Belkin F5U220ea User manual

Hi-Speed USB 2.0
5-Port PCI Card
Connect up to 5 devices for
ultrafast data transfers
User Manual
F5U220ea
En
Fr
De
Nl
Es
It
P73768ea-B_F5U220uk 17-03-2003 13:46 Page 1

P73768ea-B_F5U220uk 17-03-2003 13:46 Page 2

En
TABLE OF CONTENTS
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
USB Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Package Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
System Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Operating System Compatibility . . . . . . . . . . . . . . . . . . . . . .3
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Installation Procedure for Windows 98 SE . . . . . . . . . . . . . . .4
Installation Procedure for Windows Me . . . . . . . . . . . . . . . . .7
Installation Procedure for Windows 2000 . . . . . . . . . . . . . . . .9
Installing the Microsoft Driver . . . . . . . . . . . . . . . . . . . . . . .9
Installing the Belkin Driver . . . . . . . . . . . . . . . . . . . . . . . .11
Installation Procedure for Windows XP . . . . . . . . . . . . . . . . .13
Installing a Hi-Speed USB 2.0 Hub . . . . . . . . . . . . . . . . . . .14
Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
P73768ea-B_F5U220uk 17-03-2003 13:46 Page 3

P73768ea-B_F5U220uk 17-03-2003 13:46 Page 4

1
En
INTRODUCTION
Welcome to Belkin Hi-Speed Connectivity!
Thank you for purchasing the Belkin Hi-Speed USB 2.0 5-Port PCI Card
(the PCI Card).
Now you can upgrade your computer to the latest USB technology, for
better speed and performance. You will be able to take advantage of a
host of new Hi-Speed USB 2.0 products!
Connecting your USB 2.0 products to your computer with the PCI Card
will allow them to work much faster than ever before. This includes your
hard drives, scanners, printers, video cameras, and more. Your current or
previous-version USB devices will continue to work as they always have,
and in some cases even better, with the PCI Card. Just follow the simple
installation instructions in this manual to get your PCI Card set up and
working well—then, enjoy the speed and convenience of Belkin USB
connectivity!
P73768ea-B_F5U220uk 17-03-2003 13:46 Page 1

2
OVERVIEW
Features
• Two OHCI USB host controllers and one EHCI host controller integrated
into a single PCI Card
• Five Hi-Speed USB 2.0 ports
• Simultaneous connection capability for low-, full-, and high-speed USB
devices
• Auto-detection of new devices as they are connected, along with the
speed of each device
• Backward-compatibility with USB 1.1 devices
• Full compliance with USB specifications
• Plug-and-Play technology
USB Specifications
• Open Host Controller Interface- (OHCI-) compliant (USB 1.1 Host
Controller)
• Enhanced Host Controller Interface- (EHCI-) compliant (USB 2.0 Host
Controller)
• PCI revision 2.1-compliant
• Current: 500mA per port
• USB revision 2.0-compliant
P73768ea-B_F5U220uk 17-03-2003 13:46 Page 2

3
En
OVERVIEW
Package Contents
• Belkin Hi-Speed USB 2.0 5-Port PCI Card
• User Manual
• Installation CD
System Requirements
• 266MHz Pentium® II
• 32MB RAM
• One available PCI 2.1-compliant PCI slot
• Windows® 98 SE, 2000, Me, or XP operating system
Operating System Compatibility
Operating System USB 1.x Support USB 2.0 Support
Windows 98 SE Yes Yes
Windows 2000 Yes Yes
Windows Me Yes Yes
Windows XP Yes Yes
P73768ea-B_F5U220uk 17-03-2003 13:46 Page 3

