User Manual
Cooker Hood

2 / EN Cooker Hood / User Manual
ENGLISH 3-17
DEUTSCH 18-35
MAGYAR 36-50
CONTENTS

Please read this user manual first!
Dear Valued Customer,
Thank you for preferring this Beko appliance. We hope that you get the best results
from your appliance which has been manufactured with high quality and state-of-
the-art technology. For this reason, please read this entire user manual and all other
accompanying documents carefully before using the appliance and keep it as a
reference for future use. If you handover the appliance to someone else, give the user
manual as well. Follow the instructions by paying attention to all the information and
warnings in the user manual.
Remember that this user manual may also apply to other models. Differences between
models are explicitly described in the manual.
Meanings of the Symbols
Following symbols are used in various sections of this user manual:
CImportant information and useful hints about
usage.
AWARNING: Warnings against dangerous situa-
tions concerning the security of life and property.
WARNING: Warning for danger of fire.
BWARNING: Warning for electric shock.
This appliance has been produced in environmentally friendly facilities without harming the nature.

4 / EN Cooker Hood / User Manual
1.1 General Safety
Important Safety Instructions
Read Carefully And Keep For
Future Reference This section
contains safety instructions that
will help protect from risk of fire,
electric shock, exposure to leak
microwave energy, personal inju-
ry or property damage. Failure to
follow these instructions shall void
any warranty.
•Beko products comply with the
applicable safety standards;
therefore, in case of any damage
on the appliance or power cable,
it should be repaired or replaced
by the dealer, service center or a
specialist and authorized service
alike to avoid any danger. Faulty
or unqualified repair work may
be dangerous and cause risk to
the user.
•This appliance is intended to be
used in household and similar
applications such as:
– Staff kitchen areas in shops,
offices and other working en-
vironments;
– Farm houses
– By clients in hotels, and other
residential type environments;
– Bed and Breakfast type envi-
ronments.
•Operate the appliance for its
intended purpose only as de-
scribed in this manual.
•The manufacturer cannot be
held liable for damages result-
ing from improper installation or
misuse of the product.
•This appliance can be used by
children aged from 8 years and
above and persons with reduced
physical, sensory or mental ca-
pabilities or lack of experience
and knowledge if they have been
given supervision or instruction
concerning use of the appliance
in a safe way and understand
the hazards involved.
•Children shall not be allowed
play with the appliance. Clean-
ing and user maintenance shall
not be made by children without
supervision.
1
Important safety and environmental instructions

Cooker Hood / User Manual 5 / EN
•The minimum distance between
the supporting surface for the
cooking vessels on the hob and
the lowest part of your product
must be at least 65 cm.
•If the instructions for installation
for the gas hob specify a greater
distance, this has to be taken
into account.
•Make sure that your mains
power supply complies with the
information supplied on the rat-
ing plate of the appliance.
•Never use the appliance if the
power cable or the appliance it-
self is damaged.
•Prevent damage to the power
cable by not squeezing, bending,
or rubbing it on sharp edges.
Keep the power cable away from
hot surfaces and naked flame.
•Use the appliance with a
grounded outlet only.
WARNING: Do not connect the
appliance to the mains until the
installation is fully complete.
•Place the appliance in a way so
that the plug is always accessi-
ble.
•Do not touch the lamps if they
have operated for a long time.
They can burn your hands since
they will be hot.
•Follow the regulations set out by
competent authorities on dis-
charge of the exhaust air (this
warning is not applicable for use
without flue).
•Operate your appliance after
putting a pot, pan etc. on the
hob. Otherwise, high heat may
cause deformation in some parts
of your product.
•Turn off the hob before taking
the pot, pan etc. from it.
•Do not leave hot oil on the hob.
Pans with hot oil may cause self
combustion.
•Pay attention to your curtains
and covers since oil may catch
fire while cooking food such as
fries.
•Grease filter must be cleaned
at least monthly. Carbon filter
must be replaced at least every
3 months.
1
Important safety and environmental instructions

