
current device with a rating of no more than
30 mA. Consult your electrician for advice.
•Dry off the appliance and all accessories
prior to connecting it to a power supply and
prior to attaching the accessories.
•Make sure you do not accidentally trip on the
power cable when the appliance is in use.
•Position the appliance in such a way that the
power plug is always accessible.
•Never touch the power plug with damp or
wet hands.
1Important instructions for safety and
environment

7 / 45 EN
Steam Iron Station / User Manual
•Unplug the appliance before each cleaning
and when the device is not in use.
•Avoid damages to the power cable by not
squeezing, bending or rubbing it on sharp
edges. Keep the power cable away from hot
surfaces and open flames.
•Do not pull on the power cable to disconnect
the appliance from the power supply and
do not wrap the power cable around the
appliance; use the cable storage holder
provided.
•Do not use this appliance with an extension
cord.
•Do not submerge the appliance, the power
cable or the power plug in water or in any
other liquid.
1Important instructions for safety and
environment

8 / 45 EN Steam Iron Station / User Manual
1.1.2 Product safety
•Do not place this appliance on hotplates
(gas, electric / coal stoves, etc.). Keep this
appliance away from all hot surfaces.
•Always keep hair, clothing and other objects
away from the appliance while it is in use in
order to prevent injury and damages.
•Warning - Danger of Burns! Do not touch the
hot soleplate. Do not lean over the iron while
it is in use. Heat will rise from the device
during usage! Only touch the iron by the
handle.
•Only use the iron with the steam iron station
connected.
•If this appliance falls, if water leaks or other
defects occur, it must be inspected and
repaired by an authorized specialist. Do not
use this appliance until the defect has been
repaired.
1Important instructions for safety and
environment

9 / 45 EN
Steam Iron Station / User Manual
•Do not iron over zippers, metal buttons or
other metal parts, as this could damage the
soleplate.
•When walking away or leaving the appliance
unattended only for a short time, make sure
that the iron is always placed on the storage
base and switched it off.
•Never point the hot soleplate towards people,
animals or electrical devices whilst steam is
being emitted.
•The water drain in the bottom of the steam
ironing station must always be tightly sealed
when the iron is in use.
•After use, always let the iron cool down
completely in a location out of reach of
children and persons who are restricted in
their physical, sensory or mental abilities.
Wait until the appliance has completely
cooled down before storing it away.
1Important instructions for safety and
environment

10 / 45 EN Steam Iron Station / User Manual
An unattended, hot iron can result in burn
injuries!
•The iron must be used and rested on a stable
surface.
•When placing the iron on its stand, ensure
that the surface on which the stand is placed
is stable.
•Make sure that the device is cool before
removing water drain screw. After the
usage of the device, you should wait for
approximately 2 hours before removing the
screw.
1.2 Intended use
•The appliance is designed for domestic use
only.
1Important instructions for safety and
environment

11 / 45 EN
Steam Iron Station / User Manual
1.3 Children’s safety
•This appliance can be used by children
aged from 8 years and above and persons
with reduced physical, sensory or mental
capabilities or lack of experience and
knowledge if they have been given
supervision or instruction concerning use of
the appliance in a safe way and understand
the hazards involved. Children shall not
play with the appliance. Cleaning and user
maintenance shall not be made by children
without supervision.
•Danger of suffocation! Keep all packaging
materials away from children.
1Important instructions for safety and
environment