4
INSTALLATION
Please refer to the section that corresponds to your version of the
Windows operating system.
Installation Procedure for Windows 98 SE
This procedure will install two USB 1.1 OHCI controllers and one USB 2.0
EHCI host controller.
1. Insert the F5U220 installation CD into your CD-ROM drive.
After a few moments, the main menu will start automatically.
2. Select “Install USB 2.0 Driver”. After the driver is installed, select “No
I will restart my computer later”.
3. Click the “Start” button in the lower left-hand corner of your
Windows desktop display. Next click “Shutdown” then choose
“Shutdown” from the drop-down menu.
4. Remove the computer’s cover and locate an empty PCI slot.
5. Remove the port cover that corresponds with the PCI slot you wish to
use. (The cover is usually held in place with a single screw.)
6. Insert the PCI Card into the slot. Apply pressure as needed until the
Card is fully seated. Secure the PCI Card with the screw removed in
step 5.
7. After installing the PCI Card, replace the outer cover and turn on the
computer.
Note: Do not plug any devices into the PCI Card until driver installation is
completely finished.
8. When Windows restarts, the PCI Card will be detected and installation
of the PCI Card drivers will begin.
Note: Depending on the speed of your computer, it may take up to 30-60
seconds for the PCI Card to be detected.
P73768ea-B_F5U220uk 17-03-2003 13:46 Page 4

5
En
INSTALLATION
9. Windows will detect the “NEC USB Open Host Controller”. Click “Next”.
10. Select “Search for the best driver for your device” and click “Next”.
11. Uncheck all the boxes and click “Next”.
12
. Windows will locate drivers for the “NEC USB Open
Host Controller”. Click “Next”.
Note: Windows may prompt you to insert your Windows 98 SE installation
CD at this time.
13. After Windows installs the OHCI host controller drivers, installation
of the first host controller is complete. Click “Finish”.
14. The “Add New Hardware” wizard will repeat the installation process
for the second OHCI host controller.
15. Repeat steps 9-13.
16. Windows will now detect “Belkin USB 2.0 High Speed Host
Controller”. Click “Next”.
17. Windows will locate the EHCI host controller drivers and complete
installation of the “Belkin USB 2.0 High Speed Host Controller” and
“USB 2.0 Root Hub Device”.
Installation of the PCI Card is now complete.
P73768ea-B_F5U220uk 17-03-2003 13:46 Page 5

6
INSTALLATION
Verifying Proper Installation (Windows 98 SE)
Check the “Windows Device Manager” to confirm that your PCI Card has
been properly installed.
1. Right-click on “My Computer” and select “Properties”.
2. Select the “Device Manager” tab.
3. After installation of the Belkin USB 2.0 driver, you will notice that an
additional “Universal Serial Bus Controllers” heading has been added
to the device list.
a) Click the plus sign (+) next to the original “Universal Serial Bus
Controllers” heading. You will find that two “NEC USB Open Host
Controller” entries and two “USB Root Hub” entries have been
added to the list of devices.
b) Click the plus sign (+) next to the new “Universal Serial Bus
Controllers” heading. You will find one entry for “Belkin USB 2.0
Hi-Speed Host Controller” and one entry for “USB 2.0 Root Hub
Device”.
Note: If your computer features built-in USB ports, or if you have other
USB PCI controller cards installed, you will see additional USB
controller and root hub entries in the Device Manager list.
P73768ea-B_F5U220uk 17-03-2003 13:46 Page 6

7
En
INSTALLATION
Installation Procedure for Windows Me
This procedure will install two USB 1.1 OHCI host controllers and one
USB 2.0 EHCI host controller.
1. Insert the F5U220 installation CD into your CD-ROM drive. After a few
moments, the main menu will start automatically.
2. Select “Install USB 2.0 Driver”. After the driver is installed, select
“No, I will restart my computer later”. Click “Close”.
3. Click the “Start” button in the lower left-hand corner of your
Windows desktop display. Next, click “Shutdown” then choose
“Shutdown” from the drop-down menu.
4. Remove the computer’s cover and locate an empty PCI slot.
5. Remove the port cover that corresponds with the PCI slot you wish to
use. (The cover is usually held in place with a single screw.)
6. Insert the PCI Card into the slot. Apply pressure as needed until the
Card is fully seated. Secure the PCI Card with the screw removed in
step 5.
7. After installing the PCI Card, replace the outer cover and turn on the
computer.
Note: Do not plug any devices into the PCI Card until driver installation is
completely finished.
8. When Windows restarts, the PCI Card will be detected and installation
of the host controller drivers will begin.
Note: on the speed of your computer, it may take up to 30-60 seconds for
the PCI Card to be detected.
P73768ea-B_F5U220uk 17-03-2003 13:46 Page 7

