Beko RDNT460 Series User manual

RDNT372*
RDNT409*
RDNT371W*
RDNT371XS*
RDNT401W*
RDNT401XS*
RDNT371*
RDNT401*
RDNT460*
Refrigerator
User manual
EN / AR
5774451011/AB
www.beko.com

Please read this user manual rst!
Dear Customer,
We hope that your product, which has been produced in modern plants and checked under the most meticulous
quality control procedures, will provide you an effective service.
Therefore, read this entire user manual carefully before using the product and keep it as a reference. If you handover
the product to someone else, give the user manual as well.
The user manual will help you use the product in a fast and safe way.
Read the manual before installing and operating the product.
Make sure you read the safety instructions.
Keep the manual in an easily accessible place as you may need it later.
Read the other documents given with the product.
Remember that this user manual is also applicable for several other models.Differences between models will be
identied in the manual.
Explanation of symbols
Throughout this user manual the following symbols are used:
Important information or useful tips.
Warning against dangerous conditions for life and property.
Warning against electric voltage.
CONTENTS
1.Your Refrigerator 1
2.Important Safety warning 1
Intended use............................................................1
General safety..........................................................1
For products with a water dispenser.............. 2
Child safety...............................................................2
Compliance with WEEE Directive and
Disposing of the Waste Product....................... 2
Package information.............................................2
HC warning...............................................................3
Recommendations for the fresh food
compartment...........................................................3
Things to be done for energy saving.............. 3
3.Installation 3
Points to be paid attention to when the
relocation of the refrigerator............................. 3
Electrical connection.............................................3
Disposing of the packaging............................... 3
Disposing of your old refrigerator....................3
Placing and Installation........................................3
Door Open Warning..............................................4
Adjusting the legs..................................................4
Changing the illumination lamp...................... 4
4.Preparation 4
5.Using your refrigerator 5
Indicator panel(Internal)......................................5
Indicator panel(External).....................................5
Freezing fresh food................................................7
Recommendations for preservation of
frozen food............................................................... 7
Defrosting................................................................. 7
Placing the food......................................................7
Deep-freeze information.....................................7
Making ice.................................................................7
Twist Ice – matic......................................................7
Ice container............................................................ 8
Convertible Chiller compartment ................... 8
Crisper........................................................................ 8
For the Blue light....................................................8
For HarvestFresh ....................................................8
Fan............................................................................... 8
Using the water fountain ....................................8
Cleaning the water tank...................................... 9
6.Maintenance and cleaning 9
Protection of plastic surfaces.............................9
7.Troubleshooting 10

Figures that take place in this instruction manual are schematic and may not correspond exactly with
your product. If the subject parts are not included in the product you have purchased, then it is valid
for other models.
1Your Refrigerator
2Important Safety Warnings
Please review the following information.
Failure to observe this information may cause injuries
ior material damage. Otherwise, all warranty
and reliability commitments will become invalid.
The service life of your product is 10 years.
During this period, original spare parts will be
available to operate the product properly.
Intended use
This product is intended to be used
indoors and in closed areas such as homes;
in closed working environments such as
stores and ofces;
in closed accommodation areas such as farm
houses, hotels, pensions.
It should not be usedoutdoors.
General safety
When you want to dispose/scrap the
product, we recommend you to consult the
authorized service in order to learn the required
information and authorized bodies.
Consult your authorized service for all your
questions and problems related to the refrigerator.
Do not intervene or let someone intervene to the
refrigerator without notifying the authorised services.
For products with a freezer compartment;
Do not eat cone ice cream and ice cubes immediately
after you take them out of the freezer compartment!
(This may cause frostbite in your mouth.)
For products with a freezer compartment;
Do not put bottled and canned liquid beverages in the
freezer compartment. Otherwise, these may burst.
Do not touch frozen food by hand; they may sick
to your hand.Unplug your refrigerator before
Vapor and vaporized cleaning materials should never
be used in cleaning and defrosting processes of your
refrigerator. In such cases, the vapor may get in contact
with theelectrical parts and cause short circuit or
electric shock.
Never use the parts on your refrigerator such as
the door as a means of support or step.
Do not use electrical devices inside the refrigerator.
Do not damage the parts, where the refrigerant is
circulating, with drilling or cutting
that might blow out when the gas channels of the
evaporator, pipe extensions or surface causes skin
irritations and eye injuries.
Do not cover or block the ventilation holes on your
refrigerator with any material.
Electrical devices must be repaired by only authorised
authorised persons. Repairs performed by
in competent persons create a risk for the user.
In case of any failure or during a maintenance or repair
work, disconnect your refrigerator’s mains supply
by either turning off the relevant fuse or unplugging
your appliance.
Do not pull by the cable when pulling off the plug.
Ensure highly alcoholic beverages are stored
securely with the lid fastened and placed upright.
Never store spray cans containing ammable and
explosive substances in the refrigerator.
Do not use mechanical devices or other means
to accelerate the defrosting process, other than those
recommended by the manufacturer.
cleaning or defrosting.
This product is not intended to be used by persons
with physical, sensory or mental disorders or
unlearned or inexperienced people
(including children) unless they are attended by
a person who will be responsible for their safety or
safety or who will instruct them accordingly for use
of the product
16
17
1
1
2
3
4
*5
6
7
9
*10
11
14
12 13
13
15 15
1. Freezer - compartment door shelf
2. Egg Section
3. Fridge door shelf
4. Fridge door shelf
5. Cosmetic Box
6. Bottle shelf
7. Fridge-compartment door shelf
8. Icebox / Ice-making compartment
9. Freezer compartment glass shelf
10. Meat zone
11. Convertible Chiller compartment
12. Temperature setting button
13. Fridge compartment glass shelf
14. Crisper
15. Adjustable feet
16. Freezer compartment
17. Fridge compartment
*Selected Model
8
EN
1

