Belkin SOUNDFORM AUD001btBK Assembly instructions

Getting to know the Belkin SOUNDFORM™ Mini Wireless On-Ear Headphones for Kids
The Belkin SOUNDFORM™ Mini Wireless On-Ear Headphones for Kids is a 3.5 mm Bluetooth®
5.0 headphone designed to work with the most popular distance learning applications. It
features up to 30-hour continuous audio playback time from a battery at 100% charge at 50%
volume, and it has a built-in microphone for video and phone calls. It can be used either
through a wired or wireless connection through Bluetooth within a 30-ft connection range.

Product Features
•Bluetooth 5.0 with a 30-ft connection range
•Built-in microphone for video and phone calls
•Maximum volume of 85 dB to ensure ear protection
•Compatible with learning devices and video conference learning platforms
•Protective carrying case available as an add-on purchase
•500mAh battery capacity with up to 30 hours continuous audio playback time
•Charges from 0 to 100% in under 2 hours
•Size-adjustable headband
•Synthetic leather over-ear comfort cushion cups
•Status indicator light
•Control buttons
•Micro USB port for charging
•2-year warranty
Colors
This headphone comes in the following variants and colors:
No Case
•Black: AUD001btBK
•Blue: AUD001btBL
•Pink: AUD001btPK
•White: AUD001btWH
•Black: AUD002btBK
•Blue: AUD002btBL
•Pink: AUD002btPK
•White: AUD002btWH
With Case
•Black: AUD001btBKCS
•Blue: AUD001btBLCS
•Pink: AUD001btPKCS
•White: AUD001btWHCS
•Black: AUD002btBKCS
•Blue: AUD002btBLCS
•Pink: AUD002btPKCS

•White: AUD002btWHCS
Compatibility
This device is designed and has been tested for compatibility with the following devices:
•iPhone® 12
•iPhone 11 Pro Max
•iPhone 11 Pro
•iPhone 11
•iPhone X Pro
•iPhone XS Max
•iPhone XS
•iPhone XR
•iPhone X
•iPhone 8
•iPhone 7 plus
•iPhone 7
•iPhone 6s plus
•iPhone 6s
•iPhone 6
•iPad Air® 2
•iPad Air 2019
•iPad Air 2020
•iPad mini™ 1st generation
•iPad mini 2nd generation
•iPad mini 3rd generation
•iPad mini 4th generation
•iPad mini 5th generation
•iPad Pro®
•iPad Pro 2nd generation
•iPad Pro 3rd generation
•iPad Pro 4th generation
•Amazon Fire tablet 10.1" 2019 model
•Amazon Fire tablet 8" 2018 model
•Amazon Fire tablet 10.1" 2017 model
•Amazon Fire tablet 8" 2017 model
•Amazon Fire tablet 8" 2016 model
•Amazon Fire tablet 10.1" 2015 model
•Amazon Fire tablet 8" 2015 model
•Amazon Fire tablet 8" 2015 model
•Amazon Fire tablet 7" 2014 model

•Amazon Fire tablet 6" 2014 model
•Amazon Fire tablet 7" 2013 model
•Amazon Fire tablet 8.9" 2012 model
•Amazon Fire tablet 7" 2012 model
•Google Pixel™ book Go (i5 model)
•Lenovo® Chromebook™ C340-11
•Acer® Chromebook Spin 311 (R721T)
•ASUS® Chromebook Flip C434
•Lenovo 300e Chromebook 2nd Gen (MTK)
•ASUS Chromebook Flip C101PA
•Dell® Latitude 5300 2-in-1 Chromebook Enterprise
How to pair your Belkin AUD002 with your wireless device
The Belkin AUD002 is a 3.5 mm Bluetooth® 5.0 headphone that is made for kids. It is designed
to work with the most popular distance learning applications. It features up to 30 hours of
continuous audio playback time from a battery at 100% charge at 50% volume, and it has a
built-in microphone for video and phone calls. It can be used either through a wired or wireless
connection via Bluetooth within a 30 ft connection range.
This article will show you how to pair your headphone with a wireless device.
1. Press the power button on the headphone for 2 seconds.
2. On your mobile device, turn ON Bluetooth to begin searching for nearby devices. Note that
steps in enabling your Bluetooth may vary depending on your device's operating system.
3. Wait until the blue light flashes on your headphone, which means that it is pairing with your
device. The blue light will turn solid and then turn OFF, indicating that the headphone is now
paired with your wireless device.

Belkin SOUNDFORM™ Mini Wireless On-Ear Headphones for Kids Frequently Asked Questions
TABLE OF CONTENTS
PRODUCT INFORMATION
1. What is the Belkin SOUNDFORM™ Mini Wireless On-Ear Headphones for Kids?
2. What is the warranty of this headphone?
3. Does the headphone come with a Connected Equipment Warranty (CEW)?
4. Is the headphone REACH-certified?
5. Is the headphone USB-IF-certified?
6. Is the headphone RoHS-certified?
HARDWARE INFORMATION
1. What is the battery capacity of this product?
2. In what colors are the headphone available in?
3. What connectors are on this product?
4. What are the recommended operating and storage temperatures of this product?
5. What can I use to charge the headphone?
6. How long does the headphone charging time take?
7. Does this product have control buttons?
8. Does it have a microphone?
9. What is the weight of the headphone?

