User Manual
F1DN102U
F1DN104U
F1DN108U
OmniView® Secure
KVM Switch
OmniView® Secure
KVM Switch

Table of Contents
1. Introduction ............................................................................................. 1
Package Contents .......................................................................... 1
2. Overview ................................................................................................. 2
Security Features ........................................................................... 2
Other Features ............................................................................... 3
Equipment Requirements ............................................................... 4
System Requirements .................................................................... 5
Unit Display Diagrams .................................................................... 6
Specifications ................................................................................ 7
3. Installation .............................................................................................. 8
Pre-Configuration ........................................................................... 8
Mounting the Switch (optional) ....................................................... 9
Connecting the Console to the Switch .......................................... 11
Powering Up the Systems ............................................................ 13
Selecting a Computer Using Port Selectors .................................. 14
4. Using your Switch ...................................................................................14
5. Frequently Asked Questions ...................................................................15
6. Troubleshooting .....................................................................................16
7. Information ............................................................................................19

1
1
2
3
4
5
6
7
section
Congratulations and thank you for purchasing this Belkin OmniView Secure
KVM Switch (the Switch). Designed especially for secure military and
government installations, the Switch provides the centralized control required
by today’s IA (Information Assurance) computer environments. It allows users
to manage multiple computers from a single USB console, while preventing
unintended data transfer between computers running on different
security levels.
This User Manual provides all the details you’ll need to install and operate
your new Switch, in addition to expert troubleshooting advice—in the unlikely
event of a problem. For quick and easy installation, please refer to the Quick
Installation Guide included in your packaging.
We appreciate your business and are confident that you will soon see for
yourself why over 1 million Belkin OmniView products are in use worldwide.
Important: Tamper-evident tape has been placed on both sides of
the Switch, to provide indication if the product has been opened or
compromised (see diagram on page 6). If one of the tapes has been
removed or appears disrupted, please call Belkin Technical Support
at [phone].
Rack-Mount
Brackets with Screws
(F1DN108U
model only)
User Manual
OmniView Secure
KVM Switch
5V DC, 3A Global
Power Adapter
Quick
Installation Guide
Package Contents
4 Interchangeable
AC Plugs1
1 Includes AC plugs for the U.S., U.K., Europe, and Australia.
Introduction

2
Security Features
• Dedicated Processors
Designed specifically for secure environments, the Switch features a
dedicated processor per computer port. This keeps each computer running
on different security levels completely separated and secure at all times, and
prevents any unintended data transfer between computers.
• No Memory Buffer
The Switch does not have a memory buffer and does not have the ability
to store data. This prevents any keystrokes or other data input from being
unintentionally transferred as you switch between computers, ensuring the
integrity of your data. The Switch does not include any features that require
memory, such as hot keys, AutoScan, or an on-screen display (OSD).
• Non-Reprogrammable Firmware
The Switch features custom firmware that is not reprogrammable, preventing
the ability to tamper with the KVM logic.
• Tamper-Evident Tape
Tamper-evident tape is placed on both sides of the enclosure, to provide
indication if the Switch has been opened or compromised.
• Tamper-Proof Hardware
All integrated circuits are soldered directly to the printed circuit board to
prevent tampering with the components.
• NIAP Listing
The Switch is listed by the National Information Assurance Partnership (NIAP).
It is NIAP Common Criteria validated to EAL 4 (Evaluation Assurance Level 4).
Overview