8
INSTALLATION
9. Windows will detect two “NEC USB Open Host Controller (E13+)”
entries and two “USB Root Hub” entries. The required driver support
will be automatically installed. No user input is required.
10. Windows will then detect the “Belkin USB 2.0 Hi-Speed USB Host
Controller” and “USB 2.0 Root Hub Device”. The required driver
support will be automatically installed. No user input is required.
Installation of the PCI Card is now complete.
Verifying Proper Installation
After installation, check the Windows Device Manager to confirm that the
PCI Card has been properly installed.
1. Right-click on “My Computer” and select “Properties”.
2. Select the “Device Manager” tab.
3. After installation of the Belkin USB 2.0 driver, you will notice that an
additional “Universal Serial Bus Controllers” heading has been added
to the device list.
a) Click the plus sign (+) next to the original “Universal Serial Bus
Controllers” heading. You will find that two “NEC USB Open Host
Controller (E13+)” entries and two “USB Root Hub” entries have
been added to the list of devices.
b) Click the plus sign (+) next to the new “Universal Serial Bus
Controllers” heading. You will find one entry for “Belkin USB 2.0
Hi-Speed Host Controller” and one entry for “USB 2.0 Root Hub
Device”.
Note: If your computer features built-in USB ports, or if you have other
USB PCI controller cards installed, you will see additional USB
controller and root hub entries in the Device Manager list.
P73768ea-B_F5U220uk 17-03-2003 13:46 Page 8

9
En
INSTALLATION
Installation Procedure for Windows 2000
This procedure will install two USB 1.1 OHCI controllers and one USB 2.0
EHCI host controller.
Important Note: There are two methods of installing the required USB 2.0
drivers in Windows 2000.
1. If you have an Internet connection:
Windows 2000 will check the Windows update website and download
the most recent version of Microsoft USB 2.0 support drivers. Please
proceed to the “Installing the Microsoft Driver” section.
2. If you do not have an Internet connection:
USB 2.0 drivers will be installed from the Belkin Driver Installation
CD. Please proceed to the “Installing the Belkin Driver” section.
Installing the Microsoft Driver
1. Make sure your computer is completely powered down.
2. Remove the computer’s cover and locate an empty PCI slot.
3. Remove the port cover that corresponds with the PCI slot you wish to
use. (The cover is usually held in place with a single screw.)
4. Insert the PCI Card into the slot. Apply pressure as needed until the
Card is fully seated. Secure the PCI Card with the screw removed in
step 3.
5. After installing the PCI Card, replace the outer cover and turn on the
computer.
Note: Do not plug any devices into the PCI Card until driver installation is
completely finished.
Note: Depending on the speed of your computer, it may take up to 30-60
seconds for the PCI Card to be detected.
P73768ea-B_F5U220uk 17-03-2003 13:46 Page 9

