Belifu YF1503 User manual

[email protected]
Please download the PDF manual on the
below link:
https://belifu.com/downloads/
Pain Relief, Anywhere, Anytime.
Customer Service:
Please read the instructions manual carefully
before using the device.
Precaution
·Please read the instructions manual carefully
before using the device.
If you have any questions, please refer to the
salesman or ask your doctor.
·Please keep this manual for future reference.
Manufacturer: Shenzhen Yuehua Xinsen
Technology Co.,Ltd
Address: No. 27-201, Zhongwu 3rd Road,
Zhongwu Community, Hangcheng
Street, Bao’an District, Shenzhen City,
Guangdong Province.CHINA. 518100
-1-

TABLE OF CONTENTS
1. INTRODUCTION
2. SAFETY INTRODUCTIONS
3. FUNCTIONS OF THE DEVICE
4. OPERATING INSTRUCTIONS
5. BATTERY AND MEMORY FUNCTION
6. MAINTENANCE
7. MODE INSTRUCTION
8. TENS EMS ELECTRODE
PLACEMENT GUIDE
9. TROUBLESHOOTING
10. PRODUCT DESCRIPTIONS
11. MEDICAL DISCLAIMER
12. PRECAUTIONS
13. CONTRAINDICATIONS
14. ADVERSE REACTION
15. NOTES ON FCC CERTIFICATION
16. WARRANTY
-2-

Working principle
It acts on the human body through the
electricity pulse wave, the electric energy is
sucked by the human body and the energy
form is changed, which causes a series of
physical and chemical changes, produces
local or systemic physiological reactions,
and finally affects the pathological process
and plays a corresponding role.
Intended use
For TENS mode: To be used for temporary
relief of pain and recovery of fatigue
associated with sore and aching muscles
due to strain from exercise or normal
household work activities.
For EMS mode: To be used to stimulate
healthy muscles in order to improve and
facilitate muscle performance.
Applicable people
Adults who suffer from sore and aching
muscles in the shoulder, waist, back, neck,
upper extremities (arms), and lower
extremities (leg) due to strain from exercise
or normal household work activities can use
this device.
1.INTRODUCTION
-3-

However, it should not be used by children,
pregnant women, or anyone who has an
implanted metallic or electronic device. Ask
your physician if you have any questions.
Package contents
Features
ƔPRGHV
ƔLQWHQVLW\OHYHOV
ƔPLQXWHGHIDXOWWLPHUDGMXVWDEOHIURP
10-80 minutes or continuously
Items Quantity
Device
Manual
lead wires with 2
connectors (2.5mm)
large self-adhesive
electrode pads
medium self-adhesive
electrode pads
small self-adhesive
electrode pads
USB cable
Storage bag
1 pc
1 pc
2 pcs
1 pair
3 pairs
1 pair
1 pc
1 pc
-4-

Warnings
(DO NOT USE THIS UNIT UNDER BELOW CONDITIONS:)
2.SAFETY INTRODUCTIONS
Ɣ'RQRWXVHWKLVXQLWLI\RXDUHXVLQJDQ
implanted electronic medical device such
as a pacemaker.
Ɣ'RQRWXVHWKLVXQLWLI\RXDUHZHDULQJDQ\
electrode medical devices used for
monitoring health functions.
Ɣ'RQRWXVHWKLVXQLWZKLOHGULYLQJ
Ɣ'RQRWXVHWKLVXQLWZKLOHVOHHSLQJ
Ɣ'RQRWXVHWKLVXQLWLQDUHDVZLWKKLJK
humidity such as a bathroom.
Ɣ.HHSWKLVXQLWRXWRIUHDFKRIFKLOGUHQ
Ɣ'RQRWXVHLWRQFKLOGUHQRULQIDQWV
because the device has not been
evaluated for pediatric use.
Ɣ6WRSXVLQJWKLVGHYLFHDQGFRQVXOW\RXU
physician at once if you feel pain
discomfort such as dizziness or nausea.
Ɣ'RQRWDWWHPSWWRPRYHWKHHOHFWURGH
pads while the device is in operation.
Ɣ'RQRWXVHWKHGHYLFHQHDUWKHKHDUWRQ
the head, near the mouth, genitals or
blemished areas of the skin.
Ɣ'RQRWXVHWKLVGHYLFHRYHURULQSUR[LPLW\
to, cancerous lesions.
-5-