12 / 45 EN Steam Iron Station / User Manual
1.4 Compliance with WEEE regulation and disposal of the waste
product
This product does not contain harmful and forbidden materials
described in the “Directive on the Restriction of the Use of Certain
Hazardous Substances in Waste Electrical and Electronic
Equipment” (EEE) issued by the T.R. Ministry of Environment and
Urbanization. Complies with the WEEE Directive.
This product has been manufactured with high quality parts and materials
which can be reused and are suitable for recycling. Therefore, do not
dispose of the product with normal domestic waste at the end of its
service life. Take it to a collection point for the recycling of electrical
and electronic equipment. Please consult your local authorities to learn
the nearest collection point. Help protect the environment and natural
resources by recycling used products. For children’s safety, cut the power
cable and break the locking mechanism of the loading door so that it will
be non-functional before disposing of the product.
1.5 Package information
•Packaging materials of the product are manufactured from recyclable
materials in accordance with our National Environment Regulations. Do
not dispose of the packaging materials together with the domestic or
other wastes. Take them to the packaging material collection points
designated by the local authorities.
1Important instructions for safety and
environment

13 / 45 EN
Steam Iron Station / User Manual
1
4
5
6
2
3
7
8
9
10
11
12
13
2.1 Overview
2.1.1. Controls and parts
1- Handle
2- Steam hose
3- Temperature indicator light
4- Control panel
5- Steam ironing station
6- Cable storage holder with clamping bracket
7- Power cable with power plug
8- Removable water tank with handle and trigger
9- Soleplate
10- Storage base
11- Water filling opening with lid
12- Temperature control dials
13- Steam jet button
All declared values on the product and on the printed leaflets are picked up after laboratory measurements
performed according to related standarts. These values may differ upon usage and ambient conditions.
2 Your steam iron station

14 / 45 EN Steam Iron Station / User Manual
2.1.2. Technical data
Power supply :
220-240V~, 50/60 Hz
Power consumption: 2000-2400W
Steam pressure : 4.5 bar
Steam quantity : 110g/min.
Water tank capacity: 1.7 litres
This product conforms to the
European directives 2004/108/
EC, 2006/95/EC, 2009/125/EC
and 2011/65/EU.
14- Power indicator
15- Descaling indicator
16- Water filling indicator
17- Steam ECO indicator light green
18- Steam MEDIUM indicator light red
19- Steam HIGH indicator light red
20- On/Off switch
21- Steam adjusting button
22- Non-slip rubber foot
23- Water drainage screw
24- Rubber lid
25- Key for the water drainage screw
22
25
24
23
14
15
16
17 18
19
20
21
eco
2 Your steam iron station

15 / 45 EN
Steam Iron Station / User Manual
3.1 Initial use
1. Remove all packaging materials,
labels and protective foil and
dispose of them according to the
applicable legal regulations.
2. Clean the outer parts of the
appliance as described in the
section “Cleaning and care“.
3. Place the appliance on an even,
stable, dry and non-slip surface.
4. Place the iron onto the storage base
(10).
C
During first use, a slight
dour may occur as a
result of manufacturing
residues being burnt
off. This is harmless
and will only last for a
short time. Ensure for
sufficient ventilation.
A
WARNING: Never im-
merse the steam iron-
ing station in water or
any other liquid. Do not
fill in the steam ironing
station with vinegar,
descaling agents,
starch, perfume or
ironing aids.
C
When ironing for the
first time, use an old,
clean cloth so that
manufacturing residues
can be removed from
the soleplate (9).
3.2 Saving energy
This product has an ECO steam
generation setting.
By using this setting, you can save
40% energy in comparison to the
maximum steam generation setting
with normal usage (Tested according
to EN 60311+A1 clause 11).
Many linen types can be ironed well
with ECO steam setting.
To save energy:
•You should use the appropriate
heat setting. If you don’t know the
appropriate heat setting, start from
the lowest heat setting and increase
it until linen can be ironed well.
•Your product can generate enough
steam in ECO mode to iron many
linen types. We suggest you to start
using your product with ECO setting.
If you don’t know the appropriate
steam setting, start from the lowest
steam setting and increase it until
linen can be ironed well.
•For better ironing, try using the
steam with pulse actions.
3 Preparation

