F8E815spBNDL
Wireless Keyboard
and Mouse User Manual
Guide d’utilisation –
lavier et souris sans fil
Manual del Usuario del Ratón
y Te lado Inalámbri os
Manual do utilizador para
te lado e rato sem fio
Manuel de l’utilisateur du
lavier et de la souris sans fil
Bedienungsanleitung für
drahtlose Tastatur und Maus
Handleiding voor uw draadloze
toetsenbord en muis
Manuale utente per tastiera
e mouse wireless
P74113qb_F8E815spBNDL_man.qxd 24-01-2003 13:50 Page 3

P74113qb_F8E815spBNDL_man.qxd 24-01-2003 13:50 Page 4

Table of Contents
About Your Wireless Keyboard and Mouse . . . . . . . . . . . . . . . . . . . . . .1
Hardware Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Software Installation for Windows®98, Me, 2000, and XP . . . . . . . . . . . .4
Software Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Uninstallation for Windows 98, Me, 2000, and XP . . . . . . . . . . . . . . . . .8
Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
En
P74113qb_F8E815spBNDL_man.qxd 24-01-2003 13:50 Page 5

P74113qb_F8E815spBNDL_man.qxd 24-01-2003 13:50 Page 6

About Your Wireless Keyboard and Mouse
1
Welcome to the freedom of wireless computing. Engineered with
digital radio technology, your keyboard and mouse are designed to
work wherever you are most comfortable within its 6-foot operating
range. This advanced technology does not require “line of sight” for
operation. We have eliminated the cable clutter and added enhanced
features such as one-touch Internet and multimedia keys that give
you quick access to the Web or your CD/DVD media.
The receiver connects to the PS/2 mouse port (green connector)
and the PS/2 keyboard port (purple connector) of your computer.
Battery Life
Under average usage, 3-4 hours per day, the batteries should last
for approximately one month.
En
P74113qb_F8E815spBNDL_man.qxd 24-01-2003 13:50 Page 1

Hardware Installation
2
1. Be sure that your computer is turned off.
2. Connect the receiver to your computer. The receiver has a 2-head
connector for the keyboard and mouse connections (purple is for
the keyboard and green is for the mouse.) They also have pictures
on the top of the connector to identify them. Your computer
should either have the same color scheme or there will be a
picture next to the plug to identify it.
3. Install the batteries into your keyboard and mouse. Please make
sure you follow the picture on the inside compartment for the
batteries to make sure the batteries are installed correctly. Refer
to Fig. 1 and Fig. 2 below.
Fig. 1 Keyboard Bottom
Fig. 2 Mouse Bottom
Reset Button
Battery
Compartment
Reset Button
Battery Compartment
P74113qb_F8E815spBNDL_man.qxd 24-01-2003 13:50 Page 2

Hardware Installation
Fig. 3 Receiver Top
4. Turn your computer on.
5. The receiver was set by the factory to automatically scan for
and synchronize the keyboard and mouse once the computer is
turned on. The keyboard and mouse should now be functioning.
6. If the automatic synchronization does not occur, please see the
Troubleshooting section.
3
Reset Button
En
P74113qb_F8E815spBNDL_man.qxd 24-01-2003 13:50 Page 3

Note: The keyboard and mouse should now be functioning. If not,
repeat the setup instructions. The software can now be installed.
Warning: It is recommended that you uninstall any previously
installed keyboard and mouse software prior to installing your
new Belkin software.
1. Make sure the computer is on.
2. Insert the CD into the computer.
3. If you have no previously installed keyboard or mouse
software, click “OK” and the installation will begin. Follow
the on-screen instructions.
4. Upon completion of installation, you will be prompted to
restart your computer. You must restart at this time for the
software to function.
4
Software Installation for Windows 98, Me, 2000, and XP
P74113qb_F8E815spBNDL_man.qxd 24-01-2003 13:50 Page 4

