Beko WDA 961431 User manual

2820524454_EN/29-11-17.(12:03)Document Number=
Washer-Dryer
User Manual
WDA 961431
EN

This product was manufactured using the latest technology in environmentally friendly conditions.
Please read this manual first!
Dear Customer,
Thank you for preferring a Beko product. We hope that you get the best results from your product which
has been manufactured with high quality and state-of-the-art technology.Therefore, please read this entire
user manual and all other accompanying documents carefully before using the product and keep it as a
reference for future use. If you handover the product to someone else, give the user manual as well. Follow
all warnings and information in the user manual.
Please note that this Operating Manual may be applicable for several other models. Differences between
models will be identified in the manual.
Explanation of symbols
Throughout this Operation Manual the following symbols are used:
B
DANGER
• Warning for electric shock.
DANGER
• Product is heavy
A
CAUTION
• Warning for hazardous situations with regard to life and property.
A
CAUTION
➢Precautions to be taken.
C
NOTE
• Important information or useful hints about usage.
• Please read the user manual.
• Packaging materials of the product are manufactured from recyclable materials in
accordance with our National Environment Regulations.
• Do not dispose of the packaging materials together with the domestic or other wastes.
Take them to the packaging material collection points designated by the local authorities.
• Allergy UK is the operational name of The British Allergy Foundation. The Seal of Approval
endorsement was created in order to provide people seeking advice, with the guidance
that a product specifically restricts / reduces / removes allergens from the environment
of the allergy sufferer or has significantly reduced allergen content. It is aimed to assure
people that products had been scientifically tested or reviewed with measurable results.

User‘s Manual 3/ EN
TABLE OF CONTENTS
1 Important instructions for safety and environment 6
1.1 General safety ........................................................................................................................... 6
1.1.1 Electrical safety................................................................................................................................ 6
1.1.2 Product safety.................................................................................................................................. 7
1.1.3 Warnings for dryer............................................................................................................................ 8
1.2 Intended use ............................................................................................................................. 9
1.3 Children's safety........................................................................................................................ 9
1.4 Compliance with WEEE Directive ................................................................................................ 10
1.5 Package information.................................................................................................................. 10
2 Your washer-dryer 11
2.1 Overview...................................................................................................................................11
2.2 Package Contents ..................................................................................................................... 12
2.3 Technical specifications.............................................................................................................. 13
3 Installation 14
3.1 Appropriate installation location.................................................................................................. 14
3.2 Removing packaging reinforcement............................................................................................ 15
3.3 Removing the transportation locks.............................................................................................. 15
3.4 Flush usage with the bench ....................................................................................................... 16
3.5 Connecting water supply............................................................................................................ 17
3.6 Connecting to the drain.............................................................................................................. 18
3.7 Adjusting the feet....................................................................................................................... 19
3.8 Electrical connection.................................................................................................................. 20
3.9 Transportation of the product...................................................................................................... 20
4 Preparation 21
4.1 Sorting the laundry .................................................................................................................... 21
4.2 Preparing laundry for washing.................................................................................................... 22
4.3 Things to be done for energy saving ........................................................................................... 22
4.4 First use.................................................................................................................................... 23
4.5 Correct load capacity ................................................................................................................. 23
4.6 Loading the laundry................................................................................................................... 24
4.7 Using detergent and softener ..................................................................................................... 24
4.7.1 Detergent drawer............................................................................................................................. 24
4.7.2 Detergent, softener and other cleaning agents................................................................................... 25
4.7.3 Choosing the detergent type............................................................................................................. 25
4.7.4 Adjusting detergent amount.............................................................................................................. 25
4.7.5 Using softeners................................................................................................................................ 25
4.7.6 Using liquid detergents..................................................................................................................... 25
4.7.6.1 If the product has a liquid detergent cup............................................................................... 25
4.7.6.2 If the product does not have a liquid detergent cup ............................................................... 26