16 / 45 EN Steam Iron Station / User Manual
3.3 Tips for ironing
•Prior to ironing, always check the
garment label to ensure the correct
temperature is set on the iron.
•Since the iron heats up much
quicker than it cools down, synthetic
textiles, silk or similar fabrics should
be ironed using lower temperature
settings first.
•If the garment is made of combined
types of fabric, always begin with the
lowest temperature setting first.
•Silk and other textiles that tend to
shine should be ironed inside out.
Velvet and other types of fabric that
shine should be ironed with very little
pressure and only in one direction.
Always keep moving the iron while
ironing.
•Do not use the steam function when
ironing colored silk. This could
cause stains.
•Garments made of 100% pure wool
can be ironed using steam. Set
the temperature control dial (12)
preferably to the MAX setting and
lay a dry towel between the garment
and the iron.
•Ironing wool garments can cause
them to ‘shine’. It is therefore
recommended to iron such garments
inside out.
A
WARNING: Never iron
on metal parts, such as
zippers, rivets, or metal
buttons as they could
damage the soleplate
(9). Always iron around
these metal parts.
3.4 Storage
If you will not be using the steam iron
for a long period of time, please store
it away carefully.
•Make sure that the iron is
disconnected from the power supply
and completely dry when storing it
away.
•Empty the water tank (8).
•Open the water drainage screw (23)
and let the remaining water drain
out of the iron. Screw in the water
drainage screw (23) again and
tighten it.
•To store away the steam ironing
station, wind the steam hose (2) and
the power cable (7) around the cable
storage holder (6) and secure them
with the clamping bracket.
•Please try to store the steam iron
and the attachments in their original
packaging.
•Store it in a cool, dry place.
•Make sure the appliance is always
kept out of the reach of children.
3 Preparation

17 / 45 EN
Steam Iron Station / User Manual
4.1 Dry ironing
1. Place the appliance on an even, dry
and nonslip surface. The non-slip
feet (22) ensure the stability of the
appliance.
2. The water tank (8) must remain
empty during the dry ironing pro-
cess; otherwise steam pressure
could build up.
3. Insert the power plug (7) into the
wall socket.
4. Push the On/Off switch (20) to
switch on the steam ironing station.
– Power indicator (14) and Filling
Water indicator (16) become red.
5. Depending on the type of fabric,
turn the temperature control dial
(12) to one of the following settings:
Nylon setting 1 •
Silk setting 1 •
Wool setting 2 ••
Cotton setting 3 •••
Linen setting MAX MAX
AWARNING: Always read
the care label on your
garment before setting
the temperature.
•The temperature indicator light (3)
lights up red. The red temperature
indicator light (3) remains on while
the iron is heating up. As soon
as the iron reaches the set tem-
perature, the temperature indicator
light (3) goes off. The temperature
indicator light will go on and off
during usage to indicate that the set
temperature is being regulated.
6. The ironing process can begin.
A
WARNING: When
taking a break from
ironing, always place
the iron back onto the
storage base (10). The
tip of the soleplate (9)
must always be placed
on the surface of the
storage base (10).
7. After the ironing process is com-
plete, place the iron onto the stor-
age base (10).
8. Press and hold down the On/Off
switch (20) of the steam ironing sta-
tion for a few seconds to switch the
steam ironing station off.
9. Let the appliance cool down in a
location that is safely out of reach of
children.
4 Operating the product