Software Features
5
Keyboard
Using your mouse, right-click on the keyboard icon in your system
tray located at the bottom right of your screen. This will open the
dialog box.
The dialog box allows you to hide the keyboard icon, set your
OSD (on-screen display) time-out, and provides “About” for
the software.
Mouse
Using your mouse, right-click on the mouse icon in your system
tray located at the bottom right of your screen. This will open the
dialog box.
The dialog box allows you to hide the mouse icon, select “Set
Mouse Properties”, and provides “About” for the software.
En
P74113qb_F8E815spBNDL_man.qxd 24-01-2003 13:50 Page 5

6
The keyboard and/or mouse is/are not detected or do not work
after installation.
• Make sure the receiver cables are plugged into the PS/2 mouse port
and PS/2 keyboard port. Do not unplug or plug-in the receiver
cable while the computer is on.
• For optimal performance, place the receiver at least eight inches
(20 centimeters) away from the computer monitor, the computer,
any external storage devices, or other electrical devices.
• Make sure you have properly installed the batteries. Check to make
sure the batteries you have installed are not dead (you can do this
by installing them into another device).
• You may have other system devices that are conflicting with the
mouse and/or the keyboard. Check the IRQ/address settings of
these devices for conflicts and change the settings as required.
Refer to your computer documentation to make these changes.
• Make sure you have properly established
communication/synchronization between the receiver and the
mouse and keyboard.
• If the keyboard and/or mouse are not working, make sure that the
LED on the keyboard and/or the mouse start flashing when you
push any of the keyboard keys, mouse buttons, or move the mouse.
If the LED does not flash, check to make sure you have installed
the batteries correctly.
• When the keyboard or mouse LEDs are flashing, the LED on the
receiver should also flash to indicate they are speaking to each
other. If the LED on the receiver does not flash, it means that the
devices have not connected properly. Push the reset button on the
receiver. Within five seconds, push the reset buttons on the mouse
and on the keyboard. Refer to Fig. 1, Fig. 2, and Fig. 3 in the
Hardware Installation section.
The mouse pointer becomes choppy on-screen or the keyboard
does not register keystrokes.
• Remove batteries and replace with a fresh set.
Troubleshooting
P74113qb_F8E815spBNDL_man.qxd 24-01-2003 13:50 Page 6

Maintenan e
7
A self-cleaning ball cage helps prevent dust and lint from
building up around the ball. However, if the pointer should skip
or move abnormally on the screen, we recommend you clean
your mouse manually. Note: This only applies to mice that have
a ball mechanism.
1. Turn the retainer ring counter-clockwise to remove.
The ball can now be removed.
2. Wipe the ball with a clean lint-free cloth.
3. Blow into the ball cage to dislodge any dust and lint.
4. If there is build-up on the rubber rollers inside the ball cage,
clean using a cotton swab with isopropyl alcohol (applied
sparingly to the swab) to remove any debris.
5. Use a damp rag to clean the outer surface of your mouse (do
not use any harsh cleaning agents such as cleanser or alcohol).
En
P74113qb_F8E815spBNDL_man.qxd 24-01-2003 13:50 Page 7

1. Select “Settings”.
2. Select “Control Panel”.
3. Select “Add/Remove Programs”.
4. Select “Belkin Wireless driver”, then click on “Add/Remove”.
5. You will be asked if you are sure if you want to remove selected
application and all of its components. Click on “Yes”.
The uninstall process will begin. Follow the on-screen instructions to
complete the process.
8
Uninstallation for Windows 98, Me, 2000, and XP
P74113qb_F8E815spBNDL_man.qxd 24-01-2003 13:50 Page 8