10
INSTALLATION
6. Windows will now search for drivers for the “Universal Serial Bus
Controller”, and the “New Hardware Wizard” will start. Click “Next”.
7. Select “Search for suitable driver for my device (Recommended)”. Click
“Next”.
8. Select “Microsoft Windows Update”. Click “Next”.
Note: If the “Microsoft Windows Update” option is not available, double-
check your connection to the Internet. If you are having problems
connecting to the Internet, proceed to the “Installing the Belkin
Driver” section.
9. The driver for “Universal Serial Bus Controller” will be located. Click
“Next”.
10. The driver for “Standard Enhanced PCI to USB Host Controller” will
now be installed. Click “Finish”.
The installation procedure is now complete.
Verifying Proper Installation (Microsoft Driver)
After installation, check the Device Manager to confirm that the PCI Card
has been properly installed.
1. Right-click on “My Computer”.
2. Select “Properties”.
3. Select the “Hardware” tab and click on the “Device Manager” button.
4. Click the plus sign (+) next to “Universal Serial Bus Controllers”.
The “Universal Serial Bus Controllers” list will now include two “NEC USB
Open Host Controller” entries, two additional “USB Root Hub” entries,
one “Standard Universal PCI to USB Host Controller” entry, and one “USB
2.0 Root Hub Device” entry.
P73768ea-B_F5U220uk 17-03-2003 13:46 Page 10

11
En
INSTALLATION
Note: If your computer features built-in USB ports, or if you have other
USB PCI controller cards installed, you will see additional USB
controller and root hub entries in the Device Manager list.
Installing the Belkin Driver
1. Insert the F5U220 installation CD into your CD-ROM drive. After a few
moments, the main menu will automatically start.
2. Select “Install USB 2.0 Driver”. After the driver is installed, select
“No, I will restart my computer later”.
3. Click the “Start” button in the lower left-hand corner of your
Windows desktop display. Next, select “Turn off Computer” then select
“Turn Off”.
4. Remove the computer’s cover and locate an empty PCI slot.
5. Remove the port cover that corresponds with the PCI slot you wish to
use. (The cover is usually held in place with a single screw.)
6. Insert the PCI Card into the slot. Apply pressure as needed until the
card is fully seated. Secure the PCI Card with the screw removed in
step 5.
7. After installing the PCI Card, replace the outer cover and turn on the
computer.
Note: Do not plug any devices into the PCI Card until driver installation is
completely finished.
8. When Windows restarts, the PCI Card will be detected and all required
drivers will be automatically installed.
Note: Depending on the speed of your computer, it may take 30-60
seconds for the PCI Card to be detected.
P73768ea-B_F5U220uk 17-03-2003 13:46 Page 11

12
INSTALLATION
Verifying Proper Installation (Belkin Driver)
After installation is complete, check the Windows Device Manager to
confirm that all components of the PCI Card have been properly
installed.
1. Right-click on “My Computer”.
2. Select “Properties”.
3. Select the “Hardware” tab and click on the “Device Manager” button.
4. After installation of the Belkin USB 2.0 driver, you will notice that a
second “Universal Serial Bus Controllers” heading has been added to
the device list.
a) Click the plus sign (+) next to the original “Universal Serial Bus
Controllers” heading. You will find that two “NEC USB Open Host
Controller” entries and two “USB Root Hub” entries have been
added to the list of devices.
b) Click the plus sign (+) next to the new “Universal Serial Bus
Controllers” heading. You will find one entry for “Belkin USB 2.0
Hi-Speed Host Controller” and one entry for “USB 2.0 Root Hub
Device”.
Note: If your computer features built-in USB ports, or if you have other
USB PCI controller cards installed, you will see additional USB
controller and root hub entries in the Device Manager list.
P73768ea-B_F5U220uk 17-03-2003 13:46 Page 12

13
En
INSTALLATION
Installation Procedure for Windows XP
This installation procedure will install two USB 1.1 OHCI controllers and
one USB 2.0 EHCI host controller.
Important Note: If you have already upgraded to Windows XP Service
Pack 1, support for your PCI Card is already installed on
your computer. If you have not upgraded to Windows XP
Service Pack 1, or if you wish to use the Belkin driver,
proceed to the “Installing Belkin Driver” section.
Using the Windows XP Service Pack 1 Driver
1. Make sure your computer is completely powered down.
2. Remove the computer’s cover and locate an empty PCI slot.
3. Remove the port cover that corresponds with the PCI slot you wish to
use. (The cover is usually held in place with a single screw.)
4. Insert the PCI Card into the slot. Apply pressure as needed until the
Card is fully seated. Secure the PCI Card with the screw removed in
step 3.
5. After installing the PCI Card, replace the outer cover and turn on the
computer.
Note: Depending on the speed of your computer, it may take up to 30-60
seconds for the PCI Card to be detected.
6. When Windows restarts, the PCI Card will be detected and drivers for
the two USB OHCI host controllers and the EHCI host controller will
be automatically installed. Installation is now complete.
P73768ea-B_F5U220uk 17-03-2003 13:46 Page 13