18 / 45 EN Steam Iron Station / User Manual
4.2 Filling in the water tank
1. Grab the handle (1) of the water tank
(8) and pull the water tank out of the
steam ironing station by pushing the
trigger underneath the handle.
2. Open the lid of the water filling
opening (11) and fill the water tank
(8) with tap water or distilled water
up to the MAX marking. The maxi-
mum capacity is 1.7 liters.
3. Close the lid of the water filling
opening and push the water tank (8)
completely into the steam ironing
station. Make sure that it clicks into
place properly and is secured to the
housing of the steam ironing sta-
tion.
CDuring water intake,
the device may create
noise due to its pump
operation, this is a nor-
mal condition.
C
If your tap water is very
hard it is recommended
to mix the tap water
with distilled water on a
50:50 ratio, or use dis
tilled water only.
4.3 Steam ironing
1. Place the appliance on an even, dry
and nonslip surface. The non-slip
feet (22) ensure the stability of the
appliance.
2. Fill the water tank as described
in the section “Filling in the water
tank”.
3. Insert the power plug (7) into the
socket.
4. Push the On/Off switch (20) to
switch on the steam ironing station.
– Power indicator (14) lights in red
and ECO indicator (17) starts to
flash in green. When it is ready
for steam ironing the green light
will be on continuously.
5. Adjust the temperature control dial
(12) to the desired temperature.
– The temperature indicator
light (3) lights up red. The red
temperature indicator light (3)
remains on while the iron is
heating up. As soon as the iron
reaches the set temperature, the
temperature indicator light goes
off. The temperature indicator
light will go on and off during
usage to indicate that the set
temperature is being regulated.
4 Operating the product

19 / 45 EN
Steam Iron Station / User Manual
C
When the steam level is
set to MEDIUM or HIGH,
it is recommended to
set the temperature at
MAX level, otherwise
water dropping problem
may occur.
6. The water in the water tank (8)
heats up within 3 minutes. As soon
as the temperature indicator light
goes off and the control indicator
in (3) the steam button remains lit,
the steam iron is ready to use. Hold
the iron in horizontal position on the
garments and press the steam jet
button (13) continue to move the
iron when ironing.
AWARNING: Never
direct the steam at
people or pets.
C
When the steam iron-
ing station is switched
on it will produce a
‘pumping’ sound. This
is normal and indicates
that water is being
pumped from the water
tank into the steam iron-
ing station.
7. Set the desired steam pressure
ECO, MEDIUM or HIGH by using the
steam adjusting button (21).
– The corresponding control indica-
tor in the steam button blinks
as soon as it is selected. After
approx. 2 minutes the control
indicatorm will remain lit, indicat-
ing that the appliance is ready
for steam ironing.
8. When there is insufficient water left
in the water tank (8) the steam gen-
eration stops and the water filling
indicator (16) lights up, followed by
an audible beep. The control indica-
tor of the selected steam level goes
off. Place the iron onto the storage
base (10) and refill the water tank
(see section -Filling in the water
tank-).
9. After ironing process is complete,
place the iron onto the storage base
(10).
10.Press and hold down the On/
Off switch (20) of the steam iron-
ing station for a few seconds to
switch the steam ironing station off.
Disconnect the power plug.
11.Let the appliance cool down in a
location that is safely out of reach
of children.
AWARNING: Never
touch the hot soleplate
(9) with bare hands.
Danger of Burns!
4 Operating the product

20 / 45 EN Steam Iron Station / User Manual
C
If the steam function
has not been used for
some time the water
condensed in the
steam hose (2) trans-
forms into water. When
restarting the steam
ironing station again,
it could cause splut-
tering of the unit and
water droplets at the
soleplate (9). In order
to avoid these droplets
falling onto your gar-
ments we recommend
using an old clean cloth
in the beginning. Press
the steam jet button
(13) until the droplets
disap-pear and normal
steam will be pro-
duced.
•If dirt particles escape from the
soleplate (9), clean the steam iron-
ing station according to the instruc-
tions in section “Cleaning and care”.
4.4 Auto off
The steam ironing station will automa-
tically switch off if no button or any ot-
her control element has been activated
for a period of 10 minutes.
4.5 Vertical steam ironing
C
Vertical steam iron-
ing can be applied to
hanging curtains or
clothes (suits, jackets
and coats).
1. The steam ironing station has three
steam settings: ECO, MID and HIGH.
Please refer to section “Steam iron-
ing”.
2. When the control indicator of the
selected steam pressure remains
lit, it indicates that the appliance is
ready for steam ironing.
3. Hold the iron in vertical position on
the garments or curtains and press
the steam jet button (13). Continue
to move the iron when ironing
AWARNING: Never
direct the steam at
people or pets.
4 Operating the product