6 / EN Cooker Hood / User Manual
•Product shall be cleaned ac-
cordance with user manual. If
cleaning was not carried out in
accordance with user manual,
there may be fire risk.
•Do not use non-fire-resistant
filtering materials instead of the
current filter.
•Only use the original parts or
parts recommended by the
manufacturer.
•Do not operate the product with-
out the filter and do not remove
the filters while the product is
running.
•In the event of be started any
flame, de-energize your product
and cooking appliances.
•In the event of be started any
flame, cover the flame and never
use water to extinguish.
•Unplug the appliance before
each cleaning and when the ap-
pliance is not in use.
•The negative pressure in the en-
vironment should not exceed 4
Pa (4x10 bar) while the hood for
electric hob and appliances run-
ning on another type of energy but
electricity operate simultaneously.
•In the environment where the
appliance is being used, the ex-
haust of devices running on fuel
oil or gas, such as room heater
must be absolutely isolated or
device must be hermetical type.
•When connecting the flue, use
pipes with a diameter of 120 or
150 mm. Pipe connection must
be as short as possible and have
as few elbows as possible.
Danger of choking! Keep all the
packaging materials away from
children.
CAUTION: Accessible parts may
become hot when used with
cooking appliances.
•The product outlet must not be
connected to air channels that
include other smoke.
•The ventilation in the room may
be insufficient when the hood for
electric hob is used simultane-
ously with the devices operating
on gas or other fuels (this may
not apply to appliances that only
discharge the air back into the
room).
1
Important safety and environmental instructions

Cooker Hood / User Manual 7 / EN
1
Important safety and environmental instructions
•Objects placed on the product
may fall. Do not place any ob-
jects on the product.
•Do not flambe under the your
product.
WARNING: Before installing the
Hood, remove the protective films.
•Never leave high naked flames
under the hood when it is in op-
eration
•Deep fat fryers must be contin-
uously monitored during use:
overheated oil can burst into
flames.
1.2 Compliance with the WEEE
Directive and Disposing of the Waste
Product:
This product complies with EU WEEE Directive
(2012/19/EU). This product bears a classification
symbol for waste electrical and electronic equip-
ment (WEEE).
This symbol indicates that this product
shall not be disposed with other
household wastes at the end of its ser-
vice life. Used device must be returned
to offical collection point for recycling
of electrical and electronic devices. To find these
collection systems please contact to your local au-
thorities or retailer where the product was pu-
chased. Each household performs important role
in recovering and recycling of old appliance.
Appropriate disposal of used appliance helps pre-
vent potential negative consequences for the envi-
ronment and human health.
1.3 Compliance with RoHS Directive
The product you have purchased complies with EU
RoHS Directive (2011/65/EU). It does not contain
harmful and prohibited materials specified in the
Directive.
1.4 Package Information
Packaging materials of the product are
manufactured from recyclable materials
in accordance with our National
Environment Regulations. Do not dis-
pose of the packaging materials together with the
domestic or other wastes. Take them to the pack-
aging material collection points designated by the
local authorities.

8 / EN Cooker Hood / User Manual
2
General appearance
2.1 Overview
400
400
20
350
262
250
2080
393
896
365
Min:750 Max:1130
3
2
1
4
5
6
1. Inner chimney
2. Outer chimney
3. Body
4. Grease filter (Behind Glass Cover)
5. Control panel
6. Lighting
2.2 Műszaki adatok
Model HCA92640BH HCA92640WH
Supply voltage & frequency 220-240V ~ 50 Hz
Lamp power 2x3 W
Motor power 210 W
Flow rate – 3. Level 631 m³/h
Insulation class of motor Class F
Insulation class Class I
(Figure 1)