Do not operate a damaged refrigerator.
Consult with the service agent if you have any concerns.
Electrical safety of your refrigerator shall be guaranteed
only if the earth system in your house complies with
standards.
Exposing the product to rain, snow, sun and wind is
dangerous with respect to electrical safety.
Contact authorized service when there is a power cable
damage to avoid danger.
Never plug the refrigerator into the wall outlet during
installation.Otherwise, risk of death or serious
injury may arise.
This refrigerator is intended for only storing food items.
It must notbe used for any other purpose.
Label of technical specications is located on the
left wall inside the refrigerator.
Never connect your refrigerator to electricity saving
systems; they may damage the refrigerator.
If there is a blue light on the refrigerator, do not
look at the blue light with optical tools.
For manually controlled refrigerators, wait for at least
5 minutes to startthe refrigerator afterpower failure.
This operation manual should be handed in to the new
owner of the product when it is given to others.
Avoid causing damage on power cable when
transporting the refrigerator. Bending refrigerator
Bending cable may cause re. Never place heavy
objects on power cable.Do not touch the plug with wet
hands when plugging the product
Do not plug the refrigerator if the wall outlet is loose.
Water should not be sprayed on inner or outer
parts of the product for safety purposes.
Do not spray substances containing inammable gases
such as propane gas near the refrigerator to avoid re
and explosion risk.
Never place containers lled with water on top of the
refrigerator; in the event of spillages, this may cause
electric shock or re.
Do not overload the refrigerator with food. If overloaded,
the food items may fall down and hurt you and damage
refrigerator when you open the door.
Never place objects on top of the refrigerator;
otherwise, these objects may fall down when
you open or close the refrigerator’s door.
As they require a precise temperature, vaccines,
heat-sensitive medicine and scientic materials and
etc. should not be kept in the refrigerator.
If not to be used for a long time, refrigeratorshould
be unplugged. A possible problem in power cable
may cause re.
The plug’s tip should be cleaned regularly with a
dry cloth; otherwise, it may cause re.
Refrigerator may move if adjustable legs are not
properly secured on the oor. Properly securing
adjustable legs on the oor can prevent the
refrigerator to move.
When carrying the refrigerator, do not hold it from
it from door handle. Otherwise, it may be snapped.
When you have to place your product next to
another refrigerator or freezer, the distance between
devices should be at least 8cm. Otherwise, adjacent
side walls may be humidied.
The product shall never be used while the
compartment which is located at the top or back of
your product and in which electronic boards are
available (electronic board box cover) (1) is open.
For products with a water dispenser
Pressure for cold water inlet shall be maximum 90 psi
(6.2 bar). If your water pressure exceeds 80 psi (5.5 bar),
use a pressure limiting valve in your mains system. If
you do not know how to check your water pressure
ask for the help of a professional plumber.
If there is risk of water hammer effect in your
installation, always use a water hammer prevention
equipment in your installation. Consult Professional
plumbers is you are not sure that there is no water
hammer effect in your installation.
Do not install on the hot water inlet. Take precautions
against of the risk of freezing of the hoses. Water
temperature operating interval shall be 33°F (0.6°C)
minimum and 100°F (38°C) maximum
Use only potable water.
Child safety
If the door has a lock, the key should be kept away from
reach of children.
Children must be supervised to prevent them from
tampering with the product.
Compliance with WEEE Directive and
Disposing of the Waste Product:
This product complies with EU WEEE
Directive (2012/19/EU). This product bears
a classication symbol for waste electrical
and electronic equipment (WEEE).
This product has been manufactured with high
quality parts and materials which can be reused and
are suitable for recycling. Therefore, do not dispose
the product with normal domestic waste at the end of
its service life. Take it to a collection point for the
recycling of electrical and electronic equipment.
Please consult your local authorities to learn the
nearest collection point. Help protect the environment
and natural resources by recycling used products.
For children’s safety, cut the power cable and break
will be non-functional before disposing of the product.
the locking mechanism of the door, if any, so that it
Package information
Packaging materials of the product are manufactured
from recyclable materials in accordance with our
National Environment Regulations. Do not dispose
of the packaging materials together with the domestic
or other wastes. Take them to the packaging material
collection points designated by the local authorities.
Do not forget
Any recycled substance is anindispensable matter for
nature and our national asset wealth. If you want to
contribute to re-evaluation of the packaging materials
you can consult to your environmentalist organizations
or the municipalities where you are located.
EN
2
1