4/ EN Washer-Dryer
TABLE OF CONTENTS
4.7.7 Using gel and tablet detergent .......................................................................................................... 26
4.7.8 Using starch..................................................................................................................................... 26
4.7.9 Using bleaches ................................................................................................................................ 26
4.7.10 Using limescale remover ................................................................................................................ 26
4.8 Tips for efficient washing ........................................................................................................... 27
4.9 Tips for efficient drying............................................................................................................... 28
5 Operating the product 29
5.1 Control panel............................................................................................................................. 29
5.2 Display symbols......................................................................................................................... 30
5.3 Preparing the machine............................................................................................................... 30
5.4 Wash Programme selection ....................................................................................................... 30
5.5 Washing Programmes ............................................................................................................... 31
•Koch-/Buntwäsche (Cottons) ............................................................................................................... 31
•Pflegeleicht (Synthetics) ...................................................................................................................... 32
•Wolle (Woollens) ................................................................................................................................. 32
•Buntwäsche Eco (Cotton Economic) ..................................................................................................... 33
•Feinwäsche (Delicate) ......................................................................................................................... 33
•Handwäsche (Hand wash) ................................................................................................................... 33
•Express.............................................................................................................................................. 34
•Super Express 14 ............................................................................................................................... 34
•Hemden (Shirts).................................................................................................................................. 35
•Spülen(Rinse) ..................................................................................................................................... 35
•Schleudern+Abpumpen (Spin + Drain) ................................................................................................ 35
5.6 Temperature selection................................................................................................................ 36
5.7 Selecting the spin speed............................................................................................................ 37
5.7.1 If you want to spin your laundry after the Rinse Hold function: ............................................................ 37
5.8 Drying Programmes................................................................................................................... 38
•Pflegeleicht Trocknen (Synthetics Drying).............................................................................................. 38
•Koch-/Buntwäsche Trocknen (Cottons Drying)....................................................................................... 38
5.9 Washing and Drying Programmes .............................................................................................. 38
•6 kg Wash+Dry ................................................................................................................................. 38
•Wash+Wear ....................................................................................................................................... 39
•BabyProtect+ Wash & Dry .................................................................................................................. 39
5.10 Programme and consumption table ......................................................................................... 40
5.11 Auxiliary function selection....................................................................................................... 42
•Vorwäsche (Prewash).......................................................................................................................... 42
•Bügelleicht (Anti-Creasing) .................................................................................................................. 43
•Drying................................................................................................................................................ 43
5.12 Drying Steps ........................................................................................................................... 43
5.12.1 Iron Dry .................................................................................................................................... 43

User‘s Manual 5/ EN
TABLE OF CONTENTS
5.12.2 Wardrobe dry ............................................................................................................................. 43
5.12.3 Extra wardrobe dry .................................................................................................................... 43
5.12.4 Delicate drying .......................................................................................................................... 43
5.12.5 Time-based drying ......................................................................................................................... 44
5.13 Time display ............................................................................................................................ 44
5.14 End Time................................................................................................................................. 45
5.15 Starting the Programme........................................................................................................... 46
5.16 Loading door lock.................................................................................................................... 46
5.17 Changing the selections after Programme has started............................................................... 46
5.17.1 Adding laundry after the Programme has started:............................................................................ 46
5.17.2 Switching the machine to pause mode:........................................................................................... 46
5.17.3 Changing the Programme selection after Programme has started: ................................................... 47
5.17.4 Changing the auxiliary function, speed and temperature settings...................................................... 47
5.18 Child Lock............................................................................................................................... 47
5.18.1 To activate the Child Lock: .............................................................................................................. 47
5.18.2 To deactivate the Child Lock:........................................................................................................... 48
5.19 Cancelling the Programme....................................................................................................... 48
5.20 End of Programme .................................................................................................................. 48
5. 21 Entering the Settings menu..................................................................................................... 48
5.21.1 Changing the language selection .................................................................................................... 49
5.21.2 Changing the screen brightness setting........................................................................................... 49
5.21.3 Turning on and off the Audio Warning.............................................................................................. 50
5.22 Memory (Favourite) Programme setting.................................................................................. 50
5.22.1 To store a new favourite Programme:.............................................................................................. 50
5.22.2 To select a favourite Programme:.................................................................................................... 50
5.23 Your machine is equipped with a "Standby Mode"..................................................................... 51
6 Maintenance and cleaning 52
6.1 Cleaning the detergent drawer ................................................................................................... 52
6.2 Cleaning the loading door and the drum ..................................................................................... 53
6.3 Cleaning the air suction filter...................................................................................................... 54
6.4 Cleaning the body and control panel........................................................................................... 55
6.5 Cleaning the water intake filters ................................................................................................. 55
6.6 Draining remaining water and cleaning the pump filter................................................................ 55
6.6.1 In order to clean the dirty filter and discharge the water:.................................................................... 56
6.6.2 To discharge the water: .................................................................................................................... 56
7 Troubleshooting 57

