INTRODUCTION
Welcome to Belkin Hi-Speed Connectivity!
Thank you for purchasing the Belkin Hi-Speed USB 2.0 and FireWire PCI
Card (the PCI Card).
Now you can upgrade your computer to the latest USB and FireWire
technology. You will be able to take advantage of a host of new Hi-
Speed USB 2.0 and FireWire products!
Your USB 2.0 and FireWire products including hard drives, scanners,
printers, video cameras, and more will all work much faster than ever
before. Your current USB devices will continue to work as they always
have and, in some cases, even better with this PCI Card. Follow the
simple installation instructions in this manual to get your PCI Card up
and working—then enjoy the speed and convenience of Belkin!
P73954ea-A_F5U508ea_uk 28-03-2003 14:27 Page 1

2
OVERVIEW
Features
• Three USB host controllers integrated into a single PCI Card
• 3 Hi-Speed USB 2.0 ports
• One IEEE 1394 host controller
• 2 high-speed FireWire ports
• Simultaneous connection capability for Low-, Full-, and Hi-speed
devices
• Auto-detection of new devices as they are connected, along with the
speed of each device
• Backward-compatibility with USB 1.1 devices
• Full compliance with USB specifications
• Full compatibility with OHCI compliant FireWire peripherals
• Plug-and-Play technology
• Internal power connector
Package Contents
• Belkin Hi-Speed USB 2.0 and FireWire PCI Card
• FireWire Cable (6-pin to 4-pin)
• User Manual
• Installation CD
Technical Specifications
USB Specifications
• Open Host Controller Interface- (OHCI-) compliant (USB 1.1 Host
Controller)
• EHCI-compliant (USB 2.0 Host Controller)
• PCI revision 2.1-compliant
• Current: 500mA per port
• USB revision 2.0-compliant
P73954ea-A_F5U508ea_uk 28-03-2003 14:27 Page 2

3
En
OVERVIEW
FireWire Specifications
• Two external 400Mbps IEEE 1394 ports
• OHCI 1.0 Compliant
• PCI 2.1 & 2.2 Compliant
• IEEE 1394a Rev 5 Compliant
• Internal Auxiliary power connector
• IT/AT FIFO Buffers—4k/2k
• IR/AR FIFO Buffers—4k/2k
System Requirements
• 266MHz Pentium® II processor
• 32MB RAM
• One available PCI 2.1-compliant PCI slot
• Windows® 98 SE, 2000, Me, or XP operating system
Operating System Compatibility
Operating
System
Windows
98 SE
Windows
2000
Windows Me
Windows XP
USB 1.x
Support
Yes
Yes
Yes
Yes
USB 2.0
Support
Yes
Yes
Yes
Yes
Firewire
Support
Yes
Yes
Yes
Yes
P73954ea-A_F5U508ea_uk 28-03-2003 14:27 Page 3

4
INSTALLATION
Please refer to the section that corresponds to your version of the
Windows operating system.
Installation Procedure for Windows 98 SE
This installation procedure will successfully install two USB 1.1 OHCI
controllers, one USB 2.0 EHCI host controller, and one IEEE 1394 host
controller.
1. Insert the F5U508 installation CD into your CD-ROM drive. After a few
moments the main menu will auto-start and display each of the
available installation options.
2. Select “Install USB 2.0 Driver”. After the driver is installed select “No,
I will restart my computer later”. Select “Close”. Then select “Exit”.
3. Open the Start menu in the lower left hand corner of your Windows
display, then select “Shut Down” and click “OK”.
4. Once the computer has completely shut down, remove the computer’s
cover and locate an empty PCI slot.
5. Remove the port cover that corresponds with the PCI slot you wish to
use. (The cover is usually held in place with a single screw).
6. Insert the PCI Card into the slot. Apply pressure as needed until the
card is fully seated. Secure the PCI card with the screw removed in
step #5, above.
7. After installing the PCI Card, replace the outer cover and turn on the
computer.
8. When Windows restarts, the PCI card will be detected and installation
of the required drivers will begin.
Note: Depending on the speed of your computer, it may take up to 30
seconds for the PCI card to be detected.
9. Windows will detect the “PCI Standard PCI to PCI Bridge” and the
“Add New Hardware Wizard” dialog box will open. Click “Next”.
P73954ea-A_F5U508ea_uk 28-03-2003 14:27 Page 4