Information
FCC Statement
DECLARATION OF CONFORMITY WITH FCC RULES FOR
ELECTROMAGNETIC COMPATIBILITY
We, Belkin Corporation, of 501 West Walnut Street, Compton, CA 90220, declare under our
sole responsibility that the product, F8E815spBNDL
to which this declaration relates,
complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)
this device may not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
CE De laration of Conformity
We, Belkin Corporation, declare under our sole responsibility, that the F8E815spBNDL to which this
declaration relates, is in conformity with EN55022, EN61000-3-2, EN61000-3-3, and EN55024.
Caution: Exposure to Radio Frequen y Radiation.
The radiated output power of this device is far below the FCC radio frequency
exposure limits. Nevertheless, the device shall be used in such manner that the potential for
human contact normal operation is minimized.
When connecting an external antenna to the device, the antenna shall be placed
in such a manner to minimize the potential for human contact during normal
operation. In order to avoid the possibility of exceeding the FCC radio frequency exposure limits,
human proximity to the antenna shall not be less than 20cm (8inches) during normal operation.
Federal Communi ations Commission Noti e
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation.
This equipment generates, uses, and can radiate radio frequency energy. If not installed and used
in accordance with the instructions, it may cause harmful
interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try and correct the interference by one or
more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the distance between the equipment and the receiver.
• Connect the equipment to an outlet on a circuit different from that to
which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
9
En
P74113qb_F8E815spBNDL_man.qxd 24-01-2003 13:50 Page 9

Modifi ations
The FCC requires the user to be notified that any changes or modifications to this device
that are not expressly approved by Belkin Components may void the users authority to
operate the equipment.
Belkin Corporation Limited Lifetime Produ t Warranty
Belkin Corporation warrants this product against defects in materials and workmanship for
its lifetime. If a defect is discovered, Belkin will, at its option, repair or replace the
product at no charge provided it is returned during the warranty period, with
transportation charges prepaid,
to the authorized Belkin dealer from whom you purchased the product. Proof of purchase
may be required.
This warranty does not apply if the product has been damaged by accident, abuse, misuse,
or misapplication; if the product has been modified without the written permission of
Belkin; or if any Belkin serial number has been removed or defaced.
THE WARRANTY AND REMEDIES SET FORTH ABOVE ARE EXCLUSIVE IN LIEU OF ALL OTHERS,
WHETHER ORAL OR WRITTEN, EXPRESSED OR IMPLIED. BELKIN SPECIFICALLY DISCLAIMS ANY
AND ALL IMPLIED WARRANTIES, INCLUDING, WITHOUT LIMITATION, WARRANTIES OF
MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.
No Belkin dealer, agent, or employee is authorized to make any modification, extension,
or addition to this warranty.
BELKIN IS NOT RESPONSIBLE FOR SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES
RESULTING FROM ANY BREACH OF WARRANTY, OR UNDER ANY OTHER LEGAL THEORY,
INCLUDING BUT NOT LIMITED TO, LOST PROFITS, DOWNTIME, GOODWILL, DAMAGE TO OR
REPROGRAMMING, OR REPRODUCING ANY PROGRAM OR DATA STORED IN, OR USED WITH,
BELKIN PRODUCTS.
Some states do not allow the exclusion or limitation of incidental or consequential damages
or exclusions of implied warranties, so the above limitations of exclusions may not apply to
you. This warranty gives you specific legal rights, and you may also have other rights that
vary from state to state.
10
Information
P74113qb_F8E815spBNDL_man.qxd 24-01-2003 13:50 Page 10