6/ EN Washer-Dryer
1 Important instructions for safety and environment
This section contains safety instructions that will help protect from risk of personal injury or property
damage. Failure to follow these instructions shall void any warranty.
1.1 General safety
A
CAUTION
• This product can be used by children at and above 8 years old and by
persons whose physical, sensory or mental capabilities were not fully
developed or who lack experience and knowledge provided that they
are supervised or trained on the safe usage of the product and the risks
it brings out. Children must not play with the product. Cleaning and
maintenance works which can be done by users should not be performed
by children unless they are supervised by someone.
A
CAUTION
➢Never place the product on a carpet-covered floor. Otherwise, lack of airflow beneath
the machine will cause electrical parts to overheat. This will cause problems with
your product.
C
NOTE
• Always have the repairing procedures carried out by the Authorised Service Agent.
Manufacturer shall not be held liable for damages that may arise from procedures
carried out by unauthorised persons.
1.1.1 Electrical safety
B
DANGER
• If the product has a failure, it should not be operated unless it is repaired
by the Authorised Service Agent. There is the risk of electric shock!
• Never wash the product by spreading or pouring water onto it! There is
the risk of electric shock!
A
CAUTION
• If the power cable is damaged, it must be replaced by the manufacturer,
after-sales service or a similarly qualified person (preferably an electrician)
or someone designated by the importer in order to avoid possible risks.
A
CAUTION
➢Unplug the product when not in use.
➢Never touch the plug with wet hands! Never unplug by pulling on the cable, always
pull out by grabbing the plug.
➢Unplug the product during installation, maintenance, cleaning and repairing
procedures.
➢Do not make connections via extension cables or multi-plugs.
C
NOTE
• This product is designed to resume operating in the event of powering on after a power
interruption. If you wish to cancel the programme, see "Cancelling the programme"
section.

User‘s Manual 7/ EN
Important instructions for safety and environment
1.1.2 Product safety
A
DANGER
• Never open the loading door or remove the filter while there is still
water in the drum. Otherwise, risk of flooding and scalds from hot
water will occur.
A
CAUTION
• The water supply and draining hoses must be securely fastened and
remain undamaged. Otherwise, there is the risk of water leakage.
C
NOTE
• Do not force open the locked loading door. The loading door will be ready to open just a
few minutes after the washing cycle is completed. The loading door will not open if the
machine is not cooled down enough after the programme. You can ensure a faster cool
down of the machine by running a 10-minute drying programme, or wait until it cools
down by itself. Do not force the loading door open. The door and the lock mechanism
can get damaged.
• There should not be any lockable, sliding or hinged door that may prevent the loading
door from fully opening in the installation place of this product.
• Follow the instructions on the textile tags and on the detergent package.
• Only detergents, softeners and supplements suitable for washing machines should be
used.
• Do not install or leave this product in places where it will be exposed to weather
conditions.
• Controls should not be tampered with.
DANGER
• Oil-affected items can ignite spontaneously, especially when exposed
to heat sources such as in a tumble dryer. The items become warm,
causing an oxidation reaction in the oil. Oxidation creates heat. If the
heat cannot escape, the items can become hot enough to catch fire.
Piling, stacking or storing oil-affected items can prevent heat from
escaping and so create a fire hazard.
• If it is unavoidable that fabrics that contain vegetable or cooking oil or
have been contaminated by hair care products be placed in a tumble
dryer they should first be washed in hot water with extra detergent -
this will reduce, but not eliminate, the hazard.
• As the laundry which had been cleaned, washed, soiled or stained
with benzine/diesel oil, dry cleaning solvents or other combustible and
explosive materials before will emit flammable or explosive vapour,
they should not be dried in the machine. This may cause risk of fire.