3
1
2
3
4
5
6
7
section
3
Overview
Other Features
• USB Support
The Switch is compatible with USB 1.1 and USB 2.0 technology and supports
Plug-and-Play connectivity with USB computers, keyboards, and mice.
• Video Resolution
The Switch supports video resolutions of up to 1920x1440@75Hz.
• Dedicated Port Selectors
Port selectors, located conveniently on the front panel of the Switch, allow you
to switch easily from one computer to the next. Each button controls a single
computer port.
• LED Indicators
An LED above each port selector illuminates to indicate that the console
currently controls the corresponding computer. As a port selector is pushed,
the LED above it will light up.
• Metal Enclosure
The Switch features a rugged, metal enclosure that provides stability and
allows the Switch to be placed beneath your monitor or other desk item.
• Desktop or Rack-Mount Installation
With its compact design, the Switch can be placed on your desktop or
mounted to a standard 19-inch server rack for 1U installation.2
• Global Power Adapter
The Switch includes a global power adapter and interchangeable plugs, to
allow for both domestic and international installations.3
2 The 2- and 4-Port Switches require an optional Rack-Mount Kit for rack installation
(Belkin part number F1D005).
3Includes AC plugs for the U.S., U.K., Europe, and Australia.

4
Overview
Equipment Requirements
Cables
Belkin highly recommends you use
Belkin All-In-One USB KVM Cable Kits
for your Switch to help ensure superior
performance. These cables offer the
highest quality possible to ensure optimal
data and video transmission. One Cable
Kit is required per connected computer.
All-In-One USB KVM Cable Kits:
F3X1962b06 – 6 ft. (1.8m)
F3X1962b10 – 10 ft. (3m)
F3X1962b15 – 15 ft. (4.6m)
Note: Due to USB limitations, the
USB-cable length cannot exceed
15 feet (4.6m).
F3X1962bXX

5
1
2
3
4
5
6
7
section
Overview
System Requirements
Operating-System (OS) Platforms
The Switch is compatible with computers running on, but not limited to, the
following OS platforms:
• Windows® 2000
• Windows XP (Home/Professional)
• Windows 2003 Server
• Windows Vista®
• Red Hat® Linux® Desktop
• Red Hat Enterprise Linux WS
• Mac OS® X v10.3 and higher
Keyboards
• USB-compatible (including wireless keyboards)
Mice
• USB-compatible (including wireless or optical mice)
Monitors
• CRT and LCD with VGA support

66
   
Overview
Unit Display Diagrams
Front View
(F1DN104U model shown)
Back View
Tamper-Evident Tape
Side View
IMPORTANT NOTICE: There should be one tamper-evident tape on
each side of the Switch enclosure (total of two tapes). If both tapes
are visible and do not appear to be disrupted, your Switch has not
been opened or compromised since time of production. If for any
reason one of the tapes is missing or appears disrupted, please call
Belkin Technical Support at [phone].
Console USB
Keyboard Port
LED Indicators
Port Selectors
Computer VGA &
USB Ports
DC Power Jack
Console VGA
Monitor Port
Console USB
Mouse Port

7
1
2
3
4
5
6
7
section
Overview
Specifications
Part No.: F1DN102U, F1DN104U, F1DN108U
Enclosure: Metal enclosure with high-impact plastic faceplate
Power Requirements: 5V DC, 2.5A (minimum) power adapter with
center-pin-positive polarity4
AC Input: 100 to 240VAC
Interchangeable AC Plugs: 4 (U.S., U.K., Europe, Australia)
No. of Users Supported: 1
No. of Computers Supported: 2, 4, and 8 respectively for 2-, 4-, and 8-port models
Monitors Supported: CRT and LCD (with VGA support)
Resolution Support: Up to 1920x1440@75Hz
Console Keyboard Input: USB Type A
Console Mouse Input: USB Type A
Console Monitor Port: HDDB15 female (VGA)
CPU Keyboard/Mouse Ports: USB Type B
CPU Monitor Ports: HDDB15 male (VGA)
Port Selectors: 2, 4, and 8 respectively for 2-, 4-, and 8-port models
LED Indicators: 2, 4, and 8 respectively for 2-, 4-, and 8-port models
Operating Temp: 32° to 104° F (0° to 40° C)
Storage Temp: -4° to 140° F (-20° to 60° C)
Humidity: 0-80% RH, non-condensing
Warranty: 3 years
Dimensions: (F1DN102U) 11 x 1.75 x 6 in. (279 x 45 x 150mm)
(F1DN104U) 11 x 1.75 x 6 in. (279 x 45 x 150mm)
(F1DN108U) 17.25 x 1.75 x 7.5 in. (438 x 45 x 190mm)
Weight: (F1DN102U) 2.5 lbs. (1.1kg.)
(F1DN104U) 2.5 lbs. (1.1kg.)
(F1DN108U) 4.5 lbs. (2.0kg.)
Made in the USA of imported parts
4The Switch includes a 5-volt, 3-Amp power adapter, but only requires a minimum of 2.5 Amps.