Cooker Hood / User Manual 9 / EN
3
Operation of the appliance
3.1 Controlling the appliance
KEY FUNCTION
A : Light On / Off You may illuminate the cooking
area by pressing this button. Re-
press the button to turn off the
lamp.
B : 1. Stage
Button
Operates the appliance on 1st
speed. When you press this
button again to turn off the ap-
pliance, the screen speed stage
turns off.
C : 2. Stage
Button
Operates the appliance on 2nd
speed. When you press this but-
ton again to turn off the appli-
ance, the screen speed stage
turns off.
D : 3. Stage
Button
Operates the appliance on 3rd
speed. When you press this
button again to turn off the ap-
pliance, the screen speed stage
turns off.
3.2 Efficient use in terms of energy
saving
•When using your appliance, adjust the speed
settings according to vapour and odour intensity,
in order to save energy.
•Use low speeds (1-2) under normal conditions,
and high speed (3) for intense odour and vapour.
•The lamps on the hood are placed for illuminat-
ing the cooking area.
•Using them for environmental lighting shall
cause unnecessary energy expenditure and in-
sufficient lighting.
3.3 Operation of the hood
•Your appliance contains a motor that has various
speeds.
•For better performance, we recommend using
low speeds under normal conditions and high
speeds in cases of strong odours and intense
vapour.
•You can start your appliance by pressing on the
desired speed setting button. (B,C,D)
•You can illuminate the cooking area by pressing
the lamp. (A)
3.4 Automatic stop
Your appliance has Automatic Stop feature, ena-
bling it to ventilate for a bit more and remove the
unwanted odours and vapour inside the environ-
ment and turn off automatically after the cooking
is done. To enable Automatic Stop feature, press
the any speed stage button (B, C, D) on the control
panel for longer than 2 seconds; the 15-minute
timer function shall be activated. When the au-
tomatic stop feature is active, pressing the same
speed button shall disable the automatic stop
function and the appliance's motor shall stop. This
feature is disables when you switch between dif-
ferent speed stages.
If you want the appliance to stop automatically, you
need to enable the automatic stop feature again.
3.5 Replacement of lamp
MAX 3 W
Make the electrical connections of the appliance.
Your appliance uses 3W spot LED lamp. For re-
placing the lamps, push downwards on the holder

10 / EN Cooker Hood / User Manual
3 Operation of the appliance
from its behind, turn it counter-clockwise, and take
it out downwards. Apply the above operation in re-
verse to install new lamps.
Bulb
Bulb power 3 W
Holder / Socket GZ 10
Bulb voltage 220 - 240 V
Size 53x50 mm
ILCOS Code DR/F3-220-240-GZ10-50-53
Luminous flux 260 lm
Correlated colour
temperature
3000 K
This product contains a light source of energy ef-
ficiency class “F”.
3.6 Operation with flue connection
•Vapour is extracted through the
flue duct, which is fastened to
the connection head on the
hood.
•The diameter of the flue duct must be the same
as the connection ring. In horizontal settings, the
pipe has to have a slight upward slope (around
10º) so that the air can exit the room easily.
3.7 Operation without flue
connection
•Air is filtered through the carbon
filter and recirculated in the
room. Carbon filter is used
when it is impossible to use a
flue in the house.
•In flueless use, remove the flaps inside the flue
adapter.
•Remove the grease filter. To install the carbon
filter, fit the filter to the tabs by centring it on
the plastic piece on both sides of the fan body.
Tighten it by turning right or left.
•Replace grease filter.

Cooker Hood / User Manual 11 / EN
4 Cleaning and maintenance
CBefore cleaning and maintenance,
unplug the product or turn off the
switch.
4.1 Cleaning of the grease filter
Grease filter retains the oil particles in the air.
Grease filters may change colour after repeated
cleaning. This is normal and does not require re-
placement of filters.
(Figure 2)
•Push the grease filter lock forward.
•Then pull it slightly down and pull it out (Figure
2). Otherwise, you can bend the filter. Wash and
rinse grease filters with liquid detergent and
replace grease filters to their sockets by by car-
rying out the steps specified above in reverse
order.This filter retains the oil particles in the air.
CYou may wash your grease filters in
the dishwasher.
ACAUTION: In case of normal use,
clean your filter once in a month.
4.2 Replacement of carbon filters
Odour removing filters contain charcoal (Active
carbon). Grease filters must be installed in the
product, regardless of whether or not carbon fil-
ters are used.
(Figure 3)
•Remove the grease filter.
•To remove the carbon filter, remove the car-
bon filter from its housing by rotating it coun-
ter-clockwise from the tab (Figure 3).
•Install the new carbon filter.
•Install the grease filter.
A
CAUTION
•Carbon filter shall never be
washed.
•Replace carbon filters once every
3 months.
•You can obtain the carbon filter
from the authorized services.

