Washer-Dryer
User Manual
WDX 8543130B
EN
Document Number=

Please read these instructions
first before using your appliance
Dear Customer,
Thank you for choosing a Beko appliance.
Please take some time to read this user manual
before using your appliance, to ensure you
know how to safely operate the controls and
functions. Carefully follow all unpacking and
installation instructions to ensure the appliance
is correctly connected and fitted prior to use.
Please write your product model and serial
number on the last page of this user manual,
and store in a safe location close to the
appliance for easy future reference. This user
manual may also be applicable for several other
models. Differences between models will be
listed. If you have any questions or concerns,
please call our contact centre or find help
and information online at www.beko.co.uk
Explanation of symbols used
throughout this User Manual
B
DANGER!
• Warning for electric shock.
DANGER!
• Product weight warning
DANGER!
• Fire risk warning.
A
CAUTION!
• Warning for hazardous situations
with regard to life and property.
A
PRECAUTION!
• Precautions that need to be taken.
C
INFORMATION
• Important information or useful hints about
usage.
• Read user manual.
• Packaging materials of the
product are manufactured
from recyclable materials in
accordance with regulations.
• Do not dispose of the
Packaging materials
together with the domestic
or other wastes. Take them
to the packaging material
collection points designated
by the local authorities.
• Allergy UK, is the brand of
British Allergy Association. Their
main endorsement is the ‚Seal
of Approval‘. When you see
a product with this logo on it,
you have the reassurance the
product has been scientifically
tested to prove it is efficient at
reducing/removing allergens
from the environment
of allergy and asthma
sufferers or the products
have significantly reduced
allergen/chemical content.
“The wool wash cycle of this
machine has been approved
by The Woolmark Company
for the washing of machine
washable wool products provided
that the products are washed
according to the instructions
on the garment label and those
issued by the manufacturer of
this washing machine. M1429 “
“In UK, Eire, Hong Kong and
India the Woolmark trade mark
is a Certification trade mark.”
This product was manufactured using the latest technology in environmentally friendly conditions.

3 / EN Washer-Dryer / User’s Manual
1 Important instructions for safety and environment
This section contains safety instructions
that will help protect from risk of
personal injury or property damage.
Failure to follow these instructions
shall invalidate any warranty.
1.1 General safety
A
CAUTION!
• This product can be used by
children at and above 8 years old
and by persons whose physical,
sensory or mental capabilities
were not fully developed or who
lack experience and knowledge
provided that they are supervised
or trained on the safe usage of the
product and the risks it brings out.
Children should not play with the
device. Cleaning and maintenance
works should not be performed by
children unless they are supervised
by someone. Children under the
age of 3 should be kept away
unless continuously supervised.
A
PRECAUTION!
• Never place the product on a
carpet-covered floor. Otherwise,
lack of airflow beneath the machine
will cause electrical parts to
overheat. This will cause problems
with your product.
C
INFORMATION
• Always have the installation
procedures carried out by the
competent persons. Manufacturer
shall not be held liable for damages
that may arise from procedures
carried out by unauthorised
persons.
1.1.1 Electrical safety
B
DANGER!
• If the product has a failure, it
should not be operated unless it is
repaired by the Authorised Service
Agent. There is the risk of electric
shock!
• Never wash the product by
spreading or pouring water onto it!
There is the risk of electric shock!
A
CAUTION!
• If the power cable is damaged,
it must be replaced by the
manufacturer, after sales service
or a similarly qualified person
(preferably an electrician) or
someone designated by the
importer in order to avoid possible
risks.

4 / EN Washer-Dryer / User’s Manual
A
PRECAUTION!
• Unplug the product when it is not
in use.
• Never touch the plug with wet
hands! Never unplug by pulling on
the cable, always unplug by holding
the plug.
• Product should be unplugged
during installation, maintenance,
cleaning and repair procedures.
• Do not make connections via
extension cables or multi-plugs.
C
INFORMATION
• This product is designed to resume
operating in the event of powering
on after a power interruption. If you
wish to cancel the programme,
see “Cancelling the programme”
section.
1.1.2 Product safety
B
DANGER!
• Never open the loading door or
remove the filter while there is
still water in the drum. Otherwise,
risk of flooding and injury from hot
water will occur.
A
CAUTION!
• The water supply and draining
hoses must be securely fastened
and remain undamaged. Otherwise,
there is the risk of water leakage.
C
INFORMATION
• Do not force open the locked
loading door. Door can be opened
a few minutes after the washing
cycle ends. If the machine has not
cooled enough at the end of the
programme, loading door cannot
be opened. Do not force the loading
door to open. It must be left to cool
itself. The loading door and the lock
mechanism may get damaged.
• In the installation location of this
product, there must not be a
lockable, sliding or hinged door that
will restrict the full opening of the
loading door.
• Follow the instructions on the textile
tags and on the detergent package.
• Use only detergents, softeners and
supplements suitable for washing
machines.
• Do not install or leave this product
in places where it might be exposed
to outdoor conditions.
• Controls must not be tampered
with.
1.1.3 Warnings for drying
DANGER!
• Laundry that is previously washed,
cleaned, soiled or stained with
petrol / gasoline, dry cleaning
solvents or other flammable or
explosive substances must not be
dried in the machine as they give
out flammable or explosive steam.
It may cause fire risk.