HC warning
If your product's cooling system contains R600
This gas is ammable. Therefore, pay attention to
not damaging the cooling system and piping during
usage and transportation. In the event of damage,
keep your product away from potential re sources
that can cause the product catch a re and ventilate
the room in which the unit is placed.
Ignore this warning if your product's
cooling system contains R134a.
Type of gas used in the product is stated in the type
label which is on the left wall inside the refrigerator.
Never throw the product in re fordisposal.
Recommendations for the fresh food compartment
*optional
Do not allow the food to touch the temperature
sensor in fresh foodcompartment. To allow the fresh food
compartment keep its ideal storage temperature
sensor must not be hindered by food.
Do not place hot foods in the product.
Things to be done for energy saving
Do not leave the doors of your refrigerator open for a long time.
Do not put hot food or drinks in your refrigerator.
Do not overload your refrigerator so that the air
circulation inside of it is not prevented.
Do not install your refrigerator under direct sunlight or near heat
emitting appliances such as ovens, dishwashers or radiators.
Keep your refrigerator at least 30cm away from heat
emitting sources and at least 5cm from electrical ovens.
Pay attention to keep your food in closed containers.
For products with a freezer compartment You can store
when you remove the shelf or drawer of the freezer.
Energy consumption value stated for yourrefrigerator
has been determined has been determined by removing
freezer shelf or drawer and under maximum load.
There is no harm to use a shelf or drawer according to
the shapes and size of food to be frozen.
maximum amount of food items in the freezer
Thawing frozen food in fridge compartment will both
provide energysaving and preserve the food quality.
3Installation
In case the information which are given in the user
manual are not taken into account, manufacturer will
not assume any liability for this.
Points to be paid attention to when the
relocation of therefrigerator
1. Your refrigerator should be unplugged.Before
transportation of your refrigerator, it should be
emptied and cleaned.
2. Before it is re-packaged,shelves, accessories, crisper, etc.
inside your refrigerator should bexed with adhesive
tape and secured against impacts. Package should
be bound with a thick tape or sound ropes and the
transportation rules on the package should be
strictly observed.
3. Original packaging and foammaterials should be
kept for future transportations or moving.Before
you start the refrigerator,
Check the following before you start to use
your refrigerator:
1. Clean the interior of therefrigerator as recommended in the
“Maintenance and cleaning” section.
2. Connect the plug of therefrigerator to the wall socket.When
the fridge door is opened, fridge internal lamp will turn on.
3. When the compressor starts tooperate, a sound will
be heard. The liquid and gases sealed with in the
refrigeration system may also give rise to noise, even
the compressor is not running and this is quite normal.
4. Front edges and both sides ofthe refrigerator may
feel warm. This is normal. These areas are designed
to be warm to avoid condensation.
Electrical connection
Connect your product to a grounded socket which is
being protected by a fuse with the appropriate capacity.
Important:
The connection must be in compliance with national regulations.
The power plug must be easilyaccessible after installation.
Electrical safety of your refrigeratorshall be guaranteed only
if the earthsystem in your house complies with standards.
The voltage stated on the label located at left inner side
of your product should be equal to your network voltage.
Extension cables and multi plugs must not be used for
connection.
A damaged power cable must be replaced by a qualied electrician.
Product must not be operated beforei t is repaired!
There is the risk of electric shock!
Disposing of the packaging
The packing materials may be dangerous for children.
Keep the packing materials out of the reach of children
or dispose of them by
classifying them in accordance
with the waste instructions stated by your local
authorities. Do not throw away with regular house
waste, throw away on packaging pick up spots
designated by the local authorities The packing of
your refrigerator is produced from recyclable materials.
Disposing of your old refrigerator
Dispose of your old refrigerator without giving any
harm to the environment.
You may consult your authorizeddealer or waste collection
center of your municipality about the disposalof your refrigerator.
Before disposing of your refrigerator, cut out the electric
plug and, if there are any locks on the door, make them
inoperable in order to protect childrenagainst any danger.
Placing and Installation
If the entrance door of the room where the refrigerator
will be installed isnot wide enough for the refrigerator to
pass through, then call the authorized service to have
them remove the doors of your refrigerator and pass it
sideways through the door.
EN
3