12 / EN Cooker Hood / User Manual
AWARNING: Before starting the in-
stallation, read the safety informa-
tion on User Manual.
BWARNING: Failure to install with
screws and stabilizers in accordance
with these instructions may result in
electric shock.
For the installation of the hood, please contact the
nearest Authorized Service.
It is the customer's responsibility to prepare the
location and electrical installation of the hood.
5.1 Position of the appliance
(Figure 4)
•Distance between the cooker and the cooker
hood must be considered prior to assembly. This
distance should be 65 cm (Figure 4).
•Distance must be measured from the surface of
grate for gas cookers,
•From surface of glass for electric cookers.
5.2 Installation accessories
11 12 13 14 1615
1. Product
2. Outer chimney
3. Inner chimney
4. Chimney connection plate
5. Ø150/120mm Flue Adapter
6. User Manual
7. Assembly Pattern
8. 4 x Ø8mm Plastic Dowel
9. 6 x Ø6mm Plastic Dowel
10.4 x 4.8 x 50 Wall Mount Screw
11.6 x 3.9 x 22 Flue Connection Plate Screw
12.4 x 3.5 x 9.5 Flue Connection Screw
13.Ø120mm Flue Adapter
14.Ø150mm Plastic Flue Adapter (Option)
15.Chimney Clamp
16.Air Baffle
The information required to make the location suit-
able for the installation of the hood is given below.
5.3 Wall mounting
•Wall must be flat, straight and have the suffi-
cient bearing capacity.
5 Installation of appliance

Cooker Hood / User Manual 13 / EN
•Depth of drilling holes must comply with the
length of bolts.
•The bolts and dowels provided are suitable for
brick walls. For other construction material (e.g.
drywall, plate, porous concrete), suitable fixing
dowels and nuts shall be used.
(Figure 5)
ACAUTION: Before drilling, ensure
that there are no power, gas or wa-
ter pipes in the close proximity of the
drilling locations.
Draw a mid location line from the ceiling perpen-
dicular to the lower edge of the hood.
Paste the installing template provided within the
accessories on the surface where the hood is to
be mounted. In doing this operation, observe the
mounting height of the hood (Figure 4).
There is a tab in the middle of the flue connection
plate. Place the middle point of this tab on the line
that is drawn perpendicular to the wall. In doing
this operation, adjust the hood according to the
maximum height (Figure 1). Mark the holes where
the flue connection plate will be mounted with the
help of a pen (Figure 5/a).
Drill the marked points with Ø6mm drill and insert
2 plastic dowels in the drilled holes (Figure 5/a).
Fix the flue connection plate to the wall with
3,9x22 screws (Figure 5/a).
To assemble the hood body, you can use the
Ø8mm drill bit to drill points A, B, C, D on the as-
sembly template, and insert 4.8x50mm plastic
dowels at these points. (Figure 5/b).
2 piece 4.8x50 suspension screw with a clearance
of 5 mm between the screw head and the wall
(Figure 5/b).
(Figure 6)
1. Hanger plate
2. Hanging plate connection screw
In order to install your hood to the wall, loosen the
screws on the hanger plates mounted on the mo-
tor cabin and pull them up, and then fasten again
(Figure 6/A).
Turn on the suction glass of the hood and remove
the grease filter (Figure 2).
(Figure 7)
If the air outlet is to be connected to the air dis-
charge duct smaller than 150mm, install the 150 /
120mm plastic flue adapter (Figure 7).
5 Installation of appliance