5 / EN Washer-Dryer / User’s Manual
DANGER!
• Laundry stained with Liquid
cooking oil, acetone, alcohol,
petrol, kerosene, spot removers,
turpentine, waxes and wax
removers must be washed in hot
water with plenty of detergent
before drying. It may cause fire risk.
• Foam rubber (latex foam), shower
caps, waterproof textiles, clothes
or pillows with rubber support or
rubber foam pads must not be
dried with drying function. It may
cause fire risk.
• If you use washing ball, detergent
scale, laundry clothing cages and
balls in your machine, they can
melt during drying. Do not use
these products if drying option will
be selected. It may cause fire risk.
• When you use industrial chemicals
for cleaning, do not use drying
function. It may cause fire risk.
B
DANGER!
• Do not touch loading door glass
with bare hands after drying. There
is the risk of getting burnt.
• In order to maintain laundry in a
temperature that will prevent them
from getting damaged, a cooling
step is performed as a final step.
You may be exposed to hot steam
if you open the door before cooling
is complete. There is the risk of
scalding.
B
DANGER!
• If the drying programmes
are interrupted (as a result of
programme cancellation or power
failure), laundry in the machine can
be hot. Be careful.
A
CAUTION!
• Do not stop the machine before
drying programme is completed.
If you have to stop the machine,
remove all laundry and lay them
in a suitable place to let them cool
down.
• Your product is suitable to operate
in ambient temperatures between
0°C and +35°C.
A
CAUTION!
• Ambient temperatures between
15°C and +25°C are ideal
temperatures for your product.
• Do not let pets enter the product.
Check inside the product before
using.
• Do not overload the machine for
drying. Observe the maximum load
levels specified for drying.

6 / EN Washer-Dryer / User’s Manual
A
PRECAUTION!
• Do not dry leather laundry or
laundry that contains leather (such
as leather jeans label). The colour
from Leather parts can run into
other textiles.
• In failures that cannot be repaired
using information given in safety
instructions, turn off the machine,
unplug the power cable and call the
Authorised Service Agent.
• You can just wash laundry, just dry
laundry or wash and dry laundry in
your washer-dryer. Machine must
not be used only to dry wet loads
for a long time. When machine is
used only for drying, it must be
operated empty without loading
laundry in a short wash programme
after every 15 operation.
• Check all clothes before loading
them into the machine and ensure
that they do not have objects such
as lighters, coins, metal pieces,
needles in the pockets or inside.
• Underwear with metal supports
must not be dried in the machine.
Metal supports might come off
during drying and cause damage
in the machine. Place in a bag or
pillowcase.
• Do not dry large laundry such as
tulle curtain, curtain, bedding,
blanket, rug in the machine. Your
laundry might get damaged.
C
INFORMATION
• Do not dry unwashed laundry in the
machine.
• Do not use fabric softeners or static
preventers in the machine unless
recommended by the manufacturer.
• Products such as fabric softeners
must be used in accordance with
manufacturer’s instructions.
• Do not dry sensitive clothes such
as silk, wool, etc. in the machine.
Otherwise, wool clothes may get
shrunken and other sensitive
clothes may get damaged.
• Check symbols on the garment tag
before washing and drying.
1.2 Intended use
C
INFORMATION
• This product has been designed for
domestic use. It is not suitable for
commercial use and it must not be
used out of its intended use.
• The product must only be used
for washing, rinsing and drying of
textile products that are marked
accordingly.
• The manufacturer waives any
responsibility arisen from incorrect
usage or transportation.
• The service life of your product
is 10 years. During this period,
original spare parts will be available
to operate the product properly.

7 / EN Washer-Dryer / User’s Manual
1.3 Children's safety
A
CAUTION!
• Children below the age of 3 must be
kept away from the machine unless
they are continuously supervised.
• Packaging materials are dangerous to
children. Keep packaging materials in
a safe place away from reach of the
children.
• Electrical products are dangerous for
the children. Keep children away from
the product when it is in use. Do not
allow them to play with the product.
Use child lock to prevent children
from intervening with the product.
• Do not forget to close the loading
door when leaving the room where
the product is located.
• Store all detergents and additives in
a safe place away from the reach of
the children by closing the cover of
the detergent container or sealing the
detergent package.
1.4 Compliance with WEEE
Directive and disposing
of the waste product
This product does not contain harmful and
forbidden materials described in the "Regulation on
the Control of the Waste Electrical and Electronic
Equipment". It complies with the WEEE Directive.
This product has been
manufactured with high quality
parts and materials which can
be reused and are suitable for
recycling. Therefore, do not
dispose the product with normal
domestic waste at the end of its
service life. Take it to a collection
point for the recycling of electrical
and electronic equipment. Please
consult your local authorities to
learn the nearest collection point.
Help protect the environment and natural
resources by recycling used products.
For children’s safety, cut the power cable
and break the locking mechanism of the
loading door so that it will be non-functional
before disposing of the product.
Compliance with RoHS Directive:
The product you have purchased complies
with EU RoHS Directive (2011/65/EU). It
does not contain harmful and prohibited
materials specified in the Directive.
1.5 Package information
Packaging materials of the product are
manufactured from recyclable materials in
accordance with our National Environment
Regulations. Do not dispose of the packaging
with normal domestic waste. Take them
to the packaging material collection points
designated by the local authorities.
2 Your washer-dryer
2.1 Overview
1
2
3
4
5
6
7
8
1- Power cable 5- Loading door
2- Top panel 6- Filter cover
3- Control panel 7- Adjustable feet
4- Water
discharge hose
8- Detergent drawer