1. Install your refrigerator to aplace that allows ease of use.
2. Keep your refrigerator awayfrom heat sources, humid
places and direct sunlight.
3. There must be appropriate air ventilation around your
refrigerator in order to achieve an efcient operation.
If the refrigerator is to be placed in a recess in the wall,
there must be at least 5 cm distance with the ceiling
and at least 5 cm with the wall. Do notplace your
product on the materials such as rug or carpet.
4. Place your refrigerator on aneven oor surface to
prevent jolts.
Adjusting the legs
If your refrigerator is unbalanced;You can balance
your refrigerator by turning its front legs as illustrated
in the gure. The corner where the leg exists is lowered
when you turn in the direction of black arrow and
raised when you turn in the opposite direction.
Taking help from someone to slightly lift the
refrigerator will facilitate this process.
Changing the illumination lamp
To change the Bulb/LED used for illumination of your
refrigerator, call your AuthorisedService. The lamp(s)
used in this appliance is not suitable for house hold
room illumination. The intended purpose ofthis lamp
is to assist the user to place foodstuffs in the refrigerator
foodstuffs in the refrigerator/freezer in a safe and
comfortable way.The lamps used in this appliance have
to withstand extreme physical conditions such as
temperatures below -20 °C. (only chest and upright freezer)
Door Open Warning (This feature is optional)
Audio warning signal and ashing illumination will
be given when the door of your product is left
open for at least 1 minute. This warning will be
muted when the door is closed or any of the
display buttons (if any) are pressed.
‘ B ’
50 mm
100 mm
50 mm
50 mm
‘ C ’
‘ A ’
‘ D ’
130 (’ E ‘ )
o
Model
D66371N
D66401N
“A”
700
700
“B”
1660
1720
“C”
660
660
“D”
1168
1168
“E”
130
130
4Preparation
Your cooler/freezer should be installed at least 30 cm
away from heat sources such as hobs, ovens, central heater
and stoves and at least5 cm away from electrical ovens
and should not be located under direct sunlight.
Please make sure that the interior of your
cooler/freezer is cleaned thoroughly.
If two coolers are to be installed side by side, there
should be at least 2 cm distance between them.
When you operate your cooler/freezer for the rst time, please
observe the following instructions during the initialsix hours.
Its door should not be opened frequently.
It must be operated empty withoutplacing any food in it.
Do not unplug your cooler/freezer. If a power failure
occurs out of your control, please see the warnings in the
“Recommended solutions for the problems” section.
The baskets/drawers that are provided with the chill
compartment must always be in use for low energy
consumption and for better storage conditions.
Food contact with the temperature sensor in the freezer
compartment may increase energy consumption of appliance.
Thus any contact with the sensor(s) must be avoided.
This product has been designed to function at
ambient temperatures up to 43°C (90 SDgr F). Even if
theambient temperature falls to -15 °C, frozen food
If the ambient temperature is below 0°C, the food in fridge
compartment will freeze. Therefore, we recommend not using
the fridge compartment in such low ambient temperatures.
You may continue to use the freezer compartment as usual.
In some models, the instrument panel automatically turns
off 5 minutes after the door has closed. It will be reactivated
when the door has opened or pressed on any key.
Due to temperature change as a result of opening/closing
the product door during operation, condensationon the
door/body shelves and the glass containers is normal.
Electronic Temperature Control System. For the rst
installation, the
product should NOT be placed underlow
ambient temperatures. This is because the freezer cannot go
down to standard operation temperature. When reaching
continuous operation, the product can be moved to another
place. Thus, later you can place your product in the garage or
an unheated room without the concern of causing frozen food
to get rotten. However, it is likely that above mentioned low
temperatures may cause the freezing of the food in the fridge
compartment; thus, please consume the food items in the fridge
in a controlled way as needed. When ambient temperature goes
back to normal, you may change button setting according to
your need.
in the freezer does not thaw thanks to its Advanced
EN
4

Indicator panel (Internal Display) *Optional
Indicator panels may vary according to the product
model.Audio – visual functions on the indicator
panel helps you in using your product.
5Using your refrigerator
Indicator panel(External display)*Optional
Figures that take place in this instruction manual are
schematic and may not correspond exactly with your
product. If the subject parts are not included in the
product you have purchased, then it is valid for other
models.
12 3 4
5 6 *7 8
Figures that take place in this instruction manual
are shematic may not correcspond exactly with
your product. If the subject parts are not included
in the product you have purchased, then it is valid
for other models.
Indicator panel allows you to set the temperature
and control the other functions related to the
product without opening the door of the product.
Just press the inscriptions on relevant buttons for
function settings.
1. Quick Freezer button
Selection button Press “Quick Freeze”.Selection button
to setting freezer compartment.
2. Error status indicator
If your refrigerator does not per form enough cooling
of in case of a sensor fault, this indicator is activated.
3. Freezer compartment selection button
This function allows you to set the temperature of
freezer compartment.Press this button to set the
temperature of the freezer compartment to -16 , -18,
-20 and -24 respectively.
4. Freezer compartment temperature indicator
Temperature of the freezer compartment -24 , -20,
-18, and -16.
5. Quick Fridge button
Selection button : Press“Quick Cool”.Selection button
to setting fridge compartment.
6. Fridge compartment selection button
This function allows you to set the temperature of
fridge compartment. Press this button to set the
temperature of the fridge compartment to 8, 6, 4,
and 2, respectively.
7. Vacation function indicator (optional)
When the vacation function light.It is not suitable to
keep the food in the fridge compartment when this
function is activated.
8. Fridge compartment temperature indicator
Temperature of the fridge compartment 2, 4, 6 and 8.
1. Power failure/High temperature / error warning
indicator
This indicator ( ) illuminates during power failure,
high temperature failures and error warnings. During
sustained power failures, the highest temperature that
the freezer compartment reaches will ash on the
digital display. After checking the food located in the
freezer compartment ( ) press the alarm o button to
clear the warning. Please refer to "remedies advised
for trouble shooting" section on your manual if you
observe that this indicator is illuminated.
2. Energy saving function (display o):
If the product doors are kept closed for a long time
energy saving function is automatically activated and
energy saving symbol is illuminated. ( )When energy
saving.function is activated, all symbols on the display
other than energy saving symbol will turn o.
When the Energy Saving function is activated, if any
button is pressed or the door is opened, energy saving
function will be canceled and the symbols on display
will return to normal.
Energy saving function is activated during delivery
from factory and cannot be canceled.
3.Quick fridge function
The button has two functions. To activate or
deactivate the quick cool function press it briey.
Quick Cool indicator will turn o and the product
will return to its normal settings. ( )
EN
5