Information
11
Canada- Industry Canada (IC)
The wireless radio of this device complies with RSS 139 & RSS 210 Industry Canada.
This Class B digital complies with Canadian ICES-003.
Cet appareil numérique de la classe B conforme á la norme NMB-003 du Canada.
Europe-European Union Noti e
Radio products with the CE 0560 or CE alert marking comply
with the R&TTE Directive (1995/5/EC) issued by the Commission
of the European Community.
Compliance with this directive implies conformity to the following
European Norms (in brackets are the equivalent international standards).
• EN 60950 (IEC60950) – Product Safety
• EN 300 328 Technical requirement for radio equipment
• ETS 300 826 General EMC requirements for radio equipment.
To determine the type of transmitter, check the identification label
on your Belkin product.
Products with the CE marking comply with the EMC Directive (89/336/EEC) and the
Low Voltage Directive (72/23/EEC) issued by the Commission of the European Community.
Compliance with these directives implies conformity to the following European Norms
(in brackets are the equivalent international standards).
• EN 55022 (CISPR 22) – Electromagnetic Interference
• EN 55024 (IEC61000-4-2,3,4,5,6,8,11)- Electromagnetic Immunity
• EN 61000-3-2 (IEC610000-3-2) - Power Line Harmonics
• EN 61000-3-3 (IEC610000) – Power Line Flicker
• EN 60950 (IEC60950) – Product Safety
Products that contain the radio transmitter are labeled with CE 0560 or CE alert marking
and may also carry the CE logo.
En
P74113qb_F8E815spBNDL_man.qxd 24-01-2003 13:50 Page 11

Belkin Components Limited Lifetime Produ t Warranty
Belkin Components warrants this product against defects in materials and workmanship for its
lifetime. If a defect is discovered, Belkin will, at its option, repair or replace the product at
no charge provided it is returned during the warranty period, with transportation charges
prepaid, to the authorized Belkin dealer from whom you purchased the product. Proof of
purchase may be required.
This warranty does not apply if the product has been damaged by accident, abuse, misuse, or
misapplication; if the product has been modified without the written permission of Belkin; or
if any Belkin serial number has been removed or defaced.
THE WARRANTY AND REMEDIES SET FORTH ABOVE ARE EXCLUSIVE IN LIEU OF ALL OTHERS,
WHETHER ORAL OR WRITTEN, EXPRESSED OR IMPLIED. BELKIN SPECIFICALLY DISCLAIMS ANY AND
ALL IMPLIED WARRANTIES, INCLUDING, WITHOUT LIMITATION, WARRANTIES OF MERCHANTABILITY
AND FITNESS FOR A PARTICULAR PURPOSE.
No Belkin dealer, agent, or employee is authorized to make any modification, extension, or
addition to this warranty.
BELKIN IS NOT RESPONSIBLE FOR SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES
RESULTING FROM ANY BREACH OF WARRANTY, OR UNDER ANY OTHER LEGAL THEORY,
INCLUDING BUT NOT LIMITED TO, LOST PROFITS, DOWNTIME, GOODWILL, DAMAGE TO OR
REPROGRAMMING, OR REPRODUCING ANY PROGRAM OR DATA STORED IN, OR USED WITH,
BELKIN PRODUCTS.
Some states do not allow the exclusion or limitation of incidental or consequential damages or
exclusions of implied warranties, so the above limitations of exclusions may not apply to you.
This warranty gives you specific legal rights, and you may also have other rights that vary from
state to state.
12
Information
P74113qb_F8E815spBNDL_man.qxd 24-01-2003 13:50 Page 12

© 2003 Belkin Corporation. All rights reserved.
All trade names are registered trademarks of respective manufacturers listed.
P74113qb
Belkin Components B.V.
Starparc Building • Boeing Avenue 333
1119 PH Schiphol-Rijk • The Netherlands
Tel: [phone]
Fax: [phone]
Belkin Components, Ltd.
Express Business Park
Shipton Way • Rushden • NN10 6GL
United Kingdom
Tel: [phone]
Fax: [phone]
Belkin Corporation
501 West Walnut Street
Compton • CA • 90220 • USA
Tel: [phone]
Fax: [phone]
Belkin, Ltd.
7 Bowen Crescent • West Gosford
NSW 2250 • Australia
Tel: [phone]
Fax: [phone]
Belkin Tech Support
US: 310.898.1100 ext. 2263
800.223.5546 ext. 2263
Europe: 00 800 223 55 460
Australia: 1800 666 040
P74113qb_F8E815spBNDL_man.qxd 24-01-2003 13:50 Page 13

P74113qb_F8E815spBNDL_man.qxd 24-01-2003 13:50 Page 14