8/ EN Washer-Dryer
Important instructions for safety and environment
1.1.3 Warnings for dryer
A
DANGER
• Do not touch the door glass with bare hands after drying. This may
cause risk of burn.
• To keep the laundry under a temperature at which they will not be
damaged, a cooling step is carried out as the last stage. If you open the
loading door before cooling step is completed, you may be exposed to
hot vapour. This may cause risk of scalding.
• When drying programmes are interrupted (cancelling the programme
or power cut), laundry in the machine may be hot. Be careful.
A
CAUTION
• Do not stop the machine before the drying programme is completed. If
you have to stop it, take out all laundry promptly and spread them on
somewhere appropriate where they can cool down.
• Do not dry tulle curtains, rugs and blankets in the machine.
• Your product is suitable to operate under ambient temperatures between
0°C and +35°C.
• Ambient temperatures between 15°C and +25°C are the ideal operating
temperatures for your product.
• Pay care that pets do not enter into the product. Check inside of the
product prior to use.
• Do not perform drying by overloading the machine. Follow the maximum
load amounts specified for drying.
A
CAUTION
➢Drying should not be performed on leather garments or garments containing leather
(e.g. leather jeans tags, etc.). Leather piece may colour.
➢Turn off the machine in failures that cannot be eliminated by applying the information
given in the safety instructions, then unplug it and call the Authorised Service Agent.
➢It is possible only to wash the laundry or only to dry the laundry or perform both
washing and drying in the washer-dryer. Machine should not be used for drying for a
long time only with damp load. If the machine is used only for drying, any of the short
washing programmes should be run without putting in laundry after every 15 cycles.
➢Control all clothes before loading the machine to make sure that no belongings such
as lighter, coins, metal pieces, pins, etc have been left in the pockets or among them.
➢Underwear with metal supports should not be dried in the machine. Metal supports
may get loose and broken during drying process, thus cause damage on the cloth.
➢Do not dry voluminous laundry such as duvet and alike in the machine. Otherwise,
your laundry may get damaged.

User‘s Manual 9/ EN
Important instructions for safety and environment
C
NOTE
• Do not dry the unwashed laundry in the machine.
• Do not use fabric softeners or antistatic products in the machine unless these are
recommended by their manufacturers.
• Fabric softeners and products alike should be used in accordance with the instructions
of their producers.
• Do not dry delicate clothes such as silk, woollens, etc. in the machine. Otherwise,
woollens clothes may shrink and become smaller and other delicate clothes may get
damaged.
• Check the symbols on the product label on the garment prior to Drying and Washing
processes.
1.2 Intended use
C
NOTE
• This product has been designed for domestic use. It is not suitable for commercial use
and it must not be used out of its intended use.
• Use the product only for washing, rinsing and drying of textile products that are marked
accordingly.
• The manufacturer waives any responsibility arisen from incorrect usage or transportation.
• The service life of your product is 10 years. During this period, original spare parts will
be available to operate the appliance properly.
1.3 Children's safety
A
CAUTION
• Keep children under 3 years of age away from the appliance unless they
are supervised.
• Packaging materials are dangerous to children. Keep packaging materials
in a safe place away from reach of the children.
• Electrical products are dangerous for the children. Keep children away
from the product when it is in use. Do not let them to tamper with the
product. Use child lock to prevent children from intervening with the
product.
• Do not forget to close the loading door when leaving the room where the
product is located.
• Store all detergents and additives in a safe place away from the reach of
the children by closing the cover of the detergent container or sealing the
detergent package.