14 / EN Cooker Hood / User Manual
5 Installation of appliance
If you are going to use the Ø 120/150 mm plastic
flue adapter, connect one end of the pipe to this
adapter, if you are not going to use it, to the direct
output on the product. Connect the other end of
the pipe to your flue. Check that these two con-
nections are tight enough so they will not come out
when the appliance runs on full power. Ensure that
the flaps inside the flue work when tightened with
clamp. Connect the flue connection duct outside
the adapter (Figure 10/a). If the connection duct
is fitted inside the adapter, suction of air shall not
occur as the flue flap that prevents the return of air
will remain closed (Figure 10 / b).The length of the
pipe connection as well as the number of elbows
must be as minimum as possible.
A : Flue exit pipe
B : Flue clamps
C: Plastic flue
The valves are closed then the appliance is not
operating and prevent possible outside odour and
dust from entering inside.
(a) (b)
Suitable Not Suitable
(Figure 10)
(Figure 8)
Hold the cooker hood by its body and place it on
the mounting screws on the wall and tighten the
screws (Figure 8).
Secure the cooker hood with two 4.8x50 screws to
the wall through the mounting hole on the interior
of the appliance (Figure 8).
5.4 Connecting to flue
(Figure 9)
1. Flap pin socket
2. Flap pin
Insert the plastic pin (Figure 9/area no. 2) on the
pin socket on the motor exhaust (Figure 9/area
no.1). Then bend the flap lightly to insert the other
pin on the flap and insert the other pin to its socket
(Figure 9).

Cooker Hood / User Manual 15 / EN
5 Installation of appliance
5.5 Installation of the hood to the
flue
make the electrical connection of your hood be-
fore starting the installation of the flue. Slip the
flue plates around the body. Screw the flue to the
flue fastening plates available on the motor cabin.
(Figure 11).
Install the flue to the flue fastening plate that is
secured to the wall from its upper outer edges
(Figure 11).
(Figure 11)
5.6 Installation of air baffle
While using with the carbon filter, air baffle is pro-
vided with your appliance with the aim of re-re-
leasing the air which is cleaned with carbon filter
from the perforated located on the flue. Assemble
the air baffle as below.
(Figure 12)
There is a tab in the middle of the flue connection
plate. Place the middle point of this tab on the line
that is drawn perpendicular to the wall. Align hori-
zontally and mark the holes where the connection
plate will be mounted via a pen (Figure 12/A, B).
Drill the marked points with Ø6mm drill and in-
sert two Ø6mm plastic dowels in the drilled holes
(Figure 12/A, B).
Fix the flue connection plate to the wall with
3.9x22 screws (Figure 12/A, B).
For air baffle assembly, install point C, D, E, F with
Ø6mm drill and Ø6mm plastic dowels (Figure 12).
Assemble cooker hood’s body (Figure 8).
(Figure 13)
1. Flap pin socket
2. Flap pin

16 / EN Cooker Hood / User Manual
Attach the flue flaps to the plastic flue adapter in
the package content as follows.
Insert the plastic pin (Figure 13/area no. 2) on the
pin socket on the motor exhaust (Figure 13/area
no.1). Then bend the flap lightly to insert the other
pin on the flap and insert the other pin to its socket
(Figure 13).
1
2
(Figure 14)
1. Air Baffle
2. Plastic Chimney
Attach the plastic Chimney adapter, which is in-
cluded in the package, in the direction of the air
baffle. Lock the Chimney adapter by turning it in
the direction of the arrow (Figure 14).
(Figure 15)
Assemble the air baffle group with 3.9 x 22
screws from point C, D, E, F that you have already
prepared (Figure 15).
5 Installation of appliance
(Figure 16)
1. Aluminium Air Outlet Pipe
Make the air outlet pipe assembly (Figure 16).
CSince twists and bends in the alumin-
ium pipe will lead to reduction in the
air suction power, avoid using twists
and bends as much as possible.
Install the Chimney plates of the hood (Figure 16)