14
INSTALLATION
Verifying Proper Installation (Microsoft Driver)
After installation, check the Device Manager to confirm that the PCI Card
has been properly installed.
1. Right-click on “My Computer”.
2. Select “Properties”.
3. Select the “Hardware” tab and click on the “Device Manager” button.
4. Click the plus sign (+) next to “Universal Serial Bus Controllers”.
The “Universal Serial Bus Controllers” list will now include two “NEC USB
Open Host Controller”, one “Standard Enhanced PCI to USB Host
Controller”, one “USB 2.0 Root Hub Device”, and two “USB Root Hub”
entries.
Note: If your computer features built-in USB ports, or if you have other
USB PCI controllers installed, you will see additional host controller
and root hub entries.
Installing a Hi-Speed USB 2.0 Hub
Note: During installation of the Hi-Speed USB 2.0 PCI Card driver, a Hi-
Speed USB 2.0 hub driver is also installed. For instructions regarding
the installation of your USB 2.0 hub, consult the documentation
included with your hub.
P73768ea-B_F5U220uk 17-03-2003 13:46 Page 14

15
En
P73768ea-B_F5U220uk 17-03-2003 13:46 Page 15

16
INFORMATION
FCC Statement
DECLARATION OF CONFORMITY WITH FCC RULES FOR ELECTROMAGNETIC
COMPATIBILITY
We, Belkin Corporation, of 501 West Walnut Street, Compton, CA 90220, declare under our sole
responsibility that the product:
F5U220
to which this declaration relates:
Complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
CE Declaration of Conformity
We, Belkin Corporation, declare under our sole responsibility that the F5U220, to which this
declaration relates, is in conformity with Generic Emissions Standard EN50081-1 and with
Generic Immunity Standard EN50082-1 1992.
Belkin Corporation Limited Lifetime Product Warranty
Belkin Corporation warrants this product against defects in materials and workmanship for its
lifetime. If a defect is discovered, Belkin will, at its option, repair or replace the product at no
charge provided it is returned during the warranty period, with transportation charges prepaid,
to the authorized Belkin dealer from whom you purchased the product. Proof of purchase may
be required.
This warranty does not apply if the product has been damaged by accident, abuse, misuse, or
misapplication; if the product has been modified without the written permission of Belkin; or
if any Belkin serial number has been removed or defaced.
THE WARRANTY AND REMEDIES SET FORTH ABOVE ARE EXCLUSIVE IN LIEU OF ALL OTHERS,
WHETHER ORAL OR WRITTEN, EXPRESSED OR IMPLIED. BELKIN SPECIFICALLY DISCLAIMS ANY
AND ALL IMPLIED WARRANTIES, INCLUDING, WITHOUT LIMITATION, WARRANTIES OF
MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.
No Belkin dealer, agent, or employee is authorized to make any modification, extension, or
addition to this warranty.
BELKIN IS NOT RESPONSIBLE FOR SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES
RESULTING FROM ANY BREACH OF WARRANTY, OR UNDER ANY OTHER LEGAL THEORY, INCLUDING
BUT NOT LIMITED TO LOST PROFITS, DOWNTIME, GOODWILL, DAMAGE TO OR REPROGRAMMING
OR REPRODUCING ANY PROGRAM OR DATA STORED IN OR USED WITH BELKIN PRODUCTS.
P73768ea-B_F5U220uk 17-03-2003 13:46 Page 16