10 / EN Washer-Dryer
Important instructions for safety and environment
• This product complies with EU WEEE Directive (2012/19/EU). This
product bears a classification symbol for waste electrical and
electronic equipment (WEEE).
• This product has been manufactured with high quality parts and
materials which can be reused and are suitable for recycling. Do
not dispose of the waste product with normal domestic and other
wastes at the end of its service life. Take it to the collection center for
the recycling of electrical and electronic equipment. Please consult
your local authorities to learn about these collection centers.
• Compliance with RoHS Directive:
• The product you have purchased complies with EU RoHS Directive
(2011/65/EU). It does not contain harmful and prohibited materials
specified in the Directive.
1.5 Package information
Packaging materials of the product are manufactured from recyclable materials in accordance with our
National Environment Regulations. Do not dispose of waste package together with domestic or other
wastes. Dispose them at package collection points specified by the local authorities.
1.4 Compliance with WEEE Directive

User‘s Manual 11 / EN
2 Your washer-dryer
2.1 Overview
8
3
4
5
7
6
2
1
9
1- Power cable
2- Top panel
3- Control panel
4- Air inlet filter
5- Draining filter lid
6- Adjustable feet
7- Loading door
8- Detergent drawer
9- Drain hose

12 / EN Washer-Dryer
Your washer-dryer
1
2
345
a b c
6
7
8
9
10
2.2 Package Contents
1- Power cable
2- Drain hose
3- Air discharge section
4- Transportation safety bolts*
5- Mains water inlet hose (One of the following filter types is used for the mains hose connection.)
a- Electronic water shut-off
b- Mechanical water shut-off
c- Standard
6- Liquid detergent container**
7- User Manual
8- Blind plug***
9- Plastic plug assembly
10- Tool
* Number of transportation safety bolts may change depending on the model of your machine.
** This may be supplied with the machine depending on the model of your machine.
*** It is supplied if your machine is equipped with two water inlets at the backside.

User‘s Manual 13 / EN
Your washer-dryer
2.3 Technical specifications
C
NOTE
• Figures in this manual are schematic and may not match the product exactly.
• Values stated on the product labels or in the documentation accompanying it are
obtained in laboratory conditions in accordance with the relevant standards. Depending
on operational and environmental conditions of the product, these values may vary.
Complying Commission Delegated Regulation (EU) No.96/60/
EC/1996
Supplier name or trademark Beko
Model name WDA 961431
Washer Dryer Energy efficiency class (1) A
Washing Energy efficiency class (1) A
(Washing & Drying) Energy Consumption - full load per cycle (kWh) 6.12
Washing Energy Consumption - full load per cycle (kWh) 1.03
Annual (Washing & Drying) Energy Consumption (kWh) (2) 1224
Annual Washing Energy Consumption (kWh) (2) 206
Water Consumption (Washing & Drying) full load per cycle- (l) 61
Water Consumption (Washing) full load per cycle (l) 53
Annual Water Consumption (Washing & Drying)- (l) (3) 12200
Annual Water Consumption (Washing) (l) (3) 10600
Spin-drying efficiency class A
Maximum spin speed (rpm) 1400
Airborne acoustical noise emissions washing/spinning/drying (dB) 55/77/69
Built-in No
Rated capacity - Washing (kg) 9
Rated capacity - Drying (kg) 6
Height (cm) 84
Width (cm) 60
Depth (cm) 63
Net weight (±4 kg.) 86
Single Water inlet / Double Water inlet • / -
• Available
Electrical input (V/Hz) 230 V / 50Hz
Total current (A) 10
Total power (W) 2200
(1) Scale from A (Highest Efficiency) to G (Lowest Efficiency)
(2) Energy Consumption based on 200 standard washing cycles - full loads washing (and drying). Actual energy consumption will
depend on how the appliance is used.
(3) Water consumption based on 200 standard washing cycles - full loads washing (and drying). Actual energy consumption will
depend on how the appliance is used.
Technical specifications may be changed without prior notice to improve the quality of the product.