Cooker Hood / User Manual 17 / EN
6 Troubleshooting
Troubleshooting Root Cause Help
Appliance is not working. Check your fuses. Fuse may be blown, inspect and re-
store it.
Appliance is not working. Check the electrical connection. Mains voltage shall be between 220
and 240 V.
Appliance is not working. Check the electrical connection. Check if other appliance in your
kitchen operate.
Illumination light does not operate. Check the electrical connection. Mains voltage shall be between 220
and 240 V.
Illumination light does not operate. Inspect the lamp switch. Lamp switch shall be at "on" position.
Illumination light does not operate. Inspect the lamps. The lamps of the appliance shall il-
luminate.
Air inlet of the appliance is inad-
equate.
Inspect the grease filter. Under normal operating conditions,
grease filter shall be cleaned at least
once in a month.
Air inlet of the appliance is inad-
equate.
Check the air discharge flue. The air discharge flue shall be at “on”
position.
Air inlet of the appliance is inad-
equate.
Inspect the carbon filter. The filters of the appliances with car-
bon filters shall be replaced once in
every 3 months under normal condi-
tions.

Bitte lesen Sie zunächst diese Anleitung!
Sehr geehrte Kundin, sehr geehrter Kunde,
Vielen Dank,dass Sie sich für dieses Gerät der Marke Beko entschieden haben.Wir sind
überzeugt, dass Sie mit diesem Gerät, das mit den höchsten Qualitätsanforderungen
und modernster Technologie hergestellt wurde, beste Ergebnisse erzielen werden.
Bitte lesen Sie die gesamte Bedienungsanleitung und alle anderen Begleitdokumente
aufmerksam, bevor Sie das Gerät verwenden; bewahren Sie sie zum künftigen
Nachschlagen sicher auf. Wenn Sie das Gerät an jemanden weitergeben, händigen
Sie ihm bitte auch diese Anleitung aus. Befolgen Sie die Anweisungen, indem Sie alle
Informationen und Warnhinweise in der Bedienungsanleitung beachten.
Bitte denken Sie daran, dass diese Bedienungsanleitung eventuell für mehrere Modelle
geschrieben wurde. Unterschiede zwischen den Modellen werden in der Anleitung klar
und deutlich beschrieben.
Bedeutung der Symbole
Folgende Symbole werden in den verschiedenen Abschnitten dieser Anleitung
verwendet:
CWichtige Informationen und nützliche Hinweise zur
Verwendung.
AWARNUNG: Warnhinweise zu gefährlichen
Situationen im Hinblick auf die Sicherheit von Leib,
Leben und Eigentum.
Warnung vor Brandgefahr.
BWarnung vor Stromschlägen.
Dieses Gerät wurde in umweltfreundlichen, modernen Einrichtungen ohne schädliche Auswirkungen
auf die Natur hergestellt.

Dunstabzugshaube / Benutzerhandbuch 19 / DE
1.1 Allgemeine Sicherheit
Wichtige Sicherheitsanweisungen
sorgfältig lesen und zum künfti-
gen Nachschlagen aufbewahren
Dieser Abschnitt enthält
Sicherheitsanweisungen, die
beim Schutz vor Personen-
und Sachschäden, Bränden,
Stromschlägen und dem
Austreten von Mikrowellenenergie
helfen. Bei Nichtbeachtung die-
ser Anweisungen erlischt die
Gewährleistung.
•Beko-Produkte stimmen mit
geltenden Sicherheitsstandards
überein; daher sollten Gerät oder
Netzkabel zur Vermeidung von
Gefahren im Falle von Schäden
durch den Händler, ein Kunden-
center oder einen spezialisierten,
autorisierten Serviceanbieter
repariert oder ersetzt werden.
Fehlerhafte oder unqualifizierte
Reparaturen können Gefahren
und Risiken für den Benutzer
verursachen.
•Dieses Gerät ist für den Einsatz
in Haushalten und ähnlichen Be-
reichen vorgesehen, wie:
– In Betriebsküchen, Läden,
Büros und anderen Ar-
beitsumgebungen;
– Bauernhöfen;
– Von Gästen in Hotels und an-
deren Wohnumgebungen;
– Pensionen und Jugendher-
bergen.
•Das Gerät darf nur für seinen in
dieser Anleitung beschriebenen
vorgesehenen Zweck verwendet
werden.
•Der Hersteller haftet nicht für
Schäden, die auf unsachgemäße
Installation oder fehlerhaften Ge-
brauch zurückzuführen sind.
•Das Gerät darf nur dann von Kin-
dern ab 8 Jahren und Personen
mit körperlichen oder geistigen
Einschränkungen genutzt wer-
den, wenn diese beaufsichtigt
werden oder gründlich über den
richtigen und sicheren Umgang
mit dem Gerät aufgeklärt wur-
den und sich sämtlicher mögli-
cher Gefahren bewusst sind.
1
Wichtige Sicherheits- und Umweltanweisungen