8
Pre-Configuration
Where to place the Switch:
The enclosure of the Switch is designed for desktop or rack-mount configuration.
The 8-Port Switch (F1DN108U) can be mounted to a standard 19-inch server
rack using the included rack-mount brackets and screws. An optional
Rack-Mount Kit (Belkin part number F1D005) is available for use with the
2- and 4-Port Switches.
Consider the following when deciding where to place the Switch:
• your proximity to the port selectors on the front of the Switch
• the lengths of the cables attached to your keyboard, monitor, and mouse
• the location of your computers in relation to your console
• the lengths of the cables you use to connect your computers to the Switch
Warning: Avoid placing cables near fluorescent lights, air-conditioning
equipment, or machines that create electrical noise (e.g., vacuum cleaners).
Installation

9
1
2
3
4
5
6
7
section
Installation
Step 1 Mounting the Switch (optional)
Bracket Installation (F1DN108U)
The 8-Port Switch includes adjustable mounting brackets ideal for installation
in 19-inch racks. The mounting brackets feature three adjustment positions that
allow you to set the Switch’s face flush with the ends of the rails, or to extend the
Switch past the front of the rails. Please follow these simple steps to achieve the
desired adjustment.
1.1 Determine how far you would like the Switch to protrude from the rack.
Select a bracket-hole scheme.
1.2 Attach the bracket to the side of the Switch using the Phillips screws
provided. (Refer to diagram below.)
1.3. Mount the Switch to the rack rails. (Refer to diagram below.)
Your Switch is now mounted securely to the rack and you are ready to
connect your console.

101010
Installation
Bracket Installation (F1DN102U and F1DN104U)
The 2- and 4-Port Switches can be installed into a 19-inch rack using an optional
Rack-Mount Kit, sold separately (Belkin part number F1D005).
1.1 Attach the Rack-Mount Bracket to the Switch using the Phillips screws
provided. (Refer to diagram below.)
1.2 Mount the Switch to the rack rails. (Refer to diagram below.)
Your Switch is now mounted securely to the rack and you are ready to
connect your console.

11
1
2
3
4
5
6
7
section
Installation
Step 2 Connecting the Console to the Switch (required)
Warning: Before attempting to connect anything to the Switch or your
computers, please ensure that all computer equipment and devices are
powered off. Plugging and unplugging cables while computers are powered
on may cause irreversible damage to the computers and/or the Switch.
Belkin International, Inc., is not responsible for damage caused by your
failure to do so.
Before you connect your console to the Switch, make sure that your USB
keyboard and mouse work properly with all your computers (the Human Interface
Device (HID) USB drivers are installed on all computers).
2.1 Connect your monitor VGA cable to the VGA port on the back of the
Switch in the “User Console” section. (Refer to diagram below.)
2.2 Connect your keyboard and mouse USB cables to the USB keyboard and
mouse ports on the back of the Switch in the “User Console” section.
(Refer to diagram below.)