Ɣ'RQRWXVHWKLVGHYLFHLQWKHSUHVHQFHRI
electronic monitoring equipment (e.g.,
cardiac monitors, ECG alarms), which may
not operate properly when the electrical
stimulation device is in use.
Ɣ3UHJQDQWZRPHQ
Ɣ3HUVRQVLQFDSDEOHRIH[SUHVVLQJWKHLU
thoughts or intentions.
Ɣ+DYHHSLOHSV\
Ɣ6WRSXVLQJWKLVGHYLFHDQGFRQVXOW\RXU
physician if your pain does not improve,
becomes more than mild, or continues for
more than five days.
Ɣ'RQRWXVHWKLVGHYLFHRYHURSHQZRXQGV
or rashes, or over swollen, red, infected, or
inflamed areas or skin eruptions (e.g.,
phlebitis, thrombophlebitis, varicose veins).
Ɣ&DQQRWEHXVHGDIWHUGULQNLQJ
Ɣ/RZIUHTXHQF\WKHUDSHXWLFLQVWUXPHQWV
can not be used when using
high-frequency surgical instruments.
Ɣ1HDUWKHJHQLWDOV
Ɣ5HFRPPHQGDWLRQGRQRWXVH
low-frequency therapeutic instruments
near shortwave or microwave therapeutic
equipment (e. g. 1m), where the output of
the low frequency therapeutic instrument
used is unstable.
-6-

Ɣ7KHKLJKIUHTXHQF\VXUJLFDOHTXLSPHQWDQG
stimulator. When connected to a patient,
burns may occur at the stimulator
electrode and may damage the stimulator.
Ɣ3DWLHQWVXQGHUJRLQJPHGLFDOWUHDWPHQWDQG
feeling abnormal.
Ɣ+HDUWSDWLHQWVZLWKQHXURORJLFDO
abnormalities in the brain.
Ɣ3DWLHQWVZKRVHERG\WHPSHUDWXUH
exceeds 38℃.
Ɣ,QIHFWLRXVGLVHDVHV3DWLHQWV
Ɣ3DWLHQWVZKRFDQQRWH[SUHVVWKHLUZLOO
Ɣ'RQRWXVHWKLVSURGXFWZKLOHFKDUJLQJ
Notice
Caution should be used in the presence of the following:
Ɣ(OHFWURGHZLUHLVWRRORQJPD\FDXVH
VXIIRFDWLRQ.HHSWKHSURGXFWDQGNHHS
away from children.
Ɣ0DNHVXUH\RXDUHDOZD\VDZDUHRIDOO
warning items.
Ɣ6WLPXODWRUVVKRXOGQRWEHXVHGLQWKH
throat and mouth. This may result in
severe throat muscle spasms and muscle
contraction, which is sufficient to block the
airway and cause dyspnea.
Ɣ7KHDSSOLFDWLRQRIHOHFWURGHVQHDUWKH
-7-