9. Freezer compartment temperature setting button
Press this button to set the temperature of the freezer
compartment to-16,-17,-18,-19,-20,-22,-24,-16...
respectively. Press this button to set the freezer
compartment temperature to the desired value. ( )
10. Icematic function (optional)
Indicates whether the icematic is on or o.( )If On,
then the icematic is not operating. To operate the
icematic again press and hold the On-O button f
or 3 seconds.
Water ow from water tank will stop
when this function is selected.
However,ics made previously can be
taken from the icematic.
11. Quick freeze function button
Press this button to activate or deactivate the quick
freezing function.When you activate the function,
the freezer compartment will be cooled to a
temperature lower than the set value. ( )
12. Economic usage indicator
Indicates that the product is running in energy-ecient
mode. ( ) This indicator will be active if the Freezer
Compartment temperature is set to -16 or the energy
ecient cooling is being performed due to Eco-Extra
function.
Use the quick freeze fucntion when you
want to quickly freeze the food palced
in fridge compartment. If you want to
freeze large amounts of fresh food,
activate this fuction before putting the
food into the product.
If you do not cancel it,Quick freeze will
cancel itself automatically after 24 hours
or when the fridge compartment
reaches to the required temperature.
This function is not recalled when
power restores after a power failure.
Economic usage indicator is turned o
when quick cooling or quick freeze
functions are selected.
Use quick cooling function when you
want to quickly cool compartment. If
you want to the food placed in the
fridge cool large amounts of fresh
Food,activate this function before
putting the food into the product.
If you do not canel it,quick cooling will
cancel itself automatically after 1 hours
or when the fridge compartment
reaches to the required temperature.
If you press the quick cooling button
repeatedly with short intervals, the
electronic circuit protection will be
activated and the compressor will not
start up immediately.
This function is not recalled when
power restores after a power failure.
4. Fridge compartment temperature setting button
Press this button to set the temperature of the
fridge compartment to 8, 7,6, 5,4,3, 2, 8...
respectively. Press this button to set the fridge
compartment temperature to the desired
value. ( )
5.Vacation Function
In order to activate vacation function,press the
this button ( ) for 3 seconds, and the vacation
mode indicator ( ) will be activated. When the
the vacation function is activated, “- -” is displayed
on the fridge compartment temperature indicator
and no active cooling is performed on the fridge
compartment. It is not suitable to keep the food in
the fridge compartment when this function is
activated. Other compartments shall be continued
to be cooled as per their set temperature.To cancel
this function press Vacation function button again.
6. Alarm o warning:
In case of power failure/high temperature alarm,
after checking the food located in the freezer
compartment press the alarm o button ( )
to clear the warning.
7.Key lock
Press key lock button ( )simultaneously for
3 seconds. Key lock symbol ( )will light up and
8. Eco fuzzy
Press and hold eco fuzzy button for 1 seconds to
activate eco fuzzy function. Refrigerator will start
operating in the most economic mode at least
6 hours later and the economic usage indicator will
turn on when the function is active ( ).Press and
hold eco fuzzy function button for 3 seconds to
deactivate eco fuzzy function.This indicator is
illuminated after 6 hours when eco fuzzy is activated.
key lock mode will be activated. Buttons will not
function if the Key lock mode is active. Press key
lock button simultaneously for 3 seconds again.
Key lock symbol will turn o and the key lock mode
will be exited.
Press the Key lock button if you want to prevent
changing of the temperature setting of the
refrigerator ( )
EN
6

