Bell 872101 User manual

B50D 6 X 6
ARTICULATED DUMP TRUCK
OPERATOR’S MANUAL
Document Part Number 872101

LEFT BLANK INTENTIONALLY

TO THE OPERATOR
n
WARNING
Do not operate the machine unless you have read this manual and fully understand how to operate
the machine properly.
The safe operation of your BELL EQUIPMENT machines very important to prevent any personal injury and/
or damage. This manual must be read and fully understood before operating or carrying out any
maintenance on your BELL EQUIPMENT machine.
SAFETY SYMBOL
The following safety symbol is used for all safety messages. When you see the safety symbol, follow the
safety message to avoid personal injury or death.
WARNINGS and CAUTIONS must be read, fully understood and followed, before carrying out the action or
maintenance procedure concerned.
WARNINGS and CAUTIONS are always placed before any action or maintenance procedure where
personal injury and/or damage to the machine could occur if that action or maintenance procedure is not
carried out correctly.
WARNING AND CAUTION SYMBOL
Throughout this manual the word WARNING is used to alert the operator and others of the risk of personal
injury during the operation of the equipment. CAUTION indicates the possible damage to the machine.
NOTE highlights information of special interest.
CALIFORNIA PROPOSITION 65 WARNING n
Diesel engine exhaust and some of its constituents are known to the state of California to cause
Cancer, birth Defects and other Reproductive Harm.

LEFT BLANK INTENTIONALLY

B50D 6X6
ARTICULATED DUMP TRUCK
OPERATOR’S MANUAL
THIS MANUAL IS APPLICABLE TO
B50D 6X6 ADT
Document Part Number 872101
Issue:0
(Revised:)
Technical Documentation
BELL EQUIPMENT COMPANY
Richards Bay

IMPORTANT
Due to BELL EQUIPMENT’S policy of continuous product improvement, the information contained in this
manual was correct up to the time of printing (Revised date of manual). Any changes after this date will only
be included in the next update of this manual.
The illustrations in this manual are pictorial and not necessarily true representations of components.
Photographs and illustrations may show optional equipment.

Amendment Record Sheet
7
The table below is a record of amendments made to this manual after the publication date.
Amendment Record Sheet
Authorisation for
Amendment Page No’s. Replaced Date Page Amended/ Pages Inserted By
Referance to oil specification corrected 49 3/09/2004 J.P. Mienie

Amendment Record Sheet
8
LEFT BLANK INTENTIONALLY

9
INTRODUCTION
Read this manual carefully for it has been produced to assist you in the correct operation, maintenance and
care of your BELL EQUIPMENT machine. Failure to do so could result in personnel injury or equipment
damage.
This manual should be considered a permanent part of your machine and should remain with the machine
when you sell it.
Right and left hand sides are determined by facing in the direction of forward travel.
Write product identification numbers (P.I.N.), Vehicle Identification Number (V.I.N.) and serial Number in
Chapter 9. Accurately record all the numbers to help in tracing the machine should it be stolen. Your dealer
also needs these numbers when you order parts. File the identification numbers in a secure place off the
machine.
Warranty is provided as part of BELL EQUIPMENT’S support program for customers who operate and
maintain their equipment as described in this manual. The warranty is explained on the warranty certificate
which you should have received from your dealer.
Should the equipment be abused, or modified to change its performance beyond the original factory
specifications, the warranty will become void and field improvements may be denied.
This manual is divided into chapters. The information contained in the manual is in logical sequence, with
the instructions written in step by step format.
Effective maintenance on your BELL EQUIPMENT machine is achieved when personnel fully understand
the information contained in this manual.
Every effort has been made to ensure that the information contained in this manual was correct at the time
of publication. BELL EQUIPMENT Co. has a policy of continuous product development, improvement, and
design. BELL EQUIPMENT Co. reserves the right to change, amend and update the design of its product
at any time without prior notice. With this policy, changes may have occurred that are not included in this
manual.
Whilst every endeavour has been made to provide accurate and reliable information, BELL EQUIPMENT
Co. specifically disclaims any actual or implied warranty and under no circumstances shall be liable for any
loss, damage or injury to person or property suffered, whether direct, indirect or consequential, arising from
the use of this manual. In particular and without detracting from above, the disclaimer also applies in the
event of any specification, warning, or representation contained in this manual being inadequate,
inaccurate, or unintentionally misleading.
The user is urged to strictly comply with the instructions and warnings that are given in the interests of
general safety. Please do not hesitate to contact your BELL EQUIPMENT Product Support Representative
whenever you have a query on your BELL EQUIPMENT product or this manual.