thorax may increase the risk of cardiac
fibrillation
Ɣ7KLVVWLPXODWRUVKRXOGQRWWUHDWXQDWWHQGHG
patients, or suffer from emotional distress,
dementia, and low IQ people.
Ɣ8VHJXLGDQFHKDVEHHQGHWDLOHGDQ\
improper use may lead to danger.
Ɣ'RQRWXVHWKLVGHYLFHIRUDQ\XQGLDJQRVHG
pain symptoms, consult a doctor for
diagnosis before use.
Ɣ(OHFWURGHVFDQQRWEHSODFHGLQDUWHULHV
head and pubic area.
Ɣ3DWLHQWVVXIIHULQJIURPKHDUWGLVHDVH
cancer or other health-threatening
conditions should consult a doctor before
using this device.
Ɣ,IWKHLQWHQVLW\RIVWLPXODWLRQPDNHV\RX
feel 8 uncomfortable, reduce the intensity
of stimulation to a
comfortable level. If the problem remains,
please contact your doctor.
Ɣ'RQRWXVHWKLVHTXLSPHQWLQURRPVZKHUH
aerosol (spray) and pure oxygen are used.
Ɣ3OHDVHGRQRWXVHWKLVHTXLSPHQWQHDU
any highly flammable substances, gases
or explosives.
Ɣ3OHDVHFKHFNWKDWWKHFDEOHDQGUHODWHG
connections are in good condition before
-8-

each use.
Ɣ7XUQRIIWKHGHYLFHEHIRUHXVLQJRU
removing the electrode pad.
Ɣ(OHFWURQLFVWLPXODWRUFDQRQO\XVH
electrode wires and electrodes
recommended by manufacturers.
Consult your doctor before using the
device especially in the following cases:
Ɣ$FXWHGLVHDVHHVSHFLDOO\SDWLHQWV
suspected or suffering from hypertension,
thrombosis or malignant mass.
Ɣ3DWLHQWVZLWKYDULRXVVNLQGLVHDVHV
Ɣ3DWLHQWVZLWKFKURQLFSDLQGLVRUGHUV
(e. g. metabolic disorders) with reduced
pain.
Ɣ3DWLHQWVXQGHUJRLQJPHGLFDWLRQ
Adverse reaction:
Ɣ6NLQDOOHUJLHVFDXVHGE\HOHFWURGH
sheetpad gels and electrode irritation
burns are potential adverse reactions.
If the skin appears sensitive response,
should be discontinued and consult your
doctor.
Ɣ,IWKHLQWHQVLW\RIVWLPXODWLRQPDNHV\RX
feel uncomfortable, reduce the intensity of
stimulation to a comfortable level, and if
-9-

Explanation of figures. symbols, warning
statements and abbreviations on the
equipment
Meanings of symbols used for marking
described in instructions for use
Caution!
Type BF applied part
Protected against solid foreign
REMHFWVRIPPĭDQG
JUHDWHU3URWHFWLRQDJDLQVW
vertically falling water drops
when ENCLOSURE tilted
up to 15°
Direct current
IP22
SN
Refer to instruction manual
Serial Number
Manufacture date
Manufacture information
-10-

3.FUNCTIONS OF THE DEVICE
A B
< M
< M
A/B
1
4
6
5
92
3
7
8
10
11
1 Time indicator 2 LCD screen
3 A/B channel intensity indicator 4 Pause indicator
5 A/B output 6 Battery indicator
7 Charging port 8 Mode selection button
9 Intensity adjust button
10 Turn on/off (Long Press) & Pause button (Short Press)
11 Time button (Short Press) & Lock button (Long Press)
-11-

If the stickiness is not good enough
after a period of use, please try to add a few
drops of water on the pads and dry the pads
naturally. It can increase their longevity.
Make sure both pads on the skin do not
overlap.
BEFORE USING YOUR DEVICE
1.Please check if there are any damages to
the device, electrode leads, or electrode
pads.
2.Please ensure the electrode leads
connection is not broken.
3.Please ensure that the device is fully
charging.
4.When the device is in no-output status, it
will automatically shut down if there is no
further action within 5 minutes.
5.Clean your skin before use. Use the pads
on clean and flat areas, no sweat and no oil.
6.Attach one pair or two pairs of the
electrode pads to the massage area, such
as the shoulder and leg.
Note:
4.OPERATING INSTRUCTIONS
-12-