Freezer
compartment
shelves
Various frozen food such as
meat,sh, ice cream,
vegetables and etc.
Egg tray Egg
Fridge
compartment
shelves
Food in pans, covered plates
andclosed containers
Fridge
compartment
door shelves
Small and packaged food or
drinks (suchas milk,
fruit juice andbeer)
Crisper Vegetables and fruits
Freshzone
compartment
Delicatessen products
(cheese,butter, salami and etc.)
Food must be frozen as rapidly as possible when
they are put in a refrigerator in order to keep them
in good quality.
It is possible to keep the food for a long time only
at -18°C or lower temperatures.
Deep-freeze information
You can keep the freshness of food for many months
(at -18°C or lower temperatures in the deep freeze).
WARNING!
Freezing fresh food
• It must be preferred to wrap or cover thefood before
placing them in the refrigerator.
• Hot foodmust cool down to the room temperature before
putting them in the refrigerator.
•
The foodstu that you want freeze must be fresh and in good quality.
• Foodstumust be divided into portions according to the
family’sdailyormeal based consumption needs.
• The foodstumust be packaged in an airtight manner to
prevent themfrom drying even if they are going tofrom
drying even if they are going to be kept for a short time.
• Materials to be used for packagingmust be tear-proofand
resistant tocold, humidity, odor, oils and acids and they must
also be airtight. Moreover, they must be wellclosed and
they must be made from easyto use materials that are
suitable for deep freeze usage.
• Frozen foodmust be used immediately after they are
thawed and they should never be re-frozen.
•
Please observe the following instructions to obtain the best results.
1. Do not freeze too large quantities of food at one time.
The quality of the food is best preserved when it is
frozen right through to the core as quickly as possible.
2. Placing warm food into the freezer compartment
causes the cooling system to operate continuously
until the food is frozen solid.
3. Take special care not to mix already frozen food and fresh
food.
Recommendations for preservation of frozen food
• Prepackedcommercially frozen food should be stored in
accordance with the frozen food manufacturer's instructions
for a
( 4 star)frozen food storage compartment.
• To ensure that the high quality achieved by the frozen
food manufacturer and the food retailer is maintained, the
following should be remembered:
1. Put packages in the freezer as quickly as possible after purchase.
2. Ensure that contents are labeled and dated.
3. Do not exceed "Use By", "Best Before" dates on the packaging.
Defrosting
The freezer compartment defrosts automatically.
Placing the food
• Foodstuff must be divided into portions according to
the family’s daily or meal based consumption needs.
• Foodstuff must be packaged in an airtight manner to
prevent them from drying even if they are going to
be kept for a short time.
• Materials necessary for packaging:
• Cold resistant adhesive tape
• Self adhesive label
• Rubber rings
• Pen
Materials to be used for packaging the foodstuff must be
tear-proof andresistant to cold, humidity, odor, oils and
acids.
Foodstuff to be frozen should not be allowed to
come in contact with thepreviously frozen items to
prevent their partial thawing.
Frozen food must be used immediatelyafter they
are thawed and they should never be re-frozen.
Making ice (This feature is optional)
Fill the ice container with water and place it into the
freezer compartment. ice will be ready approximately
intwo hours.
You can remove the ice in the ice container by
removing it from the freezer and twisting it.
Twist Ice – matic (This feature is optional)
• Remove the water tank by rotating it to the left.
•
Open the water tank cover by turning it and add water to
the water tank up to the lower part of the water tank cover.
• Place the water tank on its place as shown in the gure
after adding water and have it seated by rotating it onthe
direction of the arrow. Water shall be poured down to the
icebank.
• When ice has formed, rotate icebank knob in the directionof
the arrow to allow that the ice is dropped down to the ice
drawer.
• Take the ice cubes by pulling ice drawer out.
• Pull the front face towards you in order to wash the
icebank, and put it on the slides on the interior area
and push it nto its place in order to replace it.
• Pull the twist icematic unit towards you in order to
remove the unit, and put it on the slides on the ceiling
and push it to its place in order to replace it.
EN
7

Convertible Chiller compartment
(This feature is optional)
Use this compartment to store delicatessen that shall
be stored in a lower temperature or meat products that
you will consume in a short time.
Chiller compartment is the coolest place in your refrigerator
where you can keep dairy products, meat, sh and poultry
under ideal storage conditions.Fruits and vegetables should
not be stored in this compartment. (1)
Crisper
Crisper of the product is designed specially to keep the
vegetables fresh without loosing their humidity.
For this purpose, cool air circulationis intensied around
the crisper in general. (2)
1
1
2
Fan
Fan is designed to ensure homoge neous
distribution and circulation ofthe cold air inside
your refrigerator.Operation time of the fan may
vary .depending on the properties of yourproduct.
While the fan works only with the compressor in
some products, the controlsystem determines its
operation time in some products in accordance
with the cooling requirement.
• Remove the ice container from the freezer
compartment.
• Fill the ice container with water.
• Place the ice container in the freezercom-
partment.
About two hours later, the ice is ready.
• Remove the ice container from the freezer
compartment and bend it over the service
plate. Ice cubes will easilyfall down to the
service plate.
Ice container
For the Blue light (*Depend on model)
Fruits and vegetables stored in the crispers that are
illuminated with a blue light continue their
photosynthesis by means of the wave length eect
of blue light and thus preserve their vitamin C
content.
For HarvestFresh (*Depend on model)
Fruits and vegetables stored in crispers illuminated
wit the HarvestFresh technology preserve their
vitamin content (vitamin A and C) for a longer time
thanks to the blue, green, red lights and dark
cycles, which simulate a day cycle.
Using the water fountain
(for certain models)
The rst few glasses of water taken from
the fountain will normally be warm.
If the water fountain is not used for a
long time, dispose of the rst few
glasses of water to get clean water.
You must wait approximately 12 hours to get cold
water after rst operating. then pull the trigger to
get water.
Remove the glass shortly after pulling the trigger.
EN
8
If you open the door of the refrigerator during the
dark period of the HarvestFresh technology, the
refrigerator will automatically detect this and
enable the blue, green or red light to illuminate the
crisper for your convenience. After you have closed
the door of the refrigerator, the dark period will
continue, representing the night time in a day cycle
* Before use water dispenser. Please check position
of lock button that it is on “ Unlock” position.
* To prevent unnecessary use from Children. You
can adjust lock button to “ lock” position.
when button lock in on “Lock” position, Push lever
will not able to push
WaterDispenser
Lock
Unlock
Lock Botton
Filling the fountain water tank
Open the water tank’s lid, as shown in the gure.
Fill in pure and clean drinking water. Close the lid.