5
En
INSTALLATION
10. Select “Search for the best driver for your device” and click “Next”.
11. Uncheck all the boxes and click “Next”.
12. Windows will locate the drivers for “PCI Standard PCI to PCI Bridge”.
Click “Next”.
(Windows may prompt you to insert the Windows OS installation CD.
If so, insert the CD into the CD-ROM drive and continue the
installation procedure).
13. Installation of the “PCI Standard PCI to PCI Bridge” will now
complete. Click “Finish”.
14. Windows will detect the “NEC Firewarden OHCI Compliant IEEE 1394
Host Controller”. Click “Next”.
15. Select “Search for the best driver for your device” and
click “Next”.
16. Uncheck all the boxes and click “Next”.
17. Windows will now search its driver database for the required driver.
Click “Next”.
18. Installation of the “NEC Firewarden OHCI Compliant IEEE 1394 Host
Controller” is now complete. Click “Finish”.
19. Windows will detect the “NEC USB Open Host Controller”. Click
“Next”.
20. Select “Search for the best driver for your device” and click “Next”.
21. Uncheck all the boxes and click “Next”.
22. The Windows OS will locate the drivers for “NEC USB Open Host
Controller”. Click “Next”.
23. After the Windows OS installs the required drivers, installation of the
first host controller is complete. Click “Finish”.
24. The “Add New Hardware” wizard will repeat the installation process
for the second OHCI host controller.
25. Repeat steps 20-23.
P73954ea-A_F5U508ea_uk 28-03-2003 14:27 Page 5

6
INSTALLATION
26. Windows will now detect “Belkin USB 2.0 High Speed Host
Controller”. Click “Next”.
27. Windows will locate the required drivers and complete installation of
the “Belkin USB 2.0 High Speed Host Controller” and “USB 2.0 Root
Hub Device”.
Installation of the PCI Card is now complete.
Verifying Proper Installation (Windows 98 SE)
Check the “Windows Device Manager” to confirm that your PCI Card has
been properly installed.
1. Right-click on “My Computer” and select “Properties”.
2. Select the “Device Manager” tab.
3. Click on the plus sign (+) next to “Universal Serial Bus Controllers”.
The “Universal Serial Bus Controllers” list will now include two “NEC USB
Open Host Controller” entries, one “Belkin USB 2.0 Hi-Speed Host
Controller” entry, one “USB 2.0 Root Hub Device” entry and two “USB
Root Hub” entries.
Note: If your computer features built-in USB ports, or if you have other
USB PCI controller cards installed, you will see additional USB
Controller and root hub entries.
4. Click the plus sign (+) next to “IEEE 1394 Bus Controller”.
The “IEEE 1394 Bus Controller” list will now include one “NEC Firewarden
OHCI Compliant IEEE 1394 Host Controller” entry.
Note: If your computer features built-in IEEE 1394 ports, or if you have
other IEEE 1394 PCI host controller cards installed, you will see
additional “IEEE 1394 Host Controller” entries.
P73954ea-A_F5U508ea_uk 28-03-2003 14:27 Page 6

7
En
INSTALLATION
Installation Procedure for Windows 2000
This installation procedure will successfully install two USB 1.1 OHCI
controllers, one USB 2.0 EHCI host controller, and one IEEE 1394 host
controller.
1. Insert the F5U508 installation CD into your CD-ROM drive. After a few
moments the main menu will auto-start and display each of the
available installation options.
2. Select “Install USB 2.0 Driver”. After the driver is installed select “No,
I will restart my computer later”. Select “Close”. Then select “Exit”.
3. Open the Start menu in the lower left-hand corner of your Windows
display, then select “Shut Down” and click “OK”.
4. Once the computer has completely shut down, remove the computer’s
cover and locate an empty PCI slot.
5. Remove the port cover that corresponds with the PCI slot you wish to
use. (The cover is usually held in place with a single screw).
6. Insert the PCI Card into the slot. Apply pressure as needed until the
card is fully seated. Secure the PCI card with the screw removed in
step #5, above.
7. After installing the PCI Card, replace the outer cover and turn on the
computer.
8. When Windows restarts the PCI card will be detected and all required
drivers will be automatically installed. After the install is complete,
you may be prompted to click finish and to restart.
Note: Depending on the speed of your computer, it may take up to 30
seconds for the PCI card to be detected.
P73954ea-A_F5U508ea_uk 28-03-2003 14:27 Page 7