12
Installation
Step 3 Connecting Computers to the Switch (required)
3.1 Make sure all computers and the Switch are powered off.
3.2 Using the Belkin All-In-One USB KVM Cable Kit (F3X1962bXX), connect the
male VGA connector to the monitor port on your computer. Then connect
the female VGA connector to the CPU monitor port on the Switch labeled
“VGA 01”. (Refer to diagram below.)
3.3 Using the Cable Kit, connect the USB Type A connector to an available
USB port on your computer. Then connect the USB Type B connector to
the USB port on the Switch labeled “USB 01”. (Refer to diagram below.)
3.4 Repeat steps 2 and 3 for each additional USB computer you wish
to connect.
Note: The Cable Kit must be connected directly to a free USB port on your
computer, with no USB hubs or other devices in between.

13
1
2
3
4
5
6
7
section
Installation
Step 4 Powering Up the Systems (required)
4.1 Attach the power adapter to the DC power jack labeled “5V, 2.5A” on the
back of the Switch. Only use the power adapter supplied with the Switch.
(Refer to diagram below.)
4.2 Power on your computers and your monitor. All computers can be
powered on simultaneously.
Note: Your computers should recognize the Switch and automatically install the
HID USB driver if necessary.
When you power on your computers, the Switch emulates both a mouse
and keyboard on each port and allows your computers to boot normally. The
computer connected to port “1” will be displayed on the monitor. Check to see
that the keyboard, monitor, and mouse are working normally. Proceed to do this
with all occupied ports to verify that all computers are connected and responding
correctly. If you encounter an error, check your cable connections for that
computer and reboot. If the problem persists, please refer to the Troubleshooting
section in this User Manual.

14
Selecting a Computer Using Port Selectors
Now that you have connected your console and computers to the Switch,
it is ready for use. You can select which computer you wish to control by
pressing the corresponding port selector on the front of the Switch. The LED
will illuminate to indicate which computer (or port) is currently selected. It
takes approximately 1–2 seconds for the video signal to refresh after switching
computers. Re-synchronization of the mouse and keyboard signals also occurs.
This is normal operation and ensures that proper synchronization is established
between the console and the connected computers.5
Once you press a port selector, the Switch immediately disables the connection
between your console and the previously selected computer, and establishes a
new connection between your console and the new computer selected. Keyboard
and mouse inputs can only be sent to the selected computer, and video outputs
can only be received from the selected computer. The Switch also prevents
any data transfer between connected computers, ensuring the security of
your computers.
Please note that the default port at power-up is port one. In case of a power
failure or if the power is cycled, the Switch will default to port one.
5Note: It may take longer for your mouse and keyboard to re-synchronize
when the computer is recovering (or initializing) from Standby, Hibernate, or
Sleep modes.
Using your Switch

1515
1
2
3
4
5
6
7
section
What does NIAP Common Criteria validation to EAL 4 mean?
To learn more about NIAP Common Criteria and EAL 4, visit
http://niap.nist.gov/cc-scheme/nstissp-faqs.html.
What do I do if I find that the tamper-evident tape on the Switch has
been removed or disrupted?
Please call Belkin Technical Support at [phone] immediately. The KVM
Switch’s circuitry may have been compromised.
How does the Switch allow the user to switch between computers?
The Switch only supports one method of port selection. The user can access
the desired computer by pushing the port selectors.
How far can the Switch be from my computer?
The Switch can be located up to 15 feet (4.6m) away from your computer due
to USB-cable limitation.
Do I have to install software to use the Switch?
No, the Switch does not require any software to be installed in your computers.
Can I use the Switch with a computer that does not support USB?
No, the Switch only works with USB-capable computers.
Does the Switch require an AC adapter?
Yes, the Switch requires a 5-volt DC, 2.5-Amp (minimum) power adapter in
order to function properly.
Does the Switch support Linux?
Yes, the Switch works with Red Hat Linux and some Linux kernels configured
for USB support.
Does the Switch support Microsoft® IntelliMouse®?
The Switch supports mice from Microsoft, Logitech®, Kensington®, etc.,
and Belkin. Please contact Belkin Technical Support at [phone] for
compatibility issues you may experience.
Frequently Asked Questions