14 / EN Washer-Dryer
3 Installation
Refer to the nearest Authorised Service Agent for installation of the product. To make the product ready
for use, review the information in the user manual and take care that the electricity, tap water supply and
water drainage systems are appropriate before calling the Authorized Service Agent. If they are not, call a
qualified technician and plumber to have any necessary arrangements carried out.
B
DANGER
• Have the installation and electrical connections of the product made by
the Authorized Service Agent. Manufacturer shall not be held liable for
damages that may arise from procedures carried out by unauthorized
persons.
DANGER
• Product The weight of your product is not suitable to be carried by one
person.
A
CAUTION
• Prior to installation, visually check if the product has any defects on it. If
so, do not have it installed. Damaged products cause risks for your safety.
A
CAUTION
➢Preparation of the location and electrical, tap water and waste water installations at
the place of installation are under customer’s responsibility.
➢Make sure that the water inlet and discharge hoses as well as the power cable
are not folded, pinched or crushed while pushing the product into its place after
installation or cleaning procedures.
3.1 Appropriate installation location
• Place the machine on a rigid floor. Do not place it on a long pile rug or similar surfaces.
• Do not place the product on the power cable.
• Do not install the product at places where temperature may fall below 0ºC. (See, Warnings for drying)
• Place the product at least 1.5 cm away from the edges of other furniture.
• There should not be any lockable, sliding or hinged door that may restrain the loading door to open fully
in the installation place of this product.
• Operate the product in a well-ventilated and dust-free environment.

User‘s Manual 15 / EN
Installation
3.2 Removing packaging reinforcement
Tilt the machine backwards to remove the packaging reinforcement. Remove the packaging reinforcement
by pulling the ribbon.
DANGER
• The product is heavy. Remove the packaging reinforcement as
illustrated.
• Pay attention not to squeeze your hand under the machine during this
procedure.
3.3 Removing the transportation locks
A
CAUTION
➢Do not remove the transportation locks before taking out the packaging reinforcement.
➢Remove the transportation safety bolts before operating the washing machine!
Otherwise, the product will be damaged.
3
2
1
1 Loosen all bolts with the tool supplied in the User Manual bag until they turn freely.
2 Remove transportation safety bolts by turning them gently.
3 Attach the plastic covers supplied in the User Manual bag into the holes on the rear panel.
C
NOTE
• Keep the transportation safety bolts in a safe place to reuse when the machine needs to
be moved again in the future.
• Never move the product without the transportation safety bolts properly fixed in place!

16 / EN Washer-Dryer
Installation
3.4 Flush usage with the bench
59,5 cm
84,0 cm
1,4 cm
66cm
86 cm
60 cm
65,5 cm
20 cm
15 cm
20 cm
15 cm
60 cm
A
CAUTION
• Your machine should never be operated without the top plate.
• When the Washer-Dryer is placed under the bench, front of the machine
should never be blocked by the cupboard door.
• When the Washer-Dryer is placed under the bench, air vents must be
bored into the left and right sides of the cupboard.
C
NOTE
• Follow the above dimensions when installing the product under the bench. These
dimensions are indispensable to avoid any change in the performance of your machine.
• Drying washing machine can be used under a bench if the height of the bench allows.
• At least 3 cm clearance must be left between the sides and the back of the product and
the wall when it is installed under the bench or in a cupboard.

User‘s Manual 17 / EN
Installation
3.5 Connecting water supply
C
NOTE
• The water supply pressure required to run the product is between 1 to 10 bars (0.1 – 1
MPa). It is necessary to have 10 – 80 litres of water flowing from the fully open tap in
one minute to have your machine run smoothly.Attach a pressure reducing valve if water
pressure is higher.
• If you are going to use the double water-inlet product as a single (cold) water-inlet unit,
you must install the supplied blind stopper to the hot water valve before operating the
product. (Applies for the products supplied with a blind stopper group.)
A
CAUTION
• Models with a single water inlet should not be connected to the hot water
tap. In such a case the laundry will get damaged or the product will switch
to protection mode and will not operate.
• Do not use old or used water inlet hoses on the new product. It may cause
stains on your laundry.
1 2 3
1 Connect the special hoses supplied with the product to the water inlets on the product. Red hose (left)
(max. 90 ºC) is for hot water inlet, blue hose (right) (max. 25 ºC) is for cold water inlet.
A
CAUTION
• Ensure that the cold and hot water connections are made correctly when
installing the product. Otherwise, your laundry will come out hot at the
end of the washing process and wear out.
2 Tighten all hose nuts by hand. Never use a tool when tightening the nuts.
3 Open the taps completely after making the hose connection to check for water leaks at the connection
points. If any leaks occur, turn off the tap and remove the nut. Retighten the nut carefully after checking
the seal. To prevent possible water leakages, keep the taps closed when the machine is not in use.