8 / EN Washer-Dryer / User’s Manual
2.2 Package contents
Power cable
Water discharge hose
Transit bolts
Mains water inlet hose
Liquid detergent container (*)
User manual
Plastic plug group
C
INFORMATION
• Figures in this manual are schematic and may not match the product exactly.
(*) This may be supplied with the machine depending on the model of your product.

9 / EN Washer-Dryer / User’s Manual
2.3 Technical specifications
Complying Commission Delegated Regulation (EU) No.96/60/EC/1996
Supplier name or trademark Beko
Model name WDX8543130B
Washer Dryer Energy efficiency class (1) A
Washing Energy efficiency class (1) A
(Washing & Drying) Energy Consumption - full load per cycle (kWh) 5,44
Washing Energy Consumption - full load per cycle (kWh) 0,76
Annual (Washing & Drying) Energy Consumption (kWh) (2) 1088
Annual Washing Energy Consumption (kWh) (2) 172
Water Consumption (Washing & Drying) full load per cycle- (l) 78
Water Consumption (Washing) full load per cycle (l) 47
Annual Water Consumption (Washing & Drying)- (l) (3) 15600
Annual Water Consumption (Washing) (l) (3) 9400
Spin-drying efficiency class (1) A
Maximum spin speed (rpm) 1400
Airborne acoustical noise emissions washing/spinning/drying (dB) 57/77/64
Built-in No
Rated capacity - Washing (kg) 8
Rated capacity - Drying (kg) 5
Height (cm) 84
Width (cm) 60
Depth (cm) 59
Net weight (±4 kg.) 71
Single Water inlet / Double Water inlet • / -
• Available
Electrical input (V/Hz) 230 V / 50Hz
Total current (A) 10
Total power (W) 2200
VDE Main model code 9620
(1) Scale from A (Highest Efficiency) to G (Lowest Efficiency)
(2) Energy Consumption based on 200 standard washing cycles - full loads washing (and drying). Actual energy consumption will
depend on how the appliance is used.
(3) Water consumption based on 200 standard washing cycles - full loads washing (and drying). Actual energy consumption will
depend on how the appliance is used.
Technical specifications may be changed without prior notice to improve the quality of the product.

10 / EN Washer-Dryer / User’s Manual
3 Installation
To make the product ready for use, review the
information in the user manual and make sure
that the electricity, tap water supply and water
drainage systems are appropriate. If they are
not, call a qualified technician and plumber to
have any necessary arrangements carried out.
B
DANGER!
• Make sure that the installation and
electrical connections of the product
are performed by competent persons.
Manufacturer shall not be held liable for
damages that may arise from procedures
carried out by unauthorised persons.
DANGER!
• Your product is too heavy for
one person to carry.
A
CAUTION!
• Prior to installation, visually check if
the product has any defects on it. If
so, do not have it installed. Damaged
products cause risks for your safety.
A
PRECAUTION!
• Preparation of the location and
electrical, tap water and waste water
installations at the place of installation
is under customer’s responsibility.
• Make sure that the water inlet and
discharge hoses as well as the power
cable are not folded, pinched or crushed
while pushing the product into its place
after installation or cleaning procedures.
3.1 Appropriate
installation location
• Place the product on a solid and level
floor. Do not place it onto a carpet with
high pile or other similar surfaces.
• Do not place the product close to the
edge if the floor contains steps. Do not
also place the product on a platform.
• Do not place the product on the power cable.
• Do not install the product in environments
where the temperature falls below
0 ºC.(See. Warnings for Drying)
• Leaving a gap at the sides of the machine
is suggested to reduce vibration and noise
• In the area where this product is
installed, there must not be a lockable,
sliding or hinged door that will restrict
the full opening of loading door.
• Operate the product in a well ventilated
and dust free environment.
• Do not place heat sources such as Hobs,
Irons, Ovens, etc. on the washing machine
and do not use them on the product.
3.2 Removing packaging
reinforcement
Tilt the machine
backwards to remove
the packaging
reinforcement.
Remove the
packaging
reinforcement
attached to
the ribbon.
DANGER!
• Your product is heavy. Remove packaging
reinforcement as displayed in the figure.
• Be careful not to get your hand caught
under the machine during this procedure.
3.3 Removing the transit bolts
A
PRECAUTION!
• Do not remove the transit bolts before
removing the packaging reinforcement.
• Remove the transit bolts before operating
the washing machine! Otherwise,
the product will get damaged.