6Maintenance and cleaning
Never use gasoline, benzene or similar substances for
cleaning purposes.
We recommend that you unplug the appliance before cleaning.
Never use any sharp abrasive instrument, soap, house
hold cleaner, detergent and wax polish for cleaning.
Use lukewarm water to clean thecabinet of your
refrigerator and wipe it dry.
Use a damp cloth wrung out in a solution of one
teaspoon of bicarbonate of soda to one pint of water
to clean the interior and wipe it dry.
Make sure that no water enters thelamp housing and
other electrical items.
If your refrigerator is not going to be used for a long
period of time, unplugthe power cable, remove all food,
clean it and leave the door ajar.
Check door seals regularly to ensure they are clean and
free from food particles.
Never use cleaning agents or water that contain chlorine to
clean the outer surfaces and chromium coatedparts of the
product. Chlorine causes corrosion on such metal surfaces.
Do not use sharp, abrasive tools,soap, household cleaning
agents,detergents, kerosene, fuel oil, varnish etc. to
prevent removal and deformation of the prints on the
plastic part. Use lukewarm water and a soft cloth for
cleaning and then wipe it dry.
Protection of plastic surfaces
Do not put the liquid oils or oil-cooked meals in your
refrigerator in unsealed containers as they damage the
plastic surfaces of your refrigerator. In case of spilling or
smearing oil on the plastic surfaces, clean and rinse the
relevant part of the surface at once with warm water.
To remove door racks, remove all the contents and then
simply push the door rack upwards from the base.
Cleaning the water tank
Detach water tank by holding both sides of the water tank and
remove at 45° angle.
Remove and clean the water tank lid.
Do not ll the water tank with fruit juice, zzy
beverages, alcoholic beverages or any other
liquids incompatible for use in the water
fountain. Using such liquids will cause
malfunction and irreparable damage in the
water fountain. Using the fountain in this way is
not within the scope of warranty. Such certain
chemicals and additives in the beverages /
liquids may cause material damage to the water
tank.
The water tank and water fountain components
cannot be washed with dishwashers.
EN
9

7Troubleshooting
Please review this list before calling the service. It will save your time andmoney. This list includes
frequent complaints that are not arising from defective workmanship or material usage. Some of the
features described here may notexist in your product.
The refrigerator does not operate.
The plug is not inserted into the socket correctly. >>>Insert the plug into the socket securely.
The fuse of the socket which your refrigerator is connected to or the main fusehave blown out.>>Check the fuse.
Condensation on the side wall of the fridge compartment (MULTIZONE, COOL CONTROL and FLEXI ZONE).
Door has been opened frequently. >>>Do not open and close the door of refrigerator frequently.
Ambient is very humid. >>>Do not install your refrigerator into highly humid places.
Food containing liquid is stored in open containers. >>>Do not store food with liquid content in open containers.
Door of the refrigerator is left ajar. >>>Close the door of the refrigerator.
Thermostat is set to a very cold level. >>>Set the thermostat to a suitable level.
Compressor is not running
Protective thermic of the compressor will blow out during sudden power failures or plug-out plug-ins as the refrigerant
pressure in the cooling system of the refrigerator has not been balanced yet. The refrigeratorwill start running
approximately after 6 minutes. Please call the service if the refrigerator does notstartup at the end of this period.
The fridge is in defrost cycle. >>>This is normal for a full-automatically defrostingrefrigerator. Defrosting cycle occurs periodically.
The refrigerator is not plugged into the socket. >>>Make sure that the plug is t into the socket.
Temperature settings are not made correctly. >>>Select the suitable temperature value.
There is a power outage. >>>Refrigerator returns to normal operation when the power restores.
The operation noise increases when the refrigerator is running.
The operating performance of the refrigerator may change due to the changes in the ambient
temperature. It is normal and not a fault.
The refrigerator is running frequently or for a long time.
New product may be wider than the previous one. Larger refrigerators operate for a longer period of time.
The room temperature may be high. >>>It is normal that the product operates for longer periods in hot ambient.
The refrigerator might be plugged in recently or might be loaded with food. >>>When the refrigerator is
plugged in or loaded with food recently, it will take longer for it to attain the set temperature. This is normal.
Large amounts of hot food might be put in the refrigerator recently. >>>Do notput hot food into the refrigerator.
Doors might be opened frequently or left ajar for a long time. >>>The warm air that has entered into the
refrigerator causes the refrigerator to run for longer periods. Do not open the doors frequently.v
Freezer or fridge compartment door might be left ajar. >>>Check if the doors are closed completely.
The refrigerator is adjusted to a very low temperature. >>>Adjust the refrigerator temperature to a warmer
degree and wait until the temperature is achieved.
Door seal of the fridge or freezer may be soiled, worn out, broken or not properly seated. >>>Clean or
replace the seal. Damaged/broken seal causes the refrigerator to run for a longer period of time in order
to maintain the current temperature.
Freezer temperature is very low while the fridge temperature is sufcient.
The freezer temperature is adjusted to a very low value. >>>Adjust the freezer temperature to a warmer degree and check.
Fridge temperature is very low while the freezer temperature is sufcient.
The fridge temperature is adjusted to a very low value. >>>Adjust the fridge temperature to a warmer degree and check.
Food kept in the fridge compartment drawers is frozen.
The fridge temperature is adjusted to a very high value. >>>Adjust the fridge temperature to a lower
value and check.
EN
10