8
INSTALLATION
Verifying Proper Installation (Windows 2000)
After installation is complete, check the Windows Device Manager to
confirm that all components of the PCI Card have been properly
installed.
1. Right-click on “My Computer”.
2. Select “Properties”.
3. Select the “Hardware” tab and click on the “Device Manager” button.
4. Click the plus sign (+) next to “Universal Serial Bus Controllers”.
The “Universal Serial Bus Controllers” list will now include two “NEC USB
Open Host Controller” entries, one “Belkin USB 2.0 Hi-Speed Host
Controller” entry, one “USB 2.0 Root Hub Device” entry and two “USB
Root Hub” entries.
Note: If your computer features built-in USB ports, or if you have other
USB PCI controllers installed, you will see additional “root hub”
entries.
5. Click the plus sign (+) next to “IEEE 1394 Bus Controller”. The “IEEE
1394 Bus Controller” list will now include one “NEC Firewarden OHCI
Compliant IEEE 1394 Host Controller” entry.
Note: If your computer features built-in IEEE 1394 ports, or if you have
other IEEE 1394 host controllers installed, you will see additional
“IEEE 1394 Host Controller” entries.
P73954ea-A_F5U508ea_uk 28-03-2003 14:27 Page 8

9
En
INSTALLATION
Installation Procedure for Windows Me
This installation procedure will successfully install two USB 1.1 OHCI
controllers, one USB 2.0 EHCI host controller, and one IEEE 1394 host
controller.
1. Insert the F5U508 installation CD into your CD-ROM drive. After a few
moments the main menu will auto-start and display each of the
available installation options.
2. Select “Install USB 2.0 Driver”. After the driver is installed select “No,
I will restart my computer later”. Select “Close”. Then select “Exit”.
3. Open the Start menu in the lower left hand corner of your Windows
display, then select “Shut Down” and click “OK”.
4. Once the computer has completely shut down, remove the computer’s
cover and locate an empty PCI slot.
5. Remove the port cover that corresponds with the PCI slot you wish to
use. (The cover is usually held in place with a single screw.)
6. Insert the PCI Card into the slot. Apply pressure as needed until the
card is fully seated. Secure the PCI card with the screw removed in
step #5, above.
7. After installing the PCI Card, replace the outer cover and turn on the
computer.
8. When Windows restarts the PCI card will be detected and installation
of the required drivers will begin.
Note: Depending on the speed of your computer, it may take up to 30
seconds for the PCI card to be detected.
9. Windows will detect the “PCI Standard PCI to PCI Bridge” and the
“Add New Hardware Wizard” dialog box will open. Select “Automatic
Search for the best driver for your device (Recommended)” and click
“Next”.
P73954ea-A_F5U508ea_uk 28-03-2003 14:27 Page 9