FUNCTIONALITY
1. Can I use this product outdoors?
2. Can I clean the headphone with a damp cloth?
3. What is the Bluetooth® ID of the headphone?
4. Can I use this headphone wired to my phone?
5. What is the maximum volume of this headphone?
6. Can I adjust the headband for ear comfort?
COMPATIBILITY
1. What devices will the Belkin SOUNDFORM™ Mini Wireless On-Ear Headphones for Kids work
with?
PRODUCT INFORMATION
1. What is the Belkin SOUNDFORM™ Mini Wireless On-Ear Headphones for Kids?
The Belkin SOUNDFORM™ Mini Wireless On-Ear Headphones for Kids is a 3.5 mm Bluetooth
5.0 headphone that is made for kids. It is designed to work with the most popular distance
learning applications. It features up to 30-hour continuous audio playback time from a battery
at 100% charge at 50% volume, and it has a built-in microphone for video and phone calls. It
can be used either through wired or wireless connection through Bluetooth within 30 ft
connection range.
2. What is the warranty of this headphone?
The headphone has a 2-year warranty.
3. Does the headphone come with a Connected Equipment Warranty (CEW)?
No.
4. Is the headphone REACH-certified?
Yes.
5. Is the headphone USB-IF-certified?
Yes.

6. Is the headphone RoHS-certified?
Yes.
HARDWARE INFORMATION
1. What is the battery capacity of this product?
The headphone has a 500 mAh battery capacity.
2. In what colors are the headphone available in?
The headphone is available in black, blue, pink, and white.
3. What connectors are on this product?
This product comes with a micro USB cable for charging the headphone and a 3.5-mm cable for
an optional wired connection.
4. What are the recommended operating and storage temperatures of this product?
The recommended operating and storage temperatures are:
•Storage temperature: -30°C to 70°C with humidity 5% to 95% RH
•Operating temperature: 0°C to 40°C with humidity 10% to 90% RH
5. What can I use to charge the headphone?
You can charge this headphone using the included micro USB cable.
6. How long does the headphone charging time take?
The battery charges from 0% to 100% in under 2 hours.
7. Does this product have control buttons?
Yes.
8. Does it have a microphone?
Yes.

9. What is the weight of the headphone?
This headphone weighs approximately 0.14 kg.
FUNCTIONALITY
1. Can I use this product outdoors?
This product is meant for use indoors and outdoors.
2. Can I clean the headphone with a damp cloth?
Yes.
3. What is the Bluetooth® ID of the headphone?
The headphone should be identified using the Bluetooth ID "SOUNDFORM Juniors".
4. Can I use this headphone wired to my phone?
Yes.
5. What is the maximum volume of this headphone?
The headphone has 85 dB maximum volume.
6. Can I adjust the headband for ear comfort?
Yes.
COMPATIBILITY
1. What devices will the Belkin SOUNDFORM™ Mini Wireless On-Ear Headphones for Kids
work with?
This device is designed and has been tested for compatibility with the following devices:
•iPhone® 12
•iPhone 11 Pro Max
•iPhone 11 Pro
•iPhone 11
•iPhone X Pro
•iPhone X

•iPhone 8
•iPhone 7
•iPhone 6s
•iPhone 6
•iPad Air® 2
•iPad Air 2019
•iPad Air 2020
•iPad mini™ 1st generation
•iPad mini 2
•iPad mini 3
•iPad mini 4
•iPad mini 5th generation
•iPad Pro®
•iPad Pro 2nd generation
•iPad Pro 3rd generation
•iPad Pro 4th generation
•Amazon Fire tablet 10.1" 2019 model
•Amazon Fire tablet 8" 2018 model
•Amazon Fire tablet 10.1" 2017 model
•Amazon Fire tablet 8" 2017 model
•Amazon Fire tablet 8" 2016 model
•Amazon Fire tablet 10.1" 2015 model
•Amazon Fire tablet 8" 2015 model
•Amazon Fire tablet 8" 2015 model
•Amazon Fire tablet 7" 2014 model
•Amazon Fire tablet 6" 2014 model
•Amazon Fire tablet 7" 2013 model
•Amazon Fire tablet 8.9" 2012 model
•Amazon Fire tablet 7" 2012 model
•Google Pixel™ book Go (i5 model)
•Lenovo® Chromebook™ C340-11
•Acer® Chromebook Spin 311 (R721T)
•ASUS® Chromebook Flip C434
•Lenovo 300e Chromebook 2nd Gen (MTK)
•ASUS Chromebook Flip C101PA
•Dell® Latitude 5300 2-in-1 Chromebook Enterprise
How to reset your Belkin SOUNDFORM™ Mini Wireless On-Ear Headphones for Kids
The Belkin SOUNDFORM™ Mini Wireless On-Ear Headphones for Kids is a 3.5 mm Bluetooth®
5.0 headphone that is made for kids. It is designed to work with the most popular distance
learning applications. It features up to 30-hour continuous audio playback time from a battery
at 100% charge at 50% volume, and it has a built-in microphone for video and phone calls. It
can be used wired or wirelessly through a Bluetooth connection within a 30-ft range.

The steps below will show you how to reset your headphone.
Step 1:
Press and hold both the +and -volume buttons on the headphone for 10 seconds. The
power light will blink red.
Step 2:
Wait until the power light blinks blue three times, and then turn OFF.
Step 3:
Press and hold the power button for 4 seconds. Your headphone should now be ready to pair
again.
You have now successfully reset your headset.