Bad odour inside the refrigerator.
No regular cleaning is performed. >>>Clean the inside of the refrigerator regularly with a sponge,
lukewarm water or carbonate dissolved in water.
Some containers or package materials may cause the smell. >>>Use a different container or different brand
packaging material.
Food is put into the refrigerator in uncovered containers. >>>Keep the food in closed containers.
Microorganisms spreading out from uncovered containers can cause unpleasant odours.
Remove the foods that have expired best before dates and spoiled from the refrigerator.
The door is not closing.
Food packages are preventing the door from closing. >>>Replace the packages that are obstructing the door.
The refrigerator is not completely even on the oor. >>>Adjust the feet tobalance the refrigerator.
The oor is not level or strong. >>>Make sure that the oor is level and capable to carry the refrigerator.
Crispers are stuck.
The food is touching the ceiling of the drawer. >>>Rearrange food in the drawer.
Humidity occurs on the outside of the refrigerator or between the doors.
There might be humidity in the air; this is quite normal in humid weather. When the humidity is less, condensation will disappear.
The fridge temperature is adjusted to a very high value. >>>Fridge compartment temperature setting
has an effect on the temperature of the freezer. Change the temperatures of the fridge or freezer and wait
until the relevant compartments attain a sufcient temperature.
Doors are opened frequently or left ajar for a long time. >>>Do not open the doors frequently.
Door is ajar. >>>Close the door completely.
The refrigerator is plugged in or loaded with food recently. >>>This is normal.When the refrigerator is
plugged in or loaded with food recently, it will take longer for it to attain the set temperature.
Large amounts of hot food might be put in the refrigerator recently. >>>Do notput hot food into the refrigerator.
Vibrations or noise.
The oor is not level or stable. >>> If the refrigerator rocks when moved slowly, balance it by adjusting its
feet. Also make sure that the oor is strong enough to carry the refrigerator, and level.
The items put onto the refrigerator may cause noise. >>>Remove the items on top of the refrigerator.
There are noises coming from the refrigerator like liquid owing, spraying, etc.
Liquid and gas ows occur in accordance with the operating principles of your refrigerator. It is normal and not a fault.
Whistle comes from the refrigerator.
Fans are used in order to cool the refrigerator. It is normal and not a fault.
Condensation on the inner walls of refrigerator.
Hot and humid weather increases icing and condensation. It is normal and not a fault.
Doors are opened frequently or left ajar for a long time. Do not open the doors frequently. Close them if they are open.
Door is ajar. >>>Close the door completely.
Temperature in the fridge or freezer is very high.
EN
11

Refrigerator
User manual
AR
www.beko.com

1 1
12
1
2
3
WEEE
4
4 :RoHS
4
4 (HC
4
4
5 3
5
5
5
5..............................
5..........................
5......................................
6....................................
6 4
7 5
9.................................
7.......................................
9..............................
9...........
9...........................................
9..............................
10...................................
10.............................................
10.............................
10............................
10.......................
11 6
11
12 7
10.............(ί΍έρϟ΍ΏγΣϕέίϷ΍˯ϭοϠϟ
ΔϳϧϘΗϟ
(ί΍έρϟ΍ΏγΣ HarvestFresh
10.......................................................
έη΅ϣϟ΍ΔΣϭϟ

16
17
1
1
2
3
4
*5
6
7
9
*10
11
14
12 13
13
15 15
8
AR
1
1
2
10
1
2
3
6
7
8
9
11
12
14
.13
.15
.16
.17
  
έϑΏ΍Ώ΍ϝΙϝ΍ΝΓ
  
4
5
  
ϝϳϣΟΗϟ΍Ε΍έοΣΗγϣϕϭΩϧλ
10
ϡϭΣϠϟ΍ΔϘρϧϣ

AR
2

6.2 90psi
80
AR
3

R134a
30
5
:RoHS
EU/2011/65 RoHS
(HC
R600a
0.6 33
38 100
.(1
*
AR
4

3
3
4
5
1
2
3
1
2
.1
2
3
5
5
4
AR
5