10
INSTALLATION
10. Windows will locate the drivers for “PCI Standard PCI to PCI Bridge”.
(Windows may prompt you to insert the Windows OS installation CD.
If so, insert the CD into the CD-ROM drive and continue the
installation procedure).
11. Installation of the “PCI Standard PCI to PCI Bridge” will now
complete. Click “Finish”.
12. Windows will detect the “NEC Firewarden OHCI Compliant IEEE 1394
Host Controller”. Click “Next”.
13. Select “Automatic Search for the best driver for your device
(Recommended)” and click “Next”.
14. Windows will now search its driver database for the required driver.
15. Installation of the “NEC Firewarden OHCI Compliant IEEE 1394 Host
Controller” is now complete. Click “Finish”.
16. Windows will detect “NEC USB Open Host Controller (E13+)” and
“Belkin USB 2.0 High Speed Host controller”. The required driver
support will be automatically installed. No user input is required.
17. After installation of the USB host controllers, the Windows OS will
detect “USB Root Hub” and automatically install the required driver
support. This will repeat one more time.
18. Restart your computer to complete the installation procedure.
Verifying Proper Installation (Windows Me)
After installation, check the Windows Device Manager to confirm that the
PCI Card has been properly installed.
1. Right-click on “My Computer” and select “Properties”.
2. Select the “Device Manager” tab.
3. Click on the plus sign (+) next to “Universal Serial Bus Controllers”.
The “Universal Serial Bus Controllers” list will now include two “NEC USB
Open Host Controller” entries, one “Belkin USB 2.0 Hi-Speed Host
Controller” entry, one “USB 2.0 Root Hub Device” entry and two “USB
Root Hub” entries.
P73954ea-A_F5U508ea_uk 28-03-2003 14:27 Page 10

11
En
INSTALLATION
Note: If your computer features built-in USB ports, or if you have other
USB PCI controller cards installed, you will see additional USB
Controller and root hub entries.
4. Click the plus sign (+) next to “IEEE 1394 Bus Controller”.
The “IEEE 1394 Bus Controller” list will now include one “NEC Firewarden
OHCI Compliant IEEE 1394 Host Controller” entry.
5. Click the plus sign (+) next to “Network Adapters”.
6. The “Network Adapters” list will now include one “NDIS 1394 Net
Adapter” entry.
Note: If your computer features built-in IEEE 1394 ports, or if you have
other IEEE 1394 PCI host controller cards installed, you will see
additional “IEEE 1394 Host Controller” and “NDIS 1394 Net
Adapter” entries.
P73954ea-A_F5U508ea_uk 28-03-2003 14:27 Page 11

12
INSTALLATION
Installation Procedure for Windows XP
This installation procedure will successfully install two USB 1.1 OHCI
controllers, one USB 2.0 EHCI host controller, and one IEEE 1394 host
controller.
Important Note: There are two methods of installing the required USB 2.0
drivers in Windows XP.
If you have an Internet connection:
Windows XP checks the Windows update website and downloads the most
recent version of Microsoft USB 2.0 support drivers. Please proceed to
the “With Internet Connection” section.
If you do not have a connection to the Internet:
USB 2.0 drivers will be installed from the Belkin F5U508 installation CD.
Please proceed to the “Without Internet Connection” section.
With Internet Connection
1. Make sure your computer is completely powered down.
2. Remove the computer’s cover and locate an empty PCI slot.
3. Remove the port cover that corresponds with the PCI slot you wish to
use. (The cover is usually held in place with a single screw.)
4. Insert the PCI Card into the slot. Apply pressure as needed until the
card is fully seated. Secure the PCI card with the screw removed in
step #3, above.
5. After installing the PCI Card, replace the outer cover and turn on the
computer.
6. When Windows restarts the PCI card will be detected and drivers for
the IEEE 1394 host controller, and the two USB OHCI host controllers
will be automatically installed.
P73954ea-A_F5U508ea_uk 28-03-2003 14:27 Page 12

13
En
INSTALLATION
Note: Depending on the speed of your computer, it may take up to 45
seconds for the PCI card to be detected, and the download from
Windows update to be completed.
7. Windows will now search for drivers for the “NEC PCI to USB Enhanced
Host Controller B1”, and the “New Hardware Wizard” will start. Select
“Install the software automatically (Recommended)”. Click “Next”.
Windows XP will check the Windows update website and download the
most recent version of Microsoft’s USB 2.0 support drivers.
8. The IEEE 1394 Network Device is now detected and installed. Windows
will present you with the option of setting up a Network. If you do
not want to set up an IEEE 1394 network, ignore this option. (Please
check your Windows XP help file for more information on setting up
and using an IEEE 1394 network).
The Installation procedure is now complete.
Without Internet Connection
1. Insert the F5U508 installation CD into your CD-ROM drive. After a few
moments the main menu will auto-start and display each of the
available installation options.
2. Select “Install USB 2.0 Driver”.
3. Windows will now display the following message: “The software you
are installing has not passed Windows logo testing”. Ignore this
message and select “Continue Anyway”.
4. Windows will now prompt you to restart your computer. Select “No, I
will restart my computer later”. Click “Close”.
5. Open the Start menu in the lower left-hand corner of your Windows
display, then select “Shut Down” and click “OK”.
6. Once the computer is completely shut down, remove the computer’s
cover and locate an empty PCI slot.
P73954ea-A_F5U508ea_uk 28-03-2003 14:27 Page 13