20 / DE Dunstabzugshaube / Benutzerhandbuch
•Kinder dürfen nicht mit dem
Gerät spielen. Reinigungs- und
Wartungsarbeiten dürfen nicht
unbeaufsichtigt von Kindern
ausgeführt werden.
•Der Abstand zwischen der Stütz-
fläche für Kochgeschirr auf dem
Kochfeld und dem niedrigsten
Teil der Abzugshaube muss min-
destens 65 cm betragen.
•Falls die Anweisungen zur Ins-
tallation eines Gasherdes einen
größeren Abstand angeben, ist
dieser einzuhalten.
•Stellen Sie sicher, dass Ihre
Stromversorgung mit den Anga-
ben am Typenschild des Gerätes
übereinstimmt.
•Benutzen Sie das Gerät niemals,
wenn das Netzkabel oder das
Gerät selbst beschädigt ist.
•Vermeiden Sie Schäden am
Netzkabel, indem Sie es nicht
quetschen, knicken oder über
scharfe Kanten ziehen. Hal-
ten Sie das Netzkabel von hei-
ßen Oberflächen und offener
Flamme fern.
•Verwenden Sie das Gerät nur
mit einer geerdeten Steckdose.
WARNUNG: Schließen Sie das
Gerät erst nach vollständig ab-
geschlossener Installation an das
Stromnetz an.
•Stellen Sie das Gerät so auf,
dass der Netzstecker immer zu-
gänglich ist.
•Berühren Sie die Lampen nicht,
falls sie lange Zeit in Betrieb
waren. Sie könnten sich die Fin-
ger verbrennen, da die Lampen
heiß werden.
•Befolgen Sie die von zuständigen
Behörden festgelegten Richtli-
nien zum Abführen von Abluft
(diese Warnung ist bei Einsatz
ohne Abzug nicht zutreffend).
•Nehmen Sie Ihr Gerät erst in Be-
trieb, nachdem Sie ein Kochge-
schirr auf das Kochfeld gestellt
haben. Andernfalls könnte hohe
Hitze zur Verformung von Teilen
Ihres Geräts führen.
•Schalten Sie die Kochfelder ab,
bevor Sie das Kochgeschirr her-
unternehmen.
•Lassen Sie kein heißes Öl auf
das Kochfeld gelangen. Kochge-
schirr mit heißem Öl kann sich
selbst entzünden.
1
Wichtige Sicherheits- und Umweltanweisungen
Other manuals for HCA92640BH
2
This manual suits for next models
1
Table of contents
Languages:
Other Beko Ventilation Hood manuals

Beko
Beko CTB 9407 User manual

Beko
Beko HCA62320B User manual

Beko
Beko HNU 61425 B User manual

Beko
Beko HCA62640BE User manual

Beko
Beko CTB 6407 X-W User manual

Beko
Beko BHCA66641BFBHS User manual

Beko
Beko HNU 61422 B User manual

Beko
Beko CFB 6432 WH User manual

Beko
Beko HNU51630SH User manual

Beko
Beko CFB 5432 W User manual

Beko
Beko BHCA92442BBH User manual

Beko
Beko CFB 9433 XH User manual

Beko
Beko CWB 6441 User manual

Beko
Beko HNE51210S User manual

Beko
Beko HCA92640BH User manual

Beko
Beko HCA92640BHE User manual

Beko
Beko BHCA96641BFBHS User manual

Beko
Beko HBG70 User manual

Beko
Beko HBG70X User manual

Beko
Beko CWB 6441 AN User manual