HOW TO USE
STEP 1: Connecting electrodes pads to
electrode wire. (IMG.1)
Note:
Please check the snap
connections to ensure they are
fastened. Use at least one pair of
pads, one pad can’t work alone.
STEP 2: Paste electrode pads to the area
where you want therapy. (IMG.2)
When using 1 wire with 2
connectors, please make sure both
SDGVDUHVWXFNRQ\RXUERG\
when using 2 wires, please make
sure at least 2 pairs of pads are
stuck on your body. Please confirm
the wire is plugged well and pads are
VWXFNWR\RXUVNLQEHIRUHDGMXVWLQJ
the unit.
Note:
-13-
IMG.1

STEP 3: Connecting electrodes wire to
the device (channel A/B). (IMG.3)
STEP 4: Long Press the upper-right
“Power/Pause” button to turn
on device(PS: Short Press is
for the pause function)(IMG.4)
STEP 5: Press “A”/ “B” button to choose
A or B channel mode. (IMG.5)
-14-
IMG.2
IMG.3
A B
IMG.4

STEP 6: Short press <M ,M> button to
choose the mode you like. (IMG.6)
Note:
Remember the intensity will
default to Zero when changing the
modes.It is recommended to start
with the lowest level of intensity and
gradually increase to a level that is
comfortable.
Please check the flash channel indicator on
the screen to make sure it is the channel you
want to use. The flash "A" icon indicates you
FDQDGMXVWWKHPRGHDQGLQWHQVLW\OHYHORI
Channel A. If you choose Channel B, the
Channel B icon will flash to indicate the
Channel B is working.
Note: A/B two channel all independent
you can set different mode and intensity
on different channel.
-15-
IMG.5
< M
< M
A/B

STEP 7: Short press upper-left button “+”
“-” button to adjust A/B intensity)
(IMAG.7)
The default time is 20mins. Short
Press the “Power/Time” button to
adjust the time (10-80mins), it can
STEP 8: Short press upper right-side
Time/Lock button to set the
time (PS: Long Press is for the
lock function)(IMG.8)
-16-
IMG.6
< M
< M
A/B
IMG.7
“Time/Lock” button to

be increased by 10mins. When it’s
increased up to 80mins, continue to
press the “T” button to jump to
10mins.
STEP 9:
The device will automatically turns
off when the time runs out.
STEP 10: Long Press the Power/Pause
button to turn off device if no
need to use it(PS: Short Press
is for the pause function)(IMG.10)
Long Press the Time/Lock button
to lock the unit after you complete
the above settings (PS: Short
Press is for time setting)(IMG.9)
-17-
IMG.8
IMG.9

·Battery information
Please use the AC adapter complying the
standard : IEC60601-1, DC5V/1A)
Capacity: 180 mAh
Frequency: 1-110HZ
Voltage: 3.7V
5.BATTERY AND MEMORY FUNCTION
Note:
Please don’t tear off the pads
vigorously. Please don’t remove the
pad before turning off the device.
STEP 11: Remove the pads from your skin
and store the products
Remove the pads from you skin
gently, and paste the plastic
dust-proof film on them, take them
off the electrode wires and unplug
the wires, put them and the device
into the storage bag.
-18-
IMG.10

·Charging the battery
1.The device is powered by an internal,
rechargeable lithium battery that can be
charged through a standard wall outlet or
through the USB port of a computer or
power bank. Signs the device needs to be
charged include dimness of the screen or
failure to display the screen, and weak
sensations from the electrodes.
2.Turn off the device.
3.Connect the controller and the charger
with USB extension cord.Plug charger into
any power outlet. The charging process
will last 1-2 hours.
·Memory function
The memory function can help to remember
the selected mode, the Mode will always be
the same as the value as before pause and
shut down.
Please clean the main machine frequently.
Use a piece of soft dry cloth to wipe the dirt
on the main machine. Don't wash with water
or clean with the detergent, thinner, volatile
oil, etc. that contains chemical substances.
6.MAINTENANCE
-19-