14
INSTALLATION
7. Remove the port cover that corresponds with the PCI slot you wish to
use. (The cover is usually held in place with a single screw).
8. Insert the PCI Card into the slot. Apply pressure as needed until the
card is fully seated. Secure the PCI card with the screw removed in
step #7, above.
9. After installing the PCI Card, replace the outer cover and turn on the
computer.
10. Windows restarts, the PCI card will be detected and drivers for both
the IEEE 1394 host controller and the two USB OHCI host controllers
will be automatically installed.
Note: Depending on the speed of your computer, it may take up to 30
seconds for the PCI card to be detected.
11. Windows will now search for drivers for the “Belkin USB 2.0 High
Speed Host Controller” and the “New Hardware Wizard” will start.
Select “Install the software automatically (Recommended)”. Click
“Next”.
12. Drivers for the “Belkin USB 2.0 High Speed Host Controller” will now
be located. Windows will display the following message: “The
software you are installing has not passed Windows logo testing”.
Ignore this message and select “Continue Anyway”.
13. Installation of the “Belkin USB 2.0 High Speed Host Controller” will
now be completed. Click “Finish”.
14. Windows will now detect the “USB 2.0 Root Hub Device”. Click
“Next”.
15. Drivers for the “USB 2.0 Root Hub Device” will now be located.
Windows will display the following message. “The software you are
installing has not passed Windows logo testing”. Ignore this message
and select “Continue Anyway”.
P73954ea-A_F5U508ea_uk 28-03-2003 14:27 Page 14

15
En
INSTALLATION
16. Installation of the “USB 2.0 Root Hub Device” is now complete. Click
“Finish”.
17. The “IEEE 1394 Network Device” is now detected and installed.
Windows will present you with the option of setting up a network. If
you do not wish to set up an IEEE 1394 network, ignore this option.
(Please check your Windows XP help file for more information on
setting up and using an IEEE 1394 network).
The installation procedure is now complete.
P73954ea-A_F5U508ea_uk 28-03-2003 14:27 Page 15

16
INSTALLATION
Verifying Proper Installation (Windows XP)
After installation, check the Device Manager to confirm that the PCI Card
has been properly installed.
1. Right-click on “My Computer”.
2. Select “Properties”.
3. Select the “Hardware” tab and click on the “Device Manager” button.
4. Click the plus sign (+) next to “Universal Serial Bus Controllers”.
The “Universal Serial Bus Controllers” list will now include two “NEC USB
Open Host Controller” entries, one “Belkin USB 2.0 Hi-Speed Host
Controller” entry, one “USB 2.0 Root Hub Device” entry and two “USB
Root Hub” entries.
Note: If your computer features built-in USB ports, or if you have other
USB PCI controllers installed, you will see additional “root hub”
entries.
5. Click the plus sign (+) next to “IEEE 1394 Bus Controller”.
The “IEEE 1394 Bus Controller” list will now include one “NEC Firewarden
OHCI Compliant IEEE 1394 Host Controller” entry.
6. Click the plus sign (+) next to “Network Adapters”.
The “Network Adapters” list will now include one “NDIS 1394 Net
Adapter” entry.
Note: If your computer features built-in IEEE 1394 ports, or if you have
other IEEE 1394 PCI host controller cards installed, you will see
additional “IEEE 1394 Host Controller” and “NDIS 1394 Net
Adapter” entries.
P73954ea-A_F5U508ea_uk 28-03-2003 14:27 Page 16