18 / EN Washer-Dryer
Installation
3.6 Connecting to the drain
• Connect the end of the drain hose directly to the wastewater drain, sink or to the washbasin.
A
CAUTION
• Your house will be flooded if the hose comes out of its housing during
water discharge. Moreover, there is risk of scalding due to high washing
temperatures! To prevent such situations and to ensure smooth water
intake and discharge of the machine, fix the end of the discharge hose
tightly so that it cannot come out.
90 cm
90
40
90
40
90 cm
90 cm
min.40
• The distance to the wall so that the machine be placed up to 30 cm.
• Attach the hose at a height of at least 40 cm, and 90 cm at most.
• In case the hose is elevated after laying it on the floor level or close to the ground (less than 40 cm
above the ground), water discharge becomes more difficult and the laundry may come out excessively
wet. Therefore, follow the heights described in the figure.
• To prevent flowing of waste water back into the machine and to allow for easy discharge, do not
immerse the hose end into the waste water or do not drive it in the drain more than 15 cm. If it is too
long, cut it short.
• Pay care not to bend the end of the hose, step on it or pinch the hose between the drain and the
machine.
• If the length of the hose is too short, use it by adding an original extension hose. Length of the hose
may not be longer than 3.2 m. To avoid water leak failures, the connection between the extension hose
and the drain hose of the product must be fitted well with an appropriate clamp as not to come off and
leak.

User‘s Manual 19 / EN
Installation
3.7 Adjusting the feet
123
A
CAUTION
• In order to ensure that the product operates more silently and vibration-
free, it must stand level and balanced on its feet. Balance the machine by
adjusting the feet. Otherwise, the product may move from its place and
cause crushing and vibration problems.
1 Loosen the nuts on the feet in the direction of arrow with the tool supplied in the User Manual bag.
2 Adjust the feet until the product stands level and balanced. You can move the feet downwards by
turning them counterclockwise or upwards by turning clockwise.
3 Tighten all lock nuts again in the direction of arrow by the tool supplied. You can move the nuts upwards
by turning them counterclockwise or downwards by turning clockwise.

20 / EN Washer-Dryer
Installation
3.8 Electrical connection
Connect the product to a grounded outlet protected by a 16 A fuse. Our company shall not be liable for
any damages that will arise when the product is used without grounding in accordance with the local
regulations.
• Connection must comply with national regulations.
• Power cable plug must be within easy reach after installation.
• If the current fuse or circuit breaker is less than 16 Amperes, please have a qualified electrician install
a 16 Ampere fuse or circuit breaker.
• The voltage specified in the "Technical specifications" section must be equal to your mains voltage.
B
DANGER
• Damaged power cables must be replaced by the Authorized Service
Agents.
3.9 Transportation of the product
1 Unplug the product before transporting it.
2 Remove water drain and water supply connections.
3 Drain all water that has remained in the product. See. 6.6
4 Install transportation safety bolts in the reverse order of removal procedure; see 3.3.
DANGER
• The weight of your product is not suitable to be carried by one person.
• The product is heavy; it should be carried by two persons very carefully
on the stairs. Falling of your product on you may cause disabilities.
A
CAUTION
• Packaging materials are dangerous to children. Keep packaging materials
in a safe place away from reach of the children.
C
NOTE
• Never move the product without the transportation safety bolts properly fixed in place!
